Gigabyte R283-Z97-AAF1 User manual

R283-Z97-AAF1
R283-Z97-AAL1
Rack Server - AMD EPYC™ 9004
2U DP 12+4-Bay Gen5 NVMe/SATA/SAS4
1+1 2400W (240V) 80 PLUS Platinum redundant power supplies (AAF1)
1+1 2700W (240V) 80 PLUS Titanium redundant power supplies (AAL1)
User Manual
Rev. 1.0

Copyright
© 2023 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
 User Manual: detailed information & steps about the installation, conguration and use of this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents.
For More Information
For related product specications, the latest rmware and software, and other information please visit our website at
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
server[email protected]

Conventions
The following conventions are used in this user's guide:
NOTE!
Pieces of additional
information related to the current topic.
CAUTION!
Precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts to any damage that might
result from doing or not doing specic actions.

Server Warnings and Cautions
Before installing a server, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives and the internal
system components to cool before touching them.
WARNING!
This server is equipped with high speed fans. Keep away from hazardous moving fan
blades during servicing.
CAUTION!
• Do not operate the server for long periods with the access panel open or removed. Operat-
ing the server in this manner results in improper airow and improper cooling that can lead to
thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace battery with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.
CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used bat-
teries according to the manufacturer’s instructions.

Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT-
TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER
WHEN HANDLING PARTS.
Always handle boards carefully, they can be extremely sensitive to ESD. Hold boards only by
their edges without touching any components or connectors. After removing a board from its
protective ESD bag or from the system, place the board component side up on a grounded, static
free surface. Use a conductive foam pad if available but not the ESD bag. Do not slide the board
over any surface.
System power on/off: To service components within the server, please ensure the power has
been disconnected.
e.g. Remove the node from the server chassis (to disconnect power) or disconnect the power
from the server chassis.
Make sure the system is removed from the rack before opening the chassis, adding, or removing
any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be present
on power, telephone, and communication cables. Turn off the system chassis and disconnect the
cables attached to the system before servicing the chassis. Otherwise, personal injury or equip-
ment damage can result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives, boards, and
other parts. We recommend that you perform all procedures in this chapter only at an ESD work-
station. If one is not available, provide some ESD protection by wearing an antistatic wrist strap
attached to chassis ground (any unpainted metal surface on the server) when handling parts.
ESD and handling boards: Always handle boards carefully. They can be extremely sensi-tive to
electrostatic discharge (ESD). Hold boards only by their edges. After removing a board from its
protective wrapper or from the system, place the board component side up on a grounded, static
free surface. Use a conductive foam pad if available but not the board wrapper. Do not slide
board over any surface.

Installing or removing jumpers: A jumper is a small plastic encased conductor that slips over
two jumper pins. Some jumpers have a small tab on top that can be gripped with n-gertips or
with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when us-
ing needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with the
pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the jumper,
causing intermittent problems with the function con-trolled by that jumper. Take care to grip with,
but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the board may
bend or break.

- 7 -
Table of Contents
Chapter 1 Hardware Installation ................................................................................... 11
1-1 Installation Precautions.................................................................................. 11
1-2 Product Specications.................................................................................... 12
1-3 System Block Diagram................................................................................... 17
Chapter 2 System Appearance.....................................................................................20
2-1 Front View...................................................................................................... 20
2-2 Rear View....................................................................................................... 21
2-3 Front Panel LEDs and Buttons....................................................................... 22
2-4 RoT LEDs....................................................................................................... 23
2-5 Rear System LAN LEDs................................................................................. 25
2-6 Power Supply Unit LED.................................................................................. 26
2-7 Hard Disk Drive LEDs .................................................................................... 27
Chapter 3 System Hardware Installation ......................................................................28
3-1 Removing and Installing the Chassis Cover .................................................. 29
3-2 Removing and Installing the Hard Disk Drive................................................. 30
3-3 Removing and Installing the Fan Duct ........................................................... 32
3-4 Removing and Installing the Heat Sink .......................................................... 33
3-5 Removing and Installing the CPU .................................................................. 34
3-6 Removing and Installing Memory................................................................... 36
3-6-1 Twelves Channel Memory Conguration................................................................36
3-6-2 Removing and Installing a Memory Module ...........................................................37
3-6-3 Processor and Memory Module Matrix Table .........................................................37
3-6-4 Memory Population Table .......................................................................................38
3-7 Removing and Installing the PCIe Card......................................................... 39
3-8 Installing the Mezzanine Card........................................................................ 41
3-8-1 Installing the OCP 3.0 Mezzanine Card .................................................................41
3-9 Installing the M.2 Device and Heat Sink ........................................................ 42
3-9-1 M.2 device with Heatsink........................................................................................42
3-10 Replacing the Fan Assembly.......................................................................... 43
3-11 Removing and Installing the Power Supply.................................................... 44
3-12 Cable Routing ................................................................................................ 45

- 8 -
Chapter 4 Motherboard Components ...........................................................................57
4-1 Motherboard Components ............................................................................. 57
4-2 Jumper Settings ............................................................................................. 59
4-3 G-SC Module ................................................................................................. 60
4-3-1 CDCR114 ...............................................................................................................60
4-4 Backplane Board Storage Connector ............................................................ 61
4-4-1 CBP20C7................................................................................................................61
4-4-2 CBP2025 (Rear System Storage Board)................................................................62
Chapter 2 BIOS Setup ..................................................................................................76
5-1 The Main Menu .............................................................................................. 78
5-2 Advanced Menu ............................................................................................. 81
5-2-1 Trusted Computing .................................................................................................83
5-2-2 PSP Firmware Versions..........................................................................................84
5-2-3 Legacy Video Select...............................................................................................85
5-2-4 AST2600 Super IO Conguration...........................................................................86
5-2-5 S5 RTC Wake Settings...........................................................................................88
5-2-6 Serial Port Console Redirection .............................................................................89
5-2-7 CPU Conguration..................................................................................................93
5-2-8 PCI Subsystem Settings.........................................................................................94
5-2-9 USB Conguration..................................................................................................96
5-2-10 Network Stack Conguration..................................................................................98
5-2-11 Post Report Conguration ......................................................................................99
5-2-12 NVMe Conguration .............................................................................................100
5-2-13 SATA Conguration...............................................................................................101
5-2-14 Graphic Output Conguration...............................................................................102
5-2-15 AMD Mem Conguration Status...........................................................................103
5-2-16 Tls Auth Conguration ..........................................................................................104
5-2-17 RAM Disk Conguration .......................................................................................105
5-2-18 iSCSI Conguration..............................................................................................106
5-2-19 Intel(R) I350 Gigabit Network Connection ............................................................107
5-2-20 VLAN Conguration..............................................................................................109
5-2-21 MAC IPv4 Network Conguration.........................................................................110
5-2-22 MAC IPv6 Network Conguration......................................................................... 111
5-3 AMD CBS Menu........................................................................................... 112
5-3-1 CPU Common Options.........................................................................................113
5-3-2 DF Common Options............................................................................................119
5-3-3 UMC Common Options ........................................................................................126
5-3-4 NBIO Common Options........................................................................................147
5-3-5 FCH Common Options .........................................................................................158
5-3-6 SOC Miscellaneous Control .................................................................................167

- 9 -
5-3-7 CXL Common Options..........................................................................................169
5-4 AMD PBS Menu........................................................................................... 170
5-4-1 RAS ......................................................................................................................171
5-5 Chipset Setup Menu..................................................................................... 173
5-5-1 North Bridge .........................................................................................................174
5-5-2 Fabric Resource ...................................................................................................175
5-6 Server Management Menu........................................................................... 177
5-6-1 System Event Log ................................................................................................179
5-6-2 View FRU Information ..........................................................................................180
5-6-3 BMC Network Conguration .................................................................................181
5-6-4 IPv6 BMC Network Conguration.........................................................................182
5-7 Security Menu .............................................................................................. 183
5-7-1 Secure Boot .........................................................................................................184
5-8 Boot Menu.................................................................................................... 186
5-9 Save & Exit Menu......................................................................................... 188
5-10 BIOS Recovery ............................................................................................ 189
5-11 BIOS POST Beep code (AMI standard)....................................................... 190
5-11-1 PEI Beep Codes...................................................................................................190
5-11-2 DXE Beep Codes .................................................................................................190

- 10 -
This page intentionally left blank

- 11 -
Hardware Installation
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the service guide and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
•
Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface
.
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation

Hardware Installation
- 12 -
1-2 Product Specications
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
System
Dimension
2U
438 (W) x 43.5 (H) x 815(D) mm
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
CPU AMD EPYC™ 9004 Series processors
Dual processor, 5nm technology
Up to 32-core, 64 threads per processor
Supports CPU 240W at ambient 30°C
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be
unavailable
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Socket 2 x LGA 6096
Socket SP5
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Chipset System on Chip
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Security UEFI Secure Boot
Silicon root of trust
SNMP Support: V3
Memory 24 x DIMM slots
DDR5 memory supported only
12-Channel memory architecture per processor
RDIMM modules up to 96GB supported
3DS RDIMM modules up to 256GB supported
Memory speed: Up to 4800 MHz
LAN Rear side:
2 x 1GbE LAN ports (1 x Intel® I350-AM2)
Support NCSI function
1 x 10/100/1000 management LAN
Video Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.

- 13 -
Hardware Installation
Storage Front side:
8 x 3.5"/2.5" Gen5 NVMe/SATA/SAS4 hot-swappable bays
4 x 3.5"/2.5" SATA/SAS4 hot-swappable bays
(4 x NVMe from CPU_0, 4 x NVMe from CPU_1)
(6 x SATA via CRS2810 from CPU_0, 6 x SATA via CRS2810 from CPU_1)
Rear side:
4 x 2.5" SATA/SAS4 hot-swappable bays, via CRS2810 from CPU_1
SAS card is required for SAS devices support
SAS Depends on SAS add-on card
Expansion Slot PCIe Cable x 4:
1 x PCIe x16 (Gen5 x16) FHFL slot, from CPU_0, for GPUs
1 x PCIe x16 (Gen5 x16) FHFL slot, from CPU_1, for GPUs
1 x PCIe x16 (Gen5 x16) FHHL slot, from CPU_0
1 x PCIe x16 (Gen5 x16) FHHL slot, from CPU_1
1 x OCP 3.0 slot with PCIe Gen5 x16 bandwidth, from CPU_0
Supports NCSI function
1 x OCP 3.0 slot with PCIe Gen5 x16 bandwidth, from CPU_1
Supports NCSI function
1 x M.2 slot:
M-key
PCIe Gen3 x4, from CPU_0
Supports 2280/22110 cards
Occupied by CRS2810 - 6 x SATA ports
1 x M.2 slot:
M-key
PCIe Gen3 x4, from CPU_1
Supports 2280/22110 cards
Occupied by CRS2810 - 4 x SATA ports
1 x M.2 slot:
M-key
PCIe Gen3 x2, from CPU_1
Supports 2280/22110 cards
Occupied by CRS2810 - 6 x SATA ports
Internal I/O 1 x TPM header
2 x OCP 3.0 slots

Hardware Installation
- 14 -
Front I/O 2 x USB 3.2 Gen1
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x HDD activity LED
1 x System status LED
Rear I/O 2 x USB 3.2 Gen1
1 x Mini-DP
2 x RJ45
1 x MLAN
1 x ID LED
Backplane I/O Speed and bandwidth:
Front side - CBP20C7: PCIe Gen5 x4 or SATA 6Gb/s or SAS4 24Gb/s
Rear side - CBP2025: SATA 6Gb/s or SAS4 24Gb/s
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

- 15 -
Hardware Installation
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Power Supply R283-Z97-AAF1
1+1 2400W (240V) 80 PLUS Platinum redundant power supplies
AC Input:
100-127V~/ 12.5A, 47-63Hz
180-240V~/ 14.5A, 47-63Hz
DC Input:
240Vdc/ 12A
DC Output:
Max 1000W/ 100-127V~
+ 12V/ 84A
+ 12Vsb/ 3A
Max 2200W/ 180-200V~
+ 12V/ 180A
+ 12Vsb/ 3.5A
Max 2400W/ 200-240V~ or 240Vdc
+ 12V/ 197A
+ 12Vsb/ 3.5A
NOTE: The system power supply requires C19 power cord
R283-Z97-A AL1
1+1 2700W (240V) 80 PLUS Titanium redundant power supplies
AC Input:
100-127V~/ 12A, 50-60Hz
200-240V~/ 16A, 50-60Hz
DC Input:
240Vdc/ 16A
DC Output:
Max 1008W/ 100-127V~
+ 12V/ 84A
+ 12Vsb/ 3A
Max 2700W/ 200-240V~
+ 12V/ 225A
+ 12Vsb/ 3A
NOTE: The system power supply requires C19 power cord

- 16 -
Hardware Installation
System
Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Prole
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Conguration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Operating
Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Hardware Installation
- 17 -
1-3 System Block Diagram
PCIe5.0 x16
PCIe5.0 x16 FHFL slot for GPUs
(by cable)
PCIe5.0 x16
PCIe5.0 x16 FHHL slot (by cable)
PCIe5.0 x16 PCIe5.0 x16
PCIe5.0 x16 FHFL slot for GPUs
(by cable)
PCIe5.0 x16 FHHL slot (by cable)
G-SC Module
PCIe3.0 x1
MDI
2 x 1G LAN
COM
2 x USB3.2
Gen1
(front)
2 x USB3.2 Gen1
Mini-DP
MLAN
PCIe5.0 x16
OCP 3.0 OCP 3.0
NCSI
Switch
Switch
ASPEED
AST2600
Intel
I350-AM2
SPI
PCIe3.0 x1
USB2.0 x1
TPM
USB Hub
12-Channel DDR5, 12 x DIMMs
Speed up to 4800 MHz
12-Channel DDR5, 12 x DIMMs
Speed up to 4800 MHz
PCIe5.0 x16
PCIe3.0 x4
PCIe3.0 x2
PCIe3.0 x4 M.2
Occupied by CRS2810
4 x SATA ports
Occupied by CRS2810
4 x SATA ports
M.2
Occupied by CRS2810
6 x SATA ports
Occupied by CRS2810
6 x SATA ports M.2
Occupied by CRS2810
6 x SATA ports
Occupied by CRS2810
6 x SATA ports
SATA x16
USB3.2 Gen1 x2USB3.2 Gen1 x2
xGMI3 32GT/s
4 x16 GOP
PCIe5.0 x16
2 x MCIO
CPU0
AMD EPYC™ 9004
Socket SP5 PCIe5.0 x16
2 x MCIO
CPU1
AMD EPYC™ 9004
Socket SP5
NVMe x4NVMe x4
8-bay 3.5"/2.5" Gen5 NVMe/SATA
4-bay 3.5"/2.5" SATA
4-bay 2.5" SATA (rear)

- 20 -
System Appearance
Chapter 2 System Appearance
2-1 Front View
No. Description
1. Front Panel LEDs and Buttons
2. USB 3.2 Gen1 Port x 2
Note! Drives with green latches support NVMe.
• Refer to section 2-3 Front Panel LEDs and Buttons for a detailed description of the
function of the LEDs.
1 2
HDD0
HDD1
HDD2
HDD3
HDD4
HDD5
HDD6
HDD7
HDD8
HDD9
HDD10
HDD11

System Appearance
- 21 -
2-2 Rear View
3
21 4 5
78
6 6
8
PSU1PSU2 SLOT2SLOT1
SLOT5
SLOT9
SLOT8
SLOT12
SLOT4
SLOT11
SLOT3
SLOT6
No. Description No. Description
1. Mini DP Port 5. Server Management LAN Port
2. ID LED 6. OCP 3.0 Slot (Option/SFF)
3. USB 3.2 Gen1 Port x 2 7. PCIe Slot
4. 1GbE LAN Port x 2 8. 2.5” Hard Drive Bay
• Refer to section 2-5 Rear System LAN LEDs for a detailed description of the function of
the LEDs.

- 22 -
System Appearance
(Note) If your server features RoT function, please see the following section for detail LED behavior.
2-3 Front Panel LEDs and Buttons
L1 L2
1
3
5
7
2
4
6
8
No. Name Color Status Description
1. Reset Button -- -- Press this button to reset the system.
2. NMI button -- --
Press this button for the server to generate a NMI to the
processor. If multiple-bit ECC errors occur, the server will
effectively be halted.
3. Power button
with LED
Green On Indicates the system is powered on.
Green Blink System is in ACPI S1 state (sleep mode).
N/A Off - System is not powered on or in ACPI S5 state (power off)
- System is in ACPI S4 state (hibernate mode)
4. ID Button with
LED(Note)
Blue On Indicates the system identication is active.
N/A Off Indicates the system identication is disabled.
5. HDD Status
LED(Note)
Green On Indicates locating the HDD.
Blink Indicates accessing the HDD.
Amber On Indicates HDD error.
Green/
Amber Blink Indicates HDD rebuilding.
N/A Off Indicates no HDD access or no HDD error.
6. System
Status LED
This LED represents the RoT function LED behavior.
Please see the following section for detail LED behavior.
7/8. LAN1/2 Active/
Link LED
Green On Indicates a link between the system and the network or no
access.
Green Blink Indicates data trasmission or receiving is occuring.
N/A Off Indicates no data transmission or receiving is occuring.
