Gigabyte A963 Series User manual

1
A963 Series User’s Manual
Federal Communications Commission (FCC) Statement .................. 2
Important Safety Information .............................................................. 3
WEEE-Consummer Notice ................................................................. 5
Chapter One Getting started
Packing Checklist ......................................................................... 6
Features at a Glance ..................................................................... 7
Chapter Two Installation
Upload Case .................................................................................. 9
Installing Hard Disk ........................................................................ 10
Installing Optical Disk Drive ........................................................... 11
Installing CPU ................................................................................ 12
Installing Memory .......................................................................... 13
Installing Mini PCI Video Capture Card ......................................... 14
Stealthed USB Device Door ......................................................... 15
Chapter Three Specification
Specification .................................................................................. 16
Appendix A Cleaning and Maintance ........................................... 17
Appendix B Service Center .......................................................... 18

2A963 Series User’s Manual
Federal Communications Commission (FCC)
Statement
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order to meet FCC
emission limits. Neither the provider nor the manufacturer are responsible for any radio or
television interference caused by using other than recommended cables and connectors
or by unauthorized changes or modifications to this equipment. Unauthorized changes or
modifications could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult a dealer or experienced TV/radio technician for help.
Properly shielded and grounded cables and connectors must be used in order to meet FCC
emission limits. Neither the Dealer nor the Manufacturer are responsible for any radio or
television interference caused by using other than recommended cables and connectors

3
A963 Series User’s Manual
or by unauthorized changes or modifications to this equipment. Unauthorized changes
or modifications could void the user’s authority to operate the equipment.
Important safety information
Read and follow all instructions marked on the product and in the documentation before
you operate your system. Retain all safety and operating instructions for future use.
• The product should be operated only from the type of power source indicated on the
rating label.
• If your computer has a voltage selector switch, make sure that the switch is in the
proper position for your area. The voltage selector switch is set at the factory to the
correct voltage.
• The plug-socket combination must be accessible at all times because it serves as
the main disconnecting device.
• Use only the power cord and batteries indicated in this manual. Do not dispose
of batteries in a fire. They may explode. Check with codes for possible special
disposal instructions.
• Do not use this product near water or a heat source.
• Set up the product on a stable work surface or so as to ensure stability of the
system.
• Openings in the case are provided for ventilation. Do not block or cover these
openings. Make sure you provide adequate space around the system for ventilation
when you set up your work area. Never insert objects of any kind into the ventilation
openings.
• To avoid electrical shock, always unplug all power cables and modem cables from
the wall outlets before removing covers.
• Allow the product to cool before removing covers or touching internal components.
Battery safety information
Do not disassemble, incinerate, or short-circuit the rechargeable battery
pack (in the battery pack bay). Do not put it in trash that is disposed of in
landfills. Dispose of it as required by local ordinances or regulations.
CAUTION:
• The lithium battery on the system board of the computer contains lithium and
can explode if not properly used, handled, or disposed of. Do not: (1) throw or
immerse into water, (2) heat to more than 100 deg C (212 deg F), or (3) repair or

4A963 Series User’s Manual
disassemble. Dispose of it as required by local ordinances or regulations.
• Do not disassemble, incinerate, or short-circuit the nickel metal hydride rechargeable
battery on the system board of the computer. The battery can cause burns or release
toxic chemicals. Do not put it in trash that is disposed of in landfills. Dispose of it as
required by local ordinances and regulations.
WARNING: Possible voiding of Warranty
* If the battery is not properly handled, there may be a risk of explosion; make sure
you are using the same or equivalent battery.
* Please dispose the used battery according to the instructions given by the
manufacturer.
Precautions for Products With Laser Devices
Observe the following precautions for laser devices:
• Do not open the CD-ROM drive, make adjustments, or perform procedures on a laser
device other than those specified in the product’s documentation.
• Only authorized service technicians should repair laser devices.
European Community Directive Conformance
Statement
This product is in conformity with the protection requirements of EC Council Low Voltage
Directive (Safety) 73/23/EEC, EMC Directive 89/336/EEC on the approximation of the laws
of the Member States relating to electro-magnetic compatibility.
European Community Directive Conformance
Statement: R&TTE Directive
This wireless LAN card has been approved in accordance with Council Decision 99/5/EC
on radio equipment and terminal telecommunication equipment (R&TTE Directive 1999/5/
EC) as per
* EN 60950-1 Safety of Information Technology equipment
* EN 300 328 Technical requirements for radio equipment
* EN 301 489 EMC requirements for radio equipment
This equipment is suitable for is suitable for use in all the European Community Member
States. Contact the corresponding government office of the respective country for current
information on possible operating restrictions.

5
A963 Series User’s Manual
WEEE-CONSUMER NOTICE:
The GIGABYTE product you have purchased is subject to Directive 2002/96/EC of the
European Parliament and the Council of the European Union on waste electrical and
electronic equipment (WEEE) and, in jurisdictions adopting that Directive, is marked as
being put on the market after August 13, 2005, and should not be disposed
of as unsorted municipal waste. Please utilize your local WEEE collection
facilities in the disposition of this product and otherwise observe all applicable
requirements.

6A963 Series User’s Manual
Packing Checklist
Carefullly unpack the A963 and check the following items are included:
Contact your dealer immediately if any items are missing,
appear damaged, or if the unit does not work.
Getting Started Getting Started
MCE USB
Receiver (Option)
Two AA Batteries for
Remote Control (Option)
Remote Control (Option)
USB to IDE Card
＊When ODD is not required.
TV-Out Cable
User’s Manual &
Utility Driver CD
Power Cord & Adapter CoolerA963
Screw Pack
＊When Barebone.

7
A963 Series User’s Manual
Getting Started Getting Started
Features at a Glance
►Front View
Power Button
LED Indicator
Optical Drive
Optical Drive
Eject Button
4-in-1 Card Slot
(Accepts SD/MMC/SM/
MS modules)
CF TYPE I
USB Port
Line Out (Audio Out
or Earphone)
Mic In
IEEE 1394 (4-pin)
Stealthed USB Port
Door ( User can plug
in USB device such as
Wireless LAN and RF
keyboard receiver.)

8A963 Series User’s Manual
Getting Started
Features at a Glance
►Rear View
TV Antenna
Power Port
LAN Port
COM Port
LPT Port
Mouse Port (PS/2)
Lock Port
Keyboard Port (PS/2)
DVI-D Port
VGA Port
USB Port
IEEE 1394 Port (6-pin)
SPDIF
TV-Out Port
HD Audio Port

9
A963 Series User’s Manual
Installation
Upload Case
►Step 1:
Remove the screw from the bottom of the case.
►Step 2:
Crasp the handle on the panel and pull out the case.

10 A963 Series User’s Manual
Installation
Installing Hard Disk
►Step 1:
Place HDD on the rack. Tighten HDD with screws.
►Step 2:
Connect HDD Power connector and cable to the HDD. Reinstall the HDD rack back
to the casing and tighten the screws.

11
A963 Series User’s Manual
Installation
Installing Optical Disk Drive
►Step 1:
Slide the optical disk drive in. Tighten the screws on the side to secure optical disk
drive.
►Step 2:
Tighten USB to IDE Card to the optial disk drive. Place the rack back and tighten the
rack to the chassis.

12 A963 Series User’s Manual
Installation
Installing CPU
►Step 1:
Place CPU in the socket and tighten screw to secure CPU. Pull up the retaining lever
on the side.
►Step 2:
Place cooler on the top of CPU and push down the retaining lever. Connect the
power.
Tighten screw
Pull up the
retaining lever

13
A963 Series User’s Manual
Installation
Installing Memory
►Step 1:
Align the connector edge of the memory module with the connector slot. Insert the
memory module at a 45 degree angle and press it down until it locks underneath the
retaining clip.

14 A963 Series User’s Manual
Installation
Installing Mini PCI Video Capture Card
►Step 1:
Align the connector edge of the mini PCI video capture card with the connector slot.
Insert the mini PCI video capture card at 45 degree angle and press it down until it
locks underneath the retaining clip.

15
A963 Series User’s Manual
Installation
Stealthed USB Device Door
A963 stealth bay cover provides superior style and visual appeal. User can easily plug in
USB device such as mp3 player, wireless LAN, or wireless RF keyboard receiver. Device
can be hidden from view when it is in use. This provides a neat and functional finish.
►Step 1:
Push open the stealth bay cover.
►Step 2:
Plug in USB device and close stealth bay cover.

16 A963 Series User’s Manual
Specification
Specification
Board GA-AI945GT-RH
CPU Intel Core Duo / Core 2 Duo (Socket M) CPU Series
DRAM SO-DIMM DDRII 667/533 (up to 2G)
HDD SATA (Support for 2.5” HDD) 40G/ 60G/ 80G/ 100G
Dimensions 213 (D) x 64 (W) x 234 (H) mm
Power Rating Delta 90W Adaptor 100-240V~1.5A 50-60Hz
Output 19V - 4.7A Operating TEMP 0°-40°
Front I/O USB 2.0 Port x 3 (including inside the front cover)/ MIC-in/
Headphone-out/ IEEE1394 (4-pin)
Rear I/O
USB2.0 Port x 2/ RJ45/ COM Port/ IEEE1394 (6-pin) /
PS/2 Port x 2 / TV Antenna/ PC audio x 6/
Printer Port/ DVI-D Port/ SPDIF out/ TV-out/ D-SUB/
Peripherals Slim Type DVD-Combo by USB 2.0 (option)
Keyboard/ Mouse (option)
Operating System Windows XP Home/ XP Professional/
Media Center Edition (Option)
A/P GBT Driver CD
Barebone System
Full System
(Video Capture Card)
User can personalize A963 by installing Video Capture Card
(Example is shown below). If you are not sure of any settings,
please contact your local dealer.

17
A963 Series User’s Manual
Appendix A Cleaning and Maintance
Taking Care of Your A963
• The openings on the enclosure are for air convection hence your notebook computer
can be protected from overheating. DO NOT COVER THE OPENINGS.
• Do not expose A963 to direct sunlight. Do not place it near sources of heat, such as a
radiator.
• Do not expose A963 to temperatures below 5ºC (41ºF) or above 40ºC (104ºF).
• Do not expose A963 to rain or moisture. Do not spill water or any liquid on A963.
• Do not subject A963 to heavy shock and vibration.
• Do not expose A963 to dust and dirt.
• Never place objects on top of A963 to avoid damaging A963.
• Never place A963 on uneven surfaces.
• Use only a power adapter approved for use with your A963.
• If A963 is not in use for a long time, disconnect it from mains to avoid possible damage
by transient overvoltage.
• Never open the body of A963. For safety reason, A963 should only be opened by
qualified service personnel.
Cleaning and Maintenance
Refer to the following to clean the A963 case.
1. Wipe off dust with a clean dampened cloth.
2. Moisten the cloth with warm water and wring the cloth out well, then wipe the case.
3. Rinse the cloth and wipe again.
Warning:
1. Be sure to turn off and unplug the A963 at least an hour before clean-ing.
2. Use only a dampened cloth when cleaning.
3. If a little water gets into the A963 interior while cleaning, leave un-plugged in a well-
ventilated room for several hours before using.
4. To prevent discoloration or fading of the case, do not use abrasive alcohol-based
cleaners

18 A963 Series User’s Manual
Appendix B Service Center
In order to serve you better, we have reorganized our Technical Support Zone
Please Visit our web site GIGABYTE Technical Service Zone for further technical
support.
Taiwan ( Headquarters ) GIGA-BYTE TECHNOLOGY CO., LTD.
Address: No.6, Bau Chiang Road, Hsin-Tien, Taipei 231, Taiwan
TEL: [phone]
FAX: [phone]
WEB Address(English): http://www.gigabyte.com.tw/
WEB Address(Traditional Chinese): http://www.gigabyte.tw/
