Gibson Top Freezer Frost Clear Refrigerator User manual

P/N 218972302 (0101)

2
Contents
Product Registration
This Owner’s Guide provides specific
operating instructions for your model.
Use the refrigerator only as instructed in
this Owner’s Guide.
© 2001 White Consolidated Industries, Inc.
All rights reserved.
The information contained within this Owner's Guide will instruct you on how to
properly operate and care for your product. Please read through the information
contained in your literature pack to learn more about your new appliance.
Record Your Model and Serial Numbers
RecordtheModelNo.andSerialNo.ofthisrefrigeratorinthespaceprovidedbelow.
These numbers are found on the serial plate located on the top left wall of the
refrigeratorcompartment.
ModelNo.
SerialNo.
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD should be filled in completely,
signed and returned to Electrolux Home Products.
2 ProductRegistration
3 ImportantSafetyInstructions
3 For Your Safety
3 Child Safety
3 ElectricalInformation
3 OtherPrecautions
4 First Steps
4 Location
4 Installation
4 DoorOpening
4 Leveling
4 Cleaning
5 Connecting Ice Maker to Water Supply
6 EnergySavingIdeas
6 Setting the Controls
6 Temperatures
6 MoistureReductionSwitch
7 Fresh Food Storage
8 Care and Cleaning
8 Inside
8 Outside
8 Replacingthe Light Bulb
8 Vacation and Moving Tips
9 AutomaticIceMaker
9 Ice Maker Tips
10-12 DoorReversal Instructions
13 Refrigerator Toe Grille Assembly Instructions
14-16 AvoidService Checklist
16 NormalOperatingSounds
17 Warranty(UnitedStates)
18 ServiceInformation(Canada)
19 Warranty(Canada)
Versión en español
Si desea obtener una copia en español
de este Manual del Usuario, sírvase
escribir la dirección que se incluye a
continuación.SolicitelaP/N218972301.
SpanishOwner'sGuides
ElectroluxHomeProducts
P.O.Box212378
Augusta,GA 30917

3
Important Safety
Instructions
Proper Disposal of
Your Refrigerator/Freezer
DANGER
Riskofchildentrapment.
Child entrapment and suffocation are
not problems of the past. Junked or
abandoned refrigerators or freezers are
still dangerous — even if they will sit for
"justafewdays."Ifyouaregettingridof
your old refrigerator or freezer, please
follow the instructions below to help
preventaccidents.
BEFORE YOU THROW AWAY YOUR
OLD REFRIGERATOR/FREEZER:
• Remove
doors.
• Leave
shelves in
place, so
children
may not
easily
climb
inside.
Avoid fire hazard or
electric shock. Do not use an extension
cordoranadapterplug.Donotremove
any prong from the power cord.
Read all instructions before using this refrigerator.
For Your Safety
Donotstoreorusegasolineorotherflammablevaporsandliquidsinthevicinityof
this or any other appliance. Read product labels for flammability and other warnings.
Child Safety
• Destroy carton, plastic bags, and any exterior wrapping material immediately
aftertherefrigeratorisunpacked.Childrenshouldneverusetheseitemsforplay.
Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may
become airtight chambers and can quickly cause suffocation.
• Remove all staples from the carton. Staples can cause severe cuts and destroy
finishes if they come in contact with other appliances or furniture.
• Anempty,discardedicebox,refrigeratororfreezerisaverydangerousattraction
to children. Remove the door of any appliance that is not in use, even if
it is being discarded.
ElectricalInformation
Theseguidelinesmustbefollowedtoensure thatsafetymechanismsinthe
design of this refrigerator will operate properly.
•The refrigerator must be plugged into its own 115 Volt, 60 Hz, AC only
electrical outlet. The power cord of the appliance is equipped with a 3-prong
grounding plug for your protection against shock hazards. It must be plugged
directly into a properly grounded 3-prong receptacle. The receptacle must be
installed in accordance with local codes and ordinances. Consult a qualified
electrician. Do not use an extension cord or an adapter plug.
• Ifvoltagevariesby10percent ormore,performanceofyourrefrigeratormaybe
affected. Operating the refrigerator with insufficient power can damage the
compressor.Suchdamageisnotcoveredunderyourwarranty.Ifyoususpectyour
voltage is high or low, consult your power company for testing.
• Topreventtherefrigeratorfrombeingturnedoffaccidentally,donotplugtheunit
into an outlet controlled by a wall switch or pull cord.
• Do not pinch, knot, or bend the power cord in any manner.
Other Precautions
• Neverunplugtherefrigeratorbypullingonthepowercord.Alwaysgriptheplug
firmly and pull straight out from the receptacle.
• To avoid electrical shock, unplug the refrigerator before cleaning and before
replacingalightbulb.NOTE:TurningthecontroltoOFFturnsoffthecompressor,but
doesnotdisconnectpowertothe light bulb or other electrical components.
• Do not operate the refrigerator in the presence of explosive fumes.
• Iftherefrigeratorhasanautomaticicemaker,avoidcontactwithanymovingparts.

4
G05D0010
First Steps Before starting the refrigerator, follow these important first steps:
Location
• Choose a place that is near a grounded electrical outlet. DO NOT use an
extension cord or an adapter plug.
• Ifpossible,placetherefrigeratoroutofdirectsunlightandawayfromtherange,
dishwasherorother heat sources.
• The refrigerator must be installed on a floor that is level and strong enough
tosupportafullyloaded refrigerator.
• Consider water supply availability for models equipped with an automatic ice
maker.
Installation
• Do not install the refrigerator where the temperature will drop below 60°F
(15°C)orriseabove110°F(43°C).Thecompressorwillnotbeabletomaintain
propertemperatures.
• Allow space around the unit for good air circulation. Leave a 1 inch (25 mm)
space behind and a 3 inch (75 mm) space above the refrigerator for adequate
circulation.
• In a recessed installation, allow an extra 1/2 inch (10-15 mm) on each side for
ease of installation.
• For best circulation, elevate the unit 1 inch (25 mm) from the floor, especially
if the floor is carpeted.
Door Opening
The doors should open to allow easy access to a counter when removing food.
• Donotpositiontherefrigeratorsoyouhavetowalkaroundthe refrigerator doors.
• Reverse the doors if necessary. See "Door Reversal Instructions."
Leveling
All four corners of refrigerator must rest firmly on a solid floor. Some models are
equipped with adjustable screw-type levelers. Others are equipped with rollers. If
yourrefrigeratordidnotcomewithrollers,theycanbepurchasedfromyourdealer.
Remove toe grille (some models). See Toe Grille Instructions on page 13.
•Toadjustscrew-type levelers(somemodels): Tipcabinetbackslightlyand
raise adjusting bolts as needed.
•To adjust front rollers (some models): Use a screwdriver, 3/8" socket
wrench,or nutdriver toadjust rollers as shown.
RAISE THE FRONT of cabinet enough so doors will close freely when opened
halfway. Level cabinet side to side.
Cleaning
• Wash the inside, all removable parts and the outside with mild detergent and
warm water. Wipe dry.Do not use harsh cleaners on these surfaces.
• Donotuserazorbladesorothersharpinstrumentsthatcanscratchtheappliance
surface, when removing adhesive labels. Any glue left from the tape or energy
labelcanberemovedwithamixtureofwarmwaterandmilddetergent,or,touch
the residue with the sticky side of tape already removed.
•Do not remove the serial plate.
1"
1"
1/2"
1/2"
3" AIR SPACE
Clearance
Proper air circulation and leveling will
ensure efficient operation.
Exposed bolt (some models)
Sunken bolt (some models)

5
IMPORTANT:
Ensure that your water supply line connections comply with all local plumbing codes.
Before Installing The Water Supply Line, You Will Need
•Basic tools: adjustable wrench and standard, flat blade screwdriver.
• Access to a household cold water line with water pressure between 20 and 120 psi.
• A water supply line made of ¼ inch (6.4 mm) OD, copper tubing. To determine the length of copper tubing needed, you
will need to measure the distance from the ice maker inlet valve at the back of the refrigerator to your cold water pipe.
Then add approximately 7 feet (2.1 meters), so the refrigerator can be moved out for cleaning. See Figure 1.
• A shutoff valvetoconnect the water supply line to your household water system. (DO NOT use a self-piercing type shutoff
valve.)
• A compression nut and ferrule (sleeve) for connecting the water supply line to the ice maker inlet valve.
NOTE: Water line kit number 5303917950, available from your appliance dealer at additional cost, contains 25 feet (7.6
meters) of ¼” OD copper tubing, a saddle type shutoff valve (nonpiercing), (2) ¼” brass compression nuts, (2) ferrules/sleeves,
and instructions for installing a water supply line.
To Connect Water Supply Line To Ice Maker Inlet Valve
1. Disconnectrefrigeratorfromelectricpowersupply.
2. Place end of water supply line into sink or bucket. Turn ON water supply
and flush supply line until water is clear. Turn OFF water supply at shutoff
valve.
3. Unscrew plastic cap from water valve inlet (some models) and discard cap.
4. Slide brass compression nut, then ferrule (sleeve), onto water supply line,
as shown in Figure 2.
5. Push water supply line into water valve inlet as far as it will go (¼ inch). Slide
ferrule (sleeve) into valve inlet and finger tighten compression nut onto
valve.Tighten another half turn with a wrench; DO NOT over tighten.
6. With steel clamp and screw, secure water supply line to rear panel
of refrigerator at location shown in Figure 1.
7. Coil excess water supply line (about 2½ turns) behind refrigerator as
shown in Figure 1 and arrange coils so they do not vibrate or wear
against any other surface.
8. Turn ON water supply at shutoff valve and tighten any connections
that leak.
9. Reconnectrefrigeratortoelectricpowersupply.
10.To turn ice maker on, lower wire signal arm. (See ice maker front
coverforon/off position of arm.)
It takes approximately 24 hours for the ice maker to begin producing
ice. Air in new plumbing lines may cause ice maker to cycle two or three times before making a full tray of ice. New
plumbing may cause ice to be discolored or have poor flavor. Discard ice made during the first 24 hours.
Connecting Ice Maker
to Water Supply
Figure1
Figure2
To Avoid Property Damage:
• Copper tubing is recommended for the water supply line. Water supply tubing made of 1/4” plastic is not recommended since it
greatly increases the potential for water leaks. Manufacturer will not be responsible for any damage if plastic tubing is used for
supply line.
•DO NOT install water supply tubing in areas where temperatures fall below freezing.
• Connect the ice maker to a potable water source that is not tied into a water softening system. Chemicals from the softener may
damage the ice maker, causing it to malfunction.
To avoid electric shock, which can cause death or severe personal injury, disconnect the refrigerator from
electrical power before connecting a water supply line to the refrigerator.

6
G05C0061
Energy Saving Ideas • Locatetherefrigeratorinthecoolestpartoftheroom,outofdirectsunlightand
awayfromheatingductsorregisters.Donotplacetherefrigeratornexttoheat-
producingappliancessuchasarange,ovenordishwasher.Ifthisisnotpossible,
a section of cabinetry or an added layer of insulation between the two
appliances will help the refrigerator operate more efficiently.
• Level the refrigerator so the doors close tightly.
• Refer to this Owner's Guide for the suggested refrigerator settings.
• Periodic cleaning of the condenser will help the refrigerator run more
efficiently. See Outside in the "Care and Cleaning" section.
• Do not overcrowd the refrigerator or block cold air vents. Doing so causes the
refrigeratortorunlongerandusemoreenergy.Shelvesshouldnotbelinedwith
aluminum foil, wax paper or paper toweling. Liners interfere with cold air
circulation, making the refrigerator less efficient, which could cause food
spoilage.
• Cover foods and wipe containers dry before placing them in the refrigerator.
This cuts down on moisture build-up inside the unit.
• Organize the refrigerator to reduce door openings. Remove as many items as
needed at one time and close the door as soon as possible.
Setting the Controls
Freezer Control
Cool Down Period
Toensuresafefoodstorage,allowtherefrigeratortooperatewiththedoorsclosed
for at least 8 to 12 hours before loading with food.
Refrigerator and Freezer Controls
• To start out, set control dials to the midpoint for a trial period of 24 hours.
Temperatures
• After 24 hours, adjust the controls as needed. Adjust temperatures one
numberatatime.Forcoldertemperatures,turnthedialtowardCOLDEST.For
warmer temperatures, turn the dial toward COLD. The temperature will
increase or decrease, but not necessarily by 1, 2, or 3 degrees.
Anadjustmentmadetoonecompartmentmayrequireanadjustmenttotheother.
• Turning the refrigerator control will change the temperature in BOTH
compartments. If the refrigerator control is turned to OFF, cooling
stops in both compartments.
• Turningthefreezercontrolwillchangeonlythetemperatureinthefreezer
compartment.
To maintain temperatures, a fan circulates air in the refrigerator and freezer
compartments. For good circulation, do not block cold air vents with food items.
Moisture Reduction Switch (some models)
If moisture forms on the metal between the two doors, set the Moisture Reduc-
tion Switch (located on the control box in the refrigerator compartment) to the
“ON” position. A heater will warm the surface and allow moisture to evaporate.
Refrigerator Control
Moisture Reduction Switch

7
Sliding Shelf
Cantilever Shelf
Combination Cantilever/Sliding Shelf with
Plastic Clip
Shelf Adjustment
Refrigerator shelves are easily adjustable to suit individual needs.
Somemodelshaveslidingshelves, others have cantilevershelves,
or both. Before adjusting shelves, remove all food. The shipping
clipswhichstabilizetheshelvesforshippingmayberemovedand
discarded.
To adjust sliding shelves, remove by pulling forward to the stop
position, then lift the front edge up and pull out. Replace on any
pair of rails by reversing this procedure.
To adjust cantilever shelves (shelves supported at the rear of the
refrigerator),liftthebackoftheshelfupandout.Replaceshelfby
inserting hooks at rear into wall bracket. Lower and lock into
position.
Toadjustcombinationcantilever/slidingshelves,removeshelfbyliftinghooksupand
outofrearwallbracket. Thenflexplasticcliptowardscenterofrefrigeratorandpull
shelfstraightout.Replaceshelfbyslidingplasticclippastsidewallsupport. Thenlock
hooksatrearintowallbracket. NOTE: Plasticclipwillautomaticallyfitsecureagainst
side wall.
Door Storage
Doorbinsandshelvesareprovidedforconvenientstorageofjars,bottles,andcans.
Items used often are available for quick selection.
Somemodelshaveadjustabledoorbinswhichcanbemovedtosuitindividualneeds.
Tomovethebins, remove by lifting straight up. Placethebininthe desired position
andloweroversupports.
The Dairy compartment is warmer than the general food storage section and is
intended for short term storage of cheese, spreads, or butter.
Crispers
The Crispers, located under the bottom refrigerator shelf, are designed for storing
fruits, vegetables, and other fresh produce. Wash items in clear water and remove
excesswaterbeforeplacingintheCrispers.Itemswithstrongodorsorhighmoisture
shouldbewrappedbeforestoring.
The Humidity Control (some models) allows you to adjust the humidity within the
Crisperdrawer.Thiscanextendthelifeoffreshvegetableswhichkeepbestinhigh
humidity. Leafy vegetables, however, keep best when stored with the Humidity
Control set on HIGHER, or in a drawer without a Humidity Control. This keeps
incoming air to a minimum and maintains maximum moisture content.
Crisper Cover Support (some models)
The Crisper Cover Support, located between the two Crisper drawers, is shipped
raised from the liner floor. This prevents damage to the liner floor during shipping.
Onceyour refrigeratorhasbeeninstalled in it’s finallocation,theFoot of the Crisper
Cover Support must be lowered to prevent bowing in the middle of the Crisper
Cover, when food is placed on it.
Adjusting the Foot of the Crisper Cover Support:
1. To lower theFoot, rotateitthe clockwise direction until itrestsonthelinerfloor.
2. To raise the Foot, rotate it in the counterclockwise direction.
Meat Keeper (some models)
ThetemperatureintheMeatKeeperdrawercanbemadecolderthantherestofthe
refrigerator compartment by using the adjustable air flow control. Foods can be
partially frozen and kept fresh longer than if stored on a refrigerator shelf. Before
placing food in the Meat Keeper, follow these steps:
1. Carefully handle food items with clean hands and always keep drawer clean.
2. Store meat or fish in the original wrapper. If necessary, overwrap in plastic wrap
orfoil to preventdrying.
3. Iffoodspoilageoccurs,disinfectthedrawerwithliquidchlorinebleachfollowinglabel
directions.Washwithasolutionofbakingsodaandwater.Rinsewithwateranddry.
Fresh Food Storage
Crisper Cover Support
FRESH FRUITS & VEGETABLES
LOWER
FRUITS
HIGHER
HUMIDITY CONTROL
VEGETABLES
Adjustable Humidity Control

8
Care and Cleaning
Damp objects stick to cold
metalsurfaces.Donottouchrefrigerated
surfaces with wet or damp hands.
G05D0008
To avoid damage and help
the refrigerator run as efficiently as
possible, clean the condenser
periodically.
Keepyourrefrigeratorandfreezercleantopreventodorbuild-up.Wipeupanyspills
immediately and clean both sections at least twice a year. Never use metallic
scouringpads,brushes,abrasivecleanersorstrongalkalinesolutionsonanysurface.
Do not wash any removable parts in a dishwasher.
Alwaysunplugthepowercordfromthewalloutletbeforecleaning. Turning
the control to OFF does not disconnect power to the controls, light bulb, or other
electricalcomponents.
Inside
Washinsidesurfacesoftherefrigeratorandfreezerwithasolutionof2tablespoons
baking soda in 1 quart warm water. Rinse and dry thoroughly. Be sure to wring
excesswateroutofspongeorclothwhencleaningaroundthecontrols,light
bulb, or any electrical parts.
Washremovablepartssuchasshelvesanddrawerswithbakingsodasolutionormild
detergent and warm water. Do not use harsh cleaners on these surfaces. Rinse
anddrythoroughly.Cleanthedoorgasketswithmildsuds,rinsewithclearwaterand
wipe dry. Do not use razor blades or other sharp instruments which can scratch the
appliance surface when removing adhesive labels. Any glue left from the tape or
energy label can be removed with a mixture of warm water and mild detergent, or,
touchtheresiduewiththestickysideoftapealreadyremoved.Donot removethe
serial plate.
Outside
Washthecabinetandhandleswithwarmwaterandmildliquiddetergent.Rinsewell
and wipe dry with a clean soft cloth.
Whenmovingtherefrigerator,pullstraightout.Donotshifttherefrigeratorfromsideto
sideasthismaytearorgougethefloorcovering.Iftherefrigeratorhasanautomaticice
maker, be careful not to move the refrigerator beyond plumbing connections.
Periodically clean the condenser (black tubes and wires on the back of the
refrigerator). Using a vacuum with its dusting tool attachment, vacuum the coils to
removedustbuild-up.Donotallowlintordusttoaccumulateonthecoils.Thedefrost
waterpanislocatedat the bottom rearoftherefrigeratorontopofthe compressor
(shownleft).Thepan shouldbecleanedperiodically.Wipecleanwith adampcloth.
Replacing the Light Bulb
To replace the light bulb:
1. Unplugtherefrigerator.
2. Wear gloves as protection against possible broken glass.
3. Replace old bulb with an appliance bulb of the same wattage.
4. Remember to plug the refrigerator back in.
Vacation and Moving Tips
Shortvacations: Leavetherefrigeratoroperatingduringvacationsof1to3weeks.
Useupallperishableitemsfromtherefrigeratorsection.Wrapandstoreotheritems
inthefreezer.If theunithasanautomatic icemaker,turnofftheice maker,even
if you will be gone just a few days.
Longvacations: Removeallfoodandiceifyouwillbegone1monthormore.Turn
thecontroltoOFFanddisconnectthepower.Iftheunithasanautomaticicemaker,
turnofftheicemakerandturnthewatersupplyvalvetotheclosedposition.Defrost
andcleantheinteriorthoroughly.Leavebothdoorsopentopreventodorandmold
buildup. Block open if necessary.
Moving: Whenmovingthe refrigerator, follow these guidelines topreventdamage:
• Remove all food and other items from both the refrigerator and freezer
compartments. Empty the ice storage bin. Defrost and clean the interior
thoroughly.
• If a hand truck is used in moving, load the refrigerator from the side.
• Turn rollers as far up as possible. This will protect them during sliding or
moving.
• The cabinet should be well padded and handled with care. Do not drop.

9
G05U0016
Automatic Ice Maker If your refrigerator has an automatic ice maker, it will provide a continuous supply
of ice for normal use. The automatic ice maker is an optional accessory which may
be installed in most models at any time. Call your local dealer for installation.
Aftertheplumbingconnectionshavebeencompleted,thewatersupplyvalvemust
be opened. Place the ice container under ice maker, pushing it as far back as
possible. Lower the wire signal arm to its "down" or ON position. Because of new
plumbing connections, the first production of ice cubes may be discolored or have
anoddflavor.Throwtheiceawayuntilthecubesmadearefreeofdiscolorationand
taste. Remember, water quality determines your ice quality. It is
besttoconnecticemakertowaterthatisNOTsoft. Softeningchemicalscandamage
icemaker. Ificemakerisconnectedtosoftwater,ensuresoftenerismaintained,and
workingproperly.
To stop the ice maker, lift the wire signal arm until it clicks and locks in the "up"
orOFFposition.Theicemakerturnsoffautomaticallywhentheicecontainerisfull.
If your model has an adjustable freezer shelf, place the shelf so the wire signal arm
will hit the ice when the ice container is full.
Ice Maker Tips
1. Icestoredtoolongmaydevelopanoddflavor. Emptycontainerandbesurewire
signalarmisinits"down"orONposition.Theicemakerwillthenproducemore
ice.
2. Occasionally shake the container to keep ice separated.
3. Keep the wire signal arm in its "up" or OFF position until the refrigerator is
connected to the water supply or whenever water supply is turned off.
4. Certain sounds are normal when the ice maker is operating. They are:
Motoroperation
Ice being loosened from the tray
Ice being dropped into the container
Runningwater
Water valve opening and closing
For more information on these operations, see "Normal Operating Sounds."
5. Wash ice container in warm water with mild detergent. Rinse well and dry.
6. Stop the ice maker when cleaning the freezer or for short vacations.
7. Iftheicemakerwillbeturnedoffforalongperiodoftime,turnthewatersupply
valve to the closed position.

10
Door Reversal
Instructions
1. Refer to the Toe
Grille Instructions
on page 13 to
remove the Toe
Grille (some
models). Snap off
hinge cover at top
of cabinet (some
models). With the
freezer door closed,
remove the two
screws attaching
upper hinge to
cabinet. Lift the
hinge up and off. Be sure to save screws and hinge for
reassembly later.
2. Open the freezer
door enough to
allow it to be lifted
off the center hinge.
3. With the refrigera-
tor door closed,
remove center hinge
pin. (Note the ar-
rangementoftheup-
per and lower wash-
ers (some models) on
the hinge pin. The
washers must be re-
assembled later in
the same manner.)
Open refrigerator
door enough to al-
low door to be lifted
off the lower hinge. Remove the two screws attaching the center
hinge. The third outermost screw under the center hinge should
be left in place. Save hinge, pin, and washers (some
models) for reassembly later. Reinstall screws in original
holes.
Yourrefrigeratorisequippedwithreversibledoorhinges.Hingingofthedoorcanbe
changedtotheoppositesideanytimeyouwish.Anenvelopecontainingextraplastic
holeplugsisincludedinsomemodels.Turntherefrigeratorcontrolto OFF. Remove
all food, bottles, and other items from the door. Begin with freezer door.
Completely remove one door before beginning the other.
4. Remove hinge
pin, hinge, and the
two screws
attaching the lower
hinge. Save the
hinge, hinge pin,
washer (some
models) and
screws for
reassembly later.
or
5. Carefully
remove the hole
plugs from the
hinge holes in the
center mullion and
top of cabinet and
reinstall in the
opposite set of
holes.
