Glowworm Swift flow 100 User manual

Installation Instructions
Tobeleftwiththeuser
One Contact Total Service
Customer Services:
Tel: [phone]
Fax: [phone]
Hepworth Heating Ltd.,
Nottingham Road, Belper, Derbyshire. DE56 1JT
General/Sales enquiries:
Tel: [phone] Fax: [phone]

Fanned Flue Combination Boiler
220650B.02.97
G.C. No. 47 313 07 - S.I.T
G.C. No. 47 313 08 - HONEYWELL
100
This is a Cat I2H Appliance
4309

2
220650B
Diagram 1.2
1 G e n e r a l
Diagram 1.1
2810
2804
ALL DIMENSIONS in MILLIMETRES
KEY:
22mm COMPRESSION
CENTRAL HEATING
15mm COMPRESSION
DOMESTIC WATER
Rc
1/2
(
1/2
in. BSPT)
GAS CONNECTION
63 331
168
133
450
63
SAFETY
VALVE
DISCHARGE
783
25
2.5
66
66 107 107
101
WATER
THROTTLE
MINI
EXPANSION
VESSEL
FANNED
FLUE AUTOMATIC
AIR VENT
HEAT EXCHANGER
MAIN BURNER
PILOT
BURNER
GAS VALVE
SAFETY
VALVE
PRESSURE
SWITCH
D.H.W.
COLD
INLET
D.H.W.
HOT
OUTLET
C.H.
RETURN
GAS
SUPPLY
C.H.
FLOW
SAFETY
VALVE DISCHARGE
EXPANSION
VESSEL
FLOW
SWITCH
PUMP
The instructions consist of three parts, Installation,
Servicing and Instructions for Use which includes the
Guarantee Registration Card. The instructions are an
integral part of the appliance and must, to comply with
the current issue of the Gas Safety (Installation and Use)
Regulations, be handed to the user on completion of the
installation.
Gas Testing and Certification
The boiler is tested and certificated for safety and
performance. It is, therefore, important that no alteration
is made to the boiler unless approved, in writing, by
Hepworth Heating Ltd.
Any alteration not approved by Hepworth Heating Ltd.,
could invalidate the certification, boiler warranty and
may also infringe the current issue of the Statutory
requirements.
CE Mark
The CE mark on this appliance shows compliance with:
1. Directive 90/396/EEC on the approximation of the
Laws of the Member States relating to appliances
burning gaseous fuels.
2. Directive 73/23/EEC on the harmonization of the
Laws of the Member States relating to electrical
equipment designed for use within certain voltage
limits.

3220650B
■For larger systems use an additional expansion vessel, see Section 4.
❋Boiler starts at an inlet pressure of 0.5bar but requires 0.8bar for maximum output.
●Ball valves are fitted in water and gas connections, plus a drain point on all water connections.
Lift Weight 37.0kg (81.4lb)
Total Weight 50.4kg (111lb)
●Gas connection Rc1/2(
1/
2in BSPT)
●Heating and return 22mm compression
●Domestic hot water 15mm compression
Safety valve Preset 3bar (43.5lbf/in2)
Safety valve discharge 15mm copper
Water content 1.74 litres (0.38 gallon)
■Expansion vessel capacity 8 litres (1.76 gallons)
Heating cold fill 0.7bar
pressure minimum (10.1lbf/in2)
❋D.H.W 0.5 to 10bar
working pressure (7.25 to 188lbf/in2)
■Maximum Heating 119 litres
system water (26.2 gallons)
content using with a cold
fitted expansion fill pressure
vessel. of 0.7bar
Electrical supply 240V~50Hz
Electrical rating 150W fused 3A
Internal Fuse rating 1) Type T1.6A
2) Type T630mA
NOMINAL kW 22.5 36.2 12.9
HEAT
INPUT Btu/h 76,900 123,500 44,000
NOMINAL kW 17.6 29.3 9.1
HEAT
OUTPUT Btu/h 60,000 100,000 31,000
BURNER m bar 6.0 16.3 1.7
PRESSURE in.wg 2.4 6.5 0.7
APPROX. m
3
/h 2.1 3.4 1.2
GAS RATE ft
3
/h 75.8 121.6 41.9
TABLE 1 C.H. Max D.H.W Max MIN
TABLE 2
1 G e n e r a l
This boiler will be fitted with either a Honeywell or SIT
Gas Valve.
The valve used can be identified as shown:
1.1 Installation
Materials and equipment should be fit for their purpose
and of suitable quality and workmanship.
1.2 Important Notice
This boiler is for use only on G20 gas.
1.3 Sheet metal Parts
WARNING. When installing the appliance, care should
be taken to avoid any possibility of personal injury when
handling sheet metal parts.
1.4 Requirements
The installation of this boiler must be carried out by a
competent person in accordance the rules in force in the
countries of destination.
Manufacturer’s instructions supplied.
Manufacturer’s instructions must not be taken as
overriding statutory requirements.
HONEYWELL S.I.T.
1.5 Data Label
The data label is on the inner case cover.
1.6 Data
See Tables 1 and 2.

4
220650B
1 G e n e r a l
1.8 Gas Supply
The gas installation must be in accordance with the rules
in force in the countries of destination.
The supply from the governed gas meter must be of
adequate size to provide a steady inlet working pressure
of 20mbar (8in wg) at the boiler.
1.9 Electrical Supply
WARNING: The boiler must be earthed.
The installation must be in accordance with the rules in
force in the countries of destination.
All system components shall be of an approved type.
Connection of the whole electrical system of the boiler
and any heating system controls to the electrical supply,
must be through one common isolator.
Isolation should be by a double pole switched fused spur
box, with a minimum separation of 3mm in both poles.
The fused spur box should be readily accessible and
preferably adjacent to the appliance. It should be
identified as to its use.
Alternatively connection can be made through an
unswitched shuttered socket and 3A fused 3 pin plug.
The mains supply cable and other cables connected to
the boiler must be the PVC flexible type of at least
0.75mm2, (24/0.20mm).

5220650B
2 B o i l e r P o s i t i o n
Diagram 2.1
*
**
*
Increase to 25mm clearance from
combustible material.
Dimensions in millimetres
2811
55
150
800
5
55
150
2.1 Location
The boiler must be installed in accordance with the rules
in froce in the countries of desination.
The boiler is not suitable for fitting out of doors.
Any electrical switch or boiler control using mains
electricity must be positioned so that it cannot be
touched by a person using the bath or shower.
The boiler must be mounted on a flat wall which is
sufficiently robust to take its weight, refer to Table 2.
If the boiler is to be fitted into a cupboard, compartment
or unusual location, special procedures are necessary.
Make sure that the cupboard or compartment air vents
are positioned to be clear of obstructions at all times,
refer to Section 3.
2.2 Clearances
The boiler should be positioned so that at least the
minimum operational and servicing clearances are
provided, see diagram 2.1.
Additional clearances may be required around the boiler
for installation.
For flue installations where external access is not
practicable, the clearances around the boiler may need to
be increased as follows.
For rear flue installations the dimension between the
boiler mounting wall and a permanent facing wall must
be a minimum of “X”, see diagram 3.1 and 3.3, plus
272mm.
For side flue installation the dimension between any
adjacent permanent walls must be a minimum of “Y”,
see diagram 3.2 and 3.4, plus 332mm.

6
220650B
Diagram 3.2 Diagram 3.4
SIDE FLUE - STANDARD
Left or Right SIDE FLUE - 1 and 2 metre Left or Right
DISTANCE 'Y': 80 TO 533mm
Diagram 3.1 Diagram 3.3REAR FLUE - 1 and 2 metre
WALL THICKNESS 'X': 75 TO 588mm
2813 2812
REAR FLUE - STANDARD
1m DISTANCE 'X' = 75 TO 898mm
2m DISTANCE 'X' = 75 TO 1898mm
1m DISTANCE 'Y' = 80 TO 843mm
2m DISTANCE 'Y' = 80 TO 1843mm
3 F l u e a n d V e n t i l a t i o n
"X"
"Y"
"Y"
4738
"X"
4739
3.1 Flue
Ventilation must be provided in accordance with the
rules in force in the countries of destination.
The following information refers specifically to this
boiler:
3.2 Flue Position and Length
The air and flue ducting connect to the top of the boiler
using the air box and can be positioned in one of three
directions:
rearward, left or right.
The standard flue is able to provide the duct length range
shown in diagram 3.1 for a rear flue or diagram 3.2 for a
side flue.
If a longer flue duct is required, do not extend the
ductings.
A 1 or 2metre flue system and elbow / terminal kit must
be used and can be supplied.
This is able to provide the duct length range shown in
diagram 3.3 for a rear flue, diagram 3.4 for a side flue.
A Vertical Flue Kit can be supplied with instructions.
3.3 Internal Access Flue
The flue can be installed from inside the building, when
access to the outside wall face is not practicable. An
internal access kit is provided in the standard carton.
3.4 Terminal Position
The minimum acceptable siting dimensions for the
terminal from obstructions, other terminals and
ventilation openings are shown in diagram 3.5.
The terminal must be exposed to the external air, the
position allowing free passage of air across it at all
times.
Car ports or similar extensions of a roof only, or a roof
and one wall, require special consideration with respect
to any openings, doors, vents or windows under the roof.
Care is required to protect the roof if made of plastic
sheeting. If the car port comprises of a roof and two or
more walls, seek advice from the local gas undertaking
before installing the boiler.
If the terminal is fitted within 600mm below plastic
guttering, an aluminium shield 1500mm long should be
fitted immediately beneath the guttering or eaves. If the
terminal is fitted within 450mm below painted eaves or a
painted gutter, an aluminium shield 750mm long should
be fitted immediately beneath the guttering or eaves.

7220650B
3 F l u e a n d V e n t i l a t i o n
MINIMUM
SPACING
A
A
FGEA
G
G
G
B,C B,C
FF
K
K
K
C
G
LL
UNDER CAR PORT etc.
H,I
JD
F
K
2816
MINIMUM SITING DIMENSIONS FOR
FANNED FLUE TERMINALS
POSITION
MM
A DIRECTLY BELOW AN OPENABLE
WINDOW, AIR VENT, OR ANY
OTHER VENTILATION OPENING 300
B BELOW GUTTER, DRAIN/SOIL PIPE 75
C BELOW EAVES 200
D BELOW A BALCONY OR CAR PORT 200
E FROM VERTICAL DRAIN PIPES AND
SOIL PIPES 75
F FROM INTERNAL OR EXTERNAL
CORNERS 300
G ABOVE ADJACENT GROUND OR
BALCONY LEVEL 300
H FROM SURFACE FACING THE
TERMINAL 600
I FACING TERMINALS 1200
J FROM OPENING (DOOR/WINDOW)
IN CAR PORT INTO DWELLING 1200
K VERTICAL FROM A TERMINAL 1500
L HORIZONTALLY FROM A TERMINAL 300
3.5 Terminal Guard
A terminal guard is required if persons could come into
contact with the terminal or the terminal could be subject
to damage.
If a terminal guard is required, it must be positioned to
provide a minimum of 50mm clearance from any part of
the terminal and be central over the terminal.
The guard should be similar to that shown in
diagram 3.5.
3.6 Timber Frame Buildings
If the boiler is to be installed in a timber frame building,
seek advice from the local gas undertaking or from
Hepworth Heating Ltd.
3.7 Room Ventilation
The boiler is room sealed, so when it is installed in a
room or space, a permanent air vent is not required.
3.8 Cupboard or Compartment Ventilation
If the boiler is to be fitted in a cupboard or compartment,
permanent high and low level air vents must be provided
in accordance with the rules in force in the countries of
destination. The vents must have at least the effective
areas as given in Table 3.
TABLE 3
Position Air from Air Direct
of Room or from
Air Vent Internal space Outside
High Vent 326cm2(50in2) 163cm2(25in2)
Low Vent 326cm2(50in2) 163cm2(25in2)Diagram 3.5

8
220650B
Diagram 4.1
Diagram 4.1A
4462
4463
AVAILABLE PUMP HEAD
SYSTEM DIFFERENTIAL TEMPERATURE
SYSTEM HEATING LOAD
*
0
5
10
15
17
20
11
40
35
30.6
25
19.8
15
10
5
0
F
0
C
0
0
15
30
40
50
60
0
1
2
3
5
10
16
14
4
10
12
5
FEET
4.5
4.03.53.0
2.5 5.0 GALLONS/Min
LITRES/Min
FLOW RATE
18
1715
13
11 19 20 22 23
Btu/h x
1000 kW
21
ACCEPTABLE
DIFFERENTIAL
RANGE
*
P
U
M
P
C
U
R
V
E
-
S
E
T
T
I
N
G
3
P
U
M
P
C
U
R
V
E
-
S
E
T
T
I
N
G
2
REMAINING CONVEYING CAPACITY OF PUMP 
SHOWING RELATIVE SYSTEM DIFFERENTIAL AT
VARIOUS SYSTEM HEATING LOADS.
M


4 H e a t i n g S y s t e m
GRUNDFOS
WILO
AVAILABLE PUMP HEAD
SYSTEM DIFFERENTIAL TEMPERATURE
SYSTEM HEATING LOAD
*
0
5
10
15
17
20
11
40
35
30.6
25
19.8
15
10
5
0

F
0
C
0
0
15
30
40
50
60
0
1
2
3
5
10
16
14
4
10
12
5
FEET
4.5
4.03.53.0
2.5 5.0 GALLONS/Min
LITRES/Min
FLOW RATE
18
1715
13
11 19 20 22 23
21
ACCEPTABLE
DIFFERENTIAL
RANGE
*
P
U
M
P
C
U
R
V
E
-
S
E
T
T
I
N
G
2
/
W
I
L
O
S
E
T
T
I
N
G
REMAINING CONVEYING CAPACITY OF PUMP 
SHOWING RELATIVE SYSTEM DIFFERENTIAL AT
VARIOUS SYSTEM HEATING LOADS.
M

- Setting 2- Setting 1
P
U
M
P
C
U
R
V
E
-
S
E
T
T
I
N
G
1
/
W
I
L
O
S
E
T
T
I
N
G
Btu/h x
1000 kW

9220650B
Grundfos Pump
The pump adjuster should normally be left at maximum
(3) but in some cases it is permissible to adjust the pump
to a lower setting (2). See diagram 4.1.
To use diagram 4.1 start with the required heating
system load.
In the example shown the maximum boiler output has
been chosen, 17.6kW (60,000Btu/h).
Draw a horizontal line from the required system
differential temperature axis to intersect the curve. In
the example 11°C (19.8°F) has been chosen,
shown . At the point of intersection draw a
vertical line to cross the pump curve. From this point
draw a further horizontal line to determine the available
pump head. In the example 1.9m (6ft3in) is available. A
greater pump head can be achieved by choosing a higher
system differential temperature, up to a maximum of
4.0m (13ft) at a system differential of 17°C (30.6°F).
The system must be designed such that the available
pump head is not exceeded.
If the heating system load is less than 13.2kW
(45,000Btu/h) then it is permissible to adjust the pump
setting to (2), shown .
This results in an available pump head of 2.1m (7ft).
This is the maximum that can be achieved with the pump
at this setting.
Glow-worm Wilo Pump
The pump adjuster should normally be left at maximum
(2) but in some cases it is permissible to adjust to a lower
setting (1), see diagram 4.1a.
To use diagram 4.1a start with the required heating
system load.
In the example shown the maximum boiler output has
been chosen, 17.6kW (60,000Btu/h).
Draw a horizontal line from the required system
differential temperature axis to intersect the curve. In
the example 11°C (19.8°F) has been chosen,
shown . At the point of intersection draw a
vertical line to cross the pump curve. From this point
draw a further horizontal line to determine the available
head. In the example 1.9m (6ft3in) is available. A
greater pump head can be achieved by choosing a higher
system differential temperature, up to a maximum of
4.0m (13ft) at a system differential of 17°C (30.6°F).
The system must be designed such that the available
pump head is not exceeded.
If the heating system load is less than 13.3kW
(45,000Btu/h) then it is permissible to adjust the pump
setting to (1), shown .
This results in an available pump head of 4.2m (13ft9in).
This is the maximum that can be achieved with the pump
at this setting.
4 H e a t i n g S y s t e m
4.1 General Notes
The boiler is for use in sealed water systems only.
4.2 Safety Valve
The safety valve is an integral part of the boiler and it
cannot be adjusted.
4.3 Pressure Gauge
A pressure gauge is incorporated into the boiler to
indicate the system pressure.
4.4 Pump
The circulation pump is integral with the boiler.
The remaining circulating pressure head available from
the boiler is shown in diagram 4.1, Grundfos or 4.1a
Glow-worm Wilo.
4.5 Expansion Vessel
The boiler has an integral expansion vessel with a
capacity of 8Litres (1.76gallons), with a charge pressure
of 0.75bar.
The maximum heating system water content using the
fitted expansion vessel ranges from 119Litres with a cold
fill pressure of 0.7bar, to 98Litres with a cold fill
pressure of 1.05bar. If, due to a high static head, the
cold fill pressure is higher, then the expansion vessel
pre-fill pressure must be increased, and the maximum
system volume decreased.
4.6 Flow Rate
A valve must be incorporated in the main flow or return
of the system, valve “A” shown in the flow in diagram
4.2. This valve must be lockable and positioned so that
inadvertent closure or unauthorised interference is not
possible. The design differential can be between 11°C
(20°F) and 17°C (30°F), dependent on the system
resistance and the available pump head.

10
220650B
Diagram 4.2
2818
BOILER
3-LITRE
MAKE-UP
BOTTLE
(if required)
NON-RETURN
VALVE
AUTO AIR
VENT
DOMESTIC
WATER
HOT
COLD SUPPLY
FILLING
POINT
DRAIN
POINT
MIN. 22mm
DIA. BY-PASS
'B'
'A' BY-PASS
VALVE
FLOW CONTROL
VALVE
HEATING
CIRCUIT
RETURN
ADDITIONAL
EXPANSION
VESSEL
(if required)
4 H e a t i n g S y s t e m
4.7 Bypass
It is ESSENTIAL that a bypass of 22mm od minimum is
fitted to all installations. The bypass must have a
lockable valve, “B” in diagram 4.2, incorporated in a
position so that inadvertent closure is not possible.
The bypass MUST be fitted before any system control.
A radiator bypass is NOT recommended.
4.8 Make Up
Provision should be made for replacing water lost from
the system using a make up bottle mounted in a position
higher than the top point of the system, connected
through a non-return valve to the return side of the
heating circuit, see diagram 4.2.
Alternatively, provision for make up can be made by
pre-pressurisation of the circuit.

11 220650B
Diagram 4.3
METHOD 1
METHOD 2
METHOD 3
SUPPLY STOP
VALVE
SUPPLY
PIPE
HOSE
UNIONS SERVICING
VALVE
TEMPORARY
HOSE
HEATING
SYSTEM
HEATING
SYSTEM
TEMPORARY
HOSE
HOSE
UNIONS SERVICING
VALVE
SUPPLY
PIPE
SUPPLY STOP
VALVE
DOUBLE CHECK
VALVE ASSEMBLY
HEATING
SYSTEM
SERVICING
VALVE
SUPPLY
STOP VALVE
SUPPLY
PIPE
HOSE
UNIONS DOUBLE CHECK
VALVE ASSEMBLY
OVERFLOW
CISTERN
COMBINED
CHECK VALVE
AND VACUUM
BREAKER
PRESSURE
REDUCING
VALVE
4 H e a t i n g S y s t e m
5 D o m e s t i c H o t W a t e r S y s t e m
3132
4.9 Filling Sealed Systems
Provision for filling the system at a low level must be
made. Three methods of filling are shown in diagram
4.3. There must be no permanent connection to the
mains water supply, even through a non-return valve.
4.10 Corrosion Inhibitor
If an inhibitor is to be used in the system, contact a
manufacturer so that they can recommend their most
suitable product.
When fitting the boiler into an existing system, special
care should be taken to drain the entire system, including
radiators, then thoroughly cleaning out before fitting the
boiler whether or not adding an inhibitor.
4.11 Draining Tap
A draining tap must be provided at the lowest points of
the system, which will allow the entire system to be
drained. An additional draining tap MUST be fitted
close to the boiler.
The flow and return isolation valves are provided with
drain points for boiler heat exchanger drainage.
5.1 General
The domestic hot water service must be in accordance
with the rules in for in the countries of destination.
5.2 Water Pressure
For the minimum and maximum working pressures of
the domestic hot water circuit of the boiler, refer to
Section 1.6.
If the cold water supply pressure exceeds the maximum,
a pressure reducing valve must be fitted in the supply to
the boiler to reduce the pressure to within the limits
given.
5.3 “Hard” Water Areas
In areas where the water is “hard”, that is, more than
200mg/litre, it is recommended that a proprietary scale
reducer is fitted in the cold supply to the boiler. Check
the total water “hardness” using the kit supplied, in the
door, following the instructions given. Consult the local
water undertaking for additional advice.
A double check valve assembly must be fitted upstream
of the scale reducer. For the relative position of the scale
reducer and pressure reducing valve, if required, refer to
the manufacturer’s instructions.

12
220650B
Diagram 6.1
Diagram 6.2
Diagram 6.3
4567
2822
OUTER CASE
PLASTIC PLUGS (2)
DOOR
COVER
PLATE
OUTER CASE SECURING
SCREW (2)
SECURING
SCREW (4)
INNER CASE
COVER
2821
LOCATION
CLIPS
CLIP (5)
SECURING SCREW (2)
SELECTOR SWITCH
UNIONS (5)
6 I n s t a l l a t i o n P r e p a r a t i o n
6.1 Unpacking
Remove the top carton and cut out the flue template from
the inner flap.
Open the control door, see diagram 6.1.
Remove the two screws securing the outer case and then
lift it at the top and pull it forwards and off, see diagram
6.1.
Remove the cover of the inner case, secured with four
screws, see diagram 6.2
Disconnect the gas cock union and the front unions of
the isolation valves, see diagram 6.3.
Slightly loosen the clips of the gas service cock and the
isolating valves.
Remove the two boiler securing screws then remove the
boiler from the mounting frame, by pulling the studs
from the clips and unhooking it at the top.

13 220650B
Diagram 6.4
Diagram 6.5
2882
2304
FLUE
CENTRE
LINE
CORNER
(Left Flue)
CORNER
(Right Flue)
115Dia.
168 168
6 I n s t a l l a t i o n P r e p a r a t i o n
FLUE
TEMPLATE
(Cut from
carton top
inner flap)
TOP OF
BOILER
MIN.
CLEARANCE
87
104
115Dia.
584
480
300
FLUE
CENTRELINE
BOILER
MOUNTING FRAME
FIXINGS POINTS
6.2 Marking
The boiler mounting frame is the same width as the
boiler but the flue connection sticks out at the top.
Place the boiler mounting frame on the wall in the
required position, see diagram 2.1, to maintain minimum
clearances. Make sure that the isolation valves are at the
bottom facing forwards and that the frame top is
horizontal, then mark the four wall fixing points through
the holes in the two horizontal straps.
Position the flue template on the wall, the arrow points
on the centres of the two upper fixing points previously
marked, see diagram 6.4 which also gives dimensions.
For a rear flue, mark the position as required.
For a side flue, mark the horizontal flue centre line at the
sides of the template. Extend the flue centre line
horizontally left or right to the internal corner where the
flue is required to exit to outside.
Mark the position of the circular hole, on the flue exit
wall, using the dimensions given in diagram 6.5.
From the flue position marks, check that the flue
terminal will be in a suitable position, see diagram 3.5.
6.3 Flue Hole Cutting
Cut the hole horizontally in the wall, to the diameter
shown in diagram 6.4, using, preferably, a core drill.
After cutting the hole, check that it will accept the wall
sleeve.
6.4 Wall Sleeve
Note: The wall sleeve should be used for all installations.
Place the wall sleeve into the hole, flush with the outside
wall face and seal around the sleeve to make it
weatherproof on the outside and internally “good”.
Access to the outside is possible through the sleeve.
If the sleeve is too long, cut it to the same length as the
wall thickness.
For wall thicknesses over 300mm, the wall sleeve must
be fitted flush with the outside wall face. Make good the
external wall face, leave the internal wall face till later.
6.5 Boiler Mounting Frame Fixing
Position the flue template over the flue hole and check
the position of the wall fixing points. Mark the position
of the fixing holes again, if required.
Drill the four fixing holes and insert wall plugs to suit
No.10x50mm long screws.
Secure the boiler mounting frame to the wall using
No.10x50mm long screws.

14
220650B
7 F l u e P r e p a r a t i o n
Diagram 7.1
Diagram 7.2
FLUE TERMINAL
REAR DUCT
2823
X + 165
( AIR DUCT ASSEMBLY)
X + 115
( FLUE DUCT )
X
BOILER
MOUNTING
WALL
OUTSIDE
WALL
FACE
FLUE
DUCT
FLUE
TERMINAL
63
2884
OUTSIDE
WALL
FACE
Diagram 7.3
SIDE DUCT -STANDARD FLUE
Y
Y + 209
(AIR DUCT
ASSEMBLY)
SIDE
OF
BOILER
MOUNTING
FRAME
OUTSIDE
WALL
FACE
Y + 172
(FLUE DUCT)
2824
7.1 Flue Length
For a rear flue, measure the distance from the outside
wall face to the boiler mounting wall. Check that the
flue length will be suitable, see diagram 3.1 for a
standard flue system or diagram 3.3 for a long flue
system.
For a side flue, measure the distance from the outside
wall face to the side of the boiler mounting frame.
Check that the flue length will be suitable, see diagram
3.2 for a standard flue system or diagram 3.4 for a long
flue system.
All long flue systems are installed in a similar manner to
the standard flue.
7.2 Rear Flue
Mark the air duct assembly and the flue duct at the
lengths shown in diagram 7.2 then cut to length, cutting
square and removing any burrs.
Mark a line 34mm from the end of the flue duct, see
diagram 7.4.
7.3 Side Flue
Mark the air duct assembly and the flue duct at the
lengths shown in diagram 7.3 then cut to length, cutting
square and removing any burrs.
Mark a line 34mm from the end of the flue duct, see
diagram 7.4.

15 220650B
7 F l u e P r e p a r a t i o n
Diagram 7.7
STANDARD FLUE ILLUSTRATED Diagram 7.6
STANDARD FLUE ILLUSTRATED
Diagram 7.5
2826
AIR BOX / FLUE
ASSEMBLY
2302
SECURING
NUT (4) AIR DUCT
AIR BOX
WASHER (4)
3.3 DIA
HOLE IN EACH SIDE
OF THE AIR DUCT
2827
AIR BOX
SCREW (2)
FLUE
TERMINAL
AIR DUCT
FLUE DUCT
TAPE
FLUE
TERMINAL
SEAL
OUTSIDE
WALL FACE
AIR
DUCT WALL
SLEEVE
115 DIA.
CORE
DRILLED
HOLE
AIR BOX
SPIGOT
PLATE
2825
Diagram 7.4STANDARD FLUE
FLUE
DUCT
SPACER
CLIP
FLUE DUCT
AIR DUCT
FLUE ELBOW - Excercise
caution when handling this
component (push onto, flue
duct up to the line)
MARK LINE
34mm
7.4 Flue Assembly
Fit and secure the flue elbow, see diagram 7.4.
Insert the flue and spacer into the air duct.
Fit the air box spigot plate in the correct position on the
air box according to left, right or rear flue.
Fit the air and flue duct assembly to the boiler, see
diagram 7.5.
Note: Fully insert the air duct into the air box spigot.
Make sure the flue terminal is in the correct orientation,
marked TOP and the flue duct is engaged in the flue
terminal.
Drill a hole, diameter as shown in diagram 7.6, in each
side of the air duct, through the holes in the air box.
Secure the air duct to the air box using the two screws
provided in the loose items pack.
Note: If side or front access is restricted then it may be
necessary to carry out the above operation after passing
the flue through the wall.
Seal around the joint between the air duct and the air box
using the tape provided in the loose items pack.
Place the flue assembly into the flue hole, to make sure
that the flue terminal is correctly positioned and sticking
out the correct distance from the outside wall face, see
diagram 7.1 and the appropriate diagram 7.2 or 7.3.
Remove flue assembly.
Fix the self adhesive seal to the air duct, see diagram 7.7.

16
220650B
Diagram 8.2
2828
BOILER
MOUNTING
FRAME
'NOTCH' MARKING POSITION OF
SAFETY VALVE DISCHARGE
GAS
SERVICE
COCK
Diagram 8.1
DOMESTIC
WATER CENTRAL HEATING
NOTE:
KEEP ANY PIPEWORK
CLEAR OF SHADED AREA
MINI
EXPANSION
VESSEL
EXPANSION
VESSEL
POSITION
320mm
46mm
20mm
120mm
115mm
CENTRAL
HEATING
RETURN
DOMESTIC
HOT
WATER
OUT
CENTRAL
HEATING
FLOW
DOMESTIC
COLD
WATER
SUPPLY IN
SLOT
(CLOSED)
2297
DRAIN POINT
SLOT (CLOSED)
63
8 G a s a n d W a t e r C o n n e c t i o n s
8.1 Gas Connection
The gas supply can be connected from below or through
the wall at the rear of the boiler, see diagram 8.1 for
position.
Refer also to Section 1.8.
Make the gas supply connection to the gas service cock.
Slacken or remove the clip, as desired, whilst making the
connection. Do no subject the gas service cock to heat.
8.2 Water Connections
Provision is made for the water connections to be made
from below or through an internal wall at the rear of the
boiler, see diagram 8.1 for position.
Provision is made for the domestic hot water outlet and
heating flow and return pipes to be connected from
above, if desired, passing down either side of the boiler,
see diagram 8.2 for clearances. Take care that any
pipework connected from above, within the boiler
mounting frame will clear the expansion vessels.
Flush out the domestic hot water and the heating systems
before connecting to the boiler.
Make the connections to the domestic hot water and
heating systems by way of the isolating valves, see
diagram 8.1.
Slacken or remove the clips, as desired, while making
the connections. Do not subject any of the isolating
valves to heat.
Make sure that the drain points on the isolating valves
are positioned towards the front of the boiler, also that
the drain and operating screw heads are accessible.
8.3 Safety Valve Discharge
WARNING. It must not discharge above an entrance or
window or any type of public access area.
A short discharge pipe is supplied loose with the boiler,
which when fitted to the safety valve, will end below the
boiler at the mark between the cold water inlet and the
heating flow, for position and dimension see diagram
8.1.
This must be extended, using not less than 15mm od
pipe, to discharge, in a visible position, outside the
building, facing downwards, preferably over a drain.
The pipe must have a continuous fall and be routed to a
position so that any discharge of water, possibly boiling,
or steam cannot create any danger to persons, damage to
property or external electrical components and wiring.
Note. To ease future servicing it is advisable to use a
compression type fitting to extend the discharge pipe.

17 220650B
9 E l e c t r i c a l C o n n e c t i o n s
9.1 Supply Cable Connection
CAUTION. To prevent an induced current from
switching the central heating on, when not required, it is
important that the heating system control cables are
separated from the other mains supply cables.
The boiler requires a permanent mains supply through an
isolator which must also isolate any heating system
controls, see diagram 9.1.
Any heating system controls must not interrupt the
permanent mains supply to the boiler.
Remove the electrical connector from the loose items
pack.
Remove the two screws and cover from the connector,
see diagram 9.2.
Using PVC cable of suitable length and rating as stated
in Section 1.9, connect the mains supply cable to the
appropriate terminals of the connector, see diagram 9.1.
Standard colours are, Brown - Live; Blue - Neutral;
Green and Yellow - Earth.
The mains cable outer insulation must not be cut back
external to the plug, see diagram 9.2.
Make the earth cable of a greater length so that if the
cable is strained the earth would be the last to become
disconnected.
CAUTION. It is essential that the polarity is correct.
9.2 Heating System Controls
CAUTION. To prevent an induced current from
switching the central heating on, when not required, it is
important that the heating system control cables are
separated from the other mains supply cables.
It is recommended that the heating system is controlled
by a Time-switch and Room Thermostat, (controls may
be mains, low voltage or potential free), or by
thermostatic radiator valves.
If electrical controls are not being used, DO NOT
REMOVE the red link between terminals 1 and 2.
If electrical controls are being used the red link between
terminals 1 and 2 should be removed and the heating
controls connected in series.
The mains cable outer insulation must not be cut back
external to the plug.
9.3 Clock/Timer Kit
An internal clock/timer kit can be supplied, refer to the
literature supplied with the kit.
9.4 Frost Thermostat
If the installation requires protection by a “frost
thermostat”, connect a single pole type, to the
appropriate terminals of the connector.
9.5 Cable and Connector Securing
After completing all the connections to the boiler, secure
the cable(s) with the cover, using the two screws
previously removed, see diagram 9.2.
Diagram 9.2
2643
RED LINK
Remove when
connecting any
heating system
controls.
CABLE
CLAMP
MAINS
CABLE
COVER
SCREW (2)
1
2
3
N
L
E

18
220650B
Diagram 9.1
EXTERNAL CLOCK
JUNCTION
BOX
3 AMP
FUSE
LN
240V~50Hz
PERMANENT MAINS
SUPPLY
240V~50Hz
ROOM STAT. 240V~50Hz FROST STAT.
TO BOILER
RED LINK.
REMOVE WHEN
CONNECTING
SYSTEM CONTROLS
5 POLE CONNECTOR ON
MOUNTING FRAME
240V~50Hz
POTENTIAL
FROST STAT.
240V~50Hz
POTENTIAL
ROOM STAT.
(3) (L) (N) (2) (1)
JUNCTION
BOX
3 AMP
FUSE
LN
240V~50Hz
PERMANENT MAINS
SUPPLY
240V~50Hz
ROOM STAT. USED AS LINK
240V~50Hz
FROST STAT.
TO BOILER
RED LINK.
REMOVE WHEN
CONNECTING
SYSTEM CONTROLS
5 POLE CONNECTOR ON
MOUNTING FRAME
MAINS
POTENTIAL
FROST STAT.
MAINS
POTENTIAL
ROOM STAT.
(3) (L) (N) (2) (1)
JUNCTION
BOX
3 AMP
FUSE
LN
240V~50Hz
PERMANENT MAINS
SUPPLY
240V~50Hz
FROST STAT. NO ROOM STAT.
TO BOILER
RED
LINK
5 POLE CONNECTOR ON
MOUNTING FRAME
MAINS
POTENTIAL
FROST STAT.
(3) (L) (N) (2) (1)
3 AMP
FUSE
LN
240V~50Hz
PERMANENT MAINS
SUPPLY
POTENTIAL
FREE ROOM STAT. NO FROST STAT.
TO BOILER
RED LINK.
REMOVE WHEN
CONNECTING
SYSTEM CONTROLS
5 POLE CONNECTOR ON
MOUNTING FRAME
POTENTIAL FREE
ROOM STAT.
(3) (L) (N) (2) (1)
DOUBLE
POLE
ISOLATOR
JUNCTION
BOX
3 AMP
FUSE
LN
240V~50Hz
PERMANENT MAINS
SUPPLY
240V~50Hz ROOM STAT. NO FROST STAT.
TO BOILER
RED LINK.
REMOVE WHEN
CONNECTING
SYSTEM CONTROLS
5 POLE CONNECTOR ON
MOUNTING FRAME
MAINS POTENTIAL
ROOM STAT.
(3) (L) (N) (2) (1)
5 POLE CONNECTOR ON
MOUNTING FRAME
TO BOILER
RED LINK.
REMOVE WHEN
CONNECTING ANY
HEATING SYSTEM
CONTROLS
TIME
CONTROL
CLOCK
SWITCH
CONTACTS
(3) (L) (N) (E) (2) (1)
JUNCTION
BOX
3 AMP
FUSE
ROOM
THERMOSTAT
FROST
THERMOSTAT
LNE
240V~50Hz
PERMANENT
MAINS SUPPLY
ELECTRICITY SUPPLY CONNECTIONS
DOUBLE
POLE
ISOLATOR
DOUBLE
POLE
ISOLATOR
DOUBLE
POLE
ISOLATOR
DOUBLE
POLE
ISOLATOR
DOUBLE
POLE
ISOLATOR
(E)
(E)
(E)
(E)
(E)
E
E
E
E
E
0060M
INTEGRAL CLOCK
INTEGRAL CLOCK
INTEGRAL CLOCK
INTEGRAL CLOCK
INTEGRAL CLOCK
4323
9 E l e c t r i c a l C o n n e c t i o n s

19 220650B
1 0 B o i l e r F i x i n g
10.1 Mounting the Boiler
After installing the boiler mounting frame, gas, domestic
and heating systems, making the electrical connections
and preparing the flue components, continue as below:
Lift the boiler into position, hooking it onto the boiler
mounting frame at the top, then loosely fit the two boiler
securing screws at the top, see diagram 6.3.
10.2 Gas and Water Connections
Locate the boiler water pipes into the isolation valves
and the gas service cock union halves.
Fully push the boiler back to the mounting frame,
locating the studs into the clips.
Make the compression joint on the isolating valves and
join the gas service cock union. Secure all of the valves
and gas service cock with the clips.
10.3 Boiler Securing
Secure the boiler by tightening the two boiler securing
screws at the top.
10.4 Discharge Pipe
Remove the two control housing securing screws,
see diagram 10.1.
Remove the control housing, and support the control
housing on a surface or by screwing it to the front edge
of the base, using one of its securing screws, see diagram
10.1.
Remove the pressure gauge complete with bracket, see
diagram 10.2.
Fit the short discharge pipe to the safety valve using the
nut and olive supplied loose, see diagram 10.3.
Extend the discharge, refer to Section 8.3
Refit the pressure gauge.
10.5 Clock/timer Kit (if applicable)
Fit the clock/timer kit following the appropriate sections
of the instructions supplied with the kit.
10.6 Electrical Connector
Connect the two halves of the electrical connector
together.
Clip the connector into position on the boiler mounting
frame and secure the cables with cable clamp
immediately behind the connector.
Carry out preliminary electrical system checks as below:
1. Test insulation resistance to earth of mains cables.
2. Test the earth continuity and short circuit of cables.
3. Test the polarity of the mains.
3911
SECURING SCREW
(To support the control
housing if necessary)
FASCIA
TEMPERATURE
CONTROL KNOB CONTROL HOUSING
COVER SECURING
SCREW
FASCIA
SECURING
SCREWS (3)
CONTROL HOUSING
SECURING SCREW (2)
CENTRAL
HEATING
GAS PRESSURE
ADJUSTER
CONTROL
BOARD
2292
DO NOT
ADJUST
Diagram 10.1
CONTROL
HOUSING
COVER
HOT WATER
GAS PRESSURE
ADJUSTER

20
220650B
1 0 B o i l e r F i x i n g
10.7 Flue Fixing
Remove the air box access plate from the front of the air
box, see diagram 10.4.
Pass the prepared air box and flue assembly into and
through the wall sleeve.
Note: The foam seal is a tight fit in the wall sleeve and
the flue system should not be inserted unless the cement
has fully set or it can be held from the other side.
Place the air box gasket supplied in the loose items pack,
between the boiler top and airbox.
Loosely fit the air box to the boiler.
Using the air box access hole, fit the flue elbow onto the
fan outlet and secure with the flue elbow clip, see
diagram 10.3.
MAKE SURE THAT THE FLUE DUCT REMAINS
ENGAGED IN THE TERMINAL.
Tighten the screws securing the air box to the top of the
boiler taking care not to damage the air box gasket.
Refit the air box access plate and gasket
Make sure that the ductings do not slope down towards
the boiler.
Make the wall good internally around the air duct.
2831
PRESSURE
GAUGE
CONNECTION
SECURING
SCREW(2)
PRESSURE
GAUGE
BRACKET
PRESSURE
GAUGE
SAFETY
VALVE
SEALING
WASHER
Diagram 10.2
2832
Diagram 10.5
2833
AIR BOX
ACCESS PLATE
AND GASKET
SECURING
SCREW
Diagram 10.4
FLUE
ELBOW
CLIP
FAN
ELBOW
FAN
SECURING
SCREW (2)
ELECTRICAL
CONNECTORS
Diagram 10.3
2795
UNION
CONNECTION DISCHARGE
PIPE
'NOTCH'
