Glastar super star II User manual

To print out this manual: click the PRINT icon at the top
of your browser window or select print from the file menu.
Super Star II™ & Diamond Star Grinders
Eye Protection Operation Diamond Grinding Heads
Maintenance Straight Edge Guide
DIAMOND GLASS GRINDER MANUAL
SUPER STAR II & DIAMOND STAR
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS
FOR PERSONAL SAFETY THIS MACHINE MUST BE PROPERLY GROUNDED
The power cord of this machine is equipped with a three-prong (grounding) plug which mates with a standard
three-prong (grounding) wall receptacle to minimize the possibility of electric shock hazard. Where a
standard two-prong wall receptable is encountered, it is the personal responsibility and obligation of the
customer to have it replaced with a properly grounded three-prong wall receptacle. DO NOT, UNDER ANY
CIRCUMSTANCES, CUT OR REMOVE THE THIRD (GROUNDING) PRONG FROM THE POWER CORD.
Always unplug your machine before cleaning or making any repairs-(NOTE: We strongly recommend that you return the
unit to the factory for repair.) USE ONLY IDENTICAL REPLACEMENT PARTS TO REPAIR THIS MACHINE.
SAVE THESE INSTRUCTIONS
OUTSIDE USA [phone] · INSIDE USA [phone]
FAX [phone] · WEBSITE www.glastar.com

Page
1
of
5
Glastar
10/24/2012
http://www.glastar.com/manuals/ss
-
ds.cfm

EMAIL: [e-mail]
VENTILATION
Openings in the grinder back and bottom are provided for ventilation. To insure reliable operation
and to protect the grinder from overheating, these openings must not be blocked or covered. Do not
place grinder near or over a radiator or heating vent. If this unit is installed within another enclosure,
be sure that adequate ventilation has been provided.
OPERATION
First install the flexible stopper in the drain hole located in the left-front corner of the water basin. Make
certain it is pushed in hard; then add water. It is not necessary to completely fill the reservoir. Add enough
water - about two cups - so the water level is at least touching the bottom of the grinding head. Then dip the
sponge in water and squeeze it several times to make certain it is thoroughly wet. Replace the sponge in its
pocket behind the grinding head, and turn on the grinder. As the head turns, water is pumped into the
sponge, keeping it soaking wet. The wet sponge keeps the diamond surface clean and cool. never use the
machine without first checking the water level and making certain the sponge is in place behind the grinding
head. If you notice a white paste or powder building up on the piece of glass being ground, the sponge is not
keeping the head wet enough. You should adjust the sponge by raising it a little higher on the head, or you
may have to add more water to the machine. If you use the diamond grinding head dry, you will considerably
shorten its life.
When you start to grind, push the glass against the grinding head with firm pressure. The diamond surface cuts better
with firm pressure against it. Excessive pressure will not hurt the diamond surface, although it may slow or stop the
motor. If this happens, don't be concerned. Just back the glass off slightly...and the motor will resume its normal speed.
If you have to make a deep cut into the glass in one specific area, it is best to use intermittent pressure. By using this
technique, you will allow the sponge to clean the glass residue from the diamond so that it cuts more efficiently.
Grinder coolant should prolong the life of the diamond head. A solution of 1 part coolant to 64 parts water or 1
tablespoon to 2 cups of water is recommended.
The head slings water as it rotates. The splash guard catches most of this water and returns it to the reservoir. If your
finger touches the diamond head when it is rotating, it will feel smooth. The diamond surface is not nearly the hazard to
fingers as is a belt sander or a silicone carbide grinding wheel.
TOP of page
DIAMOND GRINDING HEADS
The diamond cutting surface of the head is 5/8" (15.875 mm) high. Glastar has installed the head so that the
full 5/8" (15.875 mm) of diamond extends above the top plate. If all the glass you grind is 1/8" (3.175 mm)
thick or less, you will only use the lower one-fifth of the cutting surface. When the diamond cutting surface
dulls, lower the head 1/8" (3.175 mm). This will provide a new, sharp grinding surface. When that area dulls,
lower the head another 1/8" (3.175 mm) and so forth. This will allow five surfaces; each surface should last
approximately 20 to 50 hours, a total of 100 to 250 hours of grinding from one head. If you grind 1/4" (6.350
EYE PROTECTION
When operating the grinder, always protect yourself against
eye injuries from flying glass. Wear safety glasses or use
one of the Glastar eye shields. Either the glass or plastic
type is available as an option from your dealer. They mount
over the grinding head and keep flying chips from hitting the
face or hair.
Page
2
of
5
Glastar
10/24/2012
http://www.glastar.com/manuals/ss
-
ds.cfm

mm) thick glass, you lower the head 1/4" (6.350 mm) to change to a new, fresh surface. This gives you two
grinding surfaces per head.
It is difficult to quote a specific number of hours that the diamond cutting head will last. Like sandpaper, it does not wear
out all of a sudden. Instead, the cutting head gradually begins to dull. The head's durability depends on the type of glass
you are grinding and your definition of dull. The 20 to 50 hours per surface is an estimate. Some claim more than 100
hours per surface, while others change to a fresh surface after 10 hours. Of course you should expect far less life if you
are grinding rocks. Never grind any metal (i.e. lead, copper) with the diamond head. This will make the diamond
surface unusable for glass in a matter of seconds.
To lower the 3/4" (19.050 mm) head, loosen the set screw near the top of the head with the Allen key. The loosened
head will slide up and down on the motor shaft with ease. Each time you re-position the cutting head, Glastar
recommends the application of a lubricant, such as Vaseline, to the motor shaft. When re-tightening the set screw with
the Allen key, make certain the screw is set against the flat side of the motor shaft.
TOOL DRAWER
This drawer provides quick access for all those items needed when operating the grinder, such as extra
grinding heads, Allen key, sponges, straight edge guide etc.
MAINTENANCE
The grinder's only moving part is the electric motor which has permanently lubricated bearings. No
maintenance is required.
After using the grinder for a short period, you will find that a very fine white paste, made up of glass particles,
collects at the bottom of the reservoir. This glass will also collect in the sponge and will eventually inhibit the
movement of water. Therefore, after every hour of use, remove the sponge, hold it under a water faucet, and
squeeze it several times to rinse it clean. Every four hours of use, clean the reservoir of ground glass.
To clean the reservoir, unplug the machine and remove the white plastic work surface. Move the left front corner of the
grinder over the edge of your work bench. Place an empty container under the drain hole and unplug the stopper in the
basin. After all of the water has drained out, use a large sponge to remove the white paste from the reservoir. Don't
forget to replace the stopper before refilling your machine.
For hassle-free reservoir cleaning, use Glastar's disposable reservoir tray. When the tray fills up with glass residue, drain
the water as described above, and dispose of the tray. Then, replace with a new tray and be sure to insert stopper.
TOP of page
GLASS SCRATCHES
Despite the grid-type of work surface, some finely-ground glass may stick to the top plate, and it can scratch
smooth, soft glass, such as 3/16" (4.7625 mm) or 1/4" (6.35 mm) plate, and some antique glasses. If you are
working with soft glass, it would be wise to place several strips of masking tape on the bottom of the glass to
raise it off the table.
Diamond Star
In this carton, along with the grinder, you will find the following items.
Super Star II
In this carton, along with the grinder, you will find all of those items listed under DIAMOND STAR as well as
a 1/4" (6.350 mm) Grinding Head and Adjustable Straight Edge Guide.
1. A flexible splash guard, which is to be installed on the top plate behind the grinding head.
2. Four adhesive backed rubber feet to be installed on the bottom of the grinder.
3. A one inch sponge which provides water to the grinding head, and two spares.
4. An Allen key to raise or remove the head.
5. An owner's manual and warranty card.
6. A flexible drain stopper.
7. An insert for 1" grinding head.
Page
3
of
5
Glastar
10/24/2012
http://www.glastar.com/manuals/ss
-
ds.cfm

1/4" GRINDING HEAD
This small head allows you to grind very tight inside curves that you otherwise could not get to using the
main 3/4" (19.050 mm) head. The 1/4" (6.35 mm) head has one additional feature. It can be used to drill
holes in glass. Hold your piece of glass at approximately a 45 °angle to the work surface as shown. Use a
squeeze bottle to keep the head wet.
STRAIGHT EDGE GUIDE
This accessory permits one to grind straight-sided rectangles to exact
size. The glass is pushed between the guide and the grinding head. It
operates exactly like a fence on a table saw.
To install the guide, turn it upside down and load the five nylon rollers
onto the pegs on the guide. Place a piece of paper on top of the rollers.
Then turn the guide (paper and all) right side up onto the top plate. Slide
the paper out from between the guide and the work surface. Move the
guide so that the rollers face the grinding head and it is centered right to
left.
Set the guide at the distance from the head you desire. Put the 1" (2.54 cm) #12
screws with washers into holes "B" in the guide and screw them into the available holes in the top plate. BE CAREFUL:
Do not over-tighten the screws. It takes very little tension to hold the guide in place.
Push the glass from right to left ONLY. The arrow on the guide indicates the direction of the glass. You may grind pieces
up to 6" (15.24 cm) in width.
INPUT POWER
5 YEAR NO FAULT WARRANTY
WHAT WE WILL DO
This warranty is extended by GLASTAR CORPORATION to the original purchaser and to any succeeding owner. If your GLASTAR GRINDER
fails for any reason within the first 5 years from the date of manufacture, we will repair the product without charge for parts or labor.
To register this product, click here
HOW TO OBTAIN SERVICE
If you have any problem with your GLASTAR GRINDER call the GLASTAR TOLL FREE NUMBER for an authorization number. Then pack the
machine well and return it post-paid to GLASTAR. We will repair your grinder as rapidly as possible and return it to you post-paid.
WHAT IS NOT COVERED
This warranty does not cover wear of the top plate (work surface) or the diamond grinding surface.
This warranty applies to U.S. and Canada only.
TOP of page
MODEL SUPER STAR II DIAMOND STAR
G12 G121 G14 G141
VOLTAGE 115V 220/240V 115V 220/240V
FREQUENCY 60 hz 50 hz 60 hz 50 hz
FULL LOAD CURRENT 1.3A .60A 1.45A .55A
