GIESELER Kompakt User manual

GIESELER Kompakt DAC
Wolfson Chipset
User Manual - Version 1
Welcome to the club.

Introduction
Thank you for purchasing the Gieseler Kompakt DAC. This is a new base model but aimed
at maximum sound fidelity, and is a quality Australian made product that includes a full
two year parts and labor warranty. All parts are sourced from quality suppliers such as
Element14 and RS Components. Maximum sound quality is obtained via the USB input of
the DAC, however, the S/PDIF section is also very good and has been upgraded over
previous models. Microsoft Windows based music servers will require an additional driver
to be installed for use, however this is not necessary for Mac and Linux systems. The unit
runs remains fairly cool during operation, but warms during extended use; this is expected
and poses no problems. Upon power up of the device, automatic muting will ensue for up
to thirty seconds to ensure a silent start. Sound quality will optimize after one hundred
hours of use as electronic components are 'run in'. Please note it is normal to hear a click
through your speaker when switching between unconnected inputs.
Contents
▪Gieseler Kompakt DAC
▪9 Volt AC Plug Pack
Features
▪Asynchronous USB Input
▪Optical S/PDIF Input
▪Coaxial S/PDIF Input
▪Linear IE Core external transformer
▪Multiple low noise internal power supplies
▪DSD 64 direct auto mode
Specifications
Bit rate maximum
192 kHz
Bits per sample
32
Output impedance
600 Ω
Output voltage
2.0 v RMS
Power supply
9v AC 2.0 A Linear IE Core Transformer (Australian 240 v)
Power consumption
2.25 W
PCM 192k max on Coax & USB
PCM 96K max on Optical
DSD 64 via USB

Key Components
▪Amanero Technologies Combo 384 USB Input Module - Asynchronous Mode
▪AKM AK4118A S/PDIF Receiver
▪Wolfson WM8741 DAC Chip
▪Nichicon Gold Tune main filter capacitors
▪Choke filtered internal pre-regulation power supply
USB Input Driver
Note: Mac and Linux systems do not require any third-party drivers.
If connecting to a Windows based server, you will need to download the appropriate driver
from the Amanero Technologies website and install it on the music server.
http://amanero.com/drivers.htm
Filter Selection
Filter
A Switch Analogue - filter
Off
Up
On -3db 50k
Down
Filter
B Switch Digital - filter
Sharp
Up
Delay Slow
Mid
Slow
Down
default configuration both down

Usage
1. Power toggle switch and indicator LED
ON (down position) and OFF (up position)
2. Filter switches, see Filter Selection
3. Input toggle switch (Coaxial, Optical, and USB)
1. Coax input
2. Optical input
3. USB input
4. XLR outputs
5. RCA outputs
Connect output labeled R to the right side of the sound system when facing the
FRONT of the DAC and the L output to the left side.
6. RCA ground switch
Typical usage (and required for XLR output) –turn off.
If experiencing any audible hum when using the RCA outputs - turn on.
7. Power Input
