GIGA-BYTE TECHNOLOGY M27U User manual

Copyright
© 2022 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their
respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the
property of GIGABYTE.
Changes to the specifications and features in this manual may be made by
GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated,
transmitted, or published in any form or by any means without GIGABYTE’s
prior written permission.
• In order to assist in the use of this monitor, carefully read the User
Guide
• For more information, check on our website at:
https://www.gigabyte.com
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc. in the United States and other countries.
2022 – 05
Rev. A00

SAFETY PRECAUTIONS
Safety Precautions
Read through the following Safety Precautions before using the
monitor.
• Only use the accessories that are provided with the monitor or that
which are recommended by the manufacturer.
• Keep the plastic packaging bag for the product in a place that cannot
be reached by children.
• Before connecting the monitor to the power outlet, make sure that
the voltage rating of the power cable is compatible with the power
specification in the country where you are located.
• The power cord plug must be connected to a properly wired and
grounded power outlet.
• Do not touch the plug with wet hands, otherwise easily cause electric
shock.
• Place the monitor in a stable and well-ventilated place.
• Do not place the monitor near any heat sources such as electric
radiators or direct sunlight.
• The holes or openings on the monitor are for ventilation. Do not
cover or block the ventilation holes with any objects.
• Do not use the monitor near water, drinks, or all types of liquids.
Failure to do so may result in electric shock or damage to the
monitor.
• Make sure to unplug the monitor from the power outlet before
cleaning.
• As the screen surface is easy to be scratched, avoid touching
the surface with any hard or sharp object.
• Use a soft lint-free cloth instead of a tissue to wipe the screen. You
may use a glass cleaner to clean the monitor if required.
However, never spray the cleaner directly onto the screen.
• Disconnect the power cable if the monitor is not being used for a
long period of time.
• Do not attempt to disassemble or repair the monitor yourself.

Stability Hazard Precautions
The product may fall, causing serious personal injury or death. To
prevent injury, this product must be securely attached to the floor/wall in
accordance with the installation instructions.
Many injuries, particularly to children, can be avoided by taking simple
precautions such as:
• ALWAYS use stands or installation methods recommended by the
manufacturer of the product set.
• ALWAYS use furniture that can safely support the product.
• ALWAYS ensure the product is not overhanging the edge of the
supporting furniture.
• ALWAYS educate children about the dangers of climbing on furniture
to reach the product or its controls.
• ALWAYS route cords and cables connected to your product so they
cannot be tripped over, pulled or grabbed.
• NEVER place a product in an unstable location.
• NEVER place the product on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the product to
a suitable support.
• NEVER place the product on cloth or other materials that may be
located between the product and supporting furniture.
• NEVER place items that might tempt children to climb, such as toys
and remote controls, on the top of the product or furniture on which
the product is placed.
• If the existing product is going to be retained and relocated, the
same considerations as above should be applied.
• To prevent personal injury or damage to the product caused by
tipping over due to earthquakes or other shocks, make sure to install
the product in a stable location and take measures to prevent falling.

Gaming Monitor U
ser Guide
- Contents5 -
Contents
SAFETY PRECAUTIONS ...........................................3
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Stability Hazard Precautions. . . . . . . . . . . . . . . . . . . . . . . . . .4
INTRODUCTION .................................................6
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
GETTING STARTED ..............................................11
Installing the Monitor Base . . . . . . . . . . . . . . . . . . . . . . . . . 11
Adjusting the Viewing Angle . . . . . . . . . . . . . . . . . . . . . . . . 13
Installing a Wall-Mount Bracket (Optional) . . . . . . . . . . . . . . . 14
Making Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
USING THE DEVICE ..............................................16
Turning the Power On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . 16
User Comfort Recommendations . . . . . . . . . . . . . . . . . . . . . .17
Selecting the Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . 17
OPERATIONS ...................................................18
Quick Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Configure the Device Settings. . . . . . . . . . . . . . . . . . . . . . . .27
APPENDICES ...................................................37
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Supported Timing List . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Basic Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
GIGABYTE Service Information . . . . . . . . . . . . . . . . . . . . . . . 41
SAFETY INFORMATION ..........................................43
Regulatory Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

G
aming Monitor User Guide
- 6 -
INTRODUCTION
Unpacking
1. Open the upper cover of the packaging box. Then observe the
unpacking label attached on the inner cover.
2. Making sure the box is in the correct orientation, carefully lay the box
on the stable surface.
UP
3. Remove the transparent wrapper securing the EPS foams. Then
remove the items from the upper EPS foam.

Gaming Monitor U
ser Guide
- 7 -
4. Remove the upper EPS foam. Then you can remove the monitor from
the lower EPS foam.

G
aming Monitor User Guide
- 8 -
Package Contents
The following items come with your packaging box. If any of them is
missing, please contact your local dealer.
Monitor Monitor Base Power Cable
HDMI Cable USB Cable DP Cable
Multilingual
Installation
Guide
M27U
Warranty Card
Quick Start Guide Warranty Card
Note: Please keep the packaging box and packing materials for future
transportation of the monitor.

Gaming Monitor U
ser Guide
- 9 -
Product Overview
Front view
1
1Power LED

G
aming Monitor User Guide
- 10 -
Rear view
3
1 2
7
5 6 8 94
1 Control button 6USB Type-C port
2 KVM button 7Headphone jack
3 AC Power in 8USB upstream port
4 HDMI ports (x2) 9USB 3.2 ports (x3)
5 DisplayPort
Note:
The HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.
