Gibson GWT445RGS2 User manual

PRODUCT NO. BASE MODEL NO. COLOR
GWT445RGS2 GWT445RG White
Publication No.
5995331682
000112
ENG/SERVICE/JAB
361
WASHER
Model No.
GWT445RG
©1997White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
WASHER
WIRING DIAGRAM - # 131788100
OWNER’S GUIDE - # 131627600
6000 Perimeter Drive
Dublin, OH 43017

01/2000 2
Publication No. GWT445RGS2
5995331682 CONTROL PANEL

# = Functional Part 3 01/2000
* = Non-Illustrated Part
GWT445RGS2 Publication No.
5995331682
POS. NO PART NO DESCRIPTION
1 131272100 Cover-bleach
2 131272000 Cover-softener
3 131271900 Drawer-dispenser
4 131271300 Pin
5 131271200 Spring
6 131374500 Latch-handle
7 131427500 Spring
8 131373800 Magnet
9 131691201 Handle-white
12 # 131505900 Switch-reed
13 131729000 Switch-water temp
14 # 131048300 Buzzer
15 131243200 Switch-temp
16 131349000 Light-pilot
17 # 131273700 Switch-pressure
18 131800500 Timer-washer F/L
19 131670300 Screw-timer, 10-32 x 0.245, quadrex ph
21 131243700 Screw, pan head, 8-18AB x 0.375,
cr/sq drive
23 131270200 Lever-cam
24 131856300 Cam-timer
25 131271400 Rod
26 131205100 Screw, #8 pan head, 10-10B x 0.50,
cr/sq drive
27 131691008 Assy-cons frame/trimGBH7DRDN
29 131761707 Knob-rotary wht/cranberry
30 131446202 Asmy-timer knob white
31 131716306 Pointer-timer-wht/cranberry
32 131272400 Hose-siphon/fill
33 131306215 Clamp
34 131465200 Arm-pivot
35 131271500 Disp-eccentric
36 131270300 Assy-detergent dispenser, includes #1, 2,
3, 4, 5, 35, and 37
37 131271600 Hose-tub
39 131272300 Duct-fill
42 131168200 Screw, 8-18 x 0.31
43 131749200 Gasket-seal
45 5303321107 Bushing
46 131730600 Bracket-control
53 131269601 Lens-pilot light
* 131785900 Harness, TAW, rot 850 rpm
* 131307900 Clamp
CONTROL PANEL

01/2000 4
Publication No. GWT445RGS2
5995331682 CABINET,DOOR &TOP

# = Functional Part 5 01/2000
* = Non-Illustrated Part
GWT445RGS2 Publication No.
5995331682
CABINET,DOOR &TOP
POS. NO PART NO DESCRIPTION
1 131279602 Asmy-inlet hose cold
2 131168200 Screw, 8-18 x 0.31
3 131279603 Asmy-inlet hose-hot
4 131725300 Control Speed
5 131268900 Box-control
6 131304300 Washer .21 x .71 x .06
7 131205300 Screw-door, 10-16 x .75
8 131763200 Door lock/switch USCC
9 131303300 Screw-lock, ph ab,10-16 x .50
10 131278700 Door-outer
11 131278800 Glass-door
12 131278900 Door-inner
13 131302901 Screw, 10-16 x .75
14 131763300 Catch-interior door frame
15 131269300 Hinge-door
16 131696300 Screw 10-16 x .312 quad pn hd
17 131346400 Pin-locating
18 131279300 Panel-service white
19 131358400 Screw-panel, hwhd ab, 8-18 x 1.125
20 131460900 Bracket-top front
21 131243700 Screw, pan head, 8-18AB x 0.375,
cr/sq drive
22 131279500 Retainer-spring
23 131243800 Screw-brkt top, pan hd locking,
8-32CA x 0.375, cr/sq drive
24 131677308 Panel-top
25 131668200 Bracket-top pnl
26 131311900 Screw, quadrex ph ab, 8-18 x 1/2
28 131734800 Panel-back
31 5303208765 Cord-service
32 5303209428 Bushing-cord
33 # 5303207418 Valve-water
35 131732900 Back reinforcement
36 131003900 Leg,pad/nut
37 131304200 Roller Assy
44 131707800 Ring-drain hose
45 # 131461200 Hose-drain, 90 inch
* 131453001 Bushing-top panel

01/2000 6
Publication No. GWT445RGS2
5995331682 TUB & MOTOR

# = Functional Part 7 01/2000
* = Non-Illustrated Part
GWT445RGS2 Publication No.
5995331682
TUB & MOTOR
POS. NO PART NO DESCRIPTION
1 131793400 Ring-weight
2 131793301 Bolt-carriage 1/4-20 x 4.5
3 131793300 Bolt-carriage 1/4-20 x 4.15
4 131276500 Weight-lwr left
5 131276600 Weight-top front
6 131851900 Counterweight-lower right
7 131277300 Spring-boot
8 131277100 Bellows
10 131304700 Nut
11 131276900 Washer-spring
12 131793500 Plate-weight
13 131618600 Shell-front tub
14 131663600 Spring/sleeve
15 131303900 Screw, hxwhd a, 1/4-10 x 2.165
16 131618500 Tub-spin
17 131274600 Vane
18 131302800 Screw-vane, quad ph ab, 10-16 x .375
19 # 131276200 Motor-main, 850
20 131303500 Screw-motor, hwhd ab, 12-14 x 1.50
21 131275900 Seal-shell
22 131462800 Shell-rear/bearing
23 131709300 Weight-upper back
25 # 131276300 Belt
26 # 131632500 Pulley-drum
27 131304400 Washer .41 x 1.500 x .120
28 131304500 Washer-lock 3/8
29 131303700 Screw-pulley, m10 x .92
30 131268200 Level-shock
31 131268300 Pin-level
32 131268100 Bracket-shock
33 131303100 Screw-bracket, hwhd ab, 10-16 x .625
34 131304300 Washer .21 x .71 x .06
35 131723500 Pump-drain
41 131784700 Hose-coin trap-tub to pump
42 131333101 Clamp
43 131277500 Chamber-air
44 131277600 Tube-pressure
45 131306202 Clamp
48 131306234 Clamp-pump
65 131702200 Shield-motor
* 131560000 Sleeve-lower spring, tub
* 131592200 Sleeve-upper spring, tub

01/2000 8
Publication No. GWT445RGS2
5995331682 WIRING DIAGRAM
