Glutz E frame reader User manual
Installation instructions
E frame reader
MA-10140
45
160
15
45
163
16.5
38
100
3.5
14.5
A B C
82250.1230 18 3
82250.2230 20 3
82250.3230 22 3
82250.4230 24 3
82250.5230 24 6
82250.1 - 582250.0
125
17
80
(10)
40
Ø5max.
18
Ø13
Ø5max.
Ø13
C
B
230
A=
(9)
212
max. Ø5
max. Ø5
45
160
15
45
163
16.5
38
100
3.5
14.5
A B C
82250.1230 18 3
82250.2230 20 3
82250.3230 22 3
82250.4230 24 3
82250.5230 24 6
82250.1 - 582250.0
125
17
80
(10)
40
Ø5max.
18
Ø13
Ø5max.
Ø13
C
B
230
A=
(9)
212
max. Ø5
max. Ø5
Supply 12 - 24 V DC, max. 1.5 W
Relay 30 V DC / 125 V AC, max. 1 A
2
Dimensional drawing
3
1 Drill a hole for the required cable diameter
in preparation for feeding through the
connection cable.
2 Attach the cable to the connector in
accordance with the wiring diagram. To
relieve any strain on the cable, it can be
fixed to one of the three loops provided
using a cable tie.
3 Plug in the antenna cable on the side of
the electronics module and loop the cable
into the designated recess on the back of
the housing.
4 Use two countersunk screws to fix the
electronic module onto the prepared
surface.
5 Fit the cover by using both loops to pull
it from the top downwards and then
secure the countersunk screws from
underneath.
Surface-mounted version
4
1 Plug in the antenna cable on the side of the
electronics module.
2 Drill a hole for the required cable diameter
in preparation for feeding through the
connection cable.
3 Attach the cable to the connector in
accordance with the wiring diagram. To
relieve any strain on the cable, it can be
fixed to one of the three loops provided
using a cable tie.
4 Slot the electronics module into the
prepared recess and secure both fixing
screws.
Forend version
5
Antenna installation
1 Plug in the antenna cable on the back of
the antenna.
2 Slide the antenna into the cut out on the
base plate. Now secure the base plate,
together with the antenna, onto the
prepared surface using two countersunk
screws.
3 Place the cover over the antenna onto the
base plate until it is automatically pulled
and held in place by the magnetic force.
6
Notes
7
Notes
