Gianni Industries AD-425S User manual

Statement
AD425S
Automatic door operator
AD425S Automatic Door Operator is a reliable and quiet
door opening and closing device. This product is ideal for
enabling access to areas for people with disabilities or simply
for convenience (for example in hospitals, nursing homes and
airports etc) . It is compact and can be used in combination
with other access control system to create a barrier-free
environment.
Specifications
Motor specification
Wing dimensions
Dimensions
Net Weight
Moisture resistant grade
Temperature
Battery charge
Battery Specification
Maintain-Open time
Opening/Closing time
Current draw
Operating voltage 100~115 VAC( or 220~230 VAC)
3A max., 0.6A average (Motor)
35Nm
4.5~9.5 seconds （90）
1,5,10,20 seconds
12V 1.2AH
-20C~+55C (Battery 5C~40C)
Door wing width : 75~120 cm
Door wing weight : 30~100 kg
Door wing high:Max.280cm
IP12D
8.5 kg
12V=0.15A (Normal); 0.3A (Peak)
Operator: 526(L) x 100(W) x 96(D)
Arm: 400
(unit: mm)
Maximum current : 4A
Output : 65W
Voltage: 8~24VDC
Frequency: 2400 RPM
Torque
1. Cover
2. Motor
3. Reducer
4. Square Couplings
5. Control Board
6. Battery
7. Power Switch
8. Operating Arm
9. Sliding Rail
10. Stopper Ball
11. Baseplate
12. Transformer
13. Encoder
14. Photocell
14
13
1
23
5
6
7
4
98
EC862636
GIANNI INDUSTRIES, INC.
No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
Copyright Gianni industries, inc. All rights reserved.
DM-CA-AD425S Ver. F Published on 2010.07.21
Safety Device
Do not push/pull the door with excessive force during
p r o p e r o p e r a t i o n . E x c e s s i v e f o r c e w i l l l e a d t o
auto shut off by control board and recovery after 10 seconds.
The zinc alloy housing with heat treatment for some inner
parts enhances the construction strength and durability

Backup battery
In case of power failure, a backup
battery can maintain normal opening
and closing operations up to 250 times.
Wing dimensions
10 20 30 40 50 60 70 80 11090 120100
A
B
Features
Door wing width（cm）
Door wing weight（kg）
Service Class A: average of up to 600 cycles per day
Service Class B: average of up to 200 cycles per day
Safety device
AD425S incorporates a safety device.
When an obstruction is detected the
door will be returned to its previous
open or closed position to prevent
accidents.
Applicable for all doors
AD425S can be mounted to open
outwards or inwards and fits either left
or right swinging doors.
High accuracy
A built-in Photocell and encoder are
used to control the actio n of the
operating arm. Desired opening angle
and appropriate braking distances can
be accurately managed.
Wide Range
It is suitable for doors with width
between 75 ~ 120 cm and weight
between 50 ~ 100 kg .
※ See Figure Wing dimensions
Selectable dual voltage
T h e A D 4 2 5 S o p e r a t e s o n e i t h e r
100~115 or 220~230 VAC mains power
su ch t ha t i t ca n be u s ed a lm os t
anywhere in the world.
100~115/220~230 V
All in one
The AD425S has interfaces for up to six
optional devices such as electromagnet
locks, press to open buttons, microwave
s e ns o r s , c a r d r e a d e r s a n d o t h e r
accessories.
Maintain-Open time
The door can be adjusted to open for a
ma xi m um o f 2 0 se co n ds . T hi s i s
s u i t a b l e f o r b o t h d i s a b l e d a n d
wheelchair users.
Quiet and Reliable
AD425S is quiet and reliable when
operating.
Selectable operating speeds
Fo u r se l ec ta b le o pe r at i ng s pe e ds
settings and two levels of torque output
can be chosen based on the width and
weight of the door.
Push & Go option
AD425S includes a switch to select
between auto and manual mode. In
manual mode, applying force to the door
will activate the opening.
Remote controls
Ca n b e use d i n co n ju nc t io n w it h
wireless remote controls.
AD425S
Automatic door operator
GIANNI INDUSTRIES, INC.
No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
GIANNI INDUSTRIES, INC.
No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
Copyright Gianni industries, inc. All rights reserved.
DM-CA-AD425S Ver. E Published on 2010.01.07

Dimension
1 00
PUSHHOLDON
OFFOPENGO
00
I
I
Unit: mm
GEM
In-swing
Install AD425S on an out-swing door, make sure
that the distance between the header and leaf is
not more than 60mm, and the space between the
header and Sliding Rail mounting hole must be
61mm, on an in-swing door, make sure that the
distance between Square Couplings and hinge is
not more than 74mm , the space between header
and the bottom of AD425S must be 23mm, and the
space between header and Sliding Rail mounting
hole must be 39mm.
Depending on the door leaf opening
120°
Stopper Ball
(Max.)60mm
61mm
Outswing
Header
23mm
39mm 74mm
Inswing
Header
AD425S
Automatic door operator
GIANNI INDUSTRIES, INC.
No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
GIANNI INDUSTRIES, INC.
No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
Copyright Gianni industries, inc. All rights reserved.
DM-CA-AD425S Ver. E Published on 2010.01.07

Application
Inswing
AD425S
GEM
Right-hand
Right-hand
Outswing
AD425S
Left-hand
Left-hand
Outswing
AD425S
Inswing
AD425S
GEM
GEM
GEM
Outswing door
Inswing door
To mount the AD425S depends on the direction
way of the doors, outswing, inswing, right- open
and left-hand doors by adjusting the F/R switch
and the direction of the Operating Arm.
For the safety reason, AD425S must be installed
indoor.
Operating Arm turns clockwise or .counter-clockwise
Opening angle: 90 degree
Beginning
Destination
Brake for wall blanking function.
VM action time is the opening and closing time.
TC Maintain time of 1-20 seconds.
Beginning
Beginning
Destination(TC Maintain time)
Destination
Brake
Brake
e
m
i
t
n
o
i
t
c
A
M
V
e
m
i
t
n
o
i
t
c
A
M
V
Open Door
Close Door
AD425S
Automatic door operator
GIANNI INDUSTRIES, INC.
No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
GIANNI INDUSTRIES, INC.
No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
Copyright Gianni industries, inc. All rights reserved.
DM-CA-AD425S Ver. E Published on 2010.01.07

Relay output
Relay output
Relay output
N. O.
Com.
N. O.
Com.
Application
3
4
1
2
Wireless Push Button
Access Control System
Microwave sensor switch Electric Locking Device
1
1
1
1
2
3
8
9
VM TC REDA2
REDA1
1
2
3
8
9
N.C.
N.O.
Com.
Relay
(Lock)
Relay
( )Motor
Battery AC15V in
Motor
LED
(Motor)
LED
( Charge)
LED
( DC in) LED
( Relay)
Fuse
12V
1.2Ah
Fail safe
Fail secure
DC Power
GEM
In-swing
1
2
(Outdoor)
4
0 ~ 7 meter
Max. 4.5
meter
3
The product is warranted against defects in material and
workmanship while used in normal service for a period of 5
years from the date of sale to the original client. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
Warranty
