Gigabyte E152-ZE1 User manual

E152-ZE1
1U short depth AMD EPYC™ 7003 series server system
User Manual
Rev. 1.0

Copyright
© 2022 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
 User Manual: detailed information & steps about the installation, conguration and use of this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents.
For More Information
For related product specications, the latest rmware and software, and other information please visit our website at
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
server[email protected]

Conventions
The following conventions are used in this user's guide:
NOTE!
Gives bits and pieces of additional
information related to the current topic.
CAUTION!
Gives precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts you to any damage that might
result from doing or not doing specic actions.

Server Warnings and Cautions
Before installing a server, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug all the power cords from the power supplies to disconnect power to the equipment.
• Shock Hazard! Disconnect all power supply cords before servicing.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives
and the internal system components to cool before touching them.
WARNING!
This server is equipped with high speed fans. Keep away from hazardous
moving fan blades during servicing.
WARNING!
This equipment is not suitable for use in locations where children are
likely to be present.
WARNING!
This equipment is intended to be used in Restrict Access Location. The
access can only be gained by Skilled person.
Only authorized by well trained professional person can access the
restrict access location.
CAUTION!
• Do not operate the server for long periods with the access panel open or removed.
Operating the server in this manner results in improper airow and improper cooling that can
lead to thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace only with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.

Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT-
TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER
WHEN HANDLING PARTS.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by
their edges without any component and pin touching. After removing a board from its protective
wrapper or from the system, place the board component side up on a grounded, static free sur-
face. Use a conductive foam pad if available but not the board wrapper. Do not slide board over
any surface.
System power on/o󰀨: To remove power from system, you must remove the system from
rack. Make sure the system is removed from the rack before opening the chassis, adding, or
removing any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be
present on power, telephone, and communication cables. Turn off the system and discon-nect
the cables attached to the system before servicing it. Otherwise, personal injury or equipment
damage can result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives,
boards, and other parts. We recommend that you perform all procedures in this chapter only at
an ESD workstation. If one is not available, provide some ESD protection by wearing an antistatic
wrist strap attached to chassis ground (any unpainted metal surface on the server) when handling
parts.
ESD and handling boards: Always handle boards carefully. They can be extremely
sensi-tive to electrostatic discharge (ESD). Hold boards only by their edges. After removing a
board from its protective wrapper or from the system, place the board component side up on a
grounded, static free surface. Use a conductive foam pad if available but not the board wrapper.
Do not slide board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips
over two jumper pins. Some jumpers have a small tab on top that can be gripped with n-gertips
or with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when
using needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with
the pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the
jumper, causing intermittent problems with the function con-trolled by that jumper. Take care to
grip with, but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the
board may bend or break.

CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used bat-
teries according to the manufacturer’s instructions.

- 7 -
Table of Contents
Chapter 1 Hardware Installation ...................................................................................11
1-1 Installation Precautions.................................................................................. 11
1-2 Product Specications.................................................................................... 12
1-3 System Block Diagram................................................................................... 15
Chapter 2 System Appearance.....................................................................................17
2-1 Front View...................................................................................................... 17
2-2 Rear View....................................................................................................... 17
2-3 Front Panel LED and Buttons ........................................................................ 18
2-4 System LAN LEDs ......................................................................................... 19
2-5 Power Supply Unit LED.................................................................................. 20
2-6 Hard Disk Drive LEDs .................................................................................... 21
Chapter 3 System Hardware Installation ......................................................................23
3-1 Removing Chassis Cover............................................................................... 24
3-2 Removing and Installing the Fan Duct ........................................................... 25
3-3 Installing the CPU and Heat Sink................................................................... 26
3-4 Installing the Memory..................................................................................... 28
3-4-1 Eight Channel Memory Conguration.....................................................................28
3-4-2 Installing a Memory ...............................................................................................29
3-4-3 Processor and Memory Module Matrix Table .........................................................29
3-4-4 Memory Population Table .......................................................................................30
3-5 Installing the PCI Expansion Card ................................................................. 31
3-6 Installing the GPU Card ................................................................................. 32
3-7 Installing the Hard Disk Drive......................................................................... 33
3-8 Installing the Mezzanine Card........................................................................ 34
3-9 Replacing the Power Supply.......................................................................... 35
3-10 Cable Routing ................................................................................................ 36
Chapter 4 Motherboard Components ...........................................................................39
4-1 Motherboard Components ............................................................................. 39
4-2 Jumper Settings ............................................................................................. 41
4-3 Backplane Board Storage Connector ............................................................ 42
4-3-1 CBPH022................................................................................................................42
Chapter 5 BIOS Setup ..................................................................................................45
5-1 The Main Menu .............................................................................................. 47
5-2 Advanced Menu ............................................................................................. 49

- 8 -
5-2-1 Trusted Computing .................................................................................................51
5-2-2 PSP Firmware Versions..........................................................................................52
5-2-3 Legacy Video Select...............................................................................................53
5-2-4 AST2600 Super IO Conguration...........................................................................54
5-2-5 S5 RTC Wake Settings...........................................................................................57
5-2-6 Serial Port Console Redirection .............................................................................58
5-2-7 CPU Conguration..................................................................................................62
5-2-8 PCI Subsystem Settings.........................................................................................63
5-2-9 USB Conguration..................................................................................................65
5-2-10 Network Stack Conguration..................................................................................67
5-2-11 NVMe Conguration ...............................................................................................68
5-2-12 SATA Conguration.................................................................................................69
5-2-13 UEFI POST LOGO Conguration...........................................................................70
5-2-14 AMD Mem Conguration Status.............................................................................71
5-2-15 Tls Auth Conguration ............................................................................................72
5-2-16 ISCSI Conguration................................................................................................73
5-2-17 Intel(R) Ethernet Controller I350.............................................................................74
5-2-18 VLAN Conguration................................................................................................76
5-2-19 MAC IPv4 Network Conguration...........................................................................77
5-2-20 MAC IPv6 Network Conguration...........................................................................78
5-3 AMD CBS Menu............................................................................................. 79
5-3-1 CPU Common Options...........................................................................................80
5-3-2 DF Common Options..............................................................................................85
5-3-3 UMC Common Options ..........................................................................................90
5-3-4 NBIO Common Options........................................................................................104
5-3-5 FCH Common Options .........................................................................................110
5-3-6 NTB Common Options .........................................................................................114
5-3-7 SOC Miscellaneous Control .................................................................................115
5-3-8 Workload Tuning...................................................................................................116
5-4 AMD PBS Menu........................................................................................... 117
5-4-1 RAS ......................................................................................................................118
5-5 Chipset Setup Menu..................................................................................... 120
5-5-1 North Bridge .........................................................................................................121
5-5-2 Fabric Resource ...................................................................................................122
5-6 Server Management Menu........................................................................... 123
5-6-1 System Event Log ................................................................................................125
5-6-2 View FRU Information ..........................................................................................126
5-6-3 BMC Network Conguration .................................................................................127
5-6-4 IPv6 BMC Network Conguration.........................................................................128
5-7 Security Menu .............................................................................................. 129
5-7-1 Secure Boot .........................................................................................................130

- 9 -
5-8 Boot Menu.................................................................................................... 132
5-8-1 UEFI NETWORK Drive BBS Priorities ................................................................134
5-8-2 UEFI Application Boot Priorities ................................................................. 135
5-9 Save & Exit Menu......................................................................................... 136
5-10 BIOS POST Beep code (AMI standard)....................................................... 137
5-10-1 PEI Beep Codes ...................................................................................................137
5-10-2 DXE Beep Codes .................................................................................................137

- 10 -
This page intentionally left blank

- 11 -
Hardware Installation
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the service guide and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
• Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface .
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation

Hardware Installation
- 12 -
1-2 Product Specications
Socket
Socket
Security
Security
CPU AMD EPYC™ 7003 series processor family
Single processor, 7nm
Up to 64-core, 128 threads per processor
cTDP up to 240W
Compatible with AMD EPYC™ 7002 series processor family
Socket
Socket
Security
Security
Socket Socket SP3
Socket
Socket
Security
Security
Chipset System on Chip
Socket
Socket
Security
Security
Memory 8 x DIMM slots
DDR4 memory supported only
8-Channel memory per processor architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
Memory speed: Up to 3200/ 2933 MHz
Socket
Socket
Security
Security
LAN 2 x 1Gb/s LAN ports ( Intel® I350-AM2)
1 x 10/100/1000 management LAN
Socket
Socket
Security
Security
Video Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Socket
Socket
Security
Security
Storage 2 x 2.5" SATA/Gen4 NVMe hot-swappable HDD/SSD bays
Supports 7mm drives only
2 x M.2 slots on CMTP182 Riser Card:
M-key
PCIe Gen4 x4 per slot
Supports NGFF-2280/22110 cards
Socket
Socket
Security
Security ServerOperating Properties
Power Supply
Expansion Slot 2 x Full-height Full-length PCIe Gen4 expansion slots
1 x Low prole Half-length PCIe Gen4 expansion slot
1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 bandwidth
Supported NCSI function
Supported NCSI function
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.

- 13 -
Hardware Installation
Socket
Socket
Security
Security ServerOperating Properties
Power Supply
Internal I/O 1 x TPM header
1 x USB 3.0 connector
1 x Front Panel connector
1 x HDD BPB connector
Socket
Socket
Security
Security
Front I/O 2 x USB 3.0
1 x miniDP
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x System status LED
Socket
Socket
Security
Security ServerOperating Properties
Power Supply
Backplane I/O 2 x 2.5" SATA/Gen4 NVMe ports
Bandwidth: SATA 6Gb/s, and PCIe Gen4 x4 per port
Socket
Socket
Security
Security ServerOperating Properties
Power Supply
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Socket
Socket
Security
Security ServerOperating Properties
Power Supply
Power Supply 2 x 1000W redundant PSUs
80 PLUS Platinum
AC Input:
100-127V~/ 15A, 50-60Hz
200-240V~/ 8A, 50-60Hz
DC Output:
Max 1000W
+12V/ 83.3A
+12Vsb/ 3A

Hardware Installation
- 14 -
Socket
Socket
Security
Security ServerOperating Properties
Power Supply
System
Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Prole
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Conguration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
Socket
Socket
Security
Security ServerOperating Properties
Power Supply
Operating
Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Socket
Socket
Security
Security ServerOperating Properties
Power Supply
System
Dimension
1U
438mm (W) x 43.5mm (H) x 400mm (D)

- 15 -
Hardware Installation
1-3 System Block Diagram
mini-DP
PCIe4.0 x 4
PCIe4.0 x 4
M.2
M.2
PCIe4.0 x 8
PCIe4.0
x 16
PCIe4.0
x 16
8 x SATAIII
Riser CMTP182
2 x SlimLine
2 x SlimLine
2-bay 2.5" U.2/SATA
8-Channel DDR4, 8 x DIMMs
Speed up to 3200 MHz
2 x PCIe x16 FHFL slots
(support 1 x DW GPU or 2 x SW GPUs)
1 x PCIe x16 HHHL slot
Riser CRSE020
Riser CRSH01H
PCIe4.0 x 16
PCIe4.0 x16
PCIe2.0 x2
PCIe2.0 x1
USB2.0 x1
OCP 3.0 mezzanine
Switch NCSI
NCSI
NCSI
Intel
i350-AM2
2 x 1GLAN
Flash
512 MB
TPM
USB3.0 / USB2.0 x2
2 x USB 3.0
AMD MILAN
“Zen3” Core
Socket SP3
MUX
MLAN
RGMII 10/100/1G
PHY
USB2.0 x1 USB2.0 x1
USB HUB
GL850G
ASPEED
AST2600
BMC
Flash
32 MB

Hardware Installation
- 16 -
This page intentionally left blank

- 17 -
System Appearance
Chapter 2 System Appearance
2-1 Front View
No. Description
1. PCIe Card Slot (PCIe x16)
2. Mezzanine Card Slot (Option/OCP V3.0 Card)
3. Mini DP Port
4. 1 GbE LAN Port #2
5. 1 GbE LAN Port #1
6. 10/100/1000 Server management LAN port
7. Front Panel LEDs and Buttons
8. Front USB 3.0 Port x 2
NOTE! The Green HDD Latch Supports NVMe
• Please Go to Chapter 2-3 Front Panel LED and Buttons for detail description of function
LEDs.
2-2 Rear View
No. Description
1. GPU Card Slot
HDD#0
HDD#1
1
23 4 5 6 7 8
PSU1PSU2
1

System Appearance
- 18 -
2-3 Front Panel LED and Buttons
1 2 3
No. Name Color Status Description
1. Power button
with LED
Green On System is powered on
Green Blink System is in ACPI S1 state (sleep mode)
N/A Off
• System is not powered on or in ACPI S5 state
(power off)
• System is in ACPI S4 state (hibernate mode)
2. ID Button
This LED represents the RoT function
LED behavior. Please see the following
section for detail LED behavior.
3. System
Status LED
Green On System is operating normally.
Amber
On
Critical condition, may indicate:
System fan failure
System temperature
Blink
Non-critical condition, may indicate:
Redundant power module failure
Temperature and voltage issue
Chassis intrusion
N/A Off
System is not ready, may indicate:
POST error
Processor or terminator missing

- 19 -
System Appearance
2-4 System LAN LEDs
1 2 1 2 21
No. Name Color Status Description
1. 1GbE
Speed LED
Yellow On 1Gbps data rate
Green On 100 Mbps data rate
N/A Off 10 Mbps data rate
2.
1GbE
Link/
Activity
LED
Green
On Link between system and
network or no access
Blink Data transmission or receiving is occurring
N/A Off No data transmission or
receiving is occurring

System Appearance
- 20 -
2-5 Power Supply Unit LED
PSU LED
State Description
Off No AC power to all power supplies
1Hz Green Blinking AC present / only standby on / Cold redundant mode
0.5Hz Amber/Green
Blinking Alternative
Power supply warning events where the
power supply continues to operate:
high temp, high power, high current, slow fan
Amber Power supply critical event causing shut down:
failure, OCP, OVP, fan failure and UVP
1Hz Amber Blinking AC cord unplugged or AC power lost; with a second
power supply in parallel still with AC input power
