GEOSUN eFix R2E User manual

eFix R2 Series
Hardware Operating Instructions
(For eFix R2E and eFix R2G)
Wuhan Geosun Information Technology Co.,Ltd

About
Welcome to use
eFix
R2 series. This book describes how to install, set up and use
eFix
R2E and
eFix
R2G. Please refer to gPac User’s Manual for more information about GPac,
the multi-function GNSS data collecting & processing software embedded in the
eFix
R2
series.
Please read the instructions before start!
Copyright © 2011
Wuhan Geosun Information Technology Co.,Ltd
. All rights reserved.
For more information, please visit:
Http://www.geosun-gnss.com
.cn

i
Contents
Overview .......................................................................................................................................................... 1
eFix R2 Series Overview ....................................................................................................................... 2
Innovative Technologies ........................................................................................................................ 3
Configuration Advantages ..................................................................................................................... 4
Notice .................................................................................................................................................... 5
Technical Parameters ........................................................................................................................................ 6
System Configuration ............................................................................................................................ 7
GPS Receiver ........................................................................................................................................ 7
Network Communications ..................................................................................................................... 7
Positioning Accuracy ............................................................................................................................. 8
Interfaces ............................................................................................................................................... 8
Power Supply ........................................................................................................................................ 8
Physics .................................................................................................................................................. 8
Application Function ............................................................................................................................. 9
Electric Specifications ........................................................................................................................... 9
eFix R2 Series Introduction ............................................................................................................................ 10
Front View ........................................................................................................................................... 11
Back View ........................................................................................................................................... 12
Interfaces ............................................................................................................................................. 13
Main Parts ........................................................................................................................................... 14
Base Station Standard Configuration List ............................................................................................ 16
Rover Standard Configuration List ...................................................................................................... 17
Basic Operations............................................................................................................................................. 18
Taking Out and Putting Back the Touch Pen ........................................................................................ 19
Power On ............................................................................................................................................. 20
Power Off ............................................................................................................................................ 20
Stylus Property Settings ....................................................................................................................... 20
Power Management ............................................................................................................................. 22
Charging ................................................................................................................................... 22
Smart Charging ......................................................................................................................... 23
Check the Remaining Power ..................................................................................................... 23
Power Saving Mode .................................................................................................................. 24
Installing the Micro SD Card ............................................................................................................... 25
Installing the SIM Card ....................................................................................................................... 26
Serial Port Settings .............................................................................................................................. 27
Bluetooth and WiFi Settings ................................................................................................................ 27
Bluetooth Settings .................................................................................................................... 28
Bluetooth Dial-up Connection .................................................................................................. 31

ii
WiFi Settings ............................................................................................................................ 34
Using the Electronic Compass ............................................................................................................. 36
Restoring WinCE System .................................................................................................................... 37
Installing, Uninstalling or Updating GPac Software ............................................................................ 37
Upgrading the Firmware ...................................................................................................................... 37
Connecting to PC ............................................................................................................................................ 40
Installing Microsoft ActiveSync .......................................................................................................... 41
Hardware Connection Setup with PC .................................................................................................. 41
Microsoft ActiveSync Automatic Connection ...................................................................................... 42
Visiting eFix R2 Series Handheld ........................................................................................................ 42
Operation Mode and Configuration ................................................................................................................ 44
Single Point Positioning ...................................................................................................................... 45
Wide Area Differential ......................................................................................................................... 45
CORS Differential ............................................................................................................................... 45
RTK Positioning .................................................................................................................................. 46
Setting up Base Station ............................................................................................................. 47
Setting up the Rover (External GNSS Antenna Mode) ............................................................. 50
Handheld Rover (Built-in GNSS Antenna Mode) ..................................................................... 51
Post-Differential Dynamic Positioning ................................................................................................ 51
High-Precision Large-Range Static Control Network .......................................................................... 52
Data Communication ...................................................................................................................................... 53
GPRS/3G(WCDMA) Communication Mode....................................................................................... 54
Radio Communication Mode ............................................................................................................... 54
Troubleshooting .............................................................................................................................................. 56
Common Troubleshooting ................................................................................................................... 57
ActiveSync Common Issues ................................................................................................................ 58
Appendix: Radio Instructions ......................................................................................................................... 59
PDL Radio Features ............................................................................................................................. 60
Transmitting Radio Introduction .......................................................................................................... 61
Receiving Radio Introduction .............................................................................................................. 62
Factory Default Frequency List ........................................................................................................... 63
Radio Notices ...................................................................................................................................... 64
Index .............................................................................................................................................................. 65
Contact Us ...................................................................................................................................................... 67

1
Overview
 eFix R2 Series Overview
 Innovative Technologies
 Configuration Advantages
 Notice
C H A P T E R
1

eFix R2 Series Hardware Operating Instructions
2
eFix R2 Series Overview
Geosun eFix R2 series handheld is a high-accuracy and high-performance handheld GNSS
RTK system, which provides powerful and flexible solutions for GNSS applications.
Integrated with many proven technologies, eFix R2 series supports large size image data
and hundreds megabyte level vector data loading, and can seamlessly connect various main
stream GIS platforms. It is able to offer humanized, stable and reliable high-accuracy
dynamic/static real-time/post-processing positioning service, and can be widely used in
high-accuracy RTK surveying, high-accuracy large-area static control network building and
field data collection.
High-accuracy eFix R2 series handheld, with mature built-in GPRS network transmission
technology, helps users to easily achieve real-time data transmission. It blends into the U
disk file management and supports dragging files to download. It also has audio annotation,
audio alarm and prompts as well as audio record and image annotation features. It
completely meets user’s fieldwork needs. Using three-proof design, meeting industrial
temperature requirements, and with built-in shield casting reinforced body, eFix R2 series
handheld can easily cope with the extreme field environment.
eFix R2 series includes eFix R2E and eFix R2G. This book describes the technical
parameters and operation instructions of eFix R2E and eFix R2G. The module
configurations of eFix R2E and eFix R2G are shown in the following table, in which √
means configured, × means not available.
Module gRob R2E gRob R2G
Camera √ √
Bluetooth, WiFi √ √
GPRS √ ×
3G/WCDMA × √
Electronic Compass √ √
3.7 Inches Touch Screen √ √
Note: The product nameplate is on the back of the handheld. The first 4 characters of
the SN show the model of eFix R2 series, e.g. “ER2E” represents eFix R2E, “ER2G”
represents eFix R2G.

Overview
3
Innovative Technologies
 Integration of main processor and handset
As a new generation of highly integrated handheld GNSS RTK device, with a stable
and accurate data processing module, and practical engineering tools for
implementation, eFix R2 series can realize high-accuracy RTK by connecting with an
external GNSS antenna. Meanwhile, even just with the built-in GNSS antenna,
centimeter-level positioning accuracy could be easily reached. eFix R2 series has
actually stable performance and is easy to carry with.
 Flexible, Diversified Wireless Communication Technology
 3G High-speed Remote Wireless Communication Technology
Support high-speed multi-media business, and can process multiple media
format, such as image, music, video streaming and etc.
 GPRS Data Transmission
With mature GPRS data transmission technology, the data transmission and
communication can be even more smoothly without distance limitation,
which is especially suitable for urban or mountainous area where the
broadcasting signal is subject to be blocked.
 Integrated Bluetooth and WiFi Wireless Communications
Built-in Bluetooth and WiFi wireless communication modules easily realize
short distance wireless data transmission.
 Integrated 3D Electronic Compass
With the built-in electronic compass which can be an effective assistance to the
GPS fieldwork, it’s possible for eFix R2 series to provide the accurate direction
for users even with pool satellite signals, in low-speed or in static status.
 Intelligent Audio Technology
Support audio annotation, audio record, audio prompt, status warning, and etc.
 U Disc File Management
Easy U disc storage style is adopted for file management. Without any special
software, just the plug-and-play operation enables users to download and manage the
files of the handheld conveniently.
 Ultra-Long-Distance RTK Operation Technology
Ultra-long-distance RTK operation technology breaks the distance limitation of
traditional RTK operation, enabling your handheld more cost-effective.

eFix R2 Series Hardware Operating Instructions
4
Configuration Advantages
 Integrated Handheld Design
Highly integrated design, all built-in key components, ABS + PC material shell,
withstand 1.5 meters natural falling. Industrial three-proof standard: waterproof,
shockproof and dustproof.
 Professional Software Support
gPac software of Geosun is a professional GNSS data acquisition and processing
software suite, which adopts unique high-precision data processing algorithm and
contains many optional application modules. With GPac, you can easily handle the
point, line, area, annotation and other geographic and images, and realize seamlessly
integration of fieldwork and office work.
 Built-in Large Capacity Lithium-ion Battery
The built-in 7.4V/4400mAh large capacity battery supports continuous working for
up to 8 hours in GNSS mode while 6 hours in GNSS + GPRS/3G (WCDMA) mode.
Wide range of power input voltage: 10-15V.
 Power Adapter
Power adapter provides 12V/3A output and charges the Lithium-ion battery by the
host built-in rechargeable circuit. Short charging time, high efficiency, automatically
disconnected when full charged. For the first three times, the battery must be empty
and then be charged for 12 hours continuously. Later on, 6~8 hours charging is
enough.
 Data Communication
Support GPRS/3G (WCDMA) wireless communication which breaks the distance
limitation. Enable data transmitting and receiving freely in areas where GPRS/3G
(WCDMA) is available.
 Handheld Bracket - Carbon Fiber Centering Pole
1 m sectional carbon fiber centering pole, lightweight, practical, and a high precision
leveling bubble is attached. Professional handheld bracket can fix the handheld from
all-directional, easy to convert angle.
 Operating Mode
Users can input data via the touch screen or keyboard, easy to operate.

Overview
5
Notice
Although eFix R2 series handheld is made of corrosion-resistant and impact-resistant
materials, but this kind of sophisticated instrument still needs careful usage and
maintenance. Please preserve the handheld in dry environment as possible. To improve the
stability and service life, the handheld should avoid being exposed to extreme environment,
such as being used in damp, high temperature, low temperature, corrosive gas or liquid, etc.
To ensure the continuity and quality of the satellite tracking, the space over observation
site should be as open as possible, without large obstacles over 15° elevating angle. To
reduce various electromagnetic interference to GNSS satellite signal, please make sure
no strong electromagnetic interference in 200m range around the observation site, such
as TV tower, microwave station, high-voltage transmission. To avoid or to reduce the
multipath influence, the site should be set far away from the terrain and ground features
where the electromagnetic wave signal reflection is strong, such as high buildings,
large area waters, etc.
Warnings:
 This equipment contains ESDS (Electrostatic Discharge Sensitive Device), with
level C of electrostatic anti-interference test. To touch, move, or plug the
equipment please follow the ESD (electro-static discharge) instructions.
 Must be used and preserved in the stipulated temperature range. For details,
please refer to the chapter Technical Parameters below.

6
Technical Parameters
 System Configuration
 GPS Receiver
 Network Communications
 Positioning Accuracy
 Interfaces
 Power Supply
 Physics
 Application Function
 Electric Specifications
C H A P T E R
2

Technical Parameters
7
This chapter describes the technical parameters of Geosun eFix R2 series. The
specifications are subject to change without notice.
System Configuration
 Operating System: Windows CE 6.0
 CPU 1GHz, memory 512 MB , Flash memory 512 MB
 Extension: Built-in sealed Micro SD card slot, support massive storage expansion up
to 32GB
 Display: 3.7 inches outdoor highlight color touch screen
 Power consumption: 3W
GPS Receiver
 GPS: L1 C/A, L2 P(Y), L2C, L1 and L2 carrier phase
 SBAS: WAAS, EGNOS, MSAS
 1 Hz, 2 Hz, 5 Hz, 10 Hz, 20Hz positioning output (1Hz in default)
 Advanced user-defined measurement GNSS technology, extremely low noise GNSS
carrier phase measurements
 GLONASS: Synchronous tracking L1 C/A, L1P, L2 C/A (GLONASS M only) and
L2P
 Navigation output format support: ASCII: NMEA-0183 and binary system
 Differential format support: CMR, CMR+, RTCM 2.1, RTCM 2.2, RTCM 2.3, RTCM
3.0, RTCM 3.1
Network Communications
 eFix R2E is integrated with four-band (850/900/1800/1900GSM) GSM network
communication module
 gFix R2G is integrated with 3G / WCDMA wireless network communication module
 Built-in Bluetooth and WiFi wireless communication module, easily realize short
distance wireless communication

eFix R2 Series Hardware Operating Instructions
8
Positioning Accuracy
 Static positioning (external antenna):
Horizontal: ±(2.5 mm＋1×10
-6
D)
Vertical: ±(5.0 mm＋1×10
-6
D)
 RTK positioning (external antenna):
Horizontal: ±(10 mm＋1×10
-6
D)
Vertical: ±(20 mm＋1×10
-6
D)
 RTK positioning (built-in antenna):
Horizontal: ±(20 mm＋1×10
-6
D)
Vertical: ±(30 mm＋1×10
-6
D)
Interfaces
 One external antenna port
 One power supply, serial port and USB sharing port
 One SIM card slot
 One Micro SD card slot
Power Supply
 Battery: Built-in 7.4V/4400 mAh Lithium-ion battery supports continuous working for
up to 8 hours in GNSS mode while 6 hours in GNSS + GPRS/3G (WCDMA) mode.
 Input voltage: DC 10~15V, can switch automatically between built-in battery and
external power.
Physics
 Size: 223×98×49mm
 Weight: 950g
 Operating temperature: -20℃ ~ 60℃
 Storage temperature: -40℃ ~ 80℃
 Humidity: 95% non-condensing
 Waterproof & shockproof: IP67
 Anti-shock: Can withstand 1.5 meters natural fall

Technical Parameters
9
Application Function
 Built-in electronic compass, an effective assistance to the GPS fieldwork
 Video: Built-in 5 mega-pixel digital camera, support image annotation function
 Audio: Built-in microphone and speaker, support audio annotation, operation prompt
and alarm function.
Electric Specifications
 Level C of electrostatic anti-interference test

10
eFix R2 Series Introduction
 Front View
 Back View
 Interfaces
 Main Parts
 Base Station Standard Configuration List
 Rover Standard Configuration List
C H A P T E R
3

eFix R2 Series Introduction
11
Front View
Power Status Indicator Communication Status Indicator
Charging
Start Charging Red Radio Mode Red
Status: 80% Flashes alternately in
red and orange GPRS/3G Green
Fully charged Orange Bluetooth Orange
Discharging
(While
Working)
Fully charged Green WiFi Flashes in green
Status: 20% Flashes slowly in
green None Extinguish

eFix R2 Series Hardware Operating Instructions
12
Back View
Camera
SIM Card/
Micro SD Card Slot
Touch Pen
Belt
Nameplate

eFix R2 Series Introduction
13
Interfaces
Micro SD Card Slot
SIM Card Slot
I/O Interface
External GNSS
Antenna Interface

eFix R2 Series Hardware Operating Instructions
14
Main Parts
Data Cable Charger & Adapter
*
GNSS External Antenna External Antenna Connecting Cable
Handheld Bracket to Tripod Handheld Bracket to Centering Pole
* We will choose the suitable power plug (USA, England or Europe type, etc.) for you
according to your specific power configuration

eFix R2 Series Introduction
15
Power Charging Cable for Handheld Power Charging Cable for Receiving Radio
Receiving Radio Bracket Handheld Connecting Cable for Receiving Radio
Transmitting Radio Power and Connecting Cable Transmitting Radio Power Cable

eFix R2 Series Hardware Operating Instructions
16
Base Station Standard Configuration List
Configuration Item Number
eFix R2 Series Handheld 1
Charger & Adapter 1
External Antenna Connecting Cable 2
Data Cable (USB plug + serial port_D-sub9 female) 1
Power Charging Cable for Handheld 1
Micro SD Card (2G Byte, Flash Type) 1
External GNSS Antenna 1
Touch Pen 2
Handheld Bracket to Tripod 1
Caravel PP/Net Software Dongle 1
PDL High-Power Transmitting Radio 1
Transmitting Radio Antenna 1
Transmitting Radio Connecting Cable (For Communication
Link between Transmitting Radio and R2 Series Base Station)
1
Transmitting Radio Power Charging Cable (For Transmitting
Radio Charging) 1
Transmitting Radio Antenna Telescopic Pole 1
Fuse (Installed in Transmitting Radio Power Cable) 5
GEOSUN CD (Containing all GEOSUN catalogues, software,
manual, video) 1
eFix R2 Series Bag 1
eFix R2 Series Case 1
