Global Sat TR-102 User manual

TR-102
Personal Tracker
User Manual
Version 1.6

TR-102 page 2
Table of Content
1 Introduction and Features................................................ 4
Introduction ...................................................................4
Features.........................................................................4
2 Specifications ................................................................... 6
Hardware .......................................................................6
3 Start-up............................................................................ 8
Accessories.....................................................................8
Charging the battery........................................................9
Install SIM card.............................................................10
4 Hardware Overview........................................................ 11
Appearance ..................................................................11
Button description .........................................................13
5 TR-102 Setup and Call Center Operation ........................ 15
Install the USB driver.....................................................15
Install the Call Center program........................................20
Call Center Operation..................................................... 22
Basic Setting ................................................................23
6 Operating the device ...................................................... 32
Turn on / Turn off ..........................................................32
Answer / Hang up the phone...........................................33
Adjust the volume .........................................................33
Making a phone call .......................................................34
Send out emergency SMS...............................................35
7 Tracking by SMS Type 1 mode ........................................ 37
Setup SMS return type ...................................................37
Send SMS from a cell phone to TR-102 .............................37
TR-102 sends SMS to cell phone ......................................37
Displaying the location on map........................................ 38
8 Tracking by SMS Type 2 mode ........................................ 40
8.1) SMS command from callcenter to TR-102 ...................41
8.2) The format of return SMS from TR-102 ......................45
9 Tracking by GPRS mode.................................................. 46
Setup GPRS return type ................................................. 46

TR-102 page 3
Trigger the TR-102 to connect to Internet by GPRS............. 46
Send a command from Call Center to TR-102 ....................47
TR-102 sends back location information to Call Center ........ 50
Displaying the location on map........................................ 51
10 How does TR-102 work by SMS and GPRS? .................. 52
11 Troubleshooting and Safety info................................... 56

TR-102 page 4
1Introduction and Features
Introduction
TR-102 is a personal remote positioning device with built-in GPS and
GSM modules; it’s compact and portable. Not only can TR-102
transmit the longitude and latitude coordinate to your cell phone by
the short message service, but it can also transmit the longitude and
latitude coordinate to your personal computer via the internet
connection of GPRS and then displaying the location by specific map
software. There are three speed-dial keys and one emergency key on
the TR-102. You can use these keys to protect and search children
and old people. Further, you can use it as a security purpose and
other purpose which needs remote positioning.
Features
1. GPS/GPRS personal locator.
2. GSM/SMS/GPRS communication.
3. Omni-directional high sensitive GPS antenna which can receive
GPS signal from all direction.
4. New technology and latest GPS SiRF-Star III chipset! Excellent
for fixing the position even at a weak signal status.
5. Remote command control via mobile phones or through online
software.
6. Receive phone calls to have two way communications.
7. Monitors can track the person without interfering him, LIVE!
Real-Time tracking!
8. Locate the locator holder just by pressing a button on PC
software or through mobile phone via SMS (short messaging

TR-102 page 5
system).
9. Three quick dialing buttons for 3 preset phone numbers.
10. Works worldwide! Support 4-frequency GSM
850/900/1800/1900 MHz and GPRS class 12.
11. Independent SOS (emergency) button for sending GPS
location information via SMS up to 3 preset phone numbers (it
can be 3 sets of different numbers than the 3 sets of quick
dialing numbers).
12. Device can be connected to PC via a USB cable for setup the
arguments (package comes with mini USB cable when you
purchase the device).
13. Report device holder’s position at a preset time interval.
14. Low battery notification before the battery dies out! Worrying
free on why the locator wouldn’t respond for this kind of
situation!
Software Feature
Professional Call Center program, supporting the operating system
such as Windows 98 /2000 /XP, also supporting up to 5 sets of
TR-102's tracking function at the same time via using the GPRS
connection. Clicking on one of the TR-102's user name from the Call
Center program will open a browser with the latitude and longitude
information displaying as a point at the center of the
maps.google.com. The displayed map is Google's patented right.

TR-102 page 6
2Specifications
Hardware
GSM module: embedded GSM 850/900/1800/1900
MHz , GPRS class 12
GPS Chipset: SiRF Star III
Frequency: L1, 1575.42 MHz
C/A code: 1.023 MHz chip rate
Channels: 20 channel all-in-view tracking
Antenna Type: Omni-directional GPS antenna
Position Accuracy: 10 meters, 2D RMS
Velocity Accuracy: 0.1 m/s
Time Accuracy: 1 us synchronized to GPS time
Default datum: WGS-84
Reacquisition: 0.1 sec., average
Hot start: 1 sec., average
Warm start: 38 sec., average
Cold start: 42 sec., average
Altitude Limit: 18,000 meters (60,000 feet) max.
Velocity Limit: 515 meters/second (1000 knots) max.
Acceleration Limit: Less than 4g
Jerk Limit: 20 m/sec3
Operating
temperature:
-20° to 55° C
Humidity: 5% to 95% Non-condensing
Dimension: 115 mm × 45 mm × 22.5 mm
Voltage: Rechargeable and replaceable 1300 mAh
battery (3.7V), 5V for charging input.
Charging connector: DC 5V
Standby time: Over 100 hours
Talking time: 5 ~ 6 hours
LED: 3 LEDs showing Power, GPS and GSM
status.

TR-102 page 7
Key: 7 Keys for Power On/Off key, Emergency
key, Intimate call * 3, Lock key and
Answer/Reject key.
USB port: Mini USB port for connecting to PC.
SAR: GSM850 Head: 0.758
GSM900 Head: 0.576
PCS1800 Head: 0.582
PCS1900 Head: 0.735
GSM850 Body: 0.21
PCS1900 Body: 0.223

TR-102 page 8
3Start-up
Accessories
TR-102
AC power adapter
Mini USB cable
1300 mAh Li-ion Battery
CD-ROM
Leather case (Optional)

TR-102 page 9
Charging the battery
Fully charge the battery. Before using of TR-102 for the first time,
please connect it with AC power adapter for battery charging at least
10 hours under the power-off condition. (The attached battery is
specially designed for TR-102. Please do not use other types of
battery; otherwise it will damage the device. If you need to change
the battery for TR-102, please contact your local dealer.)

TR-102 page 10
Install SIM card
Install SIM card:
1. Press on the battery cover, and then pull it downward to open it.
2. Remove the battery.
3. Insert the SIM card into the cartridge according to the direction
shown, and close the cartridge when done.
4. Put back the battery, and close the battery cover.

TR-102 page 11
4Hardware Overview
Appearance

TR-102 page 12
(1) SOS button
(2) Power button
(3) GSM LED
(4) GPS LED
(5) Power LED
(6) Speaker
(7) Answer / Hang up
(8) Quick Dial 1 / Volume up
(9) Quick Dial 2 / Mute the microphone
(10) Quick Dial 3 / Volume down
(11) Microphone
(12) Button Lock
(13) Power Adapter Jack
(14) Mini USB connector

TR-102 page 13
Button description
Power button Turn on / Turn off: Please see page 32 for
details.
SOS button You can assign up to 3 sets of phone numbers to
the SOS button. When this button is pressed,
TR-102 will send its location information to these
3 sets of phone numbers by SMS. TR-102 will
send the location information to SOS number 1 by
SMS. Following, TR-102 will repeat the same
procedure for SOS number 2 and 3.
Answer /
Hang up
When there is an incoming call, press this button
to answer the incoming call. While in talking,
press it will hang up the phone.
Quick dial 1 /
Volume up
You can set a phone number for this button; when
this button is pressed, TR-102 will dial the preset
number. While in talking, you can press this
button to increase the volume.
Quick dial 2 /
Mute the
microphone
You can set a phone number for this button; when
this button is pressed, TR-102 will dial the preset
number. While in talking, the other party will not
hear from you if this button is pressed to mute the
microphone; press it again to enable the
microphone.
Quick dial 3 /
Volume down
You can set a phone number for this button; when
this button is pressed, TR-102 will dial the preset
number. While in talking, you can press this
button to decrease the volume.

TR-102 page 14
GSM LED LED is on: TR-102 is turned on, but not
connected to GSM network yet.
Blinking quickly (once per second): TR-102 is in
dialing or talking mode.
Blinking slowly (once per 3 seconds): TR-102 is
in the standby mode.
GPS LED The LED will blink when TR-102 is fixing its
location. More details please see page 35 for SOS
button and page 47 for GPRS mode.
Power LED The LED will turn orange when AC adapter is
plugged for charging the battery. If the battery
power is low, this LED will be on in red, and
TR-102 will send a warning SMS to SOS number.
Power adapter
jack
Plug in the Power adapter to TR-102's power
adapter jack for battery charging.
Mini USB
connector
Connecting TR-102 to PC by a Mini USB cable, you
can setup all its features and functions from
application software in PC.
Button Lock Switch to lock all the buttons for the purpose of
preventing buttons from been accidentally
touched. When Button Lock is on, the LED
indicators will flash 3 times if any other button is
pressed. (Only when power is off and USB cable is
connected, you can press the power button to
turn on TR-102.)

TR-102 page 15
5TR-102 Setup and Call
Center Operation
Install the USB driver
If the operating system of your PC is Vista, please click on the
“USB Driver for Vista” button to install PL2303 USB driver of
Vista version. Follow the screen instruction to finish the driver
installation.

TR-102 page 16

TR-102 page 17

TR-102 page 18
If the operating system of your PC is not Vista, please click on
the “Install USB Driver” button to install PL2303 USB driver.
Follow the screen instruction to finish the driver installation and
reboot your PC to activate the USB driver.

TR-102 page 19

TR-102 page 20
Install the Call Center program
1. From the Autorun dialog box, click on the "Install PC Software"
to install the Call Center program.
2. Follow instruction of Dialog box 1 to continue the installation.
3. When the installation is complete, click on Finish in Dialog box 2
to close the dialog box.
Autorun Dialog box
