Gigaware 26-1542 User manual

®
26-1542
User’s Guide
Please read this user’s guide before using
your new gaming cable.
Universal Component Gaming
Cable with Selector Switch

®
2
Package contents
• GamingCable •User’sGuide
Features
• Connectupto3gameconsolesand
switchbetweenthemwithonebutton.
• WorkswithXbox360™,PlayStation®2,
PlayStation®3,andWii™consoles.
1Connect
1. Turnoffyourtelevisionandgameconsole.
2. Plugthecomponentvideoandaudio
connectorsintoyourTV.
3. Connectthe matching gameconnector
toyourgameconsole.
4. Repeatsteps1-3foradditionalconsoles.
2Play and switch games
1. Turnonyourtelevisionandgameconsole.
2. Selectyourgamingsystembypressing
oneof3cableswitchbuttons:PS2
PS3,Wii,orXBOX 360.

®
3
Audio Connectors
Connect to the matching colored
audio jacks on your TV: White =
AL (left); Red = AR (right)
Component Video
Connectors
Connect to the matching
colored video jacks on
your TV: Green = Y;
Blue = Pb; Red = Pr

®
4
Built-in Digital
Optical jack
Remove the protective
cap and connect a digital
optical cable to TV and
Xbox 360 to enhance
audio (see Notes)
Wii™
Xbox 360™
PS2®/PS3®
PS2 PS3/ Wii/ XBOX 360
Press to switch gaming system

®
5
n Notes:
• Youcanonlyplayoneconsoleatatime.
• ForsuperiorsoundqualityonyourXbox
360,connectadigitalopticalaudio
cable(notincluded)totheXbox360
connector’sbuilt-indigitalopticaljack
and your stereo receiver or TV.
• TheXbox360digitalopticaljack
functionsseparatelyfromthegame
consoleswitchbuttons.Unplugyour
digitalopticalcablefromtheXbox360
connector before switching to PS3,
PS2, or Wii. Otherwise, your game’s
audiowillnotworkproperly.

®
6
• Alwayscoverthebuilt-indigitaloptical
jackwiththeprotectivecapwhennot
usingthejacktopreventdustanddirt
enteringtheopticallens.
• Checkyourgameconsole’sinstruction
manualforanyadditionalsetup.
w Caution:
• Avoidleavingcordsinplaceswhere
theyarelikelytobewalkedonor
trippedover.
• Donotpinch,damage,orwrapcords
aroundobjectsorpeople.Donotallow
childrentoplaywithcords.
Specifications
Cablelength................................... 3.28ft(1meter)
ConnectorPlating............................................Nickel
Video input
ConnectorsforPS2/PS3AV,WiiAV,XBOX360
Video output
ComponentVideoRCAconnectorsx3(Y;Pb/Cb;
Pr/Cr)Green=Y;Blue=Pb;Red=Pr
Audio
Stereoaudio,RCAconnectorsx2(L;R),Digital
opticalportforXbox360only.

®
7
Video output format
480i/576i,480p/576p,720p,1080i,1080p
Specicationsaresubjecttochangeand
improvementwithoutnotice.Actualproductmay
varyfromtheimagesfoundinthisdocument.
