Global Industrial 133716 User manual

MODEL #
18" Industrial Grade Air Needle Scaler
Model: 133716
User's manual Manual del usuario Manuel de l'utilisateur
Customer Service
US: 1-800-645-2986
Servicio de atención al Cliente
US: 1-800-645-2986
Service à la clientèle
Canada: 888-645-2986
IMPORTANT! Read carefully before operating this tool. Failure to operate any
power tool properly can result in personal injury and/or property damage!
Free Speed (BPM) ………………… 4,800
Air Pressure (PSI) ……………………90
Horse Size (ID) ………………………3/8”
Air Inlet (NPT) ………………………1/4”
Stroke ……………………………1-1/8”
Needle Qty …………………………19
Needle Size…………………… 7”x1/8”
Avg. Air Consumption (cfm)……… 4.5
Overall Length……………………18.4”
Weight (Lbs.) ………………………6.2
1Safety
2Lubrication
3Air Supply
1. Always wear approved eye and respiratory protection.
2. Have throttle in “o” position when connecting to air supply.
3. Disconnect tool before performing service, changing accessories, or when not in use.
4. Always be in a safe working distance from others when using tools.
5. Keep tools clean and oiled for best and safest performance.
6. Follow instructions for lubricating and changing accessories.
7. Do not wear loose tting clothing and remove all jewelry.
8. Always use proper hose and ttings. Never use quick change couplings attached at
tool.
9. Always keep proper footing and balance.
10. Never carry tools by the hose. Keep hoses from heat, oil, and sharp edges. Check
hoses for weak or worn condition before each use, making certain that all connections
are secure.
Lubricate the tool daily with a good grade of air tool oil. The oil can be applied directly
into the air inlet of the tool and then run the tool. A rust inhibitor oil is acceptable for air
tools.
Tools of this class operate on a wide range of air pressure. It is recommended that air
pressure of these tools measure 90 PSI at the tool while running free. Higher pressure
and unclean air will shorten the tool’s life and may create a hazardous condition.
1

18" Industrial Grade Air Needle Scaler
2
User's Manual
5Maintenance
4Operating Instructions
Water in the airline will cause damage to the tool. Ensure that the air tank is drained
daily Clean the air inlet lter screen on at least a weekly basis. The recommended
hookup procedure can be viewed in the illustration below.
The air inlet, used for connecting the air supply, has standard 1/4” NPT American
Thread.
Line pressure should be increased to compensate for unusually long air hoses (over 25
feet). Minimum hose diameter should be 1/4” I.D. and ttings should have the same
inside dimensions.
Other factors outside the tool may cause loss of power or erratic performance. Reduced
compressor CFM output, excessive drain on the air line, moisture or restriction in air
lines or the use of hose connections of improper size or poor condition may reduce air
ow. Dirt or debris deposits in the tool may reduce power. This may be corrected by
cleaning the air strainer and ushing out the tool with solvent oil. If outside
appearance of the tool is in order and tool is out-of-warranty, clean, reassemble, and
re-lubricate, or take tool to any air tool service center. For tools still under warranty call
Global Industrial at 1-800-645-2986 for disposition.
Locate the center of the hole to be drilled by using a center punch. Place drill bit tip in
punch mark. Hold drill square to the work piece and start motor. Apply steady, even
pressure. Do not force. Too much pressure can cause bit to break or over heat and can
cause personal injury. Too little pressure will keep bit from cutting and cause it to
overheat.
If the drill jams in the work, release the throttle immediately. Disconnect the drill before
removing bit. Do not attempt to free the bit by starting and stopping the motor. When
changing bits, always disconnect the tool from the air line. A faulty start can cause
personal injury.
The air inlet used for connecting air supply has standard 1/4” NPT thread. Have throttle
in “o” position when connecting to air supply. Disconnect tool before performing
service, changing accessories and when not in use. Always use tool at a safe distance
from other people in the work area.

18" Industrial Grade Air Needle Scaler
3
User's Manual
6Exploding View and Parts List
PLEASE READ THE FOLLOWING CAREFULLY BEFORE OPERATING:
1) Always wear Safety Goggles to guard against eye injuries caused by ying particles.
2) Light density, non-detergent lubricant oil (i.e.#60) recommended.
3) Use working pressure of 0-90 PSIG, regular speed: 4,800 RPM.
Part Name
Inlet Bushing
Stem O-Ring
Valve O-Ring
Throttle Valve
Valve Spring
O-Ring
Valve Cap
Lever
Backhead
Locking Ring
Alignment Slim
Rear Valve Block
Pin
Valve Disc
Front Valve Block
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Qty
1
2
1
1
1
1
1
1
1
1
2
1
2
1
1
Part Name
Piston
Casing Sleeve
Nozzle
Key, 3x10
Casing
Bit Retainer Buer
Bit Retainer
Retainer Clip
Spring Pin, Ø5x22
Anvil
Needles (19)
Needle Holder
Spring
Needle Housing
No.
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1

18" Industrial Grade Air Needle Scaler
4
User's Manual
7Notice
90% of all Air Tool problems are caused by moisture in air lines
This problem can be avoided by using Air Tool Lubricant (See “Lubrication”
& “Air Supply” section of this manual)
FAILURE TO OIL can void your warranty
Warning
: Dust created by power sanding, sawing, grinding, drilling, and other
activities contains particles and chemicals known to cause cancer, birth defects or
reproductive harm. Some examples of these chemicals are:
•Lead from lead-based paints
•Crystalline silica from bricks, cement, and other masonry products
•Arsenic and chromium from chemically treated lumber
To reduce your exposure to these chemicals, work in well ventilated areas with
approved safety equipment specially designed to lter out microscopic particles.
8One Year Limited Warranty
GLOBAL Industrial air tools carry a limited 1 year warranty to be free from defects in
material and workmanship for one year from date of purchase. We will repair or replace
at our discretion any defective part or unit which proves to be defective in material or
workmanship during this 1 year period. The foregoing obligation is GLOBAL sole
liability under this or any implied warranty, and under no circumstances shall it be
liable for any incidental or consequential damages.
Repairs required by abuse, misuse, damage, or repair attempts (other than GLOBAL
Industrial) are not covered by this warranty.
For warranty claims and returns, please contact GLOBAL Industrial at
1-800-645-2986 or speak to your local sales representative. Be certain to
include your name, address, and purchase date, and description of the
suspected defect.
WARNING
: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
