MANUAL FOR CONSTRUCTION AND OPERATION OF
TEZPAZ STOVE

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj

3
www.geres.eu
INTRODUCTION
Inecient use of wood and dung for cooking fuel have led to
deforestaon and serious erosion problems in Tajikistan. Over-
use of fuel has also negavely aected agricultural lands. When
dung that is normally le to ferlize elds is instead used for
fuel, crop yields are signicantly smaller.
The authors of this manual propose a soluon to these risks:
the Tezpaz Stove greatly reduces the amount of fuel required to
cook, thus migang the risk of erosion, deforestaon, and low-
crop yields. The stove presented in this manual is easy to use
and requires 50% less fuel.
Wasng re in tradional stove

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
1. “TEZPAZ” STOVE
The “Tezpaz” - saves me and money! This stove is designed to make cooking easi-
er and faster during the cold season.
You can cook with dierent
sized pots in the Tezpaz,
from 12 to 20 liters in vol-
ume.
The Tezpaz lets you save 50% on fuel when
you cook a meal for your family.
The advantages of the Tezpaz stove are listed below.
Smoke escapes through the
chimney so it doesn’t bother or
harm the cook.
The Tezpaz stove
is easy to man-
age and is proven
to be safe.

5
www.geres.eu
2. CONSTRUCTION OF “TEZPAZ”
STOVE
The Tezpaz is built dierently from tradional stoves.
The Tezpaz is made from galvanized sheet metal and
armature, whereas tradional stoves are made out
of mud bricks.
Because of its unique look, construcon of the stove
might look dicult at rst.
This manual shows how to build the Tezpaz stove
step by step.
Construcon of Tezpaz stove consists of the follow-
ing steps:
Step 1. Drawing design of the stove.
Step 2. Measurement and preparing the separate
parts .
Step 3. Pung prepared parts together .

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
The “Tezpaz” stove consists of two parts
2.1. DRAWING DESIGN OF THE
“TEZPAZ” STOVE
Step 1
Part 1.
Cylinder shaped burner for placing
cooking pots.
“Tezpaz” stove
Part 2.

7
www.geres.eu
“Tezpaz” stove
View from the
side
“Tezpaz” stove
View from front
“Tezpaz” stove
View from above
PART 1.
Lid, galvanized sheet
t= 0,7mm, see D-1,2
handle, galvanized sheet
t= 0,7mm, see D-1,2
Elbow Combuson Chamber
Iron t= 2mm, see D-1.5, 1.6
Lid, galvanized sheet
t= 0,7mm, see D-1,2
base, galvanized sheet
t= 0,7mm, see D-1,3
Knobs, galvanized sheet
t= 0,7mm, see D-1,3
Elbow camera, leaf
Iron t= 2mm, see D-1.5, 1.6
Lid, galvanized sheet
t= 0,7mm, see D-1,2
Inside size
Inside size
65
50
40
120
35
□110х110
335
360
5
320
□112,5х112,5
□112,5х112,5
5
40
50
320
200
□110х110
□112,5х112,5
150
150
5
45

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
Cylinder shaped
burner,
View from the
side
Cylinder shaped
burner,
View from front
Cylinder shaped
burner,
View from above
PART 2.
Elbow shaped pipe
galvanized sheet
t= 0,7mm, se D-3.2
Curved edge,
Н=10mm
Wall galvanized sheet
t= 0,7mm, see D-1.3
Rivet
Ø4mm, 6pieces
metal stand
Armature Ø10А-1, see D-3.2
boom, galvanized sheet
t=0,7mm, see D-3.4
Curved edge,
Н=10mm
Rivet
Ø4mm, 6 pieces
Elbow, galvanized sheet
t= 0,7mm, see D-3.2
metal stand
Metal Bar Ø10А-1, see D-3.2
Connecon fold of metal
support column, galvanized sheet
t=0,7mm, see D-3.3
Addional heat protector, 4 pieces,
galvanized sheet t=0,7mm, see D-3.3
Ø105
Ø105
107
210
258
280
10
10
□110х110
Ø380
□100х100
Ø380
15
12
R190
40
45
30
50
210
130

9
www.geres.eu
2.2. MEASUREMENT AND PREPARING
SEPARATE PARTS OF “TEZPAZ” STOVE
Step 2
Part 1. «Tezpaz” stove:
▪Parts of Tezpaz stove lid:
▪lid;
▪Lid frame of “Tezpaz” stove;
▪Foundaon of “Tezpaz” stove ;
▪Handle of “Tezpaz” stove;
▪Walls of “Tezpaz” stove;
▪L- shaped chamber;
▪Ashbox grate of “Tezpaz” stove
Part 2. Cylinder shaped burner:
▪Leg;
▪Iron foot (foot, clamp, console);
▪Addional insulaon;
▪Iron column
▪Walls of cylinder shaped burner;
▪Boom of cylinder shaped burner.
“Tezpaz” stove consists of the following parts and subparts:

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
Lid of “Tezpaz” stove
View from the side
View from above
Lid
Inside size
Inside size
Full view of lid Curve line
Curving line
Full view of frame
Inside size
□115х115
□110х110
35
□115х115
360
333
35 35 13
13
10 10
333 333 333 333
1352
360
381
10.5
333
360
333 360
333 360
10.5
45º
Frame

11
www.geres.eu
Foundaon of “Tezpaz” stove
View from side
View from above Full view of foundaon
Curving line
Curving line
Full view of handle
Handle of “Tezpaz” stove
View from the side
View from the side
View from the side
Curving line
Full view of Tezpaz stove walls
333
360
11
333
360
413
360
333
360
360
413
15,5
2х10,5
45º
18 64 18
100
40
50
10
50
18 64 18
100
45
9
45
25
2х10
□115х115
40
360
320
2х10
2х10
330 330 330 330
1360
Damper
2х10
50 50 60,5
181
10,5 10
100
64
Ø4mm, 2 piceces

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
L shaped chamber of Tezpaz stove
General view
View from above
Corner sides
∟25*25, 4pieces L=140mm
Inside size
Corner sides
∟25*25, 4pieces L=140mm
Inside size
Inside size
Sides from angel
∟25*25, 4pieces L=140mm
Inside size
2 pieces 1 piece 1 piece
1 piece
View from the side View from front
Curving line
Chamber parts
112,5
112,5
232,5
120
150
□110х110
□110х110 □110х110
□110х110
150
120
210
232,5
291
168,5
281
112,5
40
5
281
321
5
138,5
40
112,5
321
110
210
110
112,5 112,5
168,5
288,5
120
316
232,5
110
40
120
150
1. 2. 3.
4.

13
www.geres.eu
Iron grate of Tezpaz stove ash-box
View from above View from front
View from the side
Grates
Armature Ø10А-2, L=130mm, 4 pieces
Iron rod
Armature Ø10А-2, L=230mm, 1 piece
Iron holders for woods
Armature Ø7А-1, L=920mm, 1piece.
Support 1. armature
Ø7А-1, L=150мм, 1 piece.
Support 1. armature
Ø7А-1, L=115мм, 1 piece
Plank to strengthen galvanized metallic sheet
t=1,2мм-1,5мм, H105*L120мм, 1piece
Leg 1. Armature
Ø7А-1, L=200мм, 2 pieces
Leg 2. Armature
Ø7А-1, L=260мм, 1 piece
130
110 120 50 80 170
50
530
200 105
110 120
130 50 50 80 170
50
530
40 80
87
230
105 105 200
80
87
R20

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
Parts of ash-box grate
3 D view
120
106
130 230
R20
360
200
115
150
41.4 40
80
105
R20

15
www.geres.eu
Metal body
t=0,7mm 1,2
View from above View from the side View from front
stovepipe
Galvanized sheet t=0,7mm,
Side walls, 2 pieces
1,3
Galvanized sheet t=0,7mm,
Leg
View of open leg
Stove pipe, galvanized sheet t=0,7mm
Trunk, galvanized sheet t=0,7mm,
Side walls, galva-
nized sheet,
t=0.7mm, 2 pieces
Curving line
Curving line
R190
Ø105
210
258
210
255 238
10750
Ø105
157
258
50
Ø95
Ø105
R190
238
10 10 10 10
R190
210
258
107
127
10
330
370
10 10
298
258 10 10
50
90
10
10
238
1,1
10 10

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
View from above
Support
Armature Ø6А-1, L=150mm
View from the side
Support, L=150mm, 4pieces
Armature Ø6A-1
Foot L=170mm, 4дона
Armature Ø8A-1
Connecng with welding
Electrode 3mm
Clamp
Armature Ø8А-1,
L=520mm
Connecng with welding
L=10mm
Clamp, armature Ø8A-1,
L=520mm
Feet, L=170mm, 4pieces
Armature Ø8А-1
Connecng with welding
Support, L=150mm, 4 pieces
Armature Ø6А-1
Iron made stove foot
Addional insulaon. 4 pieces Iron made column
Curving line
45
150
116
116
100
sq116х116
150
3055
R190
175
116 280
85
72
45
10º
150
116
116
45º
325
265
240
30
30
20
2.2. Clamp
Armature 08A-1, L=464
Foot
Armature Ø8А-1, L=130mm

17
www.geres.eu
Curving line
1193,5 (for D500=1570)
1233,5 (for D500=1610)
Open view of cylinder shaped burner walls
Boom of cylinder shaped burner.
12
238
30
30
50
15
100
210
245
10 10
10 10
Ø380 (Ø500)

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
2.3. CONNECTING THE PARTS OF
THE STOVE
Step 3
First of all, construct the lid of stove from galvanized
sheet, (а) bend its sides downward.
Order of aach-
ing the rst part
of Tezpaz stove.
The rst part of “Tezpaz” stove is made in the following order:
Also, built the under lid frame and bend the sides
downward (а), so that later to aach it to the lid.

19
www.geres.eu
Then, aach the lid to the frame, which was prepared in previous secon. This way, the lid of the Tezpaz
stove is made.
(а) Lid , view from inside; (b) Lid from outside.
Foundaon (boom) of Tezpaz stove is made form galvanized metallic sheet. For this, cut the galvanized me-
tallic sheet in accordance with the design and bend its all four sides as shown in the picture. (а) Foundaon,
view from above; (b) Foundaon, view from boom.

MANUAL FOR CONSTRUCTION AND OPERATION OF “TEZPAZ” STOVE
www.agencynau.tj
Aer aaching walls to foundaon, aach two
knobs (handles) (а) of the stove with rivet (а) to the
right and le side of the wall.
Walls of Tezpaz stove is made from galvanized sheet
(а) aach it and (b) bend the lower sides. Then aach walls to foundaon (picture 4) (picture
5).
