Global-Ident Global-Scan GS 110 User manual

Animal implanted microchip scanner
Global-Scan™
GS 110
USER MANUAL
Introduction
Congratulations, you are now the
owner of a Global-Scan™. This
reader can read all microchip
implants of the type FDX-B, HDX
and FDX-A widely used intended to
pet’s identification.
As you can see the product is easy
to use.
Language choice
Hold the Global-Scan™ and press
(more than 5 seconds) the scanning
button, located on the left side of the
reader. The reader will display
successively different languages,
English, Français, Español, Italiano,
Portugues, Deutsch, Polski. For
additional information, refer to the
paragraph “Setting the scanner
configuration for the first time”.
Reading a transponder
Switch on the reader by pressing the
scanning button (about 1 second).
After shortly displaying the language
chosen by the user, the following
message will be displayed on the
LCD screen:
By pressing the scanning button
another time the reader will start
searching for a microchip. The
following message will be
displayed on the LCD screen:
Keep the reader in your hand and
bring the reader's antenna near the
animal's body. Scan slowly the
area where a microchip is
expected to be found while
keeping the reader for a few
centimetres distance from the
animal's skin. The reader will be
scanning for about 20 seconds.
Once the reader has finished
searching, two situations can arise:
• First case:
If a microchip has been found then
the reader will « beep » and the
unique identification number will be
displayed:
In the above example, the reader
indicates that the found chip is
ofFDX-B type.
The identification number will remain
displayed on the LCD screen for
about 2 minutes before the reader
switches off automatically. While
displaying, a new press on the
scanning button re-activates
reading.
Warning: once the reader is switch
off, it will not be possible to display
the last identification number read
again.
• Second case:
If no microchip has been found after
20 seconds, the reader will beep
three times and the following
message will be displayed on the
screen:
If this situation arises, try finding the
microchip again. To do so you must
re-activate the reader by pressing
the button. Scan the possible
microchip implantation area with as
a large sweeping movement as
possible. If necessary, repeat the
operation after having re-activated
the reader again.
Replacing the battery
Only use 9V alkaline batteries or
rechargeable batteries of PP3
type. If the battery is running low the
reader will beep twice and will
display regularly the following
message :
When the battery is too low the
reader displays this message and
switches off immediately. To replace
the battery, open the battery
compartment located under the
reader and replace the old battery
with a new one. Close the battery
compartment and check that the
locking mechanism is in place.
Bluetooth (optional)
Bluetooth feature allows wireless
communication with a host
peripheral (PC, PDA…).
Internal Bluetooth module can be
de-activated by pushing up the
Bluetooth On/Off button. This
position is recommended to save
battery life.
Technical specifications
Standards: ISO 11784 / 11785
Dimensions : L x W x H 15x8x3.5cm
Weight: 155 grams / 5.5 ounces
(Incl. battery)
Power : standard 9 Volts PP3
alkaline battery or PP3 rechargeable
NiMH battery
Serial link: RS232 9600/N/8/1 (Tx
only)
Reading distances (depending on
microchip manufacturer):
FDX-B: up to 10 cm / 4 inches
FDX-A: up to 5 cm / 2 inches
HDX: up to 20 cm / 7.8 inches (ear
tag)
Options: Bluetooth (10m)
Temperature:
Temperature range: -10°C to + 55°C
Designed in France
Made in China
This Global-Scan™ GS110 product
is in compliance with the essential
requirements of R&TTE Directive
1999/5/EC. A copy of the declaration
of Conformity can be found at:
http://www.global-ident.fr
The crossed-out wheeled bin
means that within the European
Union the product must be taken
to separate collection at the
product end-of-life. Do not
dispose of these products as
unsorted municipal waste.
Bluetooth is a registered trademark of Bluetooth
SIG,Inc.
Scanning
button
Bluetooth
®
On/Off
(Optional)
Reading
Press SCAN to
read
Tag : FDXB
978 000001226350
No tag
found !
Low
battery !
Antenna
ENGLISH

EID_UM_GS110_EN1.1
About Global-Scan™ features
Message displays are available in English – Français – Español – Italiano – Portugues – Deutsch – Polski.
There is the possibility of recording up to 800 previously-read transponder numbers in the scanner memory.
Global-Scan™ can read transponders of the following types: FDX-B (ex: Hitag, Zodiac…), FDX-A (Destron, FECAVA), HDX(ex: Tiris).
Global-Scan™ has a unidirectional serial link of the type RS 232 (TX only).
Setting the scanner configuration for the first time
You have just acquired the Global-Scan™ , but before using it, you must configure it to fit perfectly to your requirements.
Press continuously during 5 seconds on the scanning button located on the left side of the scanner.
The following messages are successively displayed:
And so on one after the other:
English – Français – Español – Italiano – Portugues – Deutsch – Polski
The sign – means, the memory function is not activated.
The sign + means, the memory function is activated.
When language and operating mode chosen are displayed, release the scanning button. Global-Scan™ will “beep” indicating that it is
configured and ready to read.
Note:
1. The configuration is recorded into the reader memory. Consequently, each time it is switched on, the language and operating mode (with
or without memory) will be saved.
2. Be careful when switching on not to press for more than 2 seconds on the scanning button. This risks entering the configuration menu.
Changing the configuration
To change the configuration, switch off the scanner if necessary and switch on by keeping the scanning button pressed down until the desired
configuration is displayed.
Global-Scan™ switch-off
The Global-Scan™ is programmed to automatically switch off after 2 minutes if the scanning button has not been pressed. It is possible to
switch off the reader by pressing continuously the scanning button when an identification number or “no tag found” is displayed.
Using the “memory” function
A scanner configured beforehand in operating mode “+ memory” will record the scanned transponder numbers (800 identification numbers
maximum)
To transmit the contents of its memory:
-If the scanner is off: switched on the reader; the display will successively show the menu below
-If the scanner is already on: press shortly the scanning button and, during the transponder-reading phase, press continuously on the
scanning button during 2 seconds. The following menu will be displayed:
Caution: Do not forget to erase the memory after sending phase.
English
- memory English + memory
Francais
- memoire Francais + memoire
Espanol
- memoria
Espanol
+ memoria
Press SCAN to
send
Sending
Press SCAN to
erase Press SCAN to read
Press SCAN to
confirm Reading
Erasing
5
sec
5
sec
5
sec
5
sec
5
sec
Scanning
button Scanning button
Scanning
button
Scanning
button
Press SCAN to
send
Scanning
button (2 sec)
3
sec
3
sec
3
sec
