6VTXE
Socket 370 Processor Motherboard
USER'S MANUAL
Socket 370 Processor Motherboard
REV. 1.0 Third Edition
12ME-6VTXE-1003

How This Manual Is Organized
This manual is divided into the following sections:
1) Revision History Manual revision information
2) Item Checklist Product item list
3) Features Product information & specification
4) Hardware Setup Instructions on setting up the motherboard
5) Performance & Block Diagram Product performance & block diagram
6) BIOS Setup Instructions on setting up the BIOS
software
7) Appendix General reference

Table Of Content
Revision History P.1
Item Checklist P.2
Summary of Features P.3
6VTXE Motherboard Layout P.5
Page Index for CPU Speed Setup / Connectors / Panel and Jumper
Definition P.6
Performance List P.29
Block Diagram P.30
Memory Installation P.31
Page Index for BIOS Setup P.32
Appendix P.60

6VTXE Motherboard
1
Revision History
Revision Revision Note Date
1.0 Initial release of the 6VTXE motherboard user’s
manual. Aug. 2001
1.0 Second release of the 6VTXEmotherboard user’s
manual. Oct. 2001
1.0 Third release of the 6VTXE motherboard user’s
manual. Jan. 2002
The author assumes no responsibility for any errors or omissions that may appear in this
document nor does the author make a commitment to update the information contained herein.
Third-party brands and names are the property of their respective owners.
Please do not remove any labels on motherboard, this may void the warranty of this
motherboard.
Jan. 18, 2002 Taipei, Taiwan, R.O.C

Item Checklist
2
Item Checklist
The 6VTXE motherboard
Cable for IDE / floppy device
Diskettes or CD for motherboard driver & utility
6VTXE user’s manual

6VTXE Motherboard
3
Summary Of Features
Form Factor  30.5 cm x 18.0 cmATX size form factor, 4 layers PCB.
CPU  Socket 370 processor
Supportsall new PentiumIII processors (FC-PGA& FC-PGA2
package)
SupportsCeleron processorsin FC-PGApackage
Supports 66/100/133MHz system bus frequency
Can’t support processor with Vcore above 1.8V
 2nd cache in CPU (Depend on CPU)
Chipset  VT82C694T (VIAApollo Pro 133T)
 VT82C686B
Clock Generator  ICS 9248DF-39
 66/100/133 MHz system bus speeds (PCI 33MHz)
 75/83/112/124/140/150 MHz system bus speeds
(PCI 44MHz) (reserved)
Memory  3 168-pin DIMM sockets.
 Supports PC-100 / PC-133 SDRAM and VCM SDRAM
 Supports up to 1.5GB DRAM
 Supports only 3.3V SDRAM DIMM
 Supports 72bit ECC type DRAM integrity mode.
I/O Control  VT82C686B
Slots  1AGP slot supports 4X mode &AGP 2.0 compliant
 5 PCI slot supports 33MHz & PCI 2.2 compliant
 1AMR(Audio Modem Riser) slot
 1 16-bit ISABus slots
On-Board IDE  2 IDE bus master (UDMA33/ATA66 /ATA100 )IDE
ports for up to 4ATAPI devices
 Supports PIO mode 3, 4 (DMA33/ATA66) IDE &
ATAPI CD-ROM
On-Board
Peripherals
 1 floppy port supports 2 FDD with 360K, 720K,1.2M,
1.44M and 2.88M bytes
 1 parallel ports supports SPP/EPP/ECPmode
 2 serial ports (COMA& COM B)
 2 USB ports
 1 IrDAconnector for Fast IrDA To be continued…

Summary of Features
4
Hardware Monitor  CPU / System fan revolution detect
 CPU / System temperature detect
 System voltage detect (Vcore,Vcc3,Vcc,+12V)
 ACPI Shutdown Temperature
PS/2 Connector  PS/2Keyboard interface and PS/2Mouse interface
BIOS  LicensedAMI BIOS, 2M bit flash ROM
Additional Features  Support Wake-On-LAN (WOL)
 Support Internal / External Modem Ring On.
 Includes 3 fan power connectors. (PWR-FAN Optional)
 Poly fuse for keyboard over-current protection

6VTXE Motherboard
5
6VTXE Motherboard Layout
6VTXE
PCI1
PCI2
PGA 370 CPU
VT82C686B
VT82C694T
COMB
COMA
LPT
PS/2
BIOS
CPU_FAN
BAT1
JP2
FLOPPY
IDE2
IDE1
AGP 1
JP15
SW2
JP1
J2
SW1
J3J1
JP23
J7
J5
USB
AMR
PCI3
PCI4
PCI5
ISA 1
DIMM1
DIMM2
DIMM3
JP9
J4
JP30
BIOS_WP
GAME & AUDIO
J8
ATX POWER
S_IRQ

6VTXE Motherboard Layout
6

Page Index for CPU Speed Setup / Connectors / Panel and Jumper
Definition Page
CPU Speed Setup P.7
Connectors P.15
COM A / COM B / LPT Port P.16
Game & Audio Port (Optional) P.16
USB Connector P.17
PS/2 Keyboard &PS/2 Mouse Connector P.17
CPU Fan P.18
Power Fan (Optional) P.18
System Fan P.19
ATX Power P.19
Floppy Port P.20
IDE 1(Primary) / IDE 2(Secondary) Port P.20
J3 (Ring Power On) P.21
J1 (Wake On LAN) P.21
J4 (IR) P.22
J5 (AUX_IN)[Optional] P.22
J7 (TEL)[Optional] P.23
J8 (CD Audio Line In)[Optional] P.23
S_IRQ(Optional) P.24
Panel and Jumper Definition P.25
J2 (2x11 Pins Jumper) P.25
JP1 (Clear CMOS Function) [Optional] P.26
JP23 (Case Open) [Optional] P.26
JP9 (Onboard AC97& AMR Select)[Optional] P.27
BIOS_WP (Optional) P.27
JP30 (Over Voltage CPU Speed Up)[Optional] P.28
BAT1(Battery) P.28

6VTXE Motherboard
7
CPU Speed Setup
The system bus speed is selectable at 66,100,133MHz and Auto. The user can select the
system bus speed (SW1) and change the DIP switch (SW2) selection to set up the CPU speed
for 500 – 1G Hz processor.
Set System Bus Speed
SW1: O:ON,X : OFF
CPU (MHz) 1 2 3 4 5 6 PCI(MHz)
Auto X X X X O O 33.3
66 O O X X X X 33.3
75 O O O X X X 37.5
83 O O X O X X 41.6
100 O X X X X X 33.3
112 O X O X X X 37.3
124 X X X O X X 31
133 X X X X X X 33.3
140 X X O O X X 35
150 X X O X X X 37.5
The CPU speed must match with the frequency ratio. It will cause system hanging up if
the frequency ratio is higher than that of CPU.
SW2: DIP SWITCHFREQ. RATIO 1 2 3 4
X3 O X O O
X3.5 X X O O
X4 O O X O
X4.5 X O X O
X5 O X X O
X5.5 X X X O
X6 O O O X
X6.5 X O O X
X7 O X O X
X7.5 X X O X
X8 O O X X
X8.5 O X O O
X9 X X O O
X9.5 X O O O
X10 X O X X
X10.5 O O X O
X11 O X X X
X11.5 X O X O
X12 O X X O

CPU Speed Setup
8
X13 X X X O
X14 O O O X
X15 X O O X
X16 O X O X


For Auto Jumper Setting:
SW1
ON
1 2 3 4 5 6


Note:
1. If you use 66/100/133 MHz CPU, We recommend you to setup your system speed to
“Auto” value.
2. We don’t recommend you to set up your system speed to 75 , 83 , 112 , 124 , 140 ,150
MHz because these frequencies are not the standard specifications for CPU, Chipset
and most of the peripherals. Whether your system can run under
75 ,83 ,112 ,124 ,140 ,150 MHz properly will depend on your hardware configurations:
CPU, SDRAM, Cards, etc.
1. CeleronTM 533/66MHzFSB
SW1
ON
1 2 3 4 5 6
SW2
ON
SW2
1 2 3 4

6VTXE Motherboard
9
2. CeleronTM 566/66MHzFSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
3. CeleronTM 600/66MHzFSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
4. CeleronTM 633/66MHzFSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
5. CeleronTM 667/66MHzFSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6

CPU Speed Setup
10
6. CeleronTM 700/66MHzFSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
7. CyrixIII 550/100MHzFSB(Optional)
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
8. CyrixIII 533 /133 MHz FSB (Optional)
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
9. CyrixIII 600/133 MHz FSB (Optional)
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6

6VTXE Motherboard
11
10. CyrixIII 733/133MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
11. Cyrix III 800/133MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
12. Pentium!!! 500/100MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
13. Pentium!!! 550/100MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6

CPU Speed Setup
12
14. Pentium!!! 600/100MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
15. Pentium!!! 650/100MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
16. Pentium!!! 700/100MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
17. Pentium!!! 750/100MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6

6VTXE Motherboard
13
18. Pentium!!! 800/100MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
19. Pentium!!! 850/100MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
20. Pentium!!! 533/133MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
21. Pentium!!! 600/133 MHz FSB
SW2
ON
1 2 3 4
SW1
ON
1 2 3 4 5 6
