These instructions are for the installation and setting of
the clock/timer.
Instructions on how to use and service are supplied with
the boiler.
Note. The boiler Installation Instructions will be
required should the clock/timer be fitted to an already
fitted boiler.
If the literature is not to hand, copies can be obtained
from:
Hepworth Heating Ltd.,
Nottingham Road,
Belper,
Derbyshire.
DE56 1JT
Telephone [phone]
It is important to quote the model, size and serial
number.
This is a Cat I 2H Appliance
Digital Clock / Timer
Kit Style 1
100 80 75

2
Clock/Timer
221061A
5214
CONTENTS OF KIT
CONTENTS OF KIT
1 Casing label
2 Instruction sheet
3 Clock/timer
4 Clock/timer bracket
5 Clock/timer harness
6 "Snap in" cable bush
"continuation of “Boiler Fixing”
Remove two of the fascia securing screws,
see diagram 1.
Remove the control housing securing screw and cover,
see diagram 1.
Fit the clock/timer bracket and loosely secure with the
two previously removed fascia securing screws,
see diagram 2.
Remove the control housing securing screws,
see diagram 3.
Secure the control housing to the frame with one of
these screws, see diagram 4.
Remove the 4 way terminal block from the top left hand
side of the control box, see diagram 4 .
Refit the earth leads.
Fit the clock/timer by pushing it into the bracket until it
clicks into place.
Route wiring harness through the keyhole slot in the
side of the control box insert the "snap in" cable bush
and connect to the clock/timer and 4 way terminal block
connector, see diagram 5.
1
4
2
5
3
6

3
Clock/Timer
221061A
Remove the clock/timer blanking plate from the outer
case and use the new blanking plugs supplied.
Stick the Casing label, from the loose items pack, to the
right hand side of the clock/timer.
Note. Some adjustment of the clock/timer bracket may
be required to allow for a satisfactory alignment of the
outer casing.
Now continue with “Boiler Fixing”, as described in the
Installation Instructions.
Basic Setting Instructions for SWIFTFLOW
Digital Clock Timer / Style 1
Detailed instructions on how to set individual
programmes are provided in the Instructions for Use.
General Description
The clock has 3 “ON” and 3 “OFF” periods each day.
These periods can be set to the same time for each day or
for different times each day. The clock features an
“OFF” setting which allows the boiler to be switched off
for a long period of time, take care when using this
feature in the winter. An “ON” feature which keeps the
boiler on for a long period of time. A “TIMED” mode
which operates the boiler according to the three
programmes a day and a “ONCE” mode which switches
the boiler on at the first programmed “ON” time of day
and switches off at the last “OFF” of the day.
Diagram 3
100 ILLUSTRATED
Diagram 2
3910
100 ILLUSTRATED
CLOCK/TIMER
MOUNTING
BRACKET
FASCIA
SECURING
SCREWS
3887
CONTROL
HOUSING
COVER
SECURING
SCREWS (2)
3909
CONTROL
HOUSING
COVER
SECURING
SCREW
Diagram 1100 ILLUSTRATED
FASCIA
SECURING
SCREWS (2)
CONTROL
HOUSING
COVER
5213
Diagram 4
CONTROL
HOUSING
SECURING
SCREW
*
4 WAY
TERMINAL
BLOCK
*Remove yellow link
Y2
Y1
N
L
BBRYY
BRBYY

4
Clock/Timer
221061A
