GLITZHOME GH11262 User manual

Assembly Instruction
4 PIECE PATIO SOFA SET

1
PRE-ASSEMBLY PREPARATION
WARNING! DO NOT LET CHILDREN PLAY IN OR AROUND THE UNIT DUE TO THE POSSIBLE RISK OF FINGER ENTRAPMENT
•Please read through this instrucon before beginning assembly.
•Two adults assembly is recommended.
•Clear out the space for assembly and lay out all parts base on parts List, extra room will allow you to easily
determine if all the pieces are present.
•Save all packing materials unl assembly is complete to avoid accidentally discarding smaller parts or hardware.
•Keep small parts and pieces away from children unl fully assembly.
•Do not fully ghten the bolts unl all have been inserted and hand ghtened.
•
•
Please check for any loose screws and ghten them before use.
This whole set including 4 Piece is packed in two boxes. 2pc single sofa is in a box and 1pc loveseat
sofa + 1pc table in the other box. All hardware list is in the box with single sofa. If there is any
quesons, please contact us first, we will quickly solve any doubt for you.

2
PANEL AND FITTINGS IDENTIFICATION
HARDWARE LIST
Left Arm Panel ARight Arm Panel B Back Panel C1 Single Seat Panel D1
Front Leg E Rear Leg F
Plastic Cap (M)Bolt (I) Bolt (J) Bolt (K) Washer (L)
Wrench (N)
M6 X 30mmM6 X 35mm M6 X 15mm
Qty: 3Qty: 3Qty: 2Qty: 2
Qty: 1
Qty: 4
Qty: 6Qty: 1Qty: 6
Table Top G Table Leg H
Qty: 4Qty: 1
Qty: 14 Qty: 12 Qty: 48 Qty: 74 Qty: 74
Qty: 1
Loveseat Panel D2
Back Cushion O
Seat Cushion P
Qty: 4
Back Panel C2
NOTE: From step 1 to step 4 is for single sofa assembly.
Please find panel A, B, C1, D1 and E, F firstly.

3
Step 2
Step 1
Aach Le Armrest Panel (A) and Right Armrest Panel (B) to Single Seat Panel D1 by using
4 long Bolts (I)and 4 Washers (L).
Finally
put Bolt Caps (M) unl all parts have been connected and bolts are ghtened.
Aach Back Panel (C1) to Armrest panels on both side by using 4 medium Bolts (J)and 4 Washers (L).
Finally
put Bolt Caps (M) unl all parts have been connected and bolts are ghtened.
L
I
M
A
B
D1
L
J
M
C1

4
Step 4
Put on Seat Cushion (P) and Back Cushion (O) to finish assembly of single sofa.
Step 3
Aach Front Leg (E) and Rear Leg (F) to seat frame by using 12 short Bolts (K)and 12 Washers (L).
Finally
put Bolt Caps (M) unl all parts have been connected and bolts are ghtened.
M
K
L
E
F
P
O

5
Step 5
Aach Le Armrest Panel (A) and Right Armrest Panel (B) to Loveseat Panel D2 by using
4 long Bolts (I)and 4 Washers (L).
Finally
put Bolt Caps (M) unl all parts have been
connected and
bolts are ghtened.
Step 6
Aach Back Panel (C2) to Armrest panels on both side by using 4 medium Bolts (J)and 4 Washers (L),
then fix it to seat panel by using 2 long Bolts (I)and 2 Washers (L).
Finally
put Bolt Caps (M) unl all parts have been connected and bolts are ghtened.
B
D2
L
I
M
A
C2
J
L
M
L
M
I
NOTE: From step 5 to step 8 is for loveseat sofa assembly.
Please find panel A, B, C2, D2 and E, F firstly.

6
Step 7
Aach Front Leg (E) and Rear Leg (F) to seat frame by using 12 short Bolts (K)and 12 Washers (L).
Finally
put Bolt Caps (M) unl all parts have been connected and bolts are ghtened.
Step 8
Put on Seat Cushion (P) and Back Cushion (O) to finish assembly of loveseat sofa.
M
K
L
E
F
O
P

7
Step 9
Aach Legs (H) to Tabel Top (G) by using 12 short Bolts (K)and 12 Washers (L).
Finally
put Bolt Caps (M) unl all parts have been connected and bolts are ghtened.
H
G
M
K
L
NOTE:Step 9 is for table assembly. Please find panel H and G firstly.
Step 11
Finished view for sofa set.
Please make sure all bolts are properly ghtened before use.
