General Data Healthcare TBS SHURClean SC-36S-X User manual

®
A Division of General Data Healthcare
Histology Innovation for a NEW Generation
Operator’s Manual
Product Name
Here
SHURClean™
Sloped Front Fume Hoods
Catalog #s
SC-36S-X, SC-36S-F
SC-36S-WOME-TV, SC-36S-WOME-RV
SC-48S-WOME-TV, SC-48S-WOME-RV
Pub No.: OM Sloped Front FH
June 2013, Version 1.3
SC-36S-X OR -F
SC-36S-WOME-TV or -RV
SC-48S-WOME-TV or -RV

2 | Page
General Data Healthcare, Inc.

3 | Page
General Data Healthcare, Inc.
Contents
1.0 INTRODUCTION ............................................................................................................................4
1.1 Contact Information......................................................................................................................4
2.0 UNPACKING...................................................................................................................................5
2.1 Contents ........................................................................................................................................5
2.2 Serial Number...............................................................................................................................7
..................................................................................................................................................................7
3.0 SETUP and INSTALLATION..........................................................................................................8
3.1 Step 1 ............................................................................................................................................8
3.2 Step 2 ............................................................................................................................................9
3.3 Step 3 ..........................................................................................................................................10
3.4 Step 4 ..........................................................................................................................................11
3.5 Step 5 ..........................................................................................................................................12
3.6 Step 6 ..........................................................................................................................................13
4.0 SPECIFICATIONS.........................................................................................................................14
4.1 SC-36S-X or -F...........................................................................................................................14
4.2 SC-36S-WOME-TV....................................................................................................................16
4.3 SC-36S-WOME-RV ...................................................................................................................18
4.4 SC-48S-WOME-TV....................................................................................................................20
4.5 SC-48S-WOME-RV ...................................................................................................................22
5.0 OPERATING INSTRUCTIONS....................................................................................................23
5.1 Control Panel Key Descriptions..................................................................................................23
5.2 Typical Use Instructions .............................................................................................................25
6.0 MAINTENANCE ...........................................................................................................................26
6.1 FUSE REPLACEMENT.............................................................................................................26
7.0 WARNING.....................................................................................................................................27
7.1 Sharp Edges ................................................................................................................................27
7.2 Electric Shock.............................................................................................................................27
CONTACT INFORMATION.................................................................................................................28

4 | Page
General Data Healthcare, Inc.
1.0 INTRODUCTION
Thank you for selecting TBS’ SHURClean™Slope Front Fume Hood. This instrument was carefully
designed to be easy to use, safe to operate and capable of producing consistent, high quality results.
This operation manual introduces the instrument’s components, key features and proper use. Please read
this operation manual carefully before utilizing the fume hood.
The employees of TBS thank you for your support. Feel free to call TBS customer service at 919-384-
9393 or e-mail us for support at prod[email protected].
1.1 Contact Information
1.1.1 TBS Corporate Headquarters
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Web: http://www.trianglebiomedical.com
1.1.2 Product Service Department
Phone: [phone]
E-mail: [email protected]

5 | Page
General Data Healthcare, Inc.
2.0 UNPACKING
Be certain to inspect the shipping container carefully for any signs of damage to the outer carton. In the
event of apparent mishandling, note the damage accordingly on the bill of lading and take pictures for
future reference. Save the shipping carton and all packing material for proof of noted damage and / or for
future shipment of the instrument back to the manufacturer for any future service needs. Failure to
document external damage to the carton may limit your ability to obtain compensation from the carrier for
damage. Remove the equipment from the shipping carton carefully. Notify the carrier immediately if
there is any visible damage to the contents.
2.1 Contents
Description Qty Illustration
Operator’s Manual 1
Active Updraft Blower
Housing 1
Slope Front Fume Hood 1

6 | Page
General Data Healthcare, Inc.
Filter
2
Pre Filter 2
Power Cord 1
PARA/Gard
™
1

7 | Page
General Data Healthcare, Inc.
2.2 Serial Number
2.2.1 Location
2.2.2 Serial Number Label
2.2.2.1 120V Version Serial Number
2.2.2.2 220V version Serial Number

8 | Page
General Data Healthcare, Inc.
3.0 SETUP and INSTALLATION
3.1 Step 1
3.1.1 Remove Sloped Front Fume Hood From Packaging
3.1.2 Remove Active Updraft Blower Housing From Packaging

9 | Page
General Data Healthcare, Inc.
3.2 Step 2
3.2.1 Place Active Updraft Fume Hood on top of Slope Front Fume
Hood.
3.2.2 Connect Sensor Wire
3.2.3 Do not pinch sensor wire when lowering Active Updraft Fume
Hood on top of Slop Front Fume Hood.

10 | Page
General Data Healthcare, Inc.
3.3 Step 3
3.3.1 Remove plastic bags from both sets of Filters on the Left and
Right side of the Active Updraft Blower Housing.
3.3.1.1 Pull out Catch Pins to Release filter housing from the
Active Updraft Blower Housing.
3.3.1.2 Slide filter housing with filters out.
3.3.1.3 Use fingers to push Filters out from the back side.

11 | Page
General Data Healthcare, Inc.
3.4 Step 4
3.4.1 Re install filters back into filter housing.
3.4.1.1 Place Pre Filter in the correct orientation with the
airflow arrows pointing up.
3.4.1.2 Place Filter on top of Pre Filter
3.4.1.3 Ensure that catch pins are pulled out.

12 | Page
General Data Healthcare, Inc.
3.4.1.4 Install filter housing with filters into the Active
Updraft Blower Housing.
3.5 Step 5
3.5.1 Install the Power Cord
3.5.1.1 Ensure Power Switch is in “OFF” position.

13 | Page
General Data Healthcare, Inc.
3.6 Step 6
3.6.1 Turn the Power on.
3.6.2 When powering on, Unit Firmware type is displayed.
3.6.3 When powering on, Firmware version is displayed.

14 | Page
General Data Healthcare, Inc.
4.0 SPECIFICATIONS
4.1 SC-36S-X or -F
4.1.1 Specifications Illustration

15 | Page
General Data Healthcare, Inc.
4.1.2 Specifications Table
Cat. # SC-36S-X (or -F) SC-36S-X(or-F)-220
TYPE Active Updraft Slope Front Fume Hood Active Updraft Slope Front Fume Hood
DEFAULT FILTER LIFE 270 HRS 270 HRS
EXTERNAL DIMENSIONS 36x30x22 inches / 91x76x57cm 36x30x22 inches / 91x76x57cm
APPLICATION Grossing, Manual Cover Slipping, Reagent
Handling
Grossing, Manual Cover Slipping, Reagent
Handling
AIR MOVERS Two Internal Fans 174 cfm each Two Internal Fans 174 cfm each
WEIGHT 81 lbs./ 37kg 81 lbs./ 37kg
Packaged Shipping Weight 150 lbs. / 68kg 150 lbs. / 68kg
Measured Face Velocity 90 feet per minute with Sash in Full Down
Position.
90 feet per minute with Sash in Full Down
Position.
Speed Settings 1-10 1-10
Carbon Filter Life 270 hours 270 hours
120V Current 1.2 Amps, 2.0 Amp Fuse N/A
240V Current N/A 0.7 Amps, 2.0 Amp Fuse
Important Notes: Decimal dimensions have been rounded off to
the nearest integer.
Decimal dimensions have been rounded off to
the nearest integer.
Rubber Feet Rubber Feet
Battery Powered Clock Back-up Battery Powered Clock Back-up
Replacement Pre Filter and Charcoal Filter
Combo Cat. # SC-36S-XF (xylene containment),
#SC-36SS-FF (formaldehyde containment).
Replacement Pre Filter and Charcoal Filter
Combo Cat. # SC-36S-XF (xylene containment),
#SC-36SS-FF (formaldehyde containment).

16 | Page
General Data Healthcare, Inc.
4.2 SC-36S-WOME-TV
4.2.1 Specifications Illustration

17 | Page
General Data Healthcare, Inc.
4.2.2 Specifications Table

18 | Page
General Data Healthcare, Inc.
4.3 SC-36S-WOME-RV
4.3.1 Specifications Illustration

19 | Page
General Data Healthcare, Inc.
4.3.2 Specifications Table

20 | Page
General Data Healthcare, Inc.
4.4 SC-48S-WOME-TV
4.4.1 Specifications Illustration
