Glastender UCR24S-L User manual

Operation Manual, Parts Directory and Price List
Glastender, Inc. · North Michigan Road · Saginaw, MI · 48604-9780
800.748.0423 · 989.752.4275 · Fax [phone] · www.glastender.com
© 2008 Glastender, Inc.
UndercoUnter refrigerator
UCR24S-L & UCR24S-R
Rev. 08-26-08
IMPORTANT!!
Attention Refrigeration Service Companies
Please review the important warranty information on page 4. If you believe a
service call should be covered by the factory, please call the factory for authorization
between 8AM and 5PM EST, Monday through Friday.
UCR24S-L

Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
2
operation
The operating temperature range is 36°F (2°C) to 40°F (5°C).
UCR24S models include an automatic defrost system. The refrigerator will defrost every six hours for approxi-
mately 20 minutes. During the defrost, the fan inside the cooler will remain on and the refrigeration system will
turn off.
technical information
• Electrical: 120 Volt AC, 1 Phase, 60 Hz. 4.7 full load Amps, 1/4HP A separate 15 Amp circuit is recom-
mended. A 6-foot grounded cord and plug is included with self-contained models.
• Plumbing:
Automatic condensate evaporator is included. No drain connection required.
• Refrigerant: 10.0 oz, R134a, Operating pressure high is 186 PSIG, low is 88 PSIG.
cleaning instrUctions
Cleaning is essential to sustaining the integrity of your equipment and preventing corrosion.
ESTIMATED CLEANING TIME: 5 to 10 minutes per unit daily, 45 minutes quarterly
FREQUENCY: Daily cleaning of exterior & door gaskets. Quarterly cleaning of interior, including shelves.
PROCEDURE:
1. A non-chlorine based cleaner or mild detergent and warm water applied with a soft cloth or sponge to all
contact surfaces.
2. Immediately rinse off cleaning agent(s), using clean warm water, clean soft cloth or sponge.
3. Dry with a soft clean cloth, removing standing water as soon as possible.
NOTES:
1. Never use hydrochloric acid, wire brushes, steel wool, scrapers, or chlorine based cleaners on stainless steel
surfaces, since they will break down the passivity layer and allow corrosion to occur.
2. On stainless steel surfaces, you may use a soft bristle brush or Scotch-Brite®pad for more stubborn stains.
Always scrub with the direction of the grain. Follow with a thorough cleaning as described above.
3. Deposits from food preparation must be properly removed. Even hard water deposits will rust stainless steel,
if not removed.
4. The cooler door gaskets are most often overlooked when cleaning. Failure to clean them regularly will lead to
premature failure, since alcohol and moisture build-up breaks down the gasket material.
sealing refrigerator to floor
To comply with NSF & health codes, the refrigerator base must be sealed to the floor using NSF listed sealant.
Place a bead of sealant along outer edges of the base and remove excess with disposable towel. The floor seal-
ing procedure does not apply to models that include legs or casters.
Ucr24s UndercoUnter refrigerator

Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com 3
replacement parts
part no. description price
06001384 Accumulator $40.00
13000048 Bracket, fan, condenser 4.50
13000030 Bracket, fan, evaporator 4.00
11000121 Capillary tubing, 0.036” x 48” 20.00
11000084 Compressor, 1/4 HP, R134A Tecumseh 370.00
11000080 Condenser coil 170.00
13000050 Door 360.00
06003713 Door gasket, 21-7/16” x 22-1/16” 42.00
13000031 Drain pan, condenser 40.00
13000002 Drain pan, evaporator 45.00
07000504 Evaporator coil, 6” x 16” 180.00
09000298 Fan blade, 5 blade, black 5.00
07000155 Fan blade, 5, silver 10.00
06004028 Filter dryer with service port 25.00
13000025 Grill, compressor back 80.00
13000026 Grill, front 35.00
06003721 Handle, door, black polypropylene (before serial #134107902F) 20.00
13000055 Handle, door, stainless (serial #134107902F and after) 22.20
13000052 Hinge set, left 25.00
13000053 Hinge set, right 25.00
06001424 Lens cover, fluorescent bulb 10.00
08000131 Light socket with wire lead 4.00
09000333 Light, fluorescent 23.50
13000062 Lock, door 25.00
13000061 Key, #C346A, for UCR24S door lock (13000062) 4.00
06001449 Motor, condenser fan, 6 watt, 115V 95.00
06001445 Motor, evaporator fan, 115V 35.00
06001303 Overload, compressor 9.00
06001415 Relay, compressor 19.00
06001412 Rocker switch, light 5.00
06003714 Shelf, 19.7” x 13.1” gray 77.00
13000028 Shroud, evaporator 75.00
13000006 Shroud, fan, condenser 25.00
06001421 Starter base, fluorescent base 18.00
06001420 Starter, fluorescent 5.00
06001553 Thermometer 6.00
06001405 Thermostat, with knob, 34° 50.00
06001632 Knob only 3.00
06001397 Timer, defrost, automatic, 6 hour 32.00
13000051 Wicking material, 5 pieces, 2.5” x 6.75” 14.00

Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
4
Warranty statement
LABOR: Glastender, Inc. warrants all products to be free of defects in
material and workmanship. In established areas, a start-up and a 90-
day labor warranty are included with glasswasher models GT-24 and
GT-30. The GT-18 series glasswashers include a 90-day labor warranty.
Self-contained refrigeration models, except beer line chillers, include a
1-year labor warranty, for the duration of one year from date of instal-
lation or up to 18 months from date of factory shipment, whichever
occurs sooner. For warranty labor claims beyond 15 months from the
date of factory shipment, proof of date of installation or occupancy must
be provided. Authorization for labor must be obtained from Glastender
within the warranty period and prior to the service being performed.
Labor warranty applies to the United States and Canada only.
PARTS: Within one year from date of installation, or 15 months from
date of factory shipment, whichever occurs sooner, Glastender, Inc.
will replace any part or assembly found defective under normal use and
service. Field replacement parts include a warranty of 90 days from date
of installation. All self-contained refrigeration models include a 5-year
compressor warranty.
A warranty claim form MUST accompany all returned defective parts or
assemblies. This form MUST be completed in full. Failure to do so may
result in delay or denial of credit. Any defective part or assembly must
be returned to Glastender, Inc., Saginaw, Michigan, with all transporta-
tion and delivery charges prepaid. Warranty repairs or replacements will
be shipped FOB factory in Saginaw, Michigan.
The warranty does not cover equipment subjected to accidents, freight
damage, alterations, improper power and/or plumbing hookups, improp-
er chemical use, general misuse, or lack of routine required maintenance
as determined by Glastender, Inc.
No representative, distributor, dealer, or any other person is authorized
to modify this warranty. This warranty replaces all other written or
verbal warranties.
NOTE: Glastender, Inc.’s policy of constant quality improvement
means that prices, specifications, and policies are subject to change
without notice. Questions regarding this warranty should be directed to
Glastender’s Customer Service Representative.
03/01/07
Wiring diagram for Ucr24s models
EVAPORATOR FAN
BLACK
COM RELAY
STARTER
RUN START
WHITE
OVERLOAD
BLACK
ORANGE
THERMOSTAT
ORANGE
BLUE
MAIN
16ga Wire
115v AC
POWER
CORD
SUPPLY
5.5amp
BLUE
BLACK
BLACK
CONDENSER FAN
WHITE
GREEN
60hz
LIGHT SWITCH
LIGHT
BLUE
WHITE
WHITE
WHITE
4 32 1
DEFROST TIMER
COMPRESSOR
RED
YELLOW
S
STARTER
BALLAST BLACK
ALL WIRE TO BE 16 GA.
