GKB 5017 User manual

GKB 5017 Analog Camera
!
!
!
!
GKB 5017 Analog Camera
Ultra High 700TVL IR Bullet Camera with Fixed Lens
!!!!!!!
!
!!!!!!!!!!!!
Before operating this unit, please read this manual
thoroughly and retain it for future reference.
Bracket is Licensed by Hwan Ming
Enterprise Co., Ltd!
User’s Manual
!

GKB 5017 Analog Camera
!!
!
1
About this Manual
This user manual is for use with the GKB 5017 Analog Camera. This
document contains important information and instructions detailing
proper operation and maintenance of GKB 5017 Analog Camera.
Be aware that GKB 5017 Analog Camera must be installed and used
in accordance with the instructions given in this manual. Before
installing or operating the unit, please read all safety notes and
warnings provided in this manual.
GKB 5017 Analog Camera is a surveillance device for use in security
systems that assist in the management of security. GKB is not liable nor
can be held responsible for any material loss and/or personal injuries
cause by robbery, fire, natural disaster or problems of any kind resulting
from the use of this device.
!
!
!
!
Do not dispose this camera as general waste. This product must be treated as a
recyclable product. Contact your local government recycling program or the
supplier of the product to confirm the proper method of disposal.
!
!

GKB 5017 Analog Camera
!
!
2
Warning and Precaution
Warning
This information is provided to ensure your safety and to prevent loss
either physical or financial. Read carefully before using the product. Read
all sections of this manual where the following marks are shown.
Ignoring this may result in material loss and/or serious
personal injury including death.
Ignoring this may result in material loss and/or slight personal
injuries.
Do not disassemble

GKB 5017 Analog Camera
!!
!
3
!
Precaution
Do not expose the camera to radioactivity and mount
facing strong light sources.
Exposing the camera to radioactivity or strong light over
long periods of time will damage the camera’s sensor.
Do not supply voltage higher than 12V DC.
GKB 5017 Analog Camera regulates power within this
range. Higher voltages will damage the camera’s
electronic components.
Do not install the camera under unstable light
conditions.
Installing GKB 5017 in environments with unstable light
conditions may cause the camera to function
abnormally.
!
!
!
!
!
!
!
!
!
!
!
!
!

GKB 5017 Analog Camera
!!
!
4
Package Content
Product Overview
Bullet Camera*1
Screw Driver Pack*1
User’s Manual*1

GKB 5017 Analog Camera
!
!
5
Installation Instructions
1. Place the bullet camera on the place you desired.
2. Connect power supply jack to DC 12V and the BNC Video Output to the desired
video line.
3. Adjust lens in correct focus, so the camera will point to the desired direction.
Features
GKB 5017 Analog Camera
!1/3" Sony Super HAD CCD II presents lower lux illumination and clear/crispy picture.
!Ultra High 700 TVL Resolution
!28 LEDs. Radiant Distance at least 20M.
!D-WDR(Digital Wide Dynamic Range).
!2D-DNR(2D Digital Noise Reduction).
!Back Light Compensation.
!Lens Shading

GKB 5017 Analog Camera
!!
!
6
Specification
GKB 5017 Analog Camera
Model Number
GKB 5017
Image Sensor
1/3” Sony Super HAD CCD II
Number of Pixels
<NTSC>: 976(H)*494(V); <PAL>:976(H)*582(V)
Resolution
700 TV Line
Min. Illumination
Color:0.01lux
B/W:0.0001lux
Shutter Control
AUTO, 1/60(1/50)~1/100,000
Auto Gain Control
ON
White Balance
ATW
Back Light
Compensation
BLC
Day & Night
ATUO
Gamma
0.45
S/N Ratio
More than 50 dB
Sync. Mode
Internal
Scanning System
2:1 Interlace
Horizontal Sync
Frequency
<NTSC>: 15.734 KHz ; <PAL>15.625KHz
BNC Video Output
1.0 Vp-p, 75 ohm
D-WDR
ON
2D-DNR
ON
Lens Shading
ON
Infrared LED
28pcs,25M*
Power Supply
DC 12V
Power Consumption
4W
Lens
4.0mm Fixed Board Lens
Ingress Protection
IP 66
Dimension
78(Ø) * 118(L) mm
Weight
0.3 kg
Operating
Temperature
-10 ~ 50 / 30% ~ 80% RH
Specifications are subject to change without prior notice. V1.0
Please refer to the website ”http://www.gkbsecurity.com.“ for more information.
* Depending on Scene Reflection.
!
!
!

GKB 5017 Analog Camera
!!
!
CR100000302
© 2013 GKB Security Corporation. Specifications are subject to change without prior notice.
Warranty Policy
Warranty Period
For detailed information on product warranties and warranty claim, please contact
your local GKB distributor or agent.
!
