Global 641288 User manual

Model 641288Global Equipment Company
Call 1-800-645-2986
ECHA GEABLE CO DLESS SWEEPE
12-INCH CLEANING PATH
IMPORTANT!
Real all instructions carefully, and keep for future reference.
globalindustrial.ca
Distribucion Industrial Globales S DE RL DE CF
Assembly Instructions Instrucciones de Ensamblaje Directives d’assemblage
g
glo
Assembly Instructions
Customer Service
US: 1-800-645-2986
globalindustrial.ca
Assembly Instructions Instrucciones de Ensamblaje
Customer Service
US: 1-800-645-2986
Servicio de atención al Cliente
México: 01.800.681.6940
globalindustrial.ca
Instrucciones de Ensamblaje
Servicio de atención al Cliente
México: 01.800.681.6940
Distribucion Industrial Globales S DE RL
Instrucciones de Ensamblaje
Servicio de atención al Cliente
ectives d’assemblageDir
Service à la clientèle
Canada: 888-645-2986
DE CFDistribucion Industrial Globales S DE RL
ectives d’assemblage
Service à la clientèle
Canada: 888-645-2986
US: 1-800-645-2986US: 1-800-645-2986 México: 01.800.681.6940México: 01.800.681.6940 Canada: 888-645-2986Canada: 888-645-2986

Contents
WA NING...........................................................................1
Important Safety Instructions...................................1
Important Battery Handling Instructions ..................2
Parts List............................................................................3
Assembly ...........................................................................4
Assembly Instructions..............................................4
Operation ...........................................................................5
peration Instructions..............................................5
Maintenance ......................................................................6
Empty Dirt Container ...............................................6
Storage ....................................................................6
Cleaning Standard Carpet Brushroll........................6
Troubleshooting .......................................................7
Battery disposal .......................................................7
Warranty.............................................................................8

1
WA NING!
To reduce the risk of fire,
electric shock, or injury:
When using an electrical appliance, basic precautions
should always be followed, including the following:
EAD ALL INST UCTIONS BEFO E USING THIS VACUUM CLEANE .
• Do not use outdoors or on wet surfaces.
• Do not expose to rain, store indoors.
• Do not allow the unit to be used as a toy. Close attention is necessary when used
by children.
• Use only as described in this manual. Use only manufacturer’s recommended
attachments.
• Do not use extension cord or outlets with inadequate current carrying capacity.
• Do not handle charger or vacuum cleaner with wet hands.
• Do not incinerate or mutilate batteries as they will explode at high temperatures.
• Do not pick up anything that is burning or smoking such as cigarettes.
matches, or hot material.
• Do not allow the battery to run down completely before charging. In doing so,
serious problems may occur in the battery life cycle.
• Do not pick up flammable or combustible liquids such as gasoline, or use in
areas where they are present.
• Store the adapter indoors in a cool dry area where it is not exposed to the
weather in order to avoid electrical shock and/or cleaner damage.
• nly use the adapter provided by the manufacturer to recharge the appliance.
Additional Safeguards:
• Always disconnect cord from electrical outlet before servicing the cleaner.
• nly charge the unit indoors.
Lubrication:
• Lubrication is not necessary since the motor and brush roller are permanently
lubricated.
SAVE THESE INST UCTIONS
If the adapter or the interconnection cord is damaged, it must be scrapped.
IMPO TANT
SAFETY INST UCTIONS!

2
WA NING!
To reduce the risk of fire,
electric shock, or injury:
When using an electrical appliance containing a NC/NM battery
basic precaution should always be followed, including the following:
EAD ALL INST UCTIONS BEFO E CHA GING THE BATTE Y
Battery charging
• Charge batteries for 3 hours (NM) before initial use.
• Never modify the electrical system. Alterations could cause a fire resulting in
serious injury and could also ruin the electrical system.
• Use of the wrong type battery or charger could cause a fire or explosion
resulting in serious injury.
• The battery must be handled by adults only Dropping the Battery could result in
serious injury.
• Never allow children to charge the battery. Battery charging must be done by
adults only. A child could be injured by the electricity involved in charging the
battery.
• Never lift or carry the battery by the wires or connector. This can damage the
battery and possibly cause a fire resulting in serious injury. Lift and carry the
battery by the case only.
• Read the safety instructions on the battery.
• Examine the battery, charger and their connectors for excessive wear or damage
each time you charge the battery. If damage or excessive wear is detected,
do not use the charger of the battery until you have replaced the worn or
damaged part.
Care
• If a battery leak develops, avoid contact with the leaking acid and place the
damaged battery in a plastic bag. Please refer to the information on this page
for proper disposal.
• If acid comes in contact with skin or eyes, flush with cool water for at least
15 minutes and call a physician.
• Do not allow the battery to run down completely before charging.
• Charge the battery at least once per month, even if the vacuum has not been
used.
• Leaving the battery in a discharged condition will ruin it.
• Do not store the battery in temperatures above 75ºF or below -10ºF.
IMPO TANT BATTE Y
HANDLING INST UCTIONS!

3
Parts List
To assist you in identifying your sweeper components, the parts have been
numbered as follows:
1. Handle complete
2. Top cover
3. Dust box
4. Dust box cover release button
5. Release button spring
6. Rear wheel
7. Belt driving ASM
8. Dust box cover
9. Crystal window
10. Fixed bracket
11. Carpet brushroll w/release button complete
12. Battery package
13. Rear wheel shaft
14. Bottom base
15. Battery charger
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

4
Assembly
Asse bly Instructions
Attach wall mount to a flat surface using the screws provided.
Attach handle to the end of strut with the telescopic wand adjustment
Pressing down the locking tab, slide shorter strut over longer strut until
locking tab catches. Insert assembled handle into the base until it locks
in place.
Loosen the telescopic wand adjustment to lengthen or shorten the
handle to the desired length and then tighten the telescopic wand adjustment
Insert battery into battery compartment unit it “snaps” in place. Connect the
power adapter and allow the unit to charge for 10 hours (NM). Also you can
remove the battery from the unit and charge the battery directly.
You can use the machine when the LED charging indicator light changes from
red to green. Keep charging about one hour after the LED charging indicator
light turns green, it can extend the runtime.
The LED charging display will light when charging.
N TE: The unit will not charge if left in the N position.
It is recommended that you remove the power adapter from the unit once
the unit has completely charged.
1
2
3
12
3

5
Operation
Operating Instructions
Press the N/ FF switch button on top of the power head when ready to
operate. Place foot on power head and lean handle back gently to release lock
for sweeping use.
Twist the handle slightly to make the sweeper turn easily to where you want
to go.
4
4
Return handle to the full upright position to engage lock. N TE: Do not operate
the unit while in the upright and locked position. Do not let the unit run while in
the stationary position for any period of time. Keep the unit moving while in
operation.
5
5

6
Maintenance
E ptying Dirt Container:
Firmly grasp the unit at handle base and with the other hand, press the dirt con-
tainer release. Note: Make sure to have a firm grasp on the handle base and
carefully lay the handle flat.
Lift the dirt container out of the unit and dump the contents into wastebasket.
Reinsert the dirt container into the unit. Grasp the handle base and carefully ro-
tate it forward until it locks into place.
The performance of your new cleaner greatly depends upon care and maintenance
The instructions in this manual will guide you in performing basic care and
maintenance. To obtain the most satisfying years of service read the instructions
and keep them handy for future reference.
6
6
Storage
Attach the lip of the brushroll chamber over the hooks of the wall mount.
Rotate handle upwards until it snaps into the handle lock.
8
8
Cleaning Standard Carpet Brushroll
Press the Brushroll Release to remove the brushroll from the brushroll chamber.
Remove any wound up debris using a knife or scissors. Cut debris along
patented cleaning grooves in the brushroll for easier cleaning.
Reinstall brushroll into brushroll chamber.
9
9
7
7

7
Maintenance
Troubleshooting
Service problems can often be solved easily. You can be your own troubleshooter
by reviewing this guide. All other servicing should be done by an authorized
service center.
Unit does not turn on
Custo er Service Hotline
Website: www.globalindustrial.co
Battery Disposal
To preserve natural resources, please recycle or dispose of expired battery
pack properly.
THIS PR DUCT C NTAINS A NICKEL-METAL HYDRIDE BATTERY (NM).
IT MUST BE DISP SED F PR PERLY. L CAL, STATE, R FEDERAL LAWS
MAY PR HIBIT DISP SAL F NICKEL-METAL HYDRIDE BATTERY (NM) IN
RDINARY TRASH. C NSULT Y UR L CAL WASTE AUTH RITY F R
INF RMATI N REGARDING AVAILABLE RECYCLING AND/ R DISP SAL
PTI NS. F R DISP SAL INF RMATI N, CALL THE RECHARGEABLE
BATTERY RECYCLING C RP RATI N AT 1-800-8-BATTERY.
LED charging indicator
not lit while charging
Suction power is not
sufficient
Running ti e is not
sufficient
Brushroll does not
work while operating
Unit still does not
Operate properly
Proble What to do
• Charge battery again.
• Check electrical source-fuse or circuit breaker.
• Make sure the charging adapter is plugged in
the electrical outlet and charging socket properly.
• Check electrical source-fuse
• Empty dirt container.
• Charge battery again.
• New battery may be required, contact an
Authorized Service Center.
• Charge battery again.
• New battery may be required, contact an
Authorized Service Center.
• Clean brushroll.
• Contact an Authorized Service Center.
• Contact Perfect for service.

8
WHAT THIS WA ANTY COVE S
Your Global Industrial Sweeper is warranted to be free from all defects
in material and workmanship in normal use FO A PE IOD OF ONE
YEA . The warranty is granted only to the original purchaser of the
cleaner. The warranty is subject to the following provisions.
Contact Customer Service (1-800-645-2986) for Warranty Coverage.
Global reserves the right to change its warranty policy without notice.
WHAT THIS WA ANTY DOES NOT COVE
• Parts of the cleaner that require replacement under normal use.
• Damages or malfunctions caused by negligence, abuse, or use not
in accordance with the Owner’s Guide.
• Defects or damages caused by unauthorized service or the use of
other than Global original parts
Global Industrial will, at its option, repair or replace a defective sweeper
or sweeper part that is covered by this warranty. As a matter of warranty
policy, Global Industrial will not refund the consumer’s purchase price.
Global Industrial does not recognize internet sales, the warranty is null
and void if the unit is purchased on E-Bay or any other non authorized
internet site.
