Portable Dehumidifier - Energy Efficient
Model 246105
30 Pint Dehumidier
Model 246106
50 Pint Dehumidier
Model 246107
70 Pint Dehumidier
Model 246108
70 Pint Dehumidier
w/ Built-In Pump
Please read entire manual
carefully before use. Save
manual for future reference.
If there are any questions,
contact Global Industrial
Customer Service at
1-800-645-2986 or visit
www.globalindustrial.com.
WARNING
• DO NOT allow children or non-qualied persons operate this dehumidier.
• Disconnect unit from its power source before cleaning, maintenance, servicing or replacing parts.
• Disconnect all supply circuits before obtaining access to terminals.
• NEVER attempt to plug in or operate dehumidier with defective or damaged wires, power cord,
or power cord plug. All defective parts should be replaced immediately by a qualied service
technician using genuine replacement parts.
• Check the nameplate for the type of refrigerant gas used in the appliance. Maintenance and
disposal operations must be carried out by qualied personnel only.
• This hermetically sealed system contains uorinated Greenhouse gases covered by Kyoto Protocol.
• DO NOT pierce the cooling circuit of the machine.
• DO NOT use this unit for functions other than those described in this manual.
• Ensure power plug is rmly and completely plugged into the outlet. Doing so will avoid risk of
electric shock or re.
• DO NOT plug other appliances into the same outlet. Doing so may result in the risk of electric shock.
• DO NOT disassemble or modify the appliance or any of its parts. Doing so may result in the risk of
electric shock or re. All services should be referred to a qualied technician.
• DO NOT place the power cord or dehumidier near a heater, radiator, or other heat source. Doing so
may result in the risk of electric shock or re.
WARNING

Portable Dehumidifier - Energy Efficient
2
• This unit is equipped with a cord that has a earthed wire connected to a pin or grounding tab. The plug
must be plugged into a socket that is properly installed and earthed. DO NOT under any circumstances
cut or remove the earthed pin or grounding tab from the plug.
• The unit should be used or stored in such a way that it is protected from moisture, condensation, splashed
water, etc.
• ALWAYS transport your appliance in a vertical position and place on a stable, level surface during use. If the
unit is transported laying on its side it should be stood up and left unplugged for 6 hours prior to use.
• ALWAYS use the power switch on the control panel or remote control to turn the unit on/o. DO NOT start
or stop operation by plugging in or unplugging the power cord. Doing so can result in the risk of electric shock.
• DO NOT press the buttons on the control panel with anything other than your ngers.
• DO NOT use hazardous chemicals to clean or come into contact with the unit. To prevent damage to the
surface nish, use only a soft cloth to clean the appliance. DO NOT use wax, thinner, or strong detergents.
• DO NOT use the unit in the presence of inammable substances or vapors such as alcohol, insecticides,
or gasoline.
• If the appliance is making unusual sounds or is emitting smoke or an unusual odor, unplug it immediately.
• DO NOT clean the unit with water. Water can enter the unit and damage the insulation, creating a shock
hazard. If water enters the unit, unplug it immediately and contact Global Industrial Customer Service at
1-800-645-2986.
• Utilize two or more people to lift and install the unit.
• Be sure all accessories are removed from the packaging before installation and use.
• Avoid contact with the metal parts of the appliance when removing or re-installing the lter.
• DO NOT block the air inlet or outlet of the dehumidier. Reduced air ow will result in poor performance
and could damage the unit.
• ALWAYS grasp the plug when plugging in or unplugging the unit. Unplugging the unit by pulling on the cord
can run the risk of electrical shock and damage.
• Install the dehumidier on a sturdy, level oor capable of supporting up to 110 lbs. (50kg). Installation on a
weak or unleveled oor can result in the risk of property damage and personal injury.
• Close all doors and windows to the room for most ecient operation.
CAN ICES-3 (B)/NMB-3(B)
FCC CAUTION:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation. Any changes or modications not expressly
approved by the party responsible for compliance could void the user's authority
to operate the equipment.
This product is factory equipped with a power supply cord that has a three-pronged grounded plug. It must be
plugged into a mating grounding type receptacle in accordance with the National Electrical Code and applicable
local codes and ordinances. If the circuit does not have a grounding type receptacle, it is the responsibility and
obligation of the customer to exchange the existing receptacle in accordance with the National Electrical Code
and applicable local codes and ordinances. The third ground prong should not, under any circumstances, be
cut or removed. Never use the cord, the plug or the appliance when they show any sign of damage. Do not use
your appliance with an extension cord unless it has been checked and tested by a qualied electrical supplier.
Improper connection of the grounding plug can result in risk of re, electric shock and/or injury to persons
associated with the appliance. Check with a qualied service representative if in doubt that the appliance is
properly grounded.
IMPORTANT - GROUNDING METHOD

Portable Dehumidifier - Energy Efficient
• The mains power supply corresponds to the value indicated on the rating plate on the back of the dehumidier.
• The power socket and electrical circuit are adequate for the dehumidier.
• The mains socket matches the plug. If this is not the case, have the plug replaced.
• The mains socket is adequately earthed. Failure to follow these important safety instructions may result in
injury or damage and absolves Global Industrial of all liability.
ELECTRICAL CONNECTIONS
Before plugging the appliance into the mains socket, check that:
Important information for correct disposal of the product in accordance with EC Directive 2012/19/EU:
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority dierentiated waste collection center or
to a dealer providing this service. Disposing of a household appliance separately
avoids possible negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials to be recovered to
obtain signicant savings in energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a crossed-
out wheeled dustbin.
NOTES ON HUMIDITY
Air always contains a certain amount of water in the form of vapor. This determines the level of humidity in an
atmosphere. The capacity of the air to hold water vapor increases with temperature. This is why in our homes,
as soon as the temperature decreases, the vapor contained in the air condenses. This is evident on the colder
surfaces in the room, such as the windows, walls, etc. The purpose of a dehumidier is to remove the excess
moisture from the air, avoiding the damage caused by condensation.
Experts have established that the optimum environmental conditions for our wellbeing and for the home are
obtained between 40% and 60% relative humidity. With very low temperatures, you are recommended to heat
the room even minimally. This considerably increases the dehumidifying power of the appliance. With heating,
the condensation formed by the water vapor on windows and other cold surfaces evaporates into the air to be
collected by the dehumidier. Air leaving the dehumidier is usually about 1-2° warmer than room temperature.
COMPONENT BREAKDOWN
3
1 Control Panel
2 Air Outlet
3 Bucket
4 Water Level Indicator
5 Casters
6 Handle
7 Air Intake Grille
8 Drainage Holes
9 Power Cord
* Note: All illustrations in this manual are for explanatory purposes
only. Your unit may look slightly dierent.

Pump Adapter
Casters
(4)
Before using, remove all accessories from the bucket: Detach the bucket, open the cover，remove the plug and all
other accessories. Reinstall the cover, and correctly reattach the bucket into the dehumidier.
Portable Dehumidifier - Energy Efficient
1
Clean Filter Symbol
5
Timer "On" Symbol
A
On/OffBuon
E
Fan Speed Buon
2
High Fan Speed Symbol
6
Bucket Full Alarm
B
Timer Buon
F
Filter Reset Buon
3
Display Screen
7
Connuous Symbol
C
Decrease Buon
G
Pump Buon
4
Timer "Off" Symbol
8
Pump Symbol
D
Increase Buon
The above gure is for model 246108 (with pump)
The above gure is for models 246105, 246106 & 246107 (without pump)
A ≤ 45°
Plug
Plate on Caster
Tilt the unit no more than 45°
and insert the casters with force.
Make sure the plate of the casters
is ush against the bottom of
the unit.
Attaching the Casters:
4
Accessories Included:
Casters (4)
Pump Adapter
(for model 246108 only)
Pump Drain Pipe
(for model 246108 only)
5

On/O power supply, used to control the start-up or shut down of the dehumidier.
Increase and decrease the indoor humidity level, or set the time.
/
• Humidity adjustable range is 35%RH-80%RH. The screen will display the setting humidity,
and after few seconds, turn to display the ambient humidity.
• When the ambient humidity is lower than the set humidity, the compressor will stop running
and after a few minutes, the fan will stop running.
• To continuously run, press the button until “ ” is displayed on the screen and the “ ”
continuous symbol lights up.
Fan Speed, used to select the speed from Low to High. Speed is on high when the “ ” symbol
lights up.
Timer Button, used to delay start-up or shutdown. This avoids wasting electricity by optimizing
operating periods.
• Turn machine on and choose mode; for example: Dehumidify Mode, High Fan Speed. Turn machine o.
Programming Start-Up
• Press Timer Button, the screen will begin to ash. Press the
from 0.5 to 24 hours.
/buttons to adjust the set-time
• After 5 seconds without operation, the Timer will begin and the “ ” symbol with light up.
• To cancel Timer, press Timer button again and the “ ” symbol will disappear.
Bucket Full Alarm
• When the bucket is full, the compressor will shut-o and after a few minutes the fan will stop. The machine
will begin to beep and the Bucket Full symbol “ ” will ash.
• The unit will not run again until the bucket is emptied and properly placed back inside the dehumidier.
• Clean the bucket weekly to prevent growth of mold, mildew and bacteria. Use a mild detergent to clean.
Ensure bucket is completely dry before reinstalling back into dehumidier.
• NOTE: Hold the bucket with both hands when emptying.
• NOTE: When the bucket is full or removed from the unit, the compressor will turn o but the fan will continue
to run for a few minutes. This is completely normal; the machine will not be removing moisture from
the air at this time.
• NOTE: During operation, it is normal for the unit to exhaust warm air from the top of the unit.
• CAUTION: DO NOT place the bucket on the oor when full as it is uneven on the bottom and water may spill.
5

Continuous Drain
• Connect the drain pipe on the back of the dehumidier, then the unit can continuously run without the use
of the bucket.
1) Put the dehumidier on a level oor, unscrew the cap on the back of the unit.
2) Install the drain and gasket connector.
3) Install the drain pipe to the connector.
4) Press Power button to run the unit.
For Model 246108 Pump Drain:
5) Press the “PUMP” button to start the pump drain function,
and the “PUMP” symbol will light up. The maximum height
of pump drainage is 16.4 ft (5 meters).
• If the continuous drain function is not needed, install the cap on the drain hole on the back of the unit and
the water will ow into the bucket.
NOTE: Make sure the drain pipe
is installed correctly, otherwise
the water will not drain properly.
NOTE: Ensure the unit is placed
on a level ground, otherwise the
water will not drain properly.
Automatic Defrost
When frost builds up on the evaporator coils, the compressor will cycle o and the fan will continue to run until the
frost disappears. When the coils are completely defrosted, the compressor or fan (depending on the model) will
automatically restart and dehumidify will resume.
Location Requirements
Note: The unit operating in a basement will have little to no eect in drying out an adjacent enclosed area, such as a closet,
unless there is adequate circulation of air in and out of the area.
6
• Do not use outdoors. This unit is designed for indoor use only.
• Place the dehumidier on a smooth and level oor surface that is
strong enough to support the unit with a full bucket of water.
• Allow at least 18 inches of air ow on all sides.
• Place the unit in an area where the temperature will not fall
below 41°F (5°C).
• Utilize the dehumidier in areas of excessive moisture, to prevent
moisture damage. Such areas as basements, kitchens, laundry
rooms and bathrooms.
• Keep dehumidier away from clothes dryer.
• The dehumidier must be operated in an enclosed area to be most
eective. Close all doors, windows and any other outside openings
to the room to get best results.

Cleaning and Maintenance
Warning: Before cleaning and maintenance, turn the power o on the control panel of the dehumidier. Wait a
few minutes then unplug the unit from the main socket. Not doing so increases the risk of electric shock or re.
The dehumidier’s water collection tank needs to be cleaned with soap and warm water or a mild
disinfectant frequently. Mold and mildew can build up quickly, and when inside a dehumidier tank,
it can get dispersed into the air, causing illness.
A few times a season, use a vacuum with a brush attachment to clean the intake and exhaust grilles.
Dust and debris build-up can cause blockages that can lead to deterioration of the unit.
To keep the appliance working eciently, it is
recommended to clean the lter every week
of operation:
Removing lter
• Use a vacuum with a brush attachment to
remove dust accumulation from the lter.
• If lter is very dirty, immerse it in warm water
and rinse a number of times. The water
temperature should never be hotter than
104°F (40°C). Allow lter to fully dry before
reattaching back to the dehumidier.
Cleaning Filter
End of Season Maintenance and Storage
• Turn o power and unplug from main socket.
• Empty the bucket.
• Remove cap and run o all water left into a basin.
• When all water has been drained, put the cap back in place.
• Clean lter and dry thoroughly before reinstalling.
• Cover the appliance to prevent from dust.
• Store the dehumidier upright in a dry location.
Start of Season Checks
• Inspect dehumidier for signs of damage.
• Inspect power cable and plug for signs of damage.
• Follow the installation instructions precisely.
• Please contact Global Industrial Customer Service at 1-800-645-2986 for questions and inquiries.
Troubleshooting:
Problem Possible Cause Soluon
The dehumidifier is unplugged. Make sure the dehumidifier's plug is pushed
completely into the outlet.
The fuse is blown/circuit breaker is tripped. Check the house fuse/circuit breaker box and
replace fuse or reset breaker.
Dehumidifier has reached its present level or
the bucket is full.
The dehumidifier automacally turns offwhen
either condion occurs. Change to a lower
seng or empty the water bucket and
replace properly.
Bucket is not in the proper posion. The bucket must be in place and securely
seated for the dehumidifier to operate.
Power Failure.
There is a protecve me delay (up to 3
minutes) to prevent tripping of the
compressor overload. For this reason, the unit
may not start normal operaon for 3 minutes
aer it is powered back on.
Dehumidifier Does
Not Start
7

Troubleshooting:
(continued)
Problem Possible Cause Soluon
Not enough me allowed for unit to remove
moisture.
When first installed, allow at least 24 hours to
maintain the desired dryness.
Airflow is restricted.
Make sure there are no curtains, blinds, or
furniture blocking the front or back of the
dehumidifier. See the Locaon Requirements
secon of this manual for more informaon.
Dirty filter. See the Cleaning Filter secon of this manual
for more informaon.
The Humidity Control may not be set low
enough.
For drier air, press the buon to lower
the percent humidity desired in the room, or
set the dehumidifier to for maximum
dehumidify.
Doors and windows may not be closed ghtly. Check that all doors, windows, and other
openings are securely closed.
Clothes dryer may be blowing moist air into
the room.
Install the dehumidifier away from the dryer.
The dryer should be vented outside.
Room temperature is too low.
Moisture removal is best at higher room
temperatures. Lower room temperatures will
reduce the moisture removal rate. This
dehumidifier is designed to operate at
temperatures above 5°C (41°F).
The area is too large. The capacity of the appliance cannot meet
the area of the room.
Doors and windows are open. Close all doors and windows.
Frost Appears on
Heat-Exchanger
Appliance has been operated recently or the
room temperature is too low.
This is normal, frost usually disappears within
60 minutes.
Fan Noise The air is passing through the appliance. This sound is normal.
Water on the Floor Drain connecons are not fastened properly.
Dehumidifier is not on a level surface.
Check the drain connecon for leaks and
fasten properly.
Make sure the appliance is operang on a
level surface.
Dehumidifier Does
Not Dry the Air as it
Should
Appliance Runs
Too Long
8
If any of the following error codes appear, contact a certied after-sales service department for inspection
and/or repair. For additional information, contact Global Industrial Customer Service at 1-800-645-2986.
CODE DESCRIPTION
P1 Bucket Pull Out
EH Humidity Sensor Failure
E1
E2
E3 Gas Leakage
Temperature Sensor
Failure
• Code “P1” applies to model 246108 (with pump) only.
• If code “E3” appears, check to see if the room temperature
is above 90°F (32°C). If this is the case, relocate the
dehumidier in a location below 86°F (30°C) and allow to
sit for 2 hours before running again. Start the unit again;
if the “E3” code still appears, contact a service department
or Global Industrial Customer Service at 1-800-645-2986
for further instructions.
