Gira eNet 5323 02 User manual

Wireless converter intermediate plug
Order No. : 5323 02
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled
persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Adapter plugs may not be connected in series and must be easily accessible.
The radio communication takes place via a non-exclusively available transmission path,
and is therefore not suitable for safety-related applications, such as emergency stop and
emergency call.
These instructions are an integral part of the product, and must remain with the end
customer.
2 Device components
Figure 1: Gateway
(1) SCHUKO socket with increased contact protection
(2) Red status LED, covered
(3) Button Prog
3 Function
Intended use
- Control of eNet actuators by Radio Bus transmitters
- Control of Radio Bus actuators by eNet transmitters
- Indoor mounting in SCHUKO® socket or socket with ground pin
iThe following Radio Bus devices are not supported: motion detectors, presence detectors,
HVAC devices, repeaters, window contacts, KNX/EIB converters and Centrals.
Product characteristics
- Reception of Radio Bus commands and conversion into eNet commands
- Reception of eNet commands and conversion into Radio Bus commands
- 24 transmitter channels from both systems can be connected
1/8
32582112 11.04.2017
Wireless converter intermediate plug
10865123

- Scene 1 to scene 5 from both systems can be recalled and changed
- All On and All Off can be recalled from both systems
- Master dimming function
Supplementary functions with eNet Server Software up to version 1.4:
- Update of the device software
- Repeater function
- Reading of error memory
Functional description
Figure 2: Inter-system radio operation
This device serves an interface between the Radio Bus, 433 MHz, and eNet, 868 MHz systems.
It allows operation of the actuators in the other system (Figure 2).
Limited functionality
The eNet system has a wider range of functions than the radio bus system. For this reason, the
following functions are not possible using the wireless converter:
- Scenes 6...16
- Threshold value functions and disabling functions
- Save switch-on brightness using transmitter
- Transmission status and status feedbacks
4 Information for electrically skilled persons
Mounting
Maintain a distance of at least 0.5 m from metal surfaces and electrical devices, e.g. microwave
ovens, hi-fi and TV systems, electronic ballasts or transformers.
Maintain a distance of at least 0.3 m between transmitter and receiver in order to prevent
overmodulation of the receiver.
oInsert device into socket outlet.
4.1 Commissioning
DANGER!
Electrical shock when live parts are touched.
Electrical shocks can be fatal.
During commissioning, cover the parts carrying voltage on radio transmitters
and actuators and in their surrounding area.
32582112 10865123 11.04.2017 2/8
Wireless converter intermediate plug

4.2 eNet transmitter controls Radio Bus actuators
iCommissioning is not possible via the eNet server.
Connecting the eNet transmitter with the Radio Bus actuator
Figure 3: Connecting the eNet transmitter
Connection takes place in two steps (Figure 3). Step A: Connect the eNet transmitter with the
gateway.
Step B: Connect the eNet transmitter to one or more Radio Bus actuators.
Step (A):
oPress the Prog button (3) of the gateway for longer than 4 seconds.
The status LED flashes after 4 seconds. The gateway is in programming mode for
approx. 1 minute.
oSwitch the eNet transmitter to programming mode as well (see eNet transmitter
instructions).
oBriefly press the channel or scene button of the eNet transmitter.
The status LED of the gateway lights up for approx. 5 seconds.
The gateway and eNet transmitter exit the programming mode automatically.
Step (B):
oSwitch one or more Radio Bus actuators to programming mode (see Radio Bus actuator
instructions).
oPress the channel button of the eNet transmitter for longer than one second or the scene
button for longer than three seconds.
The LEDs of the Radio Bus actuators light up.
The eNet transmitter is connected to the Radio Bus actuators.
oExit the programming mode of the Radio Bus actuators (see Radio Bus actuator
instructions).
32582112 10865123 11.04.2017 3/8
Wireless converter intermediate plug

Disconnect the connection to the Radio Bus actuator (C)
Figure 4: Disconnecting
Disconnection should take place before an actuator is replaced, so that occupied gateway
channels can be made free again, or before resetting to the factory setting.
oSwitch the Radio Bus actuator to be disconnected to programming mode (see Radio Bus
actuator instructions).
The LED of the Radio Bus actuator flashes slowly.
oPress the transmitter channel button connected to the Radio Bus actuator for longer than
one second or the scene button for longer than three seconds.
The connection to the Radio Bus actuator is disconnected. The LED of the actuator flashes
quickly.
oExit the programming mode of the Radio Bus actuators (see Radio Bus actuator
instructions).
Disconnect the connection between the eNet transmitter and the gateway (D)
oPress the Prog button (3) of the gateway for longer than 4 seconds.
The status LED flashes after 4 seconds. The gateway is in programming mode for
approx. 1 minute.
oSwitch the eNet transmitter to programming mode as well (see eNet transmitter
instructions).
oBriefly press the connected button of the eNet transmitter.
The connection is disconnected. The LED flashes for a few seconds.
32582112 10865123 11.04.2017 4/8
Wireless converter intermediate plug

4.3 Radio Bus transmitter controls eNet actuators
Connect the Radio Bus transmitter and eNet actuators
Figure 5: Connecting the Radio Bus transmitter
oPress the Prog button (3) of the gateway for approx. 4 seconds.
The status LED flashes after 4 seconds. The gateway is in programming mode for
approx. 1 minute.
oSwitch all the eNet actuators, which are to react to the channel or scene button, to
programming mode as well (see eNet actuator instructions).
iUp to 10 eNet actuators can be connected at the same time.
oPress the channel button on the Radio Bus transmitter for longer than one second or the
scene button for longer than three seconds.
The status LED of the gateway lights up for approx. 5 seconds.
The Radio Bus transmitter is connected to the eNet actuators. The gateway and eNet
actuators exit the programming mode automatically.
32582112 10865123 11.04.2017 5/8
Wireless converter intermediate plug

Disconnect the connection between the Radio Bus transmitter and the eNet actuator
Figure 6: Disconnecting
oPress the Prog button (3) of the gateway for longer than 4 seconds.
The status LED flashes after 4 seconds. The gateway is in programming mode for
approx. 1 minute.
oAlso switch all the eNet Bus actuators to be disconnected to programming mode (see eNet
actuator instructions).
oPress the connected channel button on the Radio Bus transmitter for longer than one
second or the scene button for longer than three seconds.
The connection to the eNet actuator is disconnected. The LED of the actuator flashes
quickly.
The eNet actuator is disconnected. The actuator exits programming mode automatically.
Resetting the device to the factory setting
All the connections in the gateway between transmitters and actuators are disconnected.
Recommissioning must take place.
iBefore resetting to the factory setting, disconnect connected Radio Bus actuators (see
Disconnecting the connection to the Radio Bus actuator). This ensures that setting up new
connections does not cause unintentional switching operations.
oPress the Prog button for at least 20 seconds.
The status LED flashes after 4 seconds. After 20 seconds the status LED flashes faster.
oRelease the Prog button and press it once again within 10 seconds.
All the connections are disconnected. The status LED flashes more slowly for approx. 5
seconds.
5 Appendix
5.1 Technical data
Rated voltage AC 230V~
Mains frequency 50 / 60Hz
Rated load current 16A (IL)
Power consumption max. 1W
Degree of protection IP 20
Ambient temperature -5 ... +45°C
Dimensions W×H×D 57×127×78 mm
Transmitting range in free field typ. 100m
Receiver category 2
32582112 10865123 11.04.2017 6/8
Wireless converter intermediate plug

eNet radio data
Radio frequency 868.0 ... 868.6MHz
Transmission capacity max. 20mW
Radio Bus radio data
Radio frequency 2
Transmission capacity max. 10 mW
5.2 Parameter list
iOnly with eNet Server Software up to version 1.4
The device parameters can be changed with the eNet server:
Settings window
Device settings
Parameters Setting options, Basic
setting
Explanations
Repeater mode On, Off
Basic setting: Off
In addition to its other
functions, the device can be
used as a repeater. In the
"On" setting, the device
repeats all the received
telegrams.
Settings, channel
Parameters Setting options, Basic
setting
Explanations
Local Operation On, Off
Basic setting: On
With this device, the
parameter has no function.
Manual commissioning On, Off
Basic setting: On
With this device, the
parameter has no function.
Sum status / transmission
repetitions
On, Off/Transmit 2x…11x,
Off/Transmit 4x (without
connection)
Basic setting: Off
With this device, the
parameter has no function.
5.3 Troubleshooting
Additional connections between the transmitter and receiver cannot be saved.
Cause: all the memory locations in the gateway are occupied.
Disconnect connections no longer required.
Or
Reset the gateway to the default setting and reconnect the transmitter and actuators.
Or
Use an additional gateway for new connections.
5.4 Conformity
Gira Giersiepen GmbH & Co. KG hereby declares that the radio system type
Order No. 5323 02
corresponds to the directive 2014/53/EU. You can find the full article number on the device. The
complete text of the EU Declaration of Conformity is available under the Internet address:
www.gira.de/konformitaet
