GEONAUTE G-EYE discover User manual
1
GB CONTENTS
VIDEO CAMERA DESCRIPTION ............................................................ 2
GETTING STARTED ............................................................................... 3
Charge..............................................................................................................................3
Insert micro-SD card ......................................................................................................3
USING YOUR G-EYE.............................................................................. 4
Power ON / OFF...............................................................................................................4
Record a video ................................................................................................................5
Take a photo ....................................................................................................................5
DATE AND TIME SETTING .................................................................... 6
LASER POINTER ................................................................................... 6
TRANSFER FILES ON COMPUTER........................................................ 7
RESET ................................................................................................... 7
ERROR MESSAGES ............................................................................... 8
TECHNICAL FEATURES ........................................................................ 8
PRECAUTIONS FOR USE....................................................................... 9
WARRANTY, LEGAL WORDING............................................................. 9
Limited liability................................................................................................................9
warranty...........................................................................................................................9
Legal wording................................................................................................................ 10
2
VIDEO CAMERA DESCRIPTION
Record button
Photo button LCD screen
Video recording /
photo capture red
indicator
Laser
Slot for μSD card
Power / Charge red
indicator
Video recording /
Data transfer green
indicator
Microphone
Speakers
Micro-USB
connector
Screw to fasten the video
camera ("Kodak" standard)
Power / Stop
button
Power indicator
Video recording
Photo capture
Duration of recording
underway
Battery level
Active USB connection
Remaining memory
available
LCD SCREEN
3
GETTING STARTED
CHARGE
4h
12
6
39
Fast Charging : When device is connected to computer, to have a more efcient charging process,
you can make a long press on "power" button to shut down the camera. Then, the green LED
will be powered off, and the red LED will be blinking during charging and stable when charge is
completed. The charging time will be around 3 hours in that case. (Warning : data transfer is not
possible during this charging mode).
INSERT MICRO-SD CARD
Compatible Cards Micro-SD cards of 2GB to 32GB (Class 10 recommended)
5
RECORD A VIDEO
START
STOP
TAKE A PHOTO
6
DATE AND TIME SETTING
3 s
Year For each setting:
Increase the value
Decrease the value
Validate
Month
Day
Time
Minute
LASER POINTER
Laser pointer enables easy framing. It can be used with the optional waterproof cover.
ACTIVATE THE LASER POINTER
3 s
7
DEACTIVATE THE LASER POINTER
3 s
TRANSFER FILES ON COMPUTER
Next, recover les the same as you do with a USB key.
SYSTEM REQUIREMENTS
PC MAC
Windows XP, Vista, 7, 8 OS > 10
RESET
If the device do not reply to any commands
(button, charging, data transfer) you can
reset the device to it's factory settings and
it might helps it to recover. Use a small
needle to press the "reset" button.
8
ERROR MESSAGES
MESSAGE DESCRIPTION ACTION
No micro-SD card inside the
camera:
• Impossible to start recording/capture.
• Possible to go to «Settings» menu.
Insert a micro-SD card in your camera,
see p. 3
Micro-SD card is full:
• Impossible to start recording/capture.
• Possible to go to «Settings» menu. Transfer videos and photos on your
computer, see p. 7.
Low level of battery:
• First, only the battery icon is
blinking.
• The message is displayed 2 s before
the camera turns OFF.
Charge the battery, see p. 3.
TECHNICAL FEATURES
Battery standby Video continuous recording approximately 2 hours
Recharge time ~ 3.5 hours. Max < 4 hours
Battery type Li-ion, 3.7V, 1000 mAh
Automatic sleep mode After 5 min
Video resolution 720p, 30fps, 16:9, viewing angle = 135°
Video bitrate 8 Mps
Frame rate 50 Hz
TV standard PAL
Photo resolution 8MP
Connectors Micro-USB
Connection to computer USB 2.0 « Full-Speed », card reader Micro-SD
Micro-SD card compatible
(sold separately)
Micro-SD of 2 GB to 32 GB
Operational temperature -10°C < … < 45°C
Video format MP4
Photo format JPG
Language English
9
PRECAUTIONS FOR USE
-10°C
-50°F
45°C
113°F
• Handle the device with care - do not drop it or subject it to strong impacts.
• This product is not waterproof, do not subject it to sprays of water or immerse it.
• For increased safety, avoid using the buttons during action. Loss of concentration can be
dangerous
• Do not take the product apart, as this may lead to damage as well as cancellation of the
warranty.
• Using the product in a very cold environment (temperature below -10°C) may lead to a
reduction in battery capacity, and therefore reduction of battery lifetime.
WARRANTY, LEGAL WORDING
LIMITED LIABILITY
• GEONAUTE is not responsible for accidents or injuries caused by handling or using the
product during high risk sports.
• In particular, GEONAUTE insists on informing the user of possible loss of concentration linked
to using the product in dangerous conditions.
• The user is warned that he assumes all legal liability for the taking, sharing, and publication of
images recorded with the product.
WARRANTY
• GEONAUTE guarantees the initial buyer of this product that it is exempt of defaults related to the
materials or fabrication and does so for a period of 2 years (inclusive) from the date of purchase.
• Please keep your receipt as proof of purchase.
• The warranty does not cover damage caused due to improper use, non-compliance with safety
precautions, accidents, or the incorrect maintenance or commercial use of the device.
• This warranty does not cover damage resulting from repairs carried out by persons not
authorised by GEONAUTE.
• The guarantees contained herein explicitly replace all other guarantees including the
implicit guarantee of merchantability and/or suitability for use. GEONAUTE can, under no
circumstances, be held responsible for any damage, direct or indirect, of a general or specic
nature, caused by or related to use of these instructions or the product they describe.
• During the warranty period, the item will either be repaired free of charge by an authorised
repair service or replaced free of charge (depending on the distributor).
• The warranty does not cover the battery, or camera if it t is cracked, broken or presents visible
dents.
10
LEGAL WORDING
CE COMPLIANCE
OXYLANE hereby declares that the G-EYE DISCOVER device complies with essential
requirements and with other relevant stipulations of the 1999/5/CE directive.
The CE compliance declaration is available at the following web link:
https://www.geonaute.com/en/ec-declaration-conformity
RECYCLING
This product and the batteries it contains may not be thrown away with
household waste. They are subject to a specic type of sorting. Take the
batteries and unusuable electronic product to an authorised collection area
for recycling. This treatment of your electronic waste will protect the
environment and your health.
CONTACT US
Contact us on www.geonaute.com.
