1.1 PRERIDE ACTIVITIES
Before riding the scooter make sure that:
• Thechargingplugisoutofthesocket.
• Thebatteryissucientlycharged.
• Thelightingandhornfunctionproperly.
• Themirrorisadjustedforproperuse.
• Thereisthecorrectairpressureand
proper tread depth in tyres.
• Thebrakesworkproperly(testbraking
while pushing the scooter).
• Itiseasytoturnthehandlebarwithout
resistance, fully left and right.
SAFE RIDING INSTRUCTIONS
Check before riding if all the folding
parts are locked. First check if main
hinge is locked by trying to fold the
GiGi without unlocking the main
hinge. If this is not possible the
folding mechanism is locked (if the
GiGi is not unfolded correct the motor
will not work).
Subsequently check if the front assembly
and folding handle bars are locked.
See short manual supplied with your GiGi for more details.
1.2 CLOTHING
• Alwaysrideinappropriateclothes(andacertiedhelmetincountrieswherelegallyrequired).
• Weartightttingandcomfortableclothing.
• Wearproperboots(don’trideinhighheels,ip-ops,orsimilaropenfootgear).
Inadequate clothing may become a threat to safe riding!
1.3 RIDING TECHNIQUE
• Vehicleshouldberiddencarefullyandsensibly.
• Alwaysholdthehandlebarswithtwohands.
• Whiledrivingtrytomaintainlightpressureonbothfeet.Thisensuresyoukeepmore
control and enjoy a comfortable ride.
• Becauseoftheshortwheelbaseandrelativelysmallwheelsparticularcautionisrecommended
while riding on poorly hardened or wet road surfaces. Brake for bumps etc..
• Payattentiontoatypicalsoundsorbehaviourofthescooterwhileriding.
EN
66
1.4 RIDER AND CARGO
• Inordertocarryobjectsorbagsoneshouldexplicitlyusetheluggagehookprovided
for bags.
• Maximumscooterweightallowancemaynotbeexceeded.Maximum100Kg.forrider
including light luggage.
• Thescooterisallowedtocarrymaximum 1 person.
1.5 AFTER RIDING
• Checkifthebatteryneedscharging.
Riding with a low level battery significantly decreases its life.
Batterylifecanbeextendedbyrechargingiteachtimeafteruse.Thereisnoriskof
overcharging,becauseafterreachingmaximumchargelevelthechargerdisconnects
automatically. It also starts charging when the battery level gets too low to avoid complete
selfdischarge. It is therefore required to plug in the GiGi when stalled for a long period of time.
EN
77
2.1 LEFT SIDE OF GIGI
1 Speedometer
2 Ignition
3 Seat
4 Rear handle to lift GiGi
5 Front handle to lift GiGi
6 Rear shock absorber
7 Front shock absorber
8 Engine compartment
VEHICLE EQUIPMENT
5
7
1
2
34
6
8
EN
88
2.2 RIGHT SIDE OF GIGI
1 Front brake lever
2 Head light
3 Centre stand
4 Storage compartment and
charging cable under seat
5 Parking and breaking light
6 Registration plate
7 Battery compartment
8 Lock for folded GiGi
1
2
8
3
7
4
6
5
EN
99
2.3 HOW TO FOLD AND UNFOLD A GIGI
fold
unfold
The yellow handles have to be used to fold & unfold the GIGI.
EN
1010
2.4 OPERATIONAL ELEMENTS
1 Left mirror
2 Speedometer
3 Throttle
4 Rear brake lever
5 Ignition
6 Front brake lever
1
4
5
2
6
3
EN
1111
2.5 IGNITION
Ignition turned o
• Allfunctionsturnedo
• GiGicanberolled
• GiGicanbesafelyhandled
Riding position
• Allfunctionsactive
• GiGireadyforriding
• Takingoutthekeyisnotpossible
• Thekeyshouldbeturnedtoriding
position only when the rider is seated
on the vehicle, directly before riding
The sound of the engine is not heard
although the handlebar throttle is active
Release GiGi for drive
• Beforeyoucandriveyouhaveto‘release’
the GiGi engine.
• Squeezerightorleftbrakeleveruntilthe
Warningsymboldisappearsindisplayand
“0”KPH/MPH.isvisible.Thisensures
the GiGi does not “spontaneously” drive
away because someone turns the throttle.
• Only‘release’theenginewhensitting
down on the GiGi.
EN
1212
2.6 SPEEDOMETER
1 Horn
2 Charge indicator
3 Battery status
4 Eco status
5 Battery type
6 Power consumption
7 Warningsymbol
8 Speed indicator
9 Trip meter
10 Odometer
11 Trip reset
12 Sportmodus(see#4)
1
2
3
4
7
8
9
10
11
12
5
6
EN
1313
SPEEDOMETER SETTINGS
When GiGi is in standby mode
(warning symbol visible in display)
A SpeedindicatorcanbesettoKPHor
MPH. Press Sport and R button
simultaneously to choose setting.
B Display clarity
Clarity can be adjusted by pressing the
Sport(darker)orR(lighter)button.
When GiGi is in released mode
(“0” KPH / MPH. is visible)
C Sportmodusallowsextrapowerforfaster
acceleration,drivinguphillorwithextreme
front wind. Sport mode can be switched on
and o by pressing the Sport button. Sport
modus is active when the word “ECO” of
“ECOPOWER”disappears.
D Reset trip set
Press R button for reset
ODO
ODO
MPH
KPH
O
ECO
POWER
8
EN
1414
2.7 TRUNK
1 Trunk
2 Seat lock
3 Charge(240V)cable
• InordertounlocktheseatslideswitchtowardsfrontwheelGiGi.
• Inordertoclosetheseatpushdownandassisttolock.
• Donotcloseseatwhilecharging.
• Leavepowercordintrunkaftercharge.
2
1
3
EN
1515
2.8 CHARGING THE BATTERY
• ChargingcablecanbeusedforallsocketstypesE/Fwithspecication16A/240V.
• Charginganemptybatterytakesapproximately3:20hoursforastandardpackand5:20
hoursforextendedrangeversion.
• Thebatteryshouldbechargedwheneverpossibleasitextendsitslifetime.
• ChargingphaseisvisibleonthechargeindicatorandbatterystatusontheSpeedometer
display.
• Avoidridingwithanotfullychargedbatteryasmuchaspossiblebecauseitdecreasesits
lifetime.
• Itisnotpossibletooverchargethebatterywhencharging.
• Chargerautomaticallystopswhenbatteryisfullandautomaticallyloadswhenbattery
voltage becomes too low.
• ItisrequiredtoconstantlychargetheGiGiwhennotusedforalongperiodoftime.
• Thebatteryrequirestobechargedatleastonceamonth,evenifyoudonot
use your GiGi.
• Donotchargethebatteryattemperaturelowerthan-10degreesCelsius.
• DonotturntheGiGionwhilecharging,itcandamagechargerorbattery.
BATTERY CHARGE TIME
Standard range 3:20
Extendedrange 5:20
EN
1616
2.9 HANDLE
Handles allow user to lift the GiGi when required. Moreover, the handle is helpful while
positioning the GiGi on the centre stand.
Lift the GiGi when unfolded with
handle 1 and 2. Do not lift GiGi
on left or right steer handle bar.
Whenunfolded.
Lift folded GiGi with handle 1 and
handle 3 underneath the seat.
Whenfolded.
2
1
1
3
EN
1717
2.10 POSITIONING THE GIGI ON THE CENTRE STAND
In order to support the GiGi on stand, pull rear grab handle upwards and press down the
centre stand.
Do not sit on GiGi while it is NOT folded and supported on the centre stand as it
may damage the vehicle!
WhenGiGiisfoldedonemaysitontheGiGi.
2.11 HOOK FOR BAGS
Hook for bags can be used to carry bags.
In order to hang a bag the operator should
pull the hook downwards.
Remember that while turning the vehicle a
swinging bags may aect riding.
Do not hang weights exceeding 3 kg on the hook.
2.12 LIGHTING
Each time, before riding, the lighting components should be checked for functionality,
damages and settings.
Out of safety head and tail light are always on when GiGi is switched on.
• Headlight
• Taillight
• Brakelightfrontandrearbrake
EN
1818
2.13 TYRES
It is necessary to check tires before riding for
possible damages or low air pressure. Low tyre
pressure aects driving performance and range
of the GiGi. Tyre pressure can be checked at a
petrol station. Check your tyre pressure monthly.
2.14 BRAKES
• TheGiGiisequippedwithdrumbrakestominimizemaintenance.
• Checkthebrakesbeforeuse.Inordertocheckperformanceofthebrakestheoperator
shouldpushthescooterseveralmeters.Whilepushingsqueezethefrontbrakeand
then the rear brake, one at a time. During braking test the scooter should be firmly held
to prevent it from falling over.
Anticipate longer brake distance in wet weather. Moisture can enter the
brake drums increasing the brake distance.
TYRES VALUE
Front 2,6-2,8 bar
Rear 2,6-2,8 bar
EN
1919
2.15 TECHNICAL SPECIFICATIONS
Speed 25KPHor35KPH.Regulationsvarypercountry.
Weight 32Kg.(standardrange)or33,5Kg.(extendedrange)
DimensionsHeight 945mm.Width:647mm.Length:1296mm.
DimensionsfoldedHeight 721mm.Width:326mm.Length:838mm.
Seat Height 695 mm.
Folding system 3 step manual folding / unfolding [10 sec.]
MaxLoad 1person/max.100Kg.
Energysource Li-ion400Wh/600Wh
Voltage 48 Volt
Range* 1hourriding.25-30Km.(400Whbattery)or30-40Km.
(600Whbattery)
Wheels&Wheelbase 2,15x8”aluminiumcasted.Wheelbase920mm.
Tyres 3,00x8”HeidenauGiGityres(customforGiGi)
Brakes Frontandrear90mm.drumbrakes(customforGiGi)
Motor 500WBrushlessPMDCmotorwithdualbeltdrive
Charger 48VDC120Won-boardcharger(110VAC-220VAC)
Charging time
3:20hrs.400Whand5:20hrs.600Whbattery(0%to100%).
Frame High Pressure Injection Moulded Aluminium
Shock absorber 40 mm. 90 Shore A PU Silent Block
Storage space 0,8 litre underneath seat
Warranty 24monthsaccordingtoregisteredterms
EC type-approval No. e11*2002/24*1763*01
Emissions Zero
Production Dutch Industrial Design. Manufactured in EEC.
*Foranaverageridingprole(85Kg.load)
EN
2020
2.15 HOW TO CHECK THE VIN NUMBERS ON VEHICLE
You can find the VIN number on two dierent locations on the GiGi: under the seat and on
therightsideofmidframe(footboard)whenGiGiisfolded.
2.17 FUSES
Thefuseboxislocatedunderneaththeseat.
From left to right when standing behind the GiGi.
1. Battery pack 30 Amp.
2. Ignition 1 Amp.
3. Lights, horn 3 Amp.
4. Display, brakes 1 Amp.
VIN number
Fuses
1
2
EN
This manual suits for next models
4
Table of contents
