Gigabyte GA-7VA User manual

When you installingAGP card, please make sure the following
notice is fully understood and practiced. If yourAGP card has
"AGP 4X/8X(1.5V) notch"(show below), please make sure yourAGP
card isAGP4X/8X(1.5V).
Caution: AGP2X(3.3V) card is not supported by VIA®KT400.You
might experience system unable to boot up normally. Please insert
anAGP4X/8X(1.5V) card
Example 1: Diamond Vipper V770 golden finger is compatible with
2X/4X modeAGP slot. It can be switched betweenAGP2X(3.3V) or 4X
(1.5V) mode by adjusting the jumper. The factory default for this card is
2X(3.3V).
The GA-7VA(or anyAGP 4X only) motherboards might not function
properly, if you install this card without switching the jumper to 4X(1.5V)
mode in it.
Example 2: SomeATi Rage 128 Pro graphics cards made by “Power
Color”, the graphics card manufacturer & some SiS 305 cards, their
golden finger is compatible with 2X(3.3V)/4X(1.5V) modeAGP slot, but
they support 2X(3.3V) only. The GA-7VA(or anyAGP 4X only)
motherboards might not function properly, If you install this
card in it.
Note :Although Gigabyte'sAG32S(G) graphics card is based on
ATi Rage 128 Pro chip, the design ofAG32S(G) is compliance
withAGP 4X(1.5V) specification.Therefore, AG32S (G)will work
fine with VIA®KT400 based motherboards.
AGP 4X/8X notch

MThe author assumes no responsibility for any errors or
omissions that may appear in this document nor does the
author make a commitment to update the information contained
herein.
MThird-party brands and names are the property of their
respective owners.
MPlease do not remove any labels on motherboard, thismay void
the warranty of this motherboard.
MDue to rapid change in technology, some of the specifications
might be out of date before publication of this booklet.

Declaration of Conformity
We, Manufacturer/Importer
(full address)
G.B.T. Technology Träding GMbH
Ausschlager Weg 41, 1F, 20537 Hamburg, Germany
declare that the product
( description of the apparatus, system, installation to which it refers)
Mother Board
GA-7VA
is in conformity with
(reference to the specification under which conformity is declared)
in accordance with 89/336 EEC-EMC Directive
oEN 55011 Limits and methods of measurement
of radio disturbance characteristics of
industrial,scientific and medical (ISM
high frequency equipment
oEN 61000-3-2*
TEN 60555-2 Disturbances in supply systems cause by household appliances and similar
electrical equipment “Harmonics”
oEN 55013 Limits and methods of measurement
of radio disturbance characteristics of
broadcast receivers and associated
equipment
oEN 61000-3-3* Disturbances in supply systems cause
by household appliances and similar
electrical equipment “Voltage fluctuations”
oEN 55014 Limits and methods of measurement
of radio disturbance characteristics of
household electrical appliances,
portable tools and similar electrical
apparatus
TEN 50081-1 Generic emission standard Part 1:
Residual commercial and light industry
TEN 50082-1 Generic immunity standard Part 1:
Residual commercial and light industry
oEN 55015 Limits and methods of measurement
of radio disturbance characteristics of
fluorescent lamps and luminaries
Generic emission standard Part 2:
Industrial environment
oEN 55081-2
Immunity from radio interference of
broadcast receivers and associated
equipment
Generic emission standard Part 2:
Industrial environment
oEN 55082-2
TEN 55022 Limits and methods of measurement
of radio disturbance characteristics of
information technology equipment
lmmunity requirements for household
appliances tools and similar apparatus
oENV 55104
Cabled distribution systems; Equipment
for receiving and/or distribution from
sound and television signals
EMC requirements for uninterruptible
power systems (UPS)
oEN50091-2
oEN 55020
oDIN VDE 0855
opart 10
opart 12
(EC conformity marking)
TCE marking
The manufacturer also declares the conformity of above mentioned product
with the actual required safety standards in accordance with LVD 73/23 EEC
Safety requirements for mains operated
electronic and related apparatus for
household and similar general use
oEN 60950
oEN 60065
Safety of household and similar
electrical appliances
oEN 60335
Manufacturer/Importer
Signature:
Name:
(Stamp) Date : September 16, 2002
TEN 60555-3
Timmy Huang
oEN 50091-1
Timmy Huang
Safety for information technology equipment
including electrical bussiness equipment
General and Safety requirments for
uninterruptible power systems (UPS)

FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109
(a),Class B Digital Device
DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2.1077(a)
Responsible PartName:
Address:
Phone/Fax No:
hereby declares that the product
Product Name:
Conforms to the following specifications:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful and (2) this device must accept any inference received,
including that may cause undesired operation.
Representative Person’s Name:
Signature: Eric Lu
Supplementary Information:
Model Number:
17358 Railroad Street
City of Industry, CA 91748
G.B.T. INC. (U.S.A.)
[phone]/ [phone]
Motherboard
GA-7VA
Date:
ERIC LU
September 16 ,2002

GIGABYTE obtained of the event to validate the
performance of ATi and Nvidia based graphics cards
(AGP 8X with VIA Chipset based motherboards
running Microsoft operating systems. Certificates of
Validation will be supplied by VIA, ATi and nVIDIA for
GA-7VAXP; GA-7VAX and GA-7VA that successfully
passed in the AGP 8X standard validation

USER'S MANUAL
GA-7VA
AMD SocketAProcessor Motherboard
AMDAthlon™/Athlon™XP/Duron™SocketAProcessorMotherboard
Rev.1032
12ME-7VA-1032

- 2 -GA-7VA Motherboard
English
Table of Content
Item Checklist .........................................................................................4
WARNING!...............................................................................................4
Chapter 1 Introduction .............................................................................5
Features Summary...................................................................................... 5
GA-7VAMotherboard Layout........................................................................ 7
Block Diagram............................................................................................. 8
Chapter 2 Hardware Installation Process................................................9
Step 1: Install the Central Processing Unit (CPU).....................................10
Step1-1: CPU Speed Setup............................................................................................ 10
Step1-2: CPU Installation.................................................................................................11
Step1-3:CPU Heat Sink Installation................................................................................ 12
Step 2: Install memory modules................................................................13
Step 3: Install expansion cards .................................................................15
Step 4: Connect ribbon cables, cabinet wires, and power supply ...........16
Step4-1:I/O Back Panel Introduction .............................................................................. 16
Step4-2: Connectors Introduction................................................................................... 18
Chapter 3 BIOS Setup ..........................................................................39
The Main Menu (For example: BIOS Ver. :F1).........................................30
Standard CMOS Features......................................................................... 32
Advanced BIOS Features ..........................................................................35
Integrated Peripherals ..............................................................................37

Table of Content
English
- 3 -
Power Management Setup .......................................................................41
PnP/PCI Configurations.............................................................................44
PC Health Status........................................................................................45
Frequency/Voltage Control........................................................................ 47
Top Performance ......................................................................................49
Load Fail-Safe Defaults.............................................................................50
Load Optimized Defaults...........................................................................51
Set Supervisor/User Password..................................................................52
Save & Exit Setup.......................................................................................53
Exit Without Saving ...................................................................................54
Chapter 4 Technical Reference ............................................................55
BIOS Flash Procedure ..............................................................................55
@ BIOS Introduction..................................................................................70
Easy TuneTM 4 Introduction .......................................................................71
2-/4-/6-Channel Audio Function Introduction........................................72
Chapter 5Appendix..............................................................................79

- 4 -GA-7VA Motherboard
English
þTheGA-7VA motherboard þ2 Port USB Cable x 1
þIDE cable x 2/ Floppy cable x 1 o4 Port USB Cable x 1
þMotherboardSettingsLabel oAudio combo Kit x1
þGA-7VAuser'smanual oIEEE 1394 Cable x1
oRAIDManual oSPDIF KIT x1 (SPD Kit)
þCDformotherboard driver &utility(Driver CD) oI/O Shield
þQuickPCInstallationGuide
Item Checklist
Computermotherboards andexpansion cardscontain very delicate Integrated Circuit (IC) chips. To
protectthemagainstdamagefromstaticelectricity,youshouldfollowsomeprecautionswheneveryou
workonyourcomputer.
1. Unplugyourcomputerwhenworking ontheinside.
2. Useagroundedwriststrapbeforehandlingcomputercomponents.Ifyoudonothave
one,touchbothofyourhandstoasafelygroundedobjectortoametalobject,suchas
the power supplycase.
3. Holdcomponentsbytheedgesandtry nottouchtheICchips,leads or connectors,or
othercomponents.
4. Placecomponentsonagroundedantistaticpadoronthebagthatcamewiththe
componentswheneverthecomponentsareseparatedfromthesystem.
5. EnsurethattheATXpowersupplyisswitchedoffbeforeyoupluginorremovetheATX
powerconnectoronthemotherboard.
Ifthemotherboardhasmountingholes,buttheydon’tlineupwiththeholesonthebaseandthereare
noslotstoattachthespacers,donotbecomealarmedyoucanstillattachthespacerstothemounting
holes.Justcutthebottomportionofthespacers(thespacermaybealittlehardtocutoff,sobecareful
ofyourhands).Inthiswayyoucanstillattachthemotherboardtothebasewithoutworryingaboutshort
circuits.Sometimesyoumayneedtousetheplasticspringstoisolatethescrewfromthemotherboard
PCBsurface,becausethecircuitwiremaybenearbythehole.Becareful,don’tletthescrewcontact
anyprintedcircuitwriteorpartsonthePCBthatarenearthefixinghole,otherwiseitmaydamagethe
boardorcauseboardmalfunctioning.
Installing the motherboard to the chassis…
WARNING!

Introduction
English
- 5 -
FormFactor 29.3cm x 20.0cmATX size form factor, 4 layers PCB.
CPU Socket Aprocessor
AMDAthlonTM/AthlonTM XP/ DuronTM (K7)
128KL1&256K/64KL2 cache on die
200/266/333<Note1>MHzFSBandDDR bus speeds
Supports1.4GHzandfaster
Chipset VIAKT400 Memory/AGP/PCI Controller (PAC)
VIAVT8235IntegratedPeripheralController(PSIPC)
Memory 3184-pinDDRsockets
SupportsDDR DRAM PC1600/PC2100/PC2700/PC3200<Note2>
Supportsup to3.0GB DDR (Max)
Supports only 2.5V DDR DIMM
I/OControl IT8705
Slots 1AGPslot supports 8X/4X/2X mode(1.5V) &AGP3.0Compliant
5 PCI slots supports 33MHz & PCI 2.2 compliant
On-BoardIDE 2 IDE controllersprovides IDE HDD/CD-ROM(IDE1, IDE2) with
PIO,BusMaster(UltraDMA33/ATA66/ATA100/ATA133)
operationmodes.
On-BoardPeripherals 1 Floppy portsupports 2 FDDwith 360K, 720K,1.2M,1.44M
and 2.88M bytes.
1Parallelport supports Normal/EPP/ECP mode
2 Serial port (COMA & COMB)
6 x USB 2.0/1.1 (4 by cable)
HardwareMonitor CPU/SystemFan Revolution detect
CPU/Systemtemperaturedetect
SystemVoltageDetect
Thermalshutdownfunction
Chapter 1 Introduction
Features Summary
tobecontinued......
<Note 1> FSB333 MHz only support DDR333 DIMM module.
<Note 2> PC3200onlysupport by Micro, Samsung,Apacer DDR moduleasweverified,more detail
plsrefertoP.87

- 6 -GA-7VA Motherboard
English
Pleaseset the CPU host frequencyinaccordancewithyourprocessor’s specifications.
Wedon’t recommendyoutosetthesystembus frequency overtheCPU’sspecification
becausethesespecificbusfrequenciesarenotthestandardspecificationsforCPU,
chipsetandmostoftheperipherals.Whetheryoursystemcanrununder thesespecific
busfrequenciesproperlywilldepend onyourhardwareconfigurations,includingCPU,
Chipsets,SDRAM,Cards….etc.
On-BoardSound Realtek ALC650 CODEC
LineOut/2frontspeaker
Line In / 2 rear speaker(by s/w switch)
Mic In / center& subwoofer(by s/w switch)
SPDIF Out /SPDIF In
CD In /AUX In / Game port
On-Board USB 2.0 Builtin VIAVT8235Chipset
PS/2Connector PS/2 KeyboardinterfaceandPS/2Mouseinterace
BIOS LicensedAward BIOS, 2M bit flash ROM
SupportsQ-Flash
AdditionalFeatures PS/2 Keyboard power on by password,PS/2 Mouse power on
ExternalModem wake up
STR(Suspend-To-RAM)
AC Recovery
Polyfuseforkeyboardover-currentprotection
USB KB/Mouse wake up from S3
Supports@BIOS
SupportsEasyTune4
Overclocking Over Voltage (DDR/AGP/CPU) by BIOS
Over Clock (DDR/AGP/CPU/PCI) by BIOS

Introduction
English
- 7 -
GA-7VA Motherboard Layout
GA-7VA
KB_MS
COMA
LPT
GAME
LINE_OUT
MIC_IN USB
IT8705
AC97
BATTERY
BIOS SYS
FAN
VT8235
KT400
SOCKETA
CPU
FAN
ATX
FLOPPY
IDE1
IDE2
PCI1
PCI2
PCI3
PCI4
DDR1
AGP
SW1
F_USB1
LINE_IN COMB
CD_IN
PCI5
DDR2
DDR3
F_AUDIO
CI F_PANEL
F_USB2
AUX_IN
SUR_CEN SPDIF_IO
USB 2.0
PWR_LED
RAM_LED

- 8 -GA-7VA Motherboard
English
Block Diagram
VIA
KT400
VIA
VT8235
CPUCLK+/- (100/133/166MHz)
System Bus100/133/166 MHz
DDR RAM
HCLK+/- (100/133/166MHz)
AGPCLK66MHz
33 MHz
14.318 MHz
48 MHz
AGP 2X/4X/8X
AGPCLK
(66MHz)
5 PCI
PCICLK
(33MHz)
AC97 Link
6 USB
Ports
ATA66/100/133
IDE Channels
CLK
GEN
HCLK+/- (100/133/166MHz)
CPUCLK+/- (100/133/166MHz)
AGPCLK (66MHz)
PCICLK (33MHz)
USBCLK (48MHz)
14.318 MHz
33 MHz
IT8705
24 MHz
33 MHz
Game Port
Floppy
LPT Port
PS/2 KB/Mouse
COM
Ports
AC97
CODEC
MIC
LINE-IN
LINE-OUT
AMD-K7TM
BIOS
66MHz V_Link
V_Link (66MHz)

- 9 - Hardware Installation Process
English
Chapter 2 Hardware Installation Process
Tosetupyourcomputer,youmustcompletethefollowingsteps:
Step1-SetDipSwitch(CK_RATIO)andsystemSwitch(SW1)
Step2-InstalltheCentralProcessingUnit(CPU)
Step3-Installmemorymodules
Step4-Installexpansioncards
Step5- Connect ribbon cables,cabinetwires,andpower supply
Step6-SetupBIOSsoftware
Step7-Installsupportingsoftwaretools
Congratulationsyouhaveaccomplishedthehardwareinstallation!
Turnon thepowersupplyorconnect thepowercabletothe poweroutlet.Continuewith
theBIOS/softwareinstallation.
Step 3
Step 1
Step 4
Step 5
Step 5
Step2
Step 5

- 10 -GA-7VA Motherboard
English
Step 1: Install the Central Processing Unit (CPU)
Step1-1: CPU Speed Setup
Thesystembusfrequencycanbeswitchedat 100/133/166MHz by adjusting system switch(SW1).
(TheinternalfrequencydependonCPU.)
O: ON / X :OFF
SW1 CPU CLOCK
100MHz Auto
1 ON OFF
SW1
1
ON
Default Setting:100MHz
Youmustset SW1to 100MHz when
you used FSB 200MHz CPU.
100MHz : Fix FSB 200MHz CPU
Auto : Support FSB 266/333 MHz CPU

- 11 - Hardware Installation Process
English
Step1-2: CPU Installation
CPU Top View CPU Bottom View
Socket Actuation Lever
1. Pull up the CPU socket lever
andupto90-degreeangle.
Pin1 indicator
2. LocatePin1inthesocketandlook
fora(golden)cutedgeontheCPU
uppercorner.TheninserttheCPU
intothesocket.
Before installing the processor, adhere to the following warning:
1.Please make sure the CPU type is supported by the motherboard.
2.If you do not match the CPU socket Pin 1 and CPU cut edge well, it will
cause improper installation. Please change the insert orientation.

- 12 -GA-7VA Motherboard
English
Step1-3:CPU Heat Sink Installation
3. Fastentheheatsinksupporting-base
ontothe CPUsocketonthemain-
board.
2. Usequalified fanapprovedbyAMD.
4. Make sure the CPU fan is
pluggedtotheCPUfan connector,
thaninstallcomplete.
1. Press down the CPU socket
leverand finishCPUinstallation.
1.Please use AMD approved cooling fan.
2.We recommend you to apply the thermal paste to provide better heat
conduction between your CPU and Cooling Fan.
3.Make sure the CPU fan power cable is plugged in to the CPU fan connector, this
completesthe installation.
Please refer to CPU cooling fan user's manual for more detail installation procedure.
Beforeinstalling theCPUHeatSink,adhereto the followingwarning:

- 13 - Hardware Installation Process
English
Step 2: Install memory modules
DDR
Notch
Beforeinstallingthememorymodules,adheretothefollowingwarning:
1.WhenDIMMLEDisON,donotinstall/removeDIMMfromsocket.
2.Please note thatthe DIMM modulecan onlyfit in onedirection dueto the one
notch. Wrong orientation will cause improper installation. Please change the
insertorientation.
Themotherboardhas3dualinlinememorymodule(DIMM)sockets.TheBIOSwillautomatically
detectsmemorytypeandsize.Toinstallthememorymodule,justpushitverticallyintotheDIMMSlot.
TheDIMMmodulecanonlyfitinonedirectionduetothenotch.Memorysizecanvarybetweensockets.
SupportUnbufferedDDR DIMM Sizestype:
64 Mbit (2Mx8x4 banks) 64 Mbit (1Mx16x4 banks) 128 Mbit(4Mx8x4 banks)
128Mbit(2Mx16x4banks) 256Mbit(8Mx8x4banks) 256Mbit(4Mx16x4banks)
512Mbit(16Mx8x4banks) 512Mbit(8Mx16x4banks)
Total System Memory (Max3GB)

- 14 -GA-7VA Motherboard
English
DDR Introduction
Established on the existing SDRAM industry infrastructure, DDR (Double Data Rate) memory is a high
performance and cost-effective solution that allows easy adoption for memory vendors, OEMs and
system integrators.
DDR memory is a sensible evolutionary solution for the PC industry that builds on the existing
SDRAM infrastructure, yet makes awesome advances in solving the system performance bottleneck by
doubling the memory bandwidth. DDR SDRAM will offer a superior solution and migration path from
existing SDRAM designs due to its availability, pricing and overall market support. PC2100 DDR memory
(DDR266) doubles the data rate through reading and writing at both the rising and falling edge of the clock,
achieving data bandwidth 2X greater than PC133 when running with the same DRAM clock frequency.
With peak bandwidth of 2.664GB per second, DDR memory enables system OEMs to build high
performance and low latency DRAM subsystems that are suitable for servers, workstations, high-end
PC's and value desktop SMA systems. With a core voltage of only 2.5 volts compared to conventional
SDRAM's 3.3 volts, DDR memory is a compelling solution for small form factor desktops and notebook
applications.
1. The DIMM slot has a notch, so the DIMM
memory module can only fit in one direction.
2. Insert the DIMM memory module vertically into
the DIMM slot. Then push it down.
3. Close the plastic clip at both edges of the DIMM
slots to lock the DIMM module.
Reverse the installation steps when you wish
to remove the DIMM module.
