This manual applies to UCR units manufactured after July 23, 2008 and starting
with SN 134117542F. For UCR units manufactured prior, please see Undercounter
Refrigerator - Archived Operation Manual and Parts Directory.
A Family Company Manufacturing
In The USA Since 1969
Operation Manual, Parts Directory, and Price List
UndercoUnter refrigerator
UCR24X-L, UCR24X-R, UCR24S-L, & UCR24S-R
IMPORTANT!!
Attention Service Companies
Please review the important warranty information on page 4. If you believe a
service call should be covered by the factory, please call the factory for authorization
between 8AM and 5PM EST, Monday through Friday.
UCR24S-LUCR24X-L

2
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
operation
The operating temperature range is 34°F (1°C) to 39°F (4°C).
UCR24S models include an automatic defrost system. The refrigerator will defrost every six hours for approximately 20 minutes. During the defrost,
the fan inside the cooler will remain on and the refrigeration system will turn off.
technical information
• Electrical: 120 Volt AC, 1 Phase, 60 Hz. 2.75 full load Amps, 1/4HP A separate 15 Amp circuit is recommended. A 6-foot grounded cord
and plug is included with self-contained models.
• Plumbing:
Automatic condensate evaporator is included. No drain connection required.
• Refrigerant: 6 oz, R134a, Operating pressure high is 210 PSIG, low is 88 PSIG.
cleaning instrUctions
Cleaning is essential to sustaining the integrity of your equipment and preventing corrosion.
ESTIMATED CLEANING TIME: 5 to 10 minutes per unit daily, 45 minutes quarterly
FREQUENCY: Daily cleaning of exterior & door gaskets. Quarterly cleaning of interior, including shelves.
PROCEDURE:
1. A non-chlorine based cleaner or mild detergent and warm water applied with a soft cloth or sponge to all contact surfaces.
2. Immediately rinse off cleaning agent(s), using clean warm water, clean soft cloth or sponge.
3. Dry with a soft clean cloth, removing standing water as soon as possible.
nOTES:
1. Never use hydrochloric acid, wire brushes, steel wool, scrapers, or chlorine based cleaners on stainless steel surfaces, since they will break down
the passivity layer and allow corrosion to occur.
2. On stainless steel surfaces, you may use a soft bristle brush or Scotch-Brite®pad for more stubborn stains. Always scrub with the direction of
the grain. Follow with a thorough cleaning as described above.
3. Deposits from food preparation must be prop-
erly removed. Even hard water deposits will rust
stainless steel, if not removed.
4. The cooler door gaskets are most often over-
looked when cleaning. Failure to clean them
regularly will lead to premature failure, since
alcohol and moisture build-up breaks down the
gasket material.
sealing refrigerator to floor
To comply with NSF & health codes, the refrigerator
base must be sealed to the floor using NSF listed seal-
ant. Place a bead of sealant along outer edges of the
base and remove excess with disposable towel. The
floor sealing procedure does not apply to models that
include legs or casters.
Ucr24 UndercoUnter refrigerator
Wiring diagram
Ucr24 models

3
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
part no.description price
07000133 Bracket, fan, condenser $20.00
06004180 Bracket, fan, evaporator 14.00
06001359 Capillary tubing, .049" ID x .099" OD x 93" 20.00
06008990 Compressor, 1/6 HP 115V R134a 390.00
04000100 Condenser coil 130.00
13000050 Door, stainless steel right hand 360.00
13000064 Door, stainless steel left hand 360.00
06004063 Door, glass stainless steel left hand 738.00
06004083 Door, glass stainless steel right hand 738.00
06003713 Gasket, door, UCR24 cooler, black, 22-1/2" x 23" OD 42.00
13000031 Drain pan, condenser 40.00
13000002 Drain pan, evaporator 45.00
11000079 Evaporator coil, 6" x 16" 215.00
09000298 Evaporator fan, 5 blade, black 5.00
09000298 Condenser fan, 5 blade, black 5.00
06001385 Filter dryer, 1/4" x 1/4" 20.00
13000093 Grill, front 35.00
13000055 Handle, door, stainless 22.20
13000052 Hinge set, left (consists of part numbers 13000041 and 13000043) 25.00
13000053 Hinge set, right (consists of part numbers 13000042 and 13000044) 25.00
06009684 Power supply for LED lightstrip kit 60.00
06006108 LED light strip, 2 lights @ 14" long 25.00
13000062 Lock, door 30.00
13000061 Key, #C346A, for UCR24S door lock (13000062) 4.00
06001445 Motor, condenser fan, 115V 45.00
06001445 Motor, evaporator fan, 115V 45.00
06009287 Overload protector, compressor 15.00
06009279 Relay, compressor 15.00
06009280 Start capacitor, compressor 21.00
06001412 Rocker switch, light 5.00
06003714 Shelf, 19.25" x 13.125" gray 77.00
06007476 Thermostat, switch, digital temperature 165.00
06003951 Probe 30.00
06001565 Clip, pilaster (shelf clip) 2.00
06001574 Thumb screw, for pilaster 2.00
06001564 Pilaster 5.00
06001383 Guard, evaporator fan 12.00
06009527 Power cord, exterior, 132" long 35.00
13000045 Bracket, lock 15.00
07000236 Wicking material, 2.5" wide 30.00
replacement parts

4
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Warranty statement
APPLICABLE TO ALL PRODUCTS SOLD WITHIN THE UNITED STATES AND CANADA
Glastender, Inc. warrants all products to be free of defects in mate-
rial and workmanship. One-year labor and parts warranty applies to
all glasswashers, self-contained refrigeration models, and BDS model
bottle disintegration units. In established areas, a start up is included
with GT-24 and GT-30 model glasswashers. Warranty is effective for
one year from the date of installation or up to 18 months from date of
factory shipment, whichever occurs sooner. Glastender, Inc. will replace
any part or assembly found defective under normal use and service.
For warranty labor claims beyond 15 months from the date of factory
shipment, proof of date of installation or occupancy must be provided.
Authorization for labor must be obtained from Glastender within the
warranty period and prior to the service being performed.
Labor warranty applies to the United States and Canada only.
Remote refrigeration models and beer line chillers include a one-year
parts warranty only. There is no labor warranty on these products.
Field replacement parts not covered under the original warranty include
a 90-day part warranty from the date of installation.
FOUR YEAR ADDITIONAL COMPRESSOR WARRANTY:
Glastender will warrant to the original user the compressor for all self-
contained refrigeration models for an additional four years following the
regular one-year warranty period. This plan applies to the compressor
only.
A completed warranty claim form MUST accompany all returned defec-
tive parts or assemblies. Upon request, a defective part or assembly must
be returned to Glastender, Inc., Saginaw, Michigan, with all transporta-
tion and delivery charges prepaid. Warranty repairs or replacements
will be shipped FOB factory in Saginaw, Michigan. Reimbursement for
applicable freight charges covers ground service only.
Glastender provides in-warranty repairs during a service company’s
regular working days and hours. There is no provision for payment
of a premium rate during “overtime” hours. When warranty service is
requested during other than normal working hours, the end user will be
charged the premium portion of the overtime rate.
The warranty covers substantiated travel expenses for up to 2 hours /
100 miles round trip and a maximum of $150. Any additional costs due
to installations that require extra work, time, or travel to gain access
for service are the sole responsibility of the equipment purchaser. Any
exceptions to these travel and access limitations must be pre-approved
by a factory representative.
The warranty does not cover equipment subjected to accidents, freight
damage, alterations from the original design, improper power and/or
plumbing hookups, improper chemical use, general misuse, or lack
of routine required maintenance as determined by Glastender, Inc.
Installation, normal control adjustments, general maintenance, correct-
ing an installation error, or service calls that reveal the unit is function-
ing normally will not be reimbursed under warranty.
Condenser coils on self-contained refrigeration products must be
cleaned regularly. Failure to provide adequate air flow to a refrigeration
unit will void the warranty.
Glastender shall not be liable for loss of use, revenue, or profit, or for
any other indirect, incidental, special, or consequential damage includ-
ing, but not limited to, product spoilage or loss.
This warranty is conditioned upon Glastender receiving notice of any
defect subject to this warranty within sixty (60) days of its discovery
by the end user or dealer. All products are warranted only for the initial
place of installation. Removal of a product automatically terminates
this warranty.
SECOND YEAR EXTENDED PARTS & LABOR WARRANTY:
Glastender’s one-year parts and labor warranty on self-contained refrig-
eration units, excluding beer line chillers, can be extended to two years
with the purchase of a two year parts and labor warranty. Specify part
number EWR2 ($150 net price) when ordering.
EXPORT WARRANTY - One year parts only.
EXCLUSION OF WARRANTIES
EXCEPT AS PROVIDED ABOVE, GLASTENDER MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
OR NON-INFRINGEMENT.
LIMITATION OF REMEDIES AND DAMAGES
If Buyer makes a valid and timely claim as outlined above, Glastender’s
liability and Buyer’s remedies under this agreement will be limited solely
to labor charges authorized and/or replacement or credit, at Glastender’s
option, with respect to Products returned at Buyer’s expense within thir-
ty (30) days after warranty repair. GLASTENDER’S LIABILITY WILL
IN NO EVENT BE GREATER IN AMOUNT THAN THE PURCHASE
PRICE OF THE RETURNED PRODUCTS. GLASTENDER
WILL NOT BE LIABLE UNDER ANY CIRCUMSTANCE FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, INCLUDING,
BUT NOT LIMITED TO, LABOR COSTS EXCEPT AS COVERED
UNDER OUR WARRANTY, LOST PROFITS OR THE LOSS OF
PERISHABLE PRODUCTS RESULTING FROM THE USE OF OR
INABILITY TO USE OUR PRODUCTS OR FROM OUR PRODUCTS’
INCORPORATION INTO OR BECOMING A COMPONENT OF
ANY OTHER PRODUCT. NEITHER PARTY WILL HAVE ANY
NEGLIGENCE OR OTHER TORT LIABILITY TO THE OTHER, OR
TO ANY THIRD PARTY, ARISING FROM ANY BREACH OF THIS
AGREEMENT.
GOVERNING LAW - JURISDICTION
The terms and conditions of an order are to be governed and construed
according to the laws of the State of Michigan, without regard to conflict
of laws principles. Buyer hereby consents to the jurisdiction and venue
of the courts located in Saginaw County, Michigan.
No representative, distributor, dealer, or any other person is authorized
to modify this warranty. This warranty replaces all other written or
verbal warranties.
NOTE: Glastender, Inc.’s policy of constant quality improvement
means that prices, specifications, and policies are subject to change
without notice. Questions regarding this warranty should be directed to
Glastender’s Warranty Administrator.
