GLEELITE GLZ19S User manual

www.gleelite.com
1
-
GLZ19S Zoom LED Wash
User manual
Thanks for choosing our goods please read this manual carefully before your operating

www.gleelite.com
2
Contents
Introduction .........................................................3
Dimensions...........................................................4
Safety Information ...............................................5
.5
Using for the first time .........................................7
AC power..............................................................8
Data link................................................................9
Setup& Menu chart ...............................................10
Operation and effects...........................................13
DMX Protocol......................................................15
Channel Function.................................................22
Service and maintenance......................................25

www.gleelite.com
3
Introduction
This kind of wash use 19*15W Osram 4in1 RGBW leds with low energy consumption
super brightness and long life time,it allow you to create an endless range of variations
color and super effects.
19pcs 15W multi color LEDs individually controllable offer more options for the
designers and also with eye candy looks LEDs offer single lens with fully pre mixed
color. Beam angle zooming 11-58 degrees provide both Beam and Wash effects.
Features
Color mixing: multi RGBW 4 in 1 LED,individually controllable with eye candy looks
LED board,RGB color mixing.
Beam color temperature control: CTO variable 10 000 - 2500 K
5 DMX Channels mode: 14CH 17CH 28CH 74CH 93CH 85CH
Color LCD display,New design operation buttons
Input : 100V~240V,50Hz~60Hz
DMX input port:3pin;5pin XLR
Pan / tilt:540°/ 270°16bit
Fan cooling
Color macro effects
Linear smooth dimming 0-100%

www.gleelite.com
4
Dimensions
AII dimensions are in millimeters

www.gleelite.com
5
Safety Information
The following symbols are used to identify important safety information on the product and in this manual
DANGER!
DANGER!
WARNING!
WARNING!
WARNING!
WARNING!
WARNING!
Safety hazard.
Hazardous
Fire hazard.
LED light
Burn hazard.
Wear protective
Refer to user
Risk of severe
Voltage.Risk
emission. Risk
Hot surface.
eyewear.
manual.
injury or death
of lethal or
of eye injury.
Do not touch
electric shock.
it.
Warning!
Risk Group 3 (high risk) LED product according to EN 62471. Do not view the light
Output with optical instruments or any devices that may concentrate the beam.
This product is for professional use only.It is not for household use.
This product exist risks of severe injury or dead due to fire and burn hazard.!
electric shock and falls.
Read this manual before installing powering or servicing the fixture.
follow the safety precautions below and observe all warnings in this manual and printed on
the fixture.Contact the dealer if needed.

www.gleelite.com
6
PROTECTION FROM ELECTRIC SHOCK
• Disconnect the fixture from AC power before removing or installing any
cover or part and when not in use.
• Always ground (earth) the fixture electrically.
• Use only a source of AC power that complies with local building and
electrical codes and has both overload and ground-fault (earth-fault) protection.
• Before using the fixture check that all power distribution equipment and
cables are in perfect condition and rated for the current requirements of all
connected devices.
• Power input and throughput cables must be rated 20 A minimum,have three
conductors 1.5 mm2 (16 AWG) minimum conductor size and an outer cable
diameter of 5 - 15 mm (0.2 - 0.6 in.). Cables must be hard usage type (SJT or
equivalent) and heat-resistant to 90°C (194°F) minimum. In the EU the cable
must be HAR approved or equivalent.
• Use only Neutrik Powercon NAC3FCA cable connectors to connect to power
input sockets. Use only Neutrik Powercon NAC3FCB cable connectors to
connect to power throughput sockets.
• Isolate the fixture from power immediately if the power plug or any seal cover
cable or other component is damaged defective deformed wet or showing signs
of overheating. Do not reapply power until repairs have been completed.
• Do not expose the fixture to rain or moisture.
PROTECTION FROM BURNS AND FIRE
• Do not operate the fixture if the ambient temperature (Ta) exceeds 40°C
(104°F).
• The exterior of the fixture becomes hot during use. Avoid contact by persons
and materials. Allow the fixture to cool for at least 10 minutes before handling.
• Keep all combustible materials (e.g. Fabric,wood,paper) at least 100 mm
(3.9 in.) away,from the fixture.
• Keep flammable materials well away from the fixture.
• Ensure that there is free and unobstructed airflow around the fixture.
• Do not expose the front glass to sunlight or other strong light sources from any
angle.

www.gleelite.com
7
• Do not illuminate surfaces within 200 mm (7.9 ins.) of the Gaea.
• Do not attempt to bypass thermostatic switches or fuses.
• Do not stick filters masks or other materials onto any optical component.
• Do not modify the fixture in any way not described in this manual
PROTECTION FROM INJURY
• Do not look at LEDs with magnifiers telescopes binoculars or similar optical
instruments that may concentrate the light output.
• Fasten the fixture securely to a fixed surface or structure when in use. The
fixture is not portable when installed.
• Ensure that any supporting structure and/or hardware used can hold at least
10 times the weight of all the devices they support.
• Allow enough clearance around the head to ensure that it cannot collide with
an object or another fixture when it moves.
• Check that all external covers and rigging hardware are securely fastened.
• Block access below the work area and work from a stable platform whenever
installing servicing or moving the fixture.
• Do not operate the fixture with missing or damaged covers shields or any
optical component.
Using for the first time
Important! Open the package make sure everything is in good conditions
before using if damage happened please don't connect power ,contact the
supplier as soon as possible !
Please read carefully before using"Safety I nformation"
• Check that the local AC mains Dower source is within the fixture's Dower

www.gleelite.com
8
AC power
Warning! Read "Safety Information" starting on page 5 before connecting
the Gaea to AC mains power.
Warning! For protection from electric shock,the Gaea must be grounded
(earthed).The power distribution circuit must be equipped with a fuse or circuit
breaker and ground-fault (earth-fault) protection.
Warning! Socket outlets or external power switches used to supply the Gaea
with power must be located near the fixture and easily accessible so that the
fixtures can easily be disconnected from power.
Important!Do not insert or remove live Neutrik Powercon connectors to
apply or cut power ,as this may cause arcing at the terminals and damage the
connectors.
Important! Do not use an external dimming system to supply power to the
Gaea as this may cause damage to the fixture that is not covered by the product
warranty.
Power voltage
Warning! Check that the voltage range specified on the fixture's serial number
label matches the local AC mains power voltage before applying power to the
fixture.
Gaea fixtures accept AC mains power at 100-240 V nominal50/60 Hz. 00 not
apply AC mains power to the fixture at any other voltage than that specified on
the fixture's serial number label.
Data link
A DMX 512 data link is required in order to control a Gaea via DMX.
The Gara has 5-pin XLR connectors for DMX data input and output. The pin-out
on all connectors is pin 1= shield ,pin 2 = cold (-),and pin 3 = hot (+). Pins 4
and 5 in the 5-pin XLR connectors are not used in the Gaea but are available for
possible additional data signals as required by the DMX512-A standard.

www.gleelite.com
9
Standard pin-out is pin 4 = data 2 cold (-) and pin 5 = data 2 hot (+).
The number of fixtures is either limited to 256 or limited by the number of
DMX channels required by the fixtures in relation to the maximum 512
channels available in one DMX universe whichever limit is lower. Note that if
independent control of a fixture is required it must have its own DMX channels.
Fixtures that are required to behave identically can share the same DMX
channels.
To add more fixtures or groups
Connecting the data link
Connecting the data link
To connect the Gaea to data:
1.Connect the DMX data output from the controller to the closest Gaea's male
5-pin XLR DMX input connector.
2. Connect the DMX output of the fixture closest to the controller to the DMX
input of the next fixture and continue connecting fixtures output to input.
3. Terminate the last fixture on the link with a 120 Ohm resistor.
after Gaea power on if there is no DMX input,display and buttons will
flash.After DMX input flash stops,then it is under DMX control model,20
seconds later display goes to power saving model and also the buttons.

10
www.gleelite.com
Setup
Control panel and menu navigation
Gaea control center to set the DMX.
When you choose a menu press OK , or t view menus.
After finding your meau,Press to enter OK ,quit
After out of menu,press to see the working condition.
Menu chart:
Control menu map
Level l
Level 2
Level 3
Level4
Level5
Level6
Setup
DMX Address
Addr:
001 - 512
001
Channel
Mode
Standard
Shape
Extended
Extended RGBW
Full
MAC Aura-14CH
Option
Pan/Tilt
Pan/Tilt speed
Normal
Fast
Pan Invert
Off,
On
Tilt Invert
Off,
On
Swap
Pan-Tilt
Off,
On
Control Menu Map

11
www.gleelite.com
Fan Mode
Auto
High
Display
Orientation
Normal
Inverted
Back light
On,
30Seconds,
2 Minutes,
5 Minutes
Intensity
Intensity
20%
-100%
80
Font Color
Red,
Green,
Blue,
Cyan,
Yellow,
Magenta,
White,
Luxury,
Gold,
Special
Function
Dimm er
Curve
Gamma
1
Gamma
l.5
Gamma
2
S-Curve
Load
Default
No
Yes
Information
System
Errors
Dimmer:No Signal
Pan:OK
Tilt:OK
Zoom:OK
System
Version

12
www.gleelite.com
DMX Monitor
Red 255
100%
Green 255
100%
...
Bkg Select 255
100%
Manual
Control
Reset
Fixture
All
Pan/Tilt
Zoom
Channel
Red 255
100%
Green 255
100%
...
Bkg Select 255
100%
0-255
Test
Pan/Tilt
Co1our
Zoom
All
Advanced
Access
Code
Calibration
Pan
-127-
127
Tilt
-127-
127
Zoom
-127-
127

13
www.gleelite.com
Operation and effects
Warning! Read "Safety Information" starting on page 5 before installing
powering,operating.
Beam and Aura
The Gaea has two LED arrays:
• The Beam: the LEDs that provide the main output,and
• The Gaea: the secondary LEDs that illuminate the front of the head,provide local
diffuse light output and can be set to contrast with the Beam output.
Dimming
Beam and Aura intensity can be adjusted 0 - 100% using electronic dimming.
Zoom
The Beam can be zoomed from 580 to maximum (narrow) 110 one-tenth peak
angles.
Aura output is automatically dimmed as the zoom approaches maximum.
There is a linear dimming curve from normal Aura output when the Beam is
at 90% zoom,to zero Aura output when the Beam is at maximum (narrow) zoom.
Macros
Gaea Beam static macros xxx dynamic macros xxx speed controllable.

14
www.gleelite.com
RGBW and RGB control
RGBW or RGB color control is available for the Beam and RGB control is
available for the Aura.
To obtain consistent color output at different intensities,do not use the RGBW or
RGB channels to control overall intensity. Instead,set the desired color on the
RGBW or RGB channels then use the dedicated beam dimmer and Aura dimmer
channels to control intensity.
LED individual controllable
Gaea Beam is with 19pcs RGBW 4 in 1LEDs each RGBW controllable of each
LED,you can make pixel map as you want to see from the front of LCD
display ,Gaea LED arrangements:
Note: At extended,extended RGBW,full 3 models,LED arrangements are the same.

15
www.gleelite.com
DMX PROTOCOL
Channel
Value
Function
Std.
Shape
Ext.
RGBW
Full
1
1
1
1
1
0-255
Red Dimmer 0% - 100%
2
2
2
2
2
0-255
Green
Dimmer 0% - 100%
3
3
3
3
3
0-255
Blue
Dimmer 0% - 100%
4
4
4
4
4
0-255
White
Dimmer 0% - 100%
5
5
5
5
5
0-9
10-255
Linear CTO
Unsed Range
2500K - 8000K
6
6
6
6
6
0-9
10
11
12
13
14
15
16
17
18
19
20 - 22
23 - 26
27 - 28
29
30
31
32 - 34
35 - 44
Macro color
OFF
Red
Green
Blue
Cyan
Yellow
Magenta
White 7000K
White 3700K
White 5000K
Black
Medium Yellow
Straw Tint
Surpriss Peach
Fire
Medium Amber
Gold Amber
Dark Amber
Sunrise Red

16
www.gleelite.com
.......
.......
.......
.......
.......
45
46 - 48
49 - 61
62 - 67
68 - 77
78 - 88
89 - 99
100 - 109
110 - 111
112
113
114
115 - 116
117
118
119
120
121 - 122
123 - 124
125
126
127
128
129 - 130
131 - 133
134 - 135
136 - 137
138 - 141
142 - 144
145
146
147 - 148
149 - 150
151 - 156
157 - 161
162 - 167
168 - 171
172 - 173
174
175 - 178
Light Pink
Medium Pink
Pink Camation
Light Lavender
Lavender
Sky Blue
Just Blue
Dark Yellow Green
Spring Yellow
Light Amber
Straw
Deep Amber
Orange
Light Rose
English Rose
Light Salmon
Middle Rose
Dark Pink
Magenta
Peacock Blue
Med Blue Green
Steel Blue
Light Blue
Dark Blue
Leaf Green
Dark Green
Mauve
Bright Pink
Medium Blue
Deep Golden Amber
Pale Lavender
Special Lavender
Primary Green
Bright Blue
Apricot
Pale Gold
Deep Orange
Bastard Amber
Flame Red
Daylight Blue

17
www.gleelite.com
.......
.......
.......
.......
.......
179
180 - 183
184 - 190
191 - 206
207
208
209 - 255
Lilac Tint
Deep Lavender
Dark Steel Blue
Congo Blue
Alice Blue
Dirty White
White
7
7
7
7
7
0 - 3
4 - 103
104 - 107
108 - 207
208 - 212
213 - 251
252 - 255
Strobe
Close
Strobe Slow to Fast
Open
Pulsation Slow to Fast
Open
Random Slow to Fast
Open
8
8
8
8
8
0-255
Master Dimmer
0%- 100%
9
9
9
9
9
0-255
Pan
Pan 0°- 540 °
10
10
10
10
10
0-255
Pan Fine
Pan Fine
11
11
11
11
11
0-255
Tilt
Ti1t 0°-210°
12
12
12
12
12
0-255
Tilt
Ti1t Fine
13
13
13
13
13
0-25
26-76
77-127
128-255
Reset
Unused Range
Zoom Reset
Pan/Ti1t Reset
Al1 Reset
14
14
14
14
14
0-255
Zoom
Beam wide to Narrow
15
15
15
15
15
0-255
Wash Red
Dimmer 0% - 100%
16
16
16
16
16
0-255
Wash Green
Dimmer 0% - 100%
17
17
17
17
17
0-255
Wash B1ue
Dimmer 0% - 100%
.......
18
.......
.......
18
0-7
8 - 14
15 - 71
72 - 255
Shape Se1ection
Macro OFF
Static Effects
Macro
Unused Range

18
www.gleelite.com
......
19
......
......
19
0-63
64 - 158
159 - 160
161 - 255
Shape Speed
Stop
Max to Min speed,c.cw rotation
Stop
Min to max speed,cc rotation
......
20
.....
.
......
20
0-255
Shape R
Dimmer 0% - 100%
......
21
.....
.
......
21
0-255
Shape G
Dimmer 0% - 100%
......
22
.....
.
......
22
0-255
Shape B
Dimmer 0% - 100%
......
23
.....
.
......
23
0-255
Shape W
Dimmer 0% - 100%
......
24
.....
.
......
24
0-255
Shape Dimmer
Dimmer 0% - 100%
......
25
.....
.
......
25
0-255
Background Dimmer
Dimmer 0% - 100%
......
26
......
......
26
0-3
4 - 103
104 - 107
108 - 207
208 - 212
213-251
252 - 255
Shape Strobe
Close
Strobe Slow to Fast
Open
Pulsation Slow to Fast
Open
Random Slow to Fast
Open
......
27
......
......
27
0-3
4 - 103
104 - 107
108 - 207
208 - 212
213-251
252 - 255
Background Strobe
Close
Strobe Slow to Fast
Open
Pulsation Slow to Fast
Open
Random Slow to Fast
Open

19
www.gleelite.com
......
28
......
......
28
0-8
9
10
II
12
13
14
15
16 - 255
Back ground Select
No selection
Pixel 1
Ring 2
Ring 3
Pixel 1 + Ring 3
Pixel 1 + Ring 2
Pixel 1 + Ring 2 + Ring 3
Ring 2 + Ring 3
No selection
......
......
18
18
29
0-255
LE D1 R
Dimmer 0% - 100%
......
......
19
19
30
0-255
LED1 G
Dimmer 0% - 100%
......
......
20
20
31
0-255
LED1 B
Dimmer 0% - 100%
......
......
......
21
......
0-255
LED1 W
Dimmer 0% - 100%
......
......
......
......
......
......
......
......
......
72
90
83
0-255
LED19 R
Dimmer 0% - 100%
......
......
73
91
84
0-255
LED19G
Dimmer 0% - 100%
......
......
74
92
85
0-255
LED19B
Dimmer 0% - 100%
......
......
......
93
......
0-255
LED19W
Dimmer 0% - 100%

20
www.gleelite.com
14 DMX Protocol
Channel
DMX Value
Function
1
0
1 - 103
104 - 107
108 - 207
208 - 212
213 - 251
252 - 255
Strobe
Close
Strobe Slow to Fast
Open
Pulsation Slow to Fast
Open
Random Slow to Fast
Open
2
0 - 255
Beam dimmer
0 → 100% intensity
3
0 - 255
Zoom
Wide → narrow
4
0 - 255
Pan
Pan 0° - 540°
5
0 - 255
Pan fine
Pan fine adjustment (Least Significant Byte)
6
0 - 255
Tilt
Tilt 0° - 232°
7
0 - 255
Tilt fine
Tilt fine adjustment
8
10-14
Reset all the light
