GIGAIPC mITX-1605A User manual

Mini-ITX Motherboard mITX-1605A (MRZNVMI)
1www.gigaipc.com
mITX-1605A (MRZNVMI)
Thin Mini-ITX Motherboard
User’s Manual 1st Ed

2
www.gigaipc.com
Copyright Notice
This document is copyrighted, 2018. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translat¬ed, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no respon¬sibility for its use, or for any
in¬fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its accuracy,
GIGAIPC assumes no liabilities resulting from errors or omissions in this
document, or from the use of the information contained herein.
GIGAIPC reserves the right to make changes in the product design
without notice to its users.

Mini-ITX Motherboard mITX-1605A (MRZNVMI)
3www.gigaipc.com
Acknowledgement
All other products’ name or trademarks are properties of their
respective owners.
• AMD® is trademark of Advanced Micro Devices.
• Microsoft Windows is a registered trademark of Microsoft Corp.
• Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel
Corporation
• Core, Atom are trademarks of Intel Corporation
• ITE is a trademark of Integrated Technology Express, Inc.
• IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
All other product names or trademarks are properties of their
respective owners.
Packing List
Before setting up your product, please make sure the following items
have been shipped:
Item Quantity
mITX-1605A MB 1
SATA power cable 1
I/O Bracket 1
mITX-V1000 Fan Sink 1
If any of these items are missing or damaged, please contact your
distributor or sales representative immediately.

4
www.gigaipc.com
Assembly Sequence
Material fan-sink.
Torque 2.2 ~ 2.8 kgf-cm
Assembly action
1>.
Fix the heat sink with your hand to correct the
corresponding hole position, and fix the heat sink as shown
in the figure above.
2>. According to the above assembly sequence, the correct
torque is used to lock the heat sink.
3>. When removing, please reverse (spinning from position 4)
to remove

Mini-ITX Motherboard mITX-1605A (MRZNVMI)
5www.gigaipc.com
About this Document
This User’s Manual contains all the essential information, such as
detailed descriptions and explanations on the product’s hardware
and software features (if any), its specifications, dimensions, jumper/
connector settings/definitions, and driver installation instructions (if
any), to facilitate users in setting up their product.
Users may refer to the GIGAIPC.com for the latest version of this
document.

6
www.gigaipc.com
Safety Precautions
Please read the following safety instructions carefully. It is advised that
you keep this manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the
device.
3. Position the power cord so that people cannot step on it. Do
not place anything over the power cord.
4. Always completely disconnect the power before working on the
system’s hardware.
5. No connections should be made when the system is powered
as a sudden rush of power may damage sensitive electronic
components.
6. If the device is not to be used for a long time, disconnect it from
the power supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before
cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray
detergents.
9. Make sure the device is installed near a power outlet and is
easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent
falls
12. Do not cover the openings on the device to ensure optimal heat
dissipation.

Mini-ITX Motherboard mITX-1605A (MRZNVMI)
7www.gigaipc.com
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is
running
15. Never pour any liquid into the openings. This could cause fire or
electric shock.
16. As most electronic components are sensitive to static electrical
charge, be sure to ground yourself to prevent static charge
when installing the internal components. Use a grounding
wrist strap and contain all electronic components in any static-
shielded containers.
17. If any of the following situations arises, please the contact our
service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described
in this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED
ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S
PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO
PREVENT DAMAGE.

8
www.gigaipc.com
FCC Statement
This device complies with Part 15 FCC Rules. Operation
is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device
must accept any interference received including
interference that may cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions and your local government’s
recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant
et les directives gouvernementales de recyclage.

Mini-ITX Motherboard mITX-1605A (MRZNVMI)
9www.gigaipc.com
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
GIGAIPC Main Board/ Daughter Board/ Backplane
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电
子组件
○ ○ ○ ○ ○ ○
外部信号
连接器
及线材
○ ○ ○ ○ ○ ○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：此 产 品 所 标 示 之 环 保 使 用 期 限，系 指 在 一 般 正 常 使 用 状 况下。

10
www.gigaipc.com
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
GIGAIPC Main Board/ Daughter Board/ Backplane
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components O O O O O ○
Wires &
Connectors
for External
Connections
O O O O O O
O：The quantity of poisonous or hazardous substances or elements found in each
of the component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least
one of the component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this
product is applicable under normal usage only

Mini-ITX Motherboard mITX-1605A (MRZNVMI)
11 www.gigaipc.com
Table Contents
Thin Mini-ITX Motherboard 1
User’s Manual 1st Ed 1
Copyright Notice .......................................................................... 2
Acknowledgement ....................................................................... 3
Packing List................................................................................... 3
Assembly Sequence ..................................................................... 4
About this Document ................................................................... 5
Safety Precautions ....................................................................... 6
FCC Statement.............................................................................. 8
China RoHS Requirements (CN).................................................... 9
China RoHS Requirement (EN) ................................................... 10
Chapter 1 - Product Specifications 13
1.1 Specifications ............................................................... 15
Chapter 2 – Hardware Information 17
2.1 Jumpers and Connectors ............................................. 18
2.2.1 AUDIO (Audio line-out port) ......................................... 21
2.2.2 USB3_LAN2, USB3_LAN1 (USB 3.0 ports + Gbe LAN
port) .............................................................................. 21
2.2.3 DP3_4, DP1_2 (Display ports)....................................... 22
2.2.4 COM1_2 (Serial ports) .................................................. 22
2.2.5 DC_IN (DC In JACK Connector) ..................................... 23
2.2.6 DC_IN2 (ATX 2x2 pin power connector)....................... 24
2.2.7 SYS_FAN (System Fan Connector) ................................ 25

12
www.gigaipc.com
2.2.8 SATA1 (SATA 6GB/S Connector) .................................... 26
2.2.9 SATAPW1 (SATA 6GB/S Power Connector).................... 27
2.2.10 F_USB2_3, F_USB2_1, F_USB2_2 (USB 2.0 header) ..... 28
2.2.11 COM3, COM4 (Serial Port header)................................ 29
2.2.12 AT_CN (AT/ATX power mode select jumper) ................ 30
2.2.13 GPIO_CNT(General purpose input/output connector) 31
2.2.14 SYS_PANEL (Front Panel Header)................................ 32
2.2.15 TPM_LPC (Trusted Platform Module Connector)......... 33
2.2.16 SODIMM1, SODIMM2 (DDR4 SO-DIMM slot#1/slot#2)
...................................................................................... 34
2.2.17 CLR_CMOS (Clear CMOS jumper) ................................. 35
2.2.18 CPU_FAN (CPU fan connector) ..................................... 36
2.2.19 M2M (M.2 M-key)....................................................... 37
2.2.20 PCIEX16 (PCIE x16 slot) ............................................... 38
2.2.21 SPK_OUT (Speaker out Connector)............................. 39
2.2.22 F_Audio (Front audio header) ....................................... 40
2.2.23 BAT (Battery Cable connector) .....................................41
2.2.24 LVDS_DP (LVDS/DP jumper) .......................................... 42
2.2.25 LSW (LVDS resolution jumper) ...................................... 43
2.2.26 M2E (M.2 E-key)............................................................ 44
2.2.27 MPCIE (Mini PCI-E)........................................................ 45
2.2.28 BKL_CN (Back light brightness control connector)....... 46
2.2.29 LVDS (LVDS connector).................................................. 47
2.2.30 JCOM1, JCOM2 (COM1 & COM2 RI# pin RI#/5V/12V
Select) ......................................................................... 48

13 www.gigaipc.com
Mini-ITX Motherboard mITX-1605A (MRZNVMI)
Chapter 1
Chapter 1 - Product Specifications

14
www.gigaipc.com

15 www.gigaipc.com
Mini-ITX Motherboard mITX-1605A (MRZNVMI)
1.1 Specifications
Motherboard mITX-H110A
Form Factor Mini-ITX
170W x 170D (mm)
CPU
AMD® RYZEN™ V1605B Embedded Processor
up to 3.6GHz
TDP 25W
2MB of shared L2 plus 4MB of shared L3 total
Socket 1 x FP5 BGA
Chipset —
Memory
2 x DDR4 1.2V SO-DIMM sockets supporting up to 32 GB of
system memory
Up to 2400Mhz
Max. memory capacity 32GB
Ethernet 2 x GbE LAN ports (Realtek® RTL8111HS)
Video
Integrated Graphics Processor - AMD Radeon™ Vega 8 Graphics
4 x DP port, supporting a maximum resolution of 4096x2160 @
60Hz
1 x LVDS port, supporting a maximum resolution of 1080P (
switch from DP)
Audio Realtek ALC269 controller
High Definition Audio
Storage 1 x SATA 6Gb/s port
Expansion Slots
1 x PCIe x16 (X8 bus) slot
1 x Mini PCIe (Full Size PCIe & USB)
1 x M.2 slot:
- M-key
- SATA 6Gb/s
- Supports NGFF-2280 cards
1 x M.2 slot:
- E-key
- Supports NGFF-2230 Combo cards

16
www.gigaipc.com
Motherboard mITX-H110A
Internal I/O
1 x 4-pin ATX power connector
1 x SATA 6Gb/s connector
1 x SATA power connector
1 x CPU fan header
1 x System fan header
1 x Front panel header
1 x Front panel audio header
1 x Speaker out header
6 x USB 2.0 header
2 x COM headers (RS-232)
1 x LPC/TPM header
1 x GPIO (4 in/ 4 out)
1 x Backlight Control header
1 x LVDS connector (Switch from DP)
1 x LVDS/ DP Jumper
1 x AT mode jumper
1 x CMOS battery
Rear I/O
3 x Audio jacks (Line in, Line out, Mic in)
2 x COM (RS-232/422/485 and RI/5V/12V)
4 x DP
2 x RJ45
4 x USB3.0
1 x DC Jack (+12V~24Vdc)
TPM 1 x TPM Header
OS Compatibility Windows 10 (x64)
PSU Connectors
1 x DC-in +12~24V Vdc (full Range)
1 x 4-pin ATX power connector
Operating temperature: 0°C to 60°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -20°C to 70°C
Non-operating humidity: 0%-95% (non-condensing)
Packing Content
BOX Packing Capacity: 10pcs
Carton size: 551 x 470 x 230 (mm)
Content:
IO Shield x 1 (12AIO-MRZNV0-00R)
SATA Power cable x 1 (25CRI-200B02-K1R)
Fansink x 1 (12SF2-01A077-00R)

17 www.gigaipc.com
Mini-ITX Motherboard mITX-1605A (MRZNVMI)
Chapter 2
Chapter 2 – Hardware Information

18
www.gigaipc.com
2.1 Jumpers and Connectors
52
1 2 3 3 4
6
7
8
10
11
12
13
1415161718
19
20
21
22
9
3 3 4
23
24 25
26 27
28
29 30

19 www.gigaipc.com
Mini-ITX Motherboard mITX-1605A (MRZNVMI)
No Code Description
1AUDIO Audio Line Out port
2USB3_LAN2,
USB3_LAN1 USB 3.0 ports + GbE LAN port
3DP3_4, DP1_2 Display ports
4COM1_2 Serial ports
5DC_IN1 DC-In Jack Connector
6DC_IN2 ATX 2x2 pin power connector
7SYS_FAN System fan connector
8SATA1 SATA 6Gb/s connector
9SATAPW1 SATA 6Gb/s power connector
10
F_USB2_3,
F_USB2_1,
F_USB2_2
USB 2.0 header
11 COM3, COM4 Serial ports header
12 AT_CN AT/ATX power mode select jumper
13 GPIO_CNT General Purpose input/output header
14 SYS_PANEL Front panel header
15 TPM_LPC TPM connector
16 SODIMM1, SODIMM2 DDR4 SO-DIMM slot#1/slot#2
17 CLR_CMOS Clear CMOS jumper
18 CPU_FAN CPU fan connector
19 M2_M M.2 M-key
20 PCIE16X PCIE x16 slot
21 SPK_OUT Speaker out connector

20
www.gigaipc.com
No Code Description
22 F_AUDIO Front Panel audio header
23 BAT Battery cable connector
24 LVDS_DP LVDS/DP Jumper
25 LSW LVDS resolution jumper
26 M2E M.2 E-key
27 MINI_PCIE MINI PCIE connector
28 BKL_CN Back light brightness control connector
29 LVDS LVDS connector
30 JCOM1, JCOM2 COM1/2 RI# pin RI#/5V/12V Select
