GIGA-BYTE TECHNOLOGY MDH11BM User manual

MDH11BM
Intel®Socket LGA1151 processor motherboard
User's Manual
Rev. 1002

Copyright
©2016 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specifications and features in this manual may be made by GIGABYTE
without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
For detailed product information, carefully read the User's Manual.
For product-related information, check on our website at:
http://www.gigabyte.com

- 3 -
Table of Contents
Box Contents...................................................................................................................4
MDH11BM Motherboard Layout ......................................................................................5
Block Diagram .................................................................................................................7
Chapter 1 Hardware Installation .....................................................................................8
1-1 Installation Precautions.................................................................................... 8
1-2 ProductSpecications...................................................................................... 9
1-3 Installing the CPU and CPU Cooler ............................................................... 11
1-3-1 Installing the CPU...................................................................................................11
1-3-2 Installing the CPU Cooler .......................................................................................13
1-4 Installing the Memory..................................................................................... 14
1-4-1 Installing a Memory ...............................................................................................14
1-5 Back Panel Connectors.................................................................................. 15
1-6 Internal Connectors........................................................................................ 17
Chapter 2 BIOS Setup ..................................................................................................24
2-1 The Main Menu .............................................................................................. 26
2-2 Advanced Menu ............................................................................................. 28
2-2-1 Trusted Computing .................................................................................................29
2-2-2 SuperIOConguration...........................................................................................30
2-2-2-1 SerialPortConguration(forport#1/#2/#3#4).......................................................31
2-2-3 Hardware Monitor ..................................................................................................34
2-2-4 S5 RTC Wake Settings...........................................................................................35
2-2-5 CPUConguration..................................................................................................36
2-2-6 SATAConguration.................................................................................................39
2-2-7 OS Selection...........................................................................................................40
2-3 Chipset Menu................................................................................................. 41
2-4 Security Menu ................................................................................................ 42
2-4-1 Secure Boot menu..................................................................................................43
2-4-1-1 Key Management ...................................................................................................44
2-5 Boot Menu...................................................................................................... 45
2-6 Save & Exit Menu........................................................................................... 46
2-7 Flash Your BIOS............................................................................................. 48

- 4 -
Box Contents
Motherboard
Driver CD
 I/OShield
• Theboxcontentsaboveareforreferenceonlyandtheactualitemsshalldependontheproductpackageyouobtain.
The box contents are subject to change without notice.
• Themotherboardimageisforreferenceonly.

- 5 -
MDH11BM Motherboard Layout
21 3 4 5
18
6
7
8
9
11
10
1214 1316 15
17
20
19
21
22
23
24
25
26 27 28 29

- 6 -
Item Code Description
1 AUDIO Audio connectors
2 USB30_LAN2 RJ45LANport(top) /USB3.0ports
(buttom)
3 USB30_LAN1 RJ45LANport(top) /USB3.0ports
(buttom)
4 VGA_DVI VGAport(top)/DVI-Dport
5COM_1/HDMI Serialport(top)/HDMIport(bottom-
rightcorner)
6 SYS_FAN1 Systemfanconnector#1
7 ATX12V_2X4 8 pin power connector
8 CPU Intel LGA 1151 socket
9 CPU_FAN CPUfanconnector
10 DDR4_1 DDR4DIMMslot#1
11 DDR4_2 DDR4DIMMslot#2
12 ATX 24 pin main power connector
13 SYS_FAN2 Systemfanconnector#2
14 SATAIII_1 SATA6Gb/sconnector
15 SATAIII_3 SATA6Gb/sconnector
16 SATAIII_2 SATA6Gb/sconnector
17 SATAIII_0 SATA6Gb/sconnector
18 F_PANEL Front panel header
19 FUSB2_1 USB 2.0 header
20 FUSB2_2 USB 2.0 header
21 COM4 Serialportcableconnector#4
22 COM3 Serialportcableconnector#3
23 COM2 Serialportcableconnector#2
24 CLR_CMOS Clear CMOS header
25 F_AUDIO Front audio header
26 PCIEX1_1 PCI Express x1 slot
27 PCIEX4 PCIExpressx4slot(runningatx2)
28 PCIEX1_0 PCI Express x1 slot
29 PCIEX16 PCI Express x16 slot

- 7 -
Block Diagram

Hardware Installation
- 8 -
1-1 Installation Precautions
The motherboard contains numerous delicate electronic circuits and components which can
becomedamagedasaresultofelectrostaticdischarge(ESD).Priortoinstallation,carefullyread
theuser'smanualandfollowtheseprocedures:
• Priortoinstallation, do not removeorbreakmotherboardS/N(Serial Number) stickeror
warrantystickerprovidedbyyourdealer.Thesestickersarerequiredforwarrantyvalidation.
• AlwaysremovetheACpowerbyunpluggingthepowercordfromthepoweroutletbefore
installing or removing the motherboard or other hardware components.
• Whenconnectinghardwarecomponentstotheinternalconnectorsonthe motherboard,
make sure they are connected tightly and securely.
• Whenhandlingthemotherboard,avoidtouchinganymetalleadsorconnectors.
• Itisbesttowearanelectrostaticdischarge(ESD)wriststrapwhenhandlingelectronic
componentssuchasamotherboard,CPUormemory.IfyoudonothaveanESDwrist
strap,keepyourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.
• Priortoinstallingthemotherboard,pleasehaveitontopofanantistaticpadorwithinan
electrostatic shielding container.
• Beforeunpluggingthepowersupplycablefromthemotherboard,makesurethepower
supplyhasbeenturnedoff.
• Beforeturningonthepower,makesurethepowersupplyvoltagehasbeensetaccordingto
the local voltage standard.
• Beforeusingtheproduct,pleaseverifythatallcablesandpowerconnectorsofyour
hardware components are connected.
• Toprevent damageto themotherboard, donot allowscrews tocomein contact withthe
motherboard circuit or its components.
• Makesuretherearenoleftoverscrewsormetalcomponentsplacedonthemotherboardor
within the computer casing.
• Donotplacethecomputersystemonanunevensurface
.
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• Ifyouareuncertainaboutanyinstallationstepsorhaveaproblemrelatedtotheuseofthe
product,pleaseconsultacertiedcomputertechnician.
Chapter 1 Hardware Installation

- 9 -
Hardware Installation
1-2 ProductSpecications
CPU Supports Intel® CoreTMi7-6700 processors in Socket LGA1151
Support Up to 65W
L2/L3cachevarieswithCPU
Chipset Intel®H110 Express chipset
Memory 2 x DDR4 slots support 2133MHz
Supports Dual channel architecture
Support up to 32GB
Audio Realtek®ALC888S codec
HighDenitionAudio
7.1 channel
Onboard
Graphics
Intel®HD graphics
LAN Intel®I219LMsupports10/100/1000Mbps
RealtekRTL8111HS10/100/1000Mbps
Expansion Slots 1 x PCI Express x16 slot
1 x PCI Express x4 slot; running at x2
2 x PCI Express x1 slot
StorageInterface 4xSATA6Gb/sconnectors
USB 4xUSB3.0ports(backpanel)
Upto4USB2.0ports(viatheUSBbracketsconnectedtotheinternalUSB
headers)
Internal
Connectors
1 x 8 pin ATX 12V power connector
1 x 24 pin ATX main power connector
4xSATA6Gb/sconnectors
1xCPUfanheader
2xSystemfanheaders
3 x Serial port cable connectors
1 x Front panel header
2 x USB 2.0 headers
1 x Front audio header
Back Panel
Connectors
1 x VGA port
1 x Serial port
1 x HDMI port
1 x DVI-D port
4 x USB 3.0 ports
2 x RJ-45 ports
3 x Audio connectors
I/OController iTE IT8786E chip

Hardware Installation
- 10 -
Hardware
Monitor
System voltage detection
CPU/Systemtemperaturedetection
CPU/Systemfanspeedcontrol
  * WhethertheCPU/systemfanspeedcontrolfunctionissupportedwilldependon
theCPU/systemcooleryouinstall.
BIOS AMI BIOS
Form Factor uATX Form Factor; 9.6 inch x 9.6 inch
GIGABYTE reserves theright to make any changes to the product specications and product-related
informationwithoutpriornotice.

- 11 -
Hardware Installation
1-3 Installing the CPU and CPU Cooler
1-3-1 Installing the CPU
A. Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.
ReadthefollowingguidelinesbeforeyoubegintoinstalltheCPU:
• Make sure that the motherboard supports the CPU.
• Alwaysturnoffthecomputerandunplugthepowercordfromthepoweroutletbeforeinstalling
the CPU to prevent hardware damage.
• LocatethepinoneoftheCPU.TheCPUcannotbeinsertediforientedincorrectly.(Oryoumay
locatethenotchesonbothsidesoftheCPUandalignmentkeysontheCPUsocket.)
• ApplyanevenandthinlayerofthermalgreaseonthesurfaceoftheCPU.
• DonotturnonthecomputeriftheCPUcoolerisnotinstalled,otherwiseoverheatingand
damageoftheCPUmayoccur.
• SettheCPUhostfrequencyinaccordancewiththeCPUspecications.Itisnotrecommended
thatthesystembusfrequencybesetbeyondhardwarespecicationssinceitdoesnotmeetthe
standardrequirementsfortheperipherals.Ifyouwishtosetthefrequencybeyondthestandard
specifications,pleasedosoaccordingtoyourhardwarespecificationsincludingtheCPU,
graphicscard,memory,harddrive,etc.
Notch
Alignment KeyAlignment Key
Notch
LGA1151 CPU
LGA1151 CPU Socket
PinOneCorneroftheCPUSocket
Triangle Pin One Marking on the CPU

Hardware Installation
- 12 -
Step1:
Gently press the CPU socket lever handle down
andawayfromthesocketwithyournger.Then
completelylifttheCPUsocketleverandthemetal
loadplatewillbeliftedaswell.
Step3:
HoldtheCPUwithyourthumbandindexngers.
AligntheCPUpinonemarking(triangle)withthe
pinone corner oftheCPU socket (oryoumay
align the CPU notches with the socket alignment
keys)andgentlyinserttheCPUintoposition.
Step5:
Push the CPU socket lever back into its locked
position.
Step4:
OncetheCPUisproperlyinserted,useone
hand to hold the socket lever and use the other
to lightly replace the load plate. When replacing
theloadplate,makesurethefrontendofthe
load plate is under the shoulder screw.
NOTE:
HoldtheCPUsocketleverbythehandle,notthe
lever base portion.
Step2:
Remove the CPU socket cover as shown. Hold
yourindexfingerdownonthereargripofthe
socketcover anduse yourthumb tolift upthe
frontedge(nexttothe"REMOVE"mark)and
thenremove the cover. (DO NOTtouch socket
contacts.ToprotecttheCPUsocket,always
replace the protective socket cover when the
CPUisnotinstalled.)
B. Follow the steps below to correctly install the CPU into the motherboard CPU socket.
Before installing the CPU, make sure to turn off the computer and unplug the power cord from
the power outlet power plug to prevent any damage to prevent damage to the CPU.

- 13 -
Hardware Installation
1-3-2 Installing the CPU Cooler
FollowthestepsbelowtocorrectlyinstalltheCPUcooleronthemotherboard.(Thefollowingprocedureuses
Intel®boxedcoolerastheexamplecooler.)
UseextremecarewhenremovingtheCPUcoolerbecausethethermalgrease/tapebetweenthe
CPU cooler and CPU may adhere to the CPU. Inadequately removing the CPU cooler may damage
the CPU.
Step1:
Applyanevenandthinlayerofthermalpasteon
thesurfaceoftheinstalledCPU.
Male Push
Pin
Female
Push Pin
The Top
ofFemale
Push Pin
Directionofthe
Arrow Sign on
the Male Push
Pin
Step2:
Beforeinstallingthecooler,notethedirectionof
the arrow sign onthemalepushpin.(Turning
thepush pinalong thedirection ofthe arrowis
forremovingthecooler,andtheopposite
directionisforinstallingit..)
Step3:
PlacethecooleratoptheCPU,aligningthe
fourpushpinsthroughthepinholesonthe
motherboard. Push down on the push pins
diagonally.
Step4:
Youshouldheara"click"whenpushingdown
each push pin. Check that the Male and Female
pushpinsarejoinedclosely.(RefertoyourCPU
coolerinstallationmanualforinstructionson
installingthecooler.)
Step5:
Aftertheinstallation,checkthebackofthe
motherboard.If thepush pinis insertedasthe
pictureaboveshows,theinstallationiscomplete.
Step6:
Finally,attach thepower connector of the CPU
coolertotheCPUfanheader(CPU_FAN)onthe
motherboard.

Hardware Installation
- 14 -
1-4 Installing the Memory
Readthefollowingguidelinesbeforeyoubegintoinstallthememory:
• Makesurethatthemotherboardsupportsthememory.Itisrecommendedthatmemoryofthe
samecapacity,brand,speed,andchipsbeused.
• Alwaysturnoffthecomputerandunplugthepowercordfromthepoweroutletbeforeinstalling
the memory to prevent hardware damage.
• Memorymoduleshaveafoolproofdesign.Amemorymodulecanbeinstalledinonlyone
direction.Ifyouareunabletoinsertthememory,switchthedirection.
1-4-1 Installing a Memory
Before installing a memory module, make sure to turn off the computer and unplug the power
cord from the power outlet to prevent damage to the memory module.
Be sure to install DDR4 DIMMs on this motherboard.
Installation Step:
Step1. InserttheDIMMmemorymoduleverticallyintotheDIMMslot,andpushitdown.
Step2. ClosetheplasticclipatbothedgesoftheDIMMslotstolocktheDIMMmodule.
Note: Fordual-channeloperation,DIMMsmustbeinstalledinmatchedpairs.
Step 3. Reverse the installation steps when you wish to remove the DIMM module.
2
2
1

- 15 -
Hardware Installation
1-5 Back Panel Connectors
Serial Port
Connects to serial-based mouse or data processing devices.
HDMI Port
TheHDMI(High-DenitionMultimediaInterface)providesanall-digitalaudio/videointerfaceto
transmittheuncompressedaudio/videosignalsandisHDCPcompliant.ConnecttheHDMI
audio/videodevicetothisport.TheHDMITechnologycansupportamaximumresolutionof
1920x1080p but the actual resolutions supported depend on the monitor being used.
Video Port
Thevideoinportallowsconnecttovideoin,whichcanalsoapplytovideoloopthrufunction.
DVI-D Port
TheDVI-DportsupportsDVI-Dspecictation.ConnectamonitorthatsupportsDVI-Dconnectiontothis
port.
RJ-45 LAN Port
TheGigabitEthernetLANportprovidesInternet connectionatupto1Gbps datarate.Thefollowing
describesthestatesoftheLANportLEDs.
USB 3.0 Port
TheUSBportsupportstheUSB3.0specification.UsethisportforUSBdevicessuchasaUSB
keyboard/mouse,USBprinter,USBashdriveandetc.
Line In Jack (Blue)
Thedefaultlineinjack.Usethisaudiojackforlineindevicessuchasanopticaldrive,walkman,etc.
Line Out Jack (Green)
Thedefaultlineoutjack.Usethisaudiojackforaheadphoneor2-channelspeaker.Thisjackcanbe
usedtoconnectfrontspeakersina4/5.1/7.1-channelaudioconguration.
MIC In (Pink)
ThedefaultMICInjack.MicrophonecabbeconnectedtoMICInjack.
• WhenAfterinstallingtheHDMIdevice,makesurethedefaultdeviceforsoundplaybackisthe
 HDMIdevice.(Theitemnamemaydifferbyoperatingsystem.Refertheguresbelow
 fordetails.),andenterBIOSSetup,thensetOnboardVGAoutputconnecttoD-SUB/
HDMI under Advanced BIOS Features..
• PleasenotetheHDMIaudiooutputonlysupportsAC3,DTSand2-channel-LPCM
 formats.(AC3andDTSrequiretheuseofanexternaldecoderfordecoding.)

Hardware Installation
- 16 -
• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour
deviceandthenremoveitfromthemotherboard.
• Whenremovingthecable,pullitstraightoutfromtheconnector.Donotrockitsidetosideto
prevent an electrical short inside the cable connector.
Activity LED
Connection/
Speed LED
LAN Port
ActivityLED:Connection/SpeedLED:
State Description
Orange 1 Gbps data rate
Green 100 Mbps data rate
Off 10 Mbps data rate
State Description
Blinking Data transmission or receiving is occurring
Off No data transmission or receiving is occurring

- 17 -
Hardware Installation
1-6 Internal Connectors
1) ATX
2) ATX12V_2X4
3) SATAIII_0/1/2/3
4) CPU_FAN
5) SYS_FAN1
6) SYS_FAN2
7) FUSB2_1
8) FUSB2_2
9) COM4
10) COM3
11) COM2
12) F_AUDIO
13) F_PANEL
14) BAT
15) CLR_CMOS
2
13
4
5
6
7
8
9
11
10
12
15
14
13
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Beforeinstallingthedevices,besuretoturnoffthedevicesandyourcomputer.Unplugthepower
cordfromthepoweroutlettopreventdamagetothedevices.
• Afterinstallingthedeviceandbeforeturningonthecomputer,makesurethedevicecablehas
been securely attached to the connector on the motherboard.

Hardware Installation
- 18 -
1/2) ATX/ATX12V_2X4 (2x4 12V Power Connector and 2x12 Main Power Connector)
 Withtheuseofthepowerconnector,thepowersupplycansupplyenoughstablepowertoallthe
componentsonthemotherboard.Before connectingthe powerconnector, rstmake surethepower
supplyisturnedoffandalldevicesareproperlyinstalled.Thepowerconnectorpossessesafoolproof
design. Connect the power supply cable to the power connector in the correct orientation. The 12V
powerconnectormainlysuppliespowertotheCPU.Ifthe12Vpowerconnectorisnotconnected,the
computer will not start.
Tomeet expansionrequirements, it isrecommended that apower supply thatcan withstand high
powerconsumptionbeused(500Worgreater).Ifapowersupplyisusedthatdoesnotprovidethe
requiredpower,theresultcanleadtoanunstableorunbootablesystem.
12
24
1
13
ATX
ATX12V_2X4
F_PANEL
F_PANEL
F_AUDIO
F_AUDIO
F_USB
COMB
MODEM
Smart Card Reader
SPDIF
AUX_IN
CD_IN
Secure Gigital /
Memory Stick
Serial ATA
F_USB
F_1394
CPU_FAN
SYS_FAN
PWR_FAN
NB_FAN
Power
WOL
SUR_CEN
IR/CIR
F_PANEL
F_PANEL
PWR_LED
CLR_CMOS
BIOS_WP
CLR_CMOS
BIOS_WP
CI
DPVRM
CLR_PWD
FDD
ATX
ATX_12V
IDE
IR
COMB
SPDIF_IO
F1_1394 F2_1394
GAME SMB_CONN F_AUDIO
(NEW)
F1_1394
PinNo. Denition
13 3.3V
14 -12V
15 GND
16 PS_ON
17 GND
18 GND
19 GND
20 NA
21 +5V
22 +5V
23 +5V
24 GND
PinNo. Denition
1 3.3V
2 3.3V
3 GND
4 +5V
5 GND
6 +5V
7 GND
8 Power OK
 9 5VSB(standby+5V)
10 +12V
11 +12V
12 3.3V
DEBUG
PORT
G.QBOFM
8
5
4
1
PinNo. Denition
1 GND
2 GND
3 GND
4 GND
5 +12V
6 +12V
7 +12V
8 +12V

- 19 -
Hardware Installation
3) SATA1/SATA2 (SATA 6Gb/s Connectors)
TheSATAconnectorsconformtoSATA6Gb/sstandardandarecompatiblewith
 SATA3Gb/sstandard.EachSATAconnectorsupportsasingleSATAdevice.
SATAIII_1
SATAIII_3
SATAIII_0
SATAIII_2
7
1
DEBUG
PORT
G.QBOFM
1
7
DEBUG
PORT
G.QBOFM
SATAIII_1
SATAIII_3
SATAIII_0
SATAIII_2
PinNo. Denition
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
4/5/6) CPU_FAN/SYS_FAN0/SYS_FAN1 (CPU Fan/System Fan Headers)
Themotherboard has one4-pinCPU fan header (CPU_FAN),andtwo 4-pin (SYS_FAN) system fan
headers.Mostfanheaderspossessafoolproofinsertiondesign.Whenconnectingafancable,besure
toconnectitinthecorrectorientation(theblackconnectorwireisthegroundwire).Themotherboard
supportsCPUfanspeedcontrol,whichrequirestheuseofaCPUfanwithfanspeedcontroldesign.For
optimumheatdissipation,itisrecommendedthatasystemfanbeinstalledinsidethechassis.
1
DEBUG
PORT
G.QBOFM
1
DEBUG
PORT
G.QBOFM
PinNo. Denition
1 GND
2 +12V
3 Sense
4 Speed Control
CPU_FAN
SYS_FAN1
SYS_FAN2
• BesuretoconnectfancablestothefanheaderstopreventyourCPUandsystemfrom
overheating. Overheating may result in damage to the CPU or the system may hang.
• Thesefanheadersarenotcongurationjumperblocks.Donotplaceajumpercapontheheaders.

Hardware Installation
- 20 -
7/8) F_USB1/F_USB2 (USB 2.0 Headers)
 Theheaders conform to USB 2.0 specication. Each USBheader can provide two USB ports via an
optionalUSBbracket.ForpurchasingtheoptionalUSBbracket,pleasecontactthelocaldealer.
F_PANEL
F_PANEL
F_AUDIO
F_AUDIO
F_USB
COMB
MODEM
Smart Card Reader
SPDIF
AUX_IN
CD_IN
Secure Gigital /
Memory Stick
Serial ATA
F_USB
F_1394
CPU_FAN
SYS_FAN
PWR_FAN
NB_FAN
Power
WOL
SUR_CEN
IR/CIR
F_PANEL
F_PANEL
PWR_LED
CLR_CMOS
BIOS_WP
CLR_CMOS
BIOS_WP
CI
DPVRM
CLR_PWD
FDD
ATX
ATX_12V
IDE
IR
COMB
SPDIF_IO
F1_1394 F2_1394
GAME SMB_CONN F_AUDIO
(NEW)
F1_1394
1
9
2
10
FUSB2_2
FUSB2_1
F_USB3
PinNo. Denition
 1 Power(5V)
 2 Power(5V)
3 USB DX-
4 USB DY-
5 USB DX+
6 USB DY+
7 GND
8 GND
9 No Pin
10 NC
