Beamage-4M User Manual Revision 1.0 7
1. BEAMAGE-4M
1.1. INTRODUCTION
Gentec-EO introduces the new Beamage-4M. Its sleek and thin design allows the Beamage-4M to fit
between tight optical components. Its USB 3.0 connection and improved algorithm allows very fast frame
rates. The new 4.2 MPixel CMOS sensor has a large 1” optical format with a small 5.5 µm pixel pitch
allowing high resolution on large beams. Most importantly the innovative and improved PC-Beamage-4M
software is simple and intuitive to any new or expert beam profiling user.
1.2. SPECIFICATIONS
The following specifications are based on a one-year calibration cycle, an operating temperature of 18 to
28°C (64 to 82 F) and a relative humidity not exceeding 80%.
Table 1-1 List of Specifications
Sensor Specification
Sensor Technology CMOS without coverglass
Sensor Size 11.3 x 11.3 mm
Sensor Area 1.28 cm
2
Pixel Count 4.2 MPixels
Pixel H x V 2048 x 2048
Optical Format 1”
Pixel Dimension 5.5 µm
Minimum Measurable Beam 55 µm
ADC 12 bit (default) or 10 bit
Shutter Type Global
Wavelength Range 350 -1150 nm
Frame Rate
6.2 fps (4.2 MPixel Full Frame)
11.4 fps (2.1 MPixel Active Area 2048 x 1024)
18.6 fps (1.1 MPixel Active Area 2048 x 544)
32 fps (0.066 MPixel Active Area 256 x 256)
RMS noise 1000:1 (60 dB)
Minimum and Maximum
Exposure Times 0.06 to 200 ms
External Trig
SMA connector
1.1 volts to 24 volts, the rise edge response time is 300 ns
Trigger signal pulse width: 300 ns to 230 ms
Optional SMA to BNC adaptor (202273) :

Beamage-4M User Manual Revision 1.0 8
Damage Thresholds
Maximum Average Power 1 W with ND filter
Saturation Level
(1064 nm, CW, ND4) 10 W/cm
2
Saturation Level
(1064 nm, Pulsed, ND4) 300 µJ/cm
2
PC Requirements
USB Port USB 3.0 port for optimal performance
USB 2.0 port
Operating System
Compatibility
Windows 8 (for optimal performance)
Windows 7 (for optimal performance)
Windows Vista
Average RAM Allocation 500 MB
Up to 1250 MB for 64 images in buffer
Recommended Requirement
4 Gb RAM minimum
8Gb RAM for optimal performance
Intel i series processors (i3, i5, i7) or equivalent for optimal
performance, other processors will have lower specifications.
i7 for optimal performance
Beamage-4M is a new and a high end product. It needs an equally
recent high end computer to work. Computer hardware must be from
2010 or after. No computer or parts bought before 2010 will be
supported
For Optimal Performance
Close all programs except the PC-Beamage-4M;
Keep a minimum of 1 GB RAM free when running the PC-
Beamage-4M;
Keep a minimum of 50% of free CPU power when running
the PC-Beamage-4M
Use an Image Buffer of 1
Multi Camera
Recommendations
When working with more than one camera, we strongly
recommend using one USB3.0 port per camera and a recent
high end computer for optimal performance
Internet Upgrades Downloadable at www.gentec-eo.com/downloads
Physical Characteristics
Dimensions 61 H x 81.1W x 19.7D
Weight 138 g
Default Attenuation ND 4.0

Beamage-4M User Manual Revision 1.0 9
Measured and Displayed Parameters
Displays 3D, 2D, XY (crosshair), Beam Tracking
Beam Diameter Definition
4 Sigma (ISO) - ISO-11146-1:2005
FWHM along crosshair (50%)
1/e
2
along crosshair (13.5%)
86% effective diameter (D86)
Beam Center Definition Centroid - ISO-11146-1:2005
First Encountered Peak
Displayed Measurements
Major Axis
Minor Axis
Effective Diameter
Ellipticity
Orientation
Centroid X and Y
Peak X and Y
Peak Saturation Level
Peak to Average Ratio X and Y
Divergence
Fitted Gaussian equations
Roughness fit along crosshairs
Gaussian fit along crosshairs
Mean Centroid Position
Azimuth
Beam Position Stability
Setup Options
Exposure Time (auto or manual)
Image Orientation (rotation and flip)
Image Averaging (temporal filter)
Active Area
Pixel Addressing
Gain
ADC Level
Magnifying Lens
Processing Option
Background Subtraction
Area Filters (triangular and flat spatial filters)
Normalized Display
Trigger
Buffer Buffer size from 1 to 64 frames
Possibility to animate stored frames
File options
Save 1 or all images in buffer
Save in native format, text format, or binary format
Load native format files
Print report
Save 3D or 2D image in bitmap format
Save crosshairs in text format
Data Acquisition of measurements in text format and in native format
