Nilox DOC URBAN User manual

1
DOC URBAN
EN

2
USER MANUAL
Thank you for purchasing a NILOX DOC URBAN electric scooter.
Please read this manual carefully before using the product and store it in a safe place for
future reference.

3
1. Introduction
This product is a foldable assisted electric scooter. It can accelerate by being pushed and
decelerate using the foot brake or the brake on the handlebars.
2. Introduction to product parts
Lights-horn-gears control
Smartphone Holder
Brake
Accelerator
Digital Display
Front Light
Rear Light
Rear Wheel
Kick Stand
Anti-skid Plate
Front Wheel and Motor
Quick release clamp
Suspension
Handlebars
Foldable handlebars
Rear Mudguard
Front Mudguard
Closing Lever
Ignition Key

4
3. Warnings
- Only use the battery supplied.
- This is not a toy. This product should be used by adults or minors with AM licences.
- Check the current traffic regulations relating to scooters where the Doc Urban is used.
- In pedestrian areas it is not possible to exceed a speed of 6 Km/h
- Ensure that all parts of the Doc Urban are secured (for example that the screws on the
handlebars are tight)
- Always wear comfortable clothing that does not restrict movement and use personal
protection equipment: on hands/wrists, knees, head and elbows.
-Do not transport objects while riding the scooter
- When using the scooter pay attention to other people around you and keep a safe
distance
- Ensure that both feet are positioned correctly on the plate
- We recommend not to accelerate and stop the suddenly to avoid losing control of the
scooter.
- Do not do any tricks.
- Do not get on and off the scooter when it is still moving.
- Respect the maximum rider weight.

5
- Avoid using the product in adverse weather conditions (for example rain, hail or snow) to
avoid damage to the electrical circuits or motor. In addition avoid using Doc Urban on
slippery surfaces or on gravel or sand. Do not get on and of the Doc Urban on steep paths
or when going up or down hill.
- In the event of poor visibility it is necessary to turn on the front and rear lights and wear
high-visibility reflective clothing.
- Do not use the Doc Urban in temperatures below -5°.
- Do not use the Doc Urban with the kick bar lowered.
- The Doc Urban is intended to be used by only one person at a time.
- Using the Doc Urban is not recommended for people with limited motor skills, those with
impaired psychological status or pregnant women.
- When using the Doc Urban for the first time first try it in an open area away from dangers
to practice safely.
- Do not use in flammable environments.
- The manufacturer, importer and distributor are not liable for any damage caused to
persons or things in the event of improper use of the Doc Urban.
- Do not attempt to repair the product by yourself, in the event of malfunction contact your
dealer.
- Disconnect from the power supply before cleaning

6
- To clean it wipe with a damp cloth or use a solution suitable for cleaning similar devices.
Do not immerse in water or try to clean it with jets of water.
- To preserve the battery, it must be charged every 30 days even if the Doc Urban is not
used, otherwise the battery loses efficiency at the expense of autonomy
- The maximum travel distance when charged can vary according to various factors such as
the rider’s weight, the gradient of the journey, surface characteristics and correct battery
maintenance.
4. Folding and unfolding the scooter
l. Install the pedal with
the spare tools
supplied along upon
delivery.
l. Install the pedal with
the spare tools
supplied along upon
delivery.
3.1.To unfold/fold
the scooter ensure
there are no
obstacles around
you.
3.2 Pull the knob
on the handlebars
outwards and pull
downwards.
3.3.Open the quick
release clamp.
3.4.Lower the handlebars
as much as possible.
3.5 Hold the scooter still
with one foot and push the
steering column with one
hand.
3.4.Push the release clamp
upwards with one finger.

7
5. Introduction on how to use it
Battery indicator
Battery capacity
"5 Bars"
Battery charged
"4 Bars"
Around 80%
"3 Bars”
Around 60%
"2 Bars”
Around 40%
“1 Bar”
Below 20% recharge the scooter.
Turn the ignition key. Rotate the throttle handle to move the scooter at the desired speed.
Doc Urban has three different speeds of 6/20/25 km/h. Pushing the +/- buttons the gears
change from 1-2-3. To slow down, push the brake lever and turn the throttle handle
anticlockwise. Turn the key to turn off the Doc Urban.
3.7.Push the steering
column down until it stops.
To unfold push the release
clamp upwards and then
pull on the steering column
until it stops.

8
6. Battery and charger
6.1. Lithium battery
Fully charge the battery when you first use the Doc Urban
6.1.1. When the battery is running low recharge it immediately to avoid
damaging it and limiting autonomy.
6.1.2. If the scooter is not used for a long time, charge it at least once a month.
6.1.3. If the battery capacity is lower than the protection status and the scooter
does not work contact your dealer immediately.
6.2. Recharging
The battery charger supplied has a charging protection function. Power is automatically cut
off when the battery is 100% charged. Damage caused by water, collisions and other
factors are not covered by the warranty.
6.2.1. Open the rubber cover on the charging port on the lower part of the foot plate
of the scooter and insert the power input connector into the charging port.
6.2.2. Insert the charger input plug into the power outlet (AC100V-240V).
6.2.3. . If the indicator on the charger is red the battery is charging; when it turns
green the battery is fully charged.
6.2.4. When charging the battery always place it in a dry and ventilated place.
7. Care and Maintenance
Lubrification: a small quantity of white grease or lubricant must be applied to the steering
column folding mechanism every three months.
Wheels: this product is fitted with solid wheels. If a wheel needs to be replaced due to
obvious wear or damage, please contact the service centre to replace it with an original one.
Always check the wheels are tightened.

9
8. Positioning and daily care
Do not leave the scooter in the sun or in humid places for long periods; clean it with a dry or
damp cloth.
9. Doc Urban Technical Specifications
Wheel dimensions
8”
Colours available
Black
Engine Power
280 W
Maximum speed *
25 Km/h
Maximum autonomy *
25 km
Maximum gradient
5°
Battery Capacity
36 V 7.5 Ah
Recharge parameters
Input 100-240 V –Output 42 V 1.5 A
Recharge time
3-4 ore
Maxim Rider Weight
100 Kg
•Rider weight of 60 kg
10. Warranty (Validity and Limitations)
- The warranty validity period for consumers, i.e. those that purchase items for purposes
unrelated to their professional or business activity is 2 years from delivery.
For those that purchase items using a VAT Code for purposes related to their professional
activity it is 1 year from delivery as the law states.
- The warranty is valid in the event the product has a material or manufacturing defect.
Consumers are not entitled to the warranty in the following cases:
- lack of proof of purchase (invoice or receipt).
1. Expanded View of Product:

10
- attempts to repair parts and/or changes carried out by unauthorised parties
- using accessories or items that are not supplied with the product;
- normal wear and tear of the product;
- accidental damage and falls;
- improper use of the product
11.Package contents
Accessory
Quantity
Doc Urban
1
Power
supply
1
Manual
1
Smartphone
Holder
1
Ignition keys
2
Note: The performance and parameters of the product supplied are subject to change
without notice. The company reserves the right to the final interpretation of all terms and
conditions in this manual.
ENVIRONMENTAL INFORMATION
This product may contain substances that can be harmful to the environment and
human health if not disposed of properly. We therefore provide you with the following
information to prevent the release of such substances and to optimize the use of natural
resources. The electrical and electronic components should not be disposed of in the
normal household waste but should be properly and correctly collected and treated. The
crossed-out wheelie bin symbol on the product and on this page indicates the need to
properly dispose of the product at the end of its lifespan. In this way you can avoid
non-specific treatment of the substances contained in these products, or improper use of

11
parts of these which can have harmful consequences for the environment and human
health. Moreover, you can contribute to the recovery, recycling and reuse of many of the
materials in these products. This is why the manufacturers and distributors of Electrical and
Electronic Equipment organize proper collection and disposal of the equipment themselves.
At the end of the product’s lifespan, please contact your dealer for instructions regarding
disposal. When purchasing this product your distributor will inform you of the possibility to
replace your old device with a new one, on condition that the type of product and its
functions are the same. If the dimensions are not over 25 cm, the electrical and electronic
equipment can be returned without any equivalent product purchase obligation. Disposal of
the product in any other way will be liable to the penalties provided by the laws in force in
the country where the product is disposed of. Moreover, we suggest the following measures
to protect the environment: recycling the inner and outer packaging supplied with the
product and disposing of used batteries (if contained in the product) correctly. With your
help, we can reduce the amount of natural resources used in the manufacture of electrical
and electronic equipment, minimize use of landfills for product disposal and improve quality
of life by preventing the release of potentially dangerous substances into the environment.
BATTERY INSTALLATION AND REPLACEMENT
The product contains a battery that could be replaced during the lifespan of the
product itself. Dispose of the battery contained in the product correctly at the end of its
lifespan (for instance when it can no longer be charged) by placing it in an appropriate
battery disposal container separate from the generic unsorted waste. Collection and
recycling of batteries helps protect the environment and preserve natural resources,
allowing recovery of valuable materials.

12
Distributed byNilox
Produced and Imported by
Exhibo S.p.A. via Leonardo da Vinci 6
20854-Vedano al Lambro (MB)
ITALY
Made in China

1
DOC URBAN
IT

2
MANUALE D’USO
Vi ringraziamo per l’acquisto del monopattino elettrico NILOX DOC URBAN.
Vi preghiamo di leggere il manuale prima dell’utilizzo del prodotto e di mantenerlo in un
luogo sicuro per future consultazioni.

3
1.Introduzione
Questo prodotto è un monopattino elettrico pieghevole assistito. Può implementare
l'accelerazione tramite l’acceleratore a manopola e le marce, la decelerazione attraverso il
freno posto sul manubrio.
2.Introduzione delle parti del prodotto
Please read this manual carefully before using S11 electric power assisted booster.
Beginners should first practice in the open area to grasp kinetic energy of the
vehicle and riding skills before riding on the road.
Please read this manual carefully before using S11 electric power assisted booster.
Beginners should first practice in the open area to grasp kinetic energy of the
vehicle and riding skills before riding on the road.
Please read this manual carefully before using S11 electric power assisted booster.
Beginners should first practice in the open area to grasp kinetic energy of the
vehicle and riding skills before riding on the road.
Comandi fanali-clacson-marce
Porta Smartphone
Freno
Acceleratore
Display Digitale
Fanale Anteriore
Fanale Posteriore
Ruota Posteriore
Cavalletto
Pedana Antiscivolo
Ruota Anteriore e Motore
Morsetto Sgancio Rapido
Ammortizzatore
Manopola
Manubrio Pieghevole
Parafango Posteriore
Parafango Anteriore
Leva chiusura
Chiave Accensione

4
Avvertenze
- Utilizzare solo l’alimentatore fornito in dotazione.
- Questo prodotto non è un giocattolo.
- Controllare le normative vigenti sulla circolazione dei monopattini del paese in cui si
utilizza Doc Urban
- Nelle aree pedonali non è possibile superare i 6 Km/h di velocità.
- Verificare che tutti i componenti del Doc Urban siano fissati (ad esempio viti manubrio
siano ben salde)
- Utilizzare sempre un abbigliamento che non sia di intralcio ai movimenti e utilizzare
attrezzature di protezione personale: per le mani/polsi, per le ginocchia, per la testa e per i
gomiti.
- Non trasportare oggetti durante l’utilizzo del monopattino.
- Durante la guida prestare attenzione alle altre persone e agli oggetti intorno e mantenere
un’adeguata distanza di sicurezza
- Assicurarsi che entrambi i piedi siano posizionati correttamente sulla pedana.
- Si consiglia di non accelerare e di non arrestare il veicolo in maniera improvvisa in modo
da evitare la perdita del controllo del monopattino.
- Non eseguire acrobazie.
- Non salire e scendere dal monopattino mentre è in movimento.

5
- Rispettare il peso massimo previsto per l’utilizzatore.
- Evitare l’utilizzo del prodotto in presenza di condizioni atmosferiche avverse ( ad esempio
pioggia, grandine o neve) per evitare danni ai circuiti elettrici o al motore. Inoltre evitare
l’utilizzo di Doc Urban su superfici con presenza di ghiaia, sabbia o scivolose. Non salire o
scendere da Doc Urban in percorsi scoscesi, in discesa o in salita.
- In caso di scarsa visibilità è necessario accendere le luci anteriori e posteriori ed utilizzare
un abbigliamento retroriflettente ad alta visibilità.
- Non usare Doc Urban con temperature al di sotto dei -5°.
- Non usare Doc Urban con il cavalletto laterale abbassato.
- Il motore non va toccato appena dopo il suo l’utilizzo.
- E’ vietato salire su Doc Urban in più persone.
- L’uso di Doc Urban è vietato a persone con abilità motorie limitate, a persone con stato
psicofisico alterato e a donne in gravidanza.
- In caso di primo utilizzo provare Doc Urban in un’area aperta lontano da pericoli per fare
pratica in tutta sicurezza.
- Non usare in ambienti infiammabili.
- Il produttore, l’importatore ed il distributore non sono responsabili di danni provocati a
cose o persone in caso di un uso improprio di Doc Urban.

6
- Non provare a riparare il prodotto da soli, ma, in caso di malfunzionamento contattare il
rivenditore.
- Prima della pulizia scollegate l’alimentazione
- Per la pulizia utilizzare un panno appena inumidito con acqua o con una soluzione adatta
alla pulizia di simili dispositivi. Non immergerlo in acqua o cercare di pulirlo con getti di
acqua.
- Per preservare la batteria, questa deve essere caricata ogni 30 giorni anche se Doc Urban
non viene utilizzato. In caso contrario la batteria perderà di efficienza a scapito
dell’autonomia.
- La distanza massima percorsa con una carica può variare in base a determinati fattori
quali il peso del conducente, l’inclinazione del percorso, le caratteristiche della superficie e
la corretta manutenzione della batteria
3. Chiudere o aprire il monopattino
l.Install the pedal with
the spare tools
supplied along upon
delivery.
l.Install the pedal with
the spare tools
supplied along upon
delivery.
3.1. Per la
chiusura/apertura
posizionarsi in una
zona libera da
ostacoli.
3.2 Tirare verso
l’esterno lo sgancio
delle manopole e
piegarle verso il
basso.
3.3.Aprire il
morsetto a
sgancio rapido.

7
4.Introduzioni delle operazioni di guida
Indicatore batteria
Capacità batteria
"5 Tacche"
Batteria carica
"4 Tacche"
Circa 80%
"3 Tacche”
Circa 60%
"2 Tacche”
Circa 40%
“1 Tacca”
Sotto il 20% ricaricare il monopattino.
3.4.Abbassare il manubrio
il più possibile.
3.5 Tenere fermo il
monopattino con un piede
e con una mano spingere
lo stelo del manubrio.
3.7.Spingere verso il basso
lo stelo del manubrio fino a
quando si blocca. Per
aprirlo spingere all’insù il
pulsante di sblocco e poi
tirare su lo stelo fino a
quando si blocca.
3.4.Spingere all’insù con
un dito il pulsante di
sblocco.
