Info LED-Clock/Alarm Clock/Thermometer 230 V~
Instructions for Installation
LED-Clock/Alarm Clock/Thermometer 230 V~ 03/99 Page 1 of 4
LED-Clock/Alarm Clock/Thermometer 230 V~ Art. Nr.: 0096 ..
Function
The LED Clock/Alarm Clock/Thermometer has the following functions:
•Alternating display of temperature and time, or display of temperature or time.
•2 different alarm times can be set.
•The light intensity of the LED display is adjustable to 2 levels.
•Reserve power from the built-in lithium battery.
•Temperature adjustment.
Safety Note
•Caution: Installation and assembly of electrical devices may only be carried out by
electrical specialists.
•Caution! Button cells do not belong in the hands of children. Immediately seek the
assistance of a physician if button cells are swallowed.
•Do not immerse button cells in water, and do not throw these into a fire.
•Only replace a button cell with an identical type.
•Immediately remove dead button cells and dispose of in an environmentally friendly manner.
Site of Installation
Only install in closed rooms.
In order to avoid damage and inaccurate reading, you should not expose the thermometer to high
humidity, extreme temperature (in combination with a dimmer for example), vibration and shock.
Installation
The LED Clock/Alarm Clock/Thermometer is mounted in a 60 mm flush-type switch box.
For connection: see illustration c.
Caution: Only insert the batteries after connection to the supply system (see battery change).
N
L1
L
NAC 230 V
Illustration cIllustration d

GIRA
Info LED-Clock/Alarm Clock/Thermometer 230 V~
Instructions for Installation
LED-Clock/Alarm Clock/Thermometer 230 V~ 03/99 Page 2 of 4
Battery Change
The end of the battery charge is shown by a point (see illustration e) in the LED display.
1. To change the battery, remove the cover and open the battery drawer (see illustration d).
2. Replace the old battery with a new one of the same type (lithium button cell CR1025) while paying
attention to the correct polarity.
The battery is laid in the drawer with the + pole up (see illustration d).
3. Close the drawer and place the cover on the support ring again.
4. Do not dispose of batteries in normal household waste. Give the batteries to a suitable collection
point.
LED Display
BAT.
HM
123
4
5
6
Illustration e
1. Button: hours/temperature correction ↓
2. Button: brightness display/switch off alarm
signal/display change on/off
3. Button: minutes/temperature correction ↑
4. Display: alarm time 1 on/off
5. Display: alarm time 2 on/off
6. Display: battery end
Display Alternation On/Off
You can choose from alternating, time, or temperature display.
Press briefly on the button 1 x to pause the display or to start the alternating display.
Time
Display
Temperature-
Display
00:00
°C
00:00 °C
Alternating
Display
Button
press 1 x briefly
Button
press 1 x briefly
Example: The LED Clock/Alarm Clock/Thermometer constantly alternates between time and
temperature. You want only the time to be displayed. Wait until the time appears in the
LED display and then press 1 x briefly on the button . The time will now be constantly
displayed.
Press 1 x briefly on the button and the LED display alternates between temperature
and time again.
Setting the time
1. Wait or change (see: Display Alternation On/Off) to the time display.
2. Press the button H to set the hours and the button M for the minutes. To advance quickly, hold
button H or M down.

GIRA
Info LED-Clock/Alarm Clock/Thermometer 230 V~
Instructions for Installation
LED-Clock/Alarm Clock/Thermometer 230 V~ 03/99 Page 3 of 4
Setting the Alarm Time
Alarm Time 1:
1. Wait or change (see: Display Alternation On/Off) to the time display.
2. Press the button until the symbol for alarm time 1 blinks.
3. Hold the button down and set the alarm time with the buttons H and M. To advance quickly,
hold the button H or M down.
4. After setting the alarm time, release the button .
Alarm Time 2:
The adjustment of the alarm time 2 takes place as with the setting of alarm time 1. The button
must only be pressed long enough that the symbol for alarm time 2 blinks.
Switch Alarm On/Off
Alarm Time 1:
1. Wait or change (see: Display Alternation On/Off) to the time display.
2. Press the button until the symbol for alarm time 1 blinks.
3. Release the button and then briefly press the button again to switch the alarm on or off.
4. The alarm time 1 is switched on when the symbol lights up.
Alarm time 2:
The alarm time 2 is switched on/off as with alarm time 1. The button must only be pressed long
enough that the symbol for alarm time 2 blinks. Then, release the button and press briefly again.
Switch Alarm Sound Off
Press the button briefly to switch the alarm sound off.
Temperature Adjustment
The thermometer is calibrated before delivery in a climatic chamber. The temperature at the
installation site can differ from the living space temperature, due to structural conditions (outer wall,…).
Therefore, you can adjust the temperature display to the living space temperature.
1. Take a second thermometer and place it in the center of the room.
2. Wait a while and compare the two temperatures.
3. If the two measured temperatures differ greatly from one another, you can now change the
temperature display.
4. Wait or change (see: Display Alternation On/Off) to the temperature display.
5. Press the button H to lower the temperature display, or the button M to raise it. With each press of
the button H or M, the temperature display is lowered or raised by 0.5°C. This is signaled by a brief
sound. Since the temperature is displayed without decimal figures, the display only changes with
every second press of the button.
Note: In order to restore the thermometer to the delivery condition, wait or change (see: Display
Alternation On/Off) to the temperature display. Press the button (H or M) in the opposite
direction. This means that if you have raised the temperature display (button M), repeatedly
press the button H until you hear a longer sound.

GIRA
Info LED-Clock/Alarm Clock/Thermometer 230 V~
Instructions for Installation
LED-Clock/Alarm Clock/Thermometer 230 V~ 03/99 Page 4 of 4
Switch Display Light/Dark
Wait or change (see: Display Alternation On/Off) to the temperature display.
Press the button until the display brightness changes. Then, release the button .
Technical Data
Display: LED Display
Temperature Range: - 10°C to + 50°C
Display Accuracy: 1°C
Power Supply System: AC 230 V / 50-80 Hz
Battery: Lithium Button Cell CR1025
Power Consumption: Approximately 4 W
Acceptance of guarantee
We accept the guarantee in accordance with the corresponding legal provisions.
Please return the unit postage paid to our central service department giving a brief description
of the fault:
Gira
Giersiepen GmbH & Co. KG
Service Center
Dahlienstrasse 12
D-42477 Radevormwald
The CE sign is a free trade sign addressed exclusively to the authorities and does not include
any warranty of any properties.
