GLITZHOME GH11266 User manual

PATIO LOVESEAT GLIDER CHAIR
Assembly Instruction

PRE-ASSEMBLY PREPARATION
WARNING! DO NOT LET CHILDREN PLAY IN OR AROUND THE UNIT DUE TO THE POSSIBLE RISK OF FINGER ENTRAPMENT
•Please read through this instruction before beginning assembly.
•Two adults assembly is recommended.
•Clear out the space for assembly and lay out all parts base on Parts List, extra room will allow you to easily
determine if all the pieces are present.
•Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or hardware.
•Keep small parts and pieces away from children until fully assembly.
•Do not fully tighten the bolts until all have been inserted and hand tightened.
•Please check for any loose screws and tighten them before use.
PANEL AND FITTINGS IDENTIFICATION
HARDWARE LIST
Bolt (I)
Qty: 8
Qty: 1
Bolt (J)
Qty: 4
Qty: 2
Bolt (K)
Right Armrest (A)
Base (E)
Left Armrest (B)
Conneting Rod (F)
Back Panel (C)
Seat Cushion (G)
Seat Panel (D)
Back Cushion (H)
Qty: 7
Qty: 2
Washer (L)
Qty: 19
Qty: 2
Qty: 1 Qty: 1 Qty: 1 Qty: 1
Plastic Cap (M)
Qty: 19
Wrench (N)
Qty: 1
M6 x 30mm M6 x 15mm M6 x 40mm

STEP-BY-STEP ASSEMBLY
STEP 1
STEP 2
Aach Back Panel (C) to Seat Panel (D) with Washer (L), Bolt (K) and Bolt Cap (M); Save bolt
cap(M) unl all parts have been connected and add aer final ghtening.
During final assembly, when you are ghtening all screws, the center screw in this step may
not ghten as fully down as the other 2 end screws. This is not a defecve issue. The center
screw may remain a lile higher due to the wrapped vinyl straps that are aached to the
seat frame.
Aach 2 pc short end of Connecng Rods (F) to Base (E) with Washer (L) and Bolt (I). Save
bolt cap (M) unl all parts have been connected and add aer final ghtening. If this step is
completed correctly, the long end of connector bar (F) should hang down as shown in
assembly picture.
M
M
IL
L
F
E
K
D
C

STEP 3
STEP 4:
NOTE:Whenaaching the arms, insert screws in opposite order to ensure hole lineup,
as follows, in an “X” paern per arm.--
Aach Right Armrest (A) and LeArmrest (B) to Back Panel (C) and Seat Panel (D) with
Washer (L), Bolt (K), Bolt (J) and Bolt Cap (M); Save bolt cap (M) unl all parts have been
connected and add aer final ghtening.
NOTE: Bolt K is used for the back arm assembly.
Bolt J is used for the front arm assembly.
L
J
M
L
K
M
L I
M
Connect Right Armrest (A) and Le Armrest (B) to Conneng Rod (F) with Washer (L), Bolt (I)
and Bolt Cap (M); Save bolt cap (M) unl all parts have been connected and add aer
final ghtening.

STEP 5
STEP 6
Put on Seat Cushion (G) and Back Cushion (H).
Please make sure all bolts are properly ghtened before use.
Now ghten all screwas using the locking wrench to ensure assembly is complete and
secure. Once complete, use bolt cap(M) to cover all screw heads.
H
G
