GME RXI300 User manual

RX1300
MULTIBAND
SCANNING RECEIVER
INSTRUCTION MANUAL

PAGE 2 INSTRUCTION MANUAL RX1300
·Never connect the receiver to a
power source other than the specified
battery otherwise damage to your
receiver may occur.
·Do Not place the receiver in front of
a vehicle airbag.
·Do Not operate the receiver on board
an aircraft.
·Always charge the receiver at normal
room temperature.
·Always replace the accessory jack
cover when the jack is not in use.
·Use only GME approved
rechargeable batteries in your receiver.
·Do Not expose the receiver to
water. It is not waterproof.
·Avoid storing or charging the
receiver in direct sunlight.
·Avoid storing the receiver in
temperatures below -20°C or
above +60°C.
ACCESSORIES SUPPLIED . . . . . . . . . . 3
FITTING AND REMOVING
THE BATTERY PACK..............3
INSTALLING THE ANTENNA ........4
INSTALLING THE LANYARD . . . . . . . . 4
CHARGING THE BATTERY . . . . . . . . . 4
CONTROLS....................5
Keypad. . . . . . . . . . . . . . . . . . . . . 6
LCD DISPLAY...................8
GENERAL OPERATION............8
SELECTING FREQUENCIES.........9
FREQUENCY BANDS ............11
FREQUENCY SEARCH . . . . . . . . . . . 11
Band search................11
Full search .................12
Limited search . . . . . . . . . . . . . . 12
Priority search . . . . . . . . . . . . . . 13
MEMORY BANKS . . . . . . . . . . . . . . 15
Manual memories . . . . . . . . . . . 15
Automatic memories . . . . . . . . . 15
Limited search memories . . . . . . 15
Dual Watch memories. . . . . . . . . 15
Storing frequencies into the
memories..................16
MENU SETTINGS...............19
CoNTENTS
CAUTIoN
Please read these instructions carefully before operating your receiver. Your scanner
is a complex and powerful unit with many functions. Please retain this manual for
future reference.

RX1300 INSTRUCTION MANUAL PAGE 3
ACCESSoRIES SUppLIED
FITTING AND REMoVING ThE BATTERy pACk
Fitting
1. Ensure the receiver is switched off.
2. Align the bottom of the battery pack with the securing slots in the base of
the receiver.
3. Press the top of the battery pack into the back of the receiver until it ‘clicks’.
Removing
1. Ensure the receiver is switched off.
2. Holding the receiver in one hand, press down on the battery release catch.
3. Swing the top of the battery pack away from the receiver.
COPYING FREQUENCIES BETWEEN
MEMORY BANKS . . . . . . . . . . . . . . 20
CLONING STORED MEMORIES WITH
ANOTHER UNIT................22
DCS TONE FREQUENCY CHART ....23
CTCSS TONE FREQUENCY CHART . .24
WARRANTY ..................25
SPECIFICATIONS ...............27
Fitting the Battery Removing the Battery
• ScannerReceiver
• Antenna
• RechargeableBatteryPack
• Earphone
• ChargerCradle
• Power Adaptor
• LanyardStrap

PAGE 4 INSTRUCTION MANUAL RX1300
INSTALLING ThE ANTENNA
1. Place the antenna onto the antenna
socket on top of the radio.
2.
Rotate the antenna clockwise to screw
into place.
3. Do not over tighten.
INSTALLING ThE LANyARD
1. Slide the small end loop of the
lanyard through the slot in the rear of
the receiver’s top panel.
2. Feed the large end of the lanyard
through the loop and tighten
ChARGING ThE BATTERy
Your scanner receiver is supplied with
a rechargeable battery back, desktop
charging cradle and AC adaptor.
To charge the battery:
1. Fit the battery to the receiver (see
instructions left). Ensure the receiver
is switched off.
2.
Connect the AC adaptor to the
charging cradle.
3. Plug the AC adaptor into a mains
power outlet
.
4. Insert the receiver into the charging
cradle until it ‘clicks’ home. The
charging LED will glow RED and
charging will begin.
If the charging LED blinks RED and
GREEN or does not light at all, remove
the receiver from the cradle and
reinsert it.
The charging time for a discharged
battery is typically 12–15 hours. When
the battery is fully charged, the LED will
turn GREEN.
Note: If you find yourself in a position
where you need to charge the battery
but the charging cradle is not available,
you can plug the AC adaptor directly
into the receiver’s charging socket
located under the accessory jack cover.
RX1300
RX1 3 00
RX1300
RX1 3 00
RX1300
RX1 3 00
Charging LED

RX1300 INSTRUCTION MANUAL PAGE 5
CoNTRoLS
1. Power On/Off Lock Button
2. Control Knob
3. Up/Down Keys
4. Squelch Up/Down Keys
5. Function Key
6. Menu Key
7. Enter/VFO Key
8. Keypad
9. Memory Cloning/Charging Jack
10. Ear phone Jack
11. LCD Display
12. Jack Cover Securing Point
13. Antenna
14. Lanyard Slot
1
10
9
12
13
7
8
11
14
4
6
5
3
2
D
W
P
R
I
T
O
N
E
A
T
T
C
A
N
C
M
O
D
E
S
K
I
P
L
M
T
A
W
M
W
M
R
D
L
Y
RX1300
MENU
FUNC
SQL

PAGE 6 INSTRUCTION MANUAL RX1300
1. Power On/Off Lock Button – turns
the receiver on and off. Also Locks
the keypad.
2. Control Knob – selects frequencies
and channels and selects values
from menus.
3. Up/Down Keys – adjusts the
Volume and selects Menu items and
frequency steps.
4. Squelch Up/Down Keys – opens
and closes the squelch.
5. Function Key – enables extended
keypad functions.
6. Menu Key –
provides access to
setup menus.
7. Enter/VFO Key – confirms selections
and selects the VFO Mode.
8. Keypad – allows direct entry of
frequencies and selection
of functions.
9. Accessory Jack – provides charging
and earphone jacks.
10. LCD Display – shows frequencies
and selected functions.
11. Jack Cover Securing Point –
holds the accessory jack cover
in place.
12. Antenna – provides reception
of signals.
13. Lanyard Slot – allows connection
of the Lanyard to protect the
receiver from being
accidentally dropped.
Direct Input Keys
1. Number Keys – used to enter
frequencies in VFO Mode and to
make direct selection of Banks in
memory Read Mode.
2. Bank/Band Key – used to change
Memory Banks or Frequency Bands.
3. Scan/Search Key – used to activate
or deactivate the Scan function in
memory read Mode or the Search
function in VFO Mode.
Extended Function Keys
The Keypad Keys on the front panel
have secondary functions which
are printed below each key. These
secondary functions are accessed after
pressing the FUNC key.
See chart on following page for
key functions.
D
W
P
R
I
T
O
N
E
A
T
T
C
A
N
C
M
O
D
E
S
K
I
P
L
M
T
A
W
M
W
M
R
D
L
Y
FUNCTION KEY
kEypAD

RX1300 INSTRUCTION MANUAL PAGE 7
KEY FUNCTION DESCRIPTION
1 - AW Automatic Write Automatically stores scanned frequencies in the
automatic memory storage area.
2 - MW Manual Write Allows manual storage of frequencies into the
manual memory storage area.
3 - MR Memory Read Allows reading of the frequencies in the
stored memories.
4 - CANC Cancel
Used to cancel an incorrect input.
5 - Mode Mode Selects the receiver Modes
(AM, FM, WFM or Automatic).
6 - SKIP Skip Used to skip channels when scanning or skip
frequencies when searching.
7 - DW Dual Watch Activates or deactivates the Dual Watch function.
8 - PRI Priority Channel
Activates or deactivates the selection of a
Priority Channel.
9 - TONE Tone Activates Activates or deactivates the selected CTCSS/
DCS tone. The required tone is selected from
the menu function in VFO Mode.
0 - DLY Delay Activates or deactivates the delay timer which
determines how long the radio will wait on a
frequency after a signal has disappeared. The
delay time is set from the menu function.
BANK
BAND
LMT
Limit: Allows the entry of upper and lower frequency
limits when searching.
SCAN SRC
ATT
Attenuator: Activates or deactivates the signal attenuator
to reduce the receiver’s sensitivity in strong
signal conditions.

PAGE 8 INSTRUCTION MANUAL RX1300
Turning the unit On or Off
Press and hold the RED Button on the
top of the unit to turn the unit ON. Press
and hold the RED Button again to turn
the unit OFF.
KEY Lock
Briefly press the RED Button on the top
of the unit to turn the Key Lock ON.
Briefly press the RED Button again to
turn the Key Lock OFF again.
1 3 1 4 21 1 7
19
1 5 1 6 1 8
20
42 7 9 1 0 1 2 3 8 1 1 651
1. Dual Watch
2. Priority Channel
3. Power Save
4. Scan
5. Function
6. Memory
7. Search
8. Skip
9. Key Tone & Beep Tone
10. Keypad Lock
11. Data Transfer
12. Battery Charge Level
13. Frequency Display
14. Channel Indicator
15. AM, FM, WFM Mode
16. Attenuator
17. Bank Number
18. Scan Delay Timer
19. Frequency Step
20. Tone
21. Signal Meter
LCD DISpLAy
GENERAL opERATIoN

RX1300 INSTRUCTION MANUAL PAGE 9
Volume
Press the key to increase the volume.
Press the key to decrease the volume.
The volume level will be displayed from
00 to 31.
Squelch
Press the key on the side of the radio
to increase the Squelch setting and
the key on to decrease the Squelch
setting. The Squelch level will be
displayed from 00 to 09. At maximum
Squelch setting, ‘AT’ is selected which
represents an automatic (preset)
level setting.
Function Key
The Function key provides access to
secondary functions associated with
the front panel keys. The secondary
function labels are printed below their
respective keys.
Menu Key
The Menu key provides access to the
radios settings. The settings menus will
vary depending on which Mode the
receiver is in.
E/VFO Key [Enter/VFO]
Press the E/VFO key to select the VFO
(Variable Frequency Oscillator) Mode.
Frequencies can now be entered directly
from the keyboard. Press the E/VFO key
to Enter (accept) the selected frequency.
Note: The receiver always selects the
VFO Mode each time it is turned on.
Control Knob
The Control knob is used to change the
current display option.
In VFO Mode, rotate the Control knob
to change the displayed frequency at
the selected frequency steps. Rotate
clockwise to increase the frequency and
counter clockwise to decrease
the frequency.
In Menu Mode, rotate the Control knob
to change the selected setting.
In Channel memory Mode, rotate the
Control knob to step up or down
through the memories.
SELECTING FREQUENCIES
The receiver always selects the VFO
Mode when it is turned on. You can
select frequencies using one of the
following methods:
Direct Frequency Input
Enter frequencies using the numbered
keypad. Don’t forget to include the
decimal point where applicable.
When you have entered the required
frequency, press the E/VFO key to accept
it. If the frequency you have entered is
not within the selected frequency step, it
is automatically corrected to the nearest
correct frequency.
e.g. Entering 456.25 followed by E/VFO
results in 456.2500 being selected.
The frequency step can be changed
to allow more precision of desired
frequency.

PAGE 10 INSTRUCTION MANUAL RX1300
Using the Control Knob
First select the required starting
frequency using the direct frequency
input method, then rotate the control
knob to step up or down in frequency
from the starting point. The frequency
will change in the selected
frequency step.
· To change frequency in 1 MHz steps,
press the FUNC key, then press the
or keys to change the frequency.
(F is displayed while the ‘Func’ Mode
is active).
· To change frequency in 10 MHz steps,
press the Func key then rotate the
control knob to change the frequency.
(F is displayed while the ‘Func’ Mode
is active).
Note: The Func Mode clears a few
seconds after the last key press or
control knob change.
Mode Selection
By default, the receiver automatically
selects the modulation Mode most
commonly used for each band (see the
Frequency Band chart for the default
Modes for each band) To manually
select a different Mode, press ‘Func’
followed by the Mode key.
Each press will step through the Mode
settings in the following order:
-> AM -> FM -> WFM (Wideband FM)
-> Auto ->
To automatically have the receiver select
the Mode for the band you are on,
select the Auto Mode.
Frequency Step Selection
By default, the receiver automatically
selects the frequency Steps most
commonly used for each band (see the
Frequency Band chart for the default
Steps for each band).
To select a different step:
1. In VFO Mode press MENU.
2. Press the Volume or keys until
STEP is displayed.
3. Turn the Control knob until the
desired frequency step is displayed.
4. Press E/VFO to confirm the selection.
The following Frequency Steps
are available:
5 kHz
6.25 kHz
8.33 kHz (108 MHz - 135.975 MHz)
9 kHz (below 1.620 MHz ONLY)
10 kHz
12.5 kHz
15 kHz
20 kHz
25 kHz
30 kHz
50 kHz
100 kHz
500 kHz
Auto

RX1300 INSTRUCTION MANUAL PAGE 11
If Auto is selected the receiver will automatically select the appropriate default
Frequency Step for each band.
FREQUENCy BANDS
The scanner supports the following Frequency Bands:
FREQUENCy SEARCh
Band Search
Use the Search function to locate active frequencies in one or more bands
1.Press the E/VFO key to select VFO Mode. (Note: the receiver automatically selects
the VFO Mode when it is turned on).
2. Press the BAND key to select the required Band. There are 10 factory preset
bands to choose from (see Frequency Band Table).
3. Set the Squelch level using the Squelch or keys so that the noise
just disappears.
Frequency Band Startup Frequency Default Mode Default Step
150 kHz to 495 kHz AM 5 kHz
504 kHz to 1.620 MHz 1.5 MHz AM 5 kHz
1.625 MHz to 29.995 MHz 5 MHz AM 5 kHz
30 MHz to 87.975 MHz 51 MHz FM 25 kHz
88 MHz to 107.950 MHz 88 MHz WFM 100 kHz
108 MHz to 135.975 MHz 118 MHz AM 25 kHz
136 MHz to 255.100 MHz 150 MHz FM 25 kHz
255.1125 MHz to 382.100 MHz 370 MHz FM 12.5 kHz
382.125 MHz to 769.800 MHz 430 MHz FM 25 kHz
769.8125MHz to 960.100 MHz 850 MHz FM 12.5 kHz
960.125 MHz to 1309.975 MHz 1295 MHz FM 25 kHz

PAGE 12 INSTRUCTION MANUAL RX1300
4. Select a start frequency to search
from. To do this, enter the frequency
on the keypad, then press E/VFO key.
5. Press the SCAN SRC key briefly. The
‘SRCH’ icon will be displayed and the
receiver will search the selected band
starting from the start frequency.
Once the end of the band is reached
the search continues at the beginning
of the selected band.
6. To stop the search, press the SCAN
SRC key again.
•
During the search, press the BANK
BAND key to move to the next band.
 •Tochangethesearchdirection
rotate the control knob clockwise or
counter clockwise.
 •Thereceiverwillstayonanactive
channel according to the Scan Timer
settings in the VFO Menu. If the
Scan Timer is set to ‘5 seconds’,
the receiver will continue searching
after 5 seconds even if the channel
is still busy. If the Scan Timer is set
to ‘Busy’, the receiver will remain on
the busy frequency for as long as it
stays busy, then resume searching
when the signal disappears.
Full Search
The Full Search function searches the
entire scanner frequency range
for signals.
1. Press the E/VFO key to select
VFO Mode. (Note: the receiver
automatically selects the VFO Mode
when it is turned on).
2. Set the Squelch level using the
Squelch keys so that the noise
just disappears.
3. Press and hold the SCAN SRC key
for 2 seconds. The ‘SRCH’ icon will
be displayed and the receiver will
search the entire frequency range of
the receiver.
4. To stop the search, press the SCAN
SRC key again.
•Duringthesearch,presstheBANK
BAND key to move to the next Band.
•Tochangethesearchdirectionrotate
the control knob clockwise or counter
clockwise.
•Thereceiverwillstayonanactive
channel according to the Scan Timer
settings in the VFO Menu. If the
Scan Timer is set to ‘5 seconds’, the
receiver will continue searching after
5 seconds even if the channel is still
busy. If the Scan Timer is set to ‘Busy’,
the receiver will remain on the busy
frequency for as long as it stays busy,
then resume searching when the
signal disappears.
LIMITED SEARCh
You can limit the search between two
user-selectable frequency limits.
1. Press the E/VFO key to select
VFO Mode. (Note: the receiver
automatically selects the VFO Mode
when it is turned on).

RX1300 INSTRUCTION MANUAL PAGE 13
2. Set the Squelch level using the
Squelch keys so that the noise just
disappears.
3. Press Func followed by the LMT key.
[L1] is displayed.
4. Enter the First frequency using the
keypad or the control knob.
5. Press E/VFO when done. [L2]
is displayed.
6. Enter the Second frequency using the
keypad or the control knob.
7. Press SCAN SRC. The Limited Search
will begin, searching upwards from
the first frequency to the second in a
continuous cycle.
8. To stop the Search, press the SCAN
SRC key again.
•TochangetheSearchdirectionrotate
the control knob clockwise or
counter clockwise.
•Thereceiverwillstayonanactive
channel according to the Scan Timer
settings in the VFO Menu. If the
Scan Timer is set to ‘5 seconds’, the
receiver will continue Searching after
5 seconds even if the channel is still
busy. If the Scan Timer is set to ‘Busy’,
the receiver will remain on the busy
frequency for as long as it stays busy,
then resume searching when the
signal disappears.
NOTE: The Limit Search always searches
upwards in frequency. If the first
frequency is lower than the second it
will search between the two frequencies.
If the first frequency is higher then the
second it will search outside the
two frequencies.
pRIoRITy SEARCh
Priority Search allows you to insert a
Priority Channel into the frequency
search. When the search is activated,
the receiver will visit the Priority channel
or frequency at an interval set by the
‘Priority Time’ in the Menu setup.
L1 is a lower frequency than L2
L1 is a higher frequency than L2
Lower Band
Edge
Lower Band
Edge
L1 L2
L2 L1
Upper Band
Edge
Upper Band
Edge
1st
Frequency
2nd
Frequency
Frequencies
Searched
40 MHz 50 MHz 40 –> 50 MHz
50 MHz 40 MHz 50 –> 87.975,
30 –> 40 MHz

PAGE 14 INSTRUCTION MANUAL RX1300
To perform a Priority Search using a
frequency as the Priority Channel:
1. Enter the required Priority Channel
frequency using the Keypad then
press E/VFO.
2. Press Func PRI. The selected
frequency is now the Priority Channel.
3. Press Band/Bank to select the
require frequency band you wish
to scan.
4. Press Scan/Src. The receiver will
begin scanning the selected band and
will switch to the Priority channel at
an interval set by the ‘Priority Time’
setting in the setup menu.
5. Press FUNC PRI to deselect current
priority channel. Follow steps 1-4 to
add new priority channel.
To perform a Priority Search using a
stored channel as the Priority Channel:
1. Press Func MR to select the Memory
Read Mode.
2. Press Bank/Band to select the
required memory bank.
3. Rotate the Control Knob to select
the required channel.
4. Press Func PRI. The selected channel
is now the Priority Channel.
5. Press Band/Bank to select the
require frequency band you wish
to scan.
6. Press Scan/Src. The receiver will
begin scanning the selected band and
will switch to the Priority Channel at
an interval set by the ‘Priority Time’
setting in the setup menu.
•Ifasignalisreceived,thereceiverwill
remain on the active frequency for the
duration of the ‘Busy Timer’ setting
in the Menu setup. If the ‘Busy timer’
is set to Busy the receiver will stay on
the active channel for as long as the
signal is present.
•
To change the frequency band while
searching, briefly press Band/Bank key.
•Tochangethesearchdirectionwhile
searching, rotate the control knob
clockwise or counter clockwise.
Dual Watch
The Dual Watch function lets you
constantly monitor two frequencies for
activity.
To set the Dual Watch function:
1. Enter one of the required frequencies
using the Keypad then press E/VFO.
2. Adjust the squelch so that the
receiver is muted.
3. Press Func DW.
4. Enter the second frequency using the
Keypad then press E/VFO.
5. The Dual watch begins automatically.
If a signal is received, the receiver will
remain on the active frequency for the
duration of the ‘Busy Timer’ setting in
the Menu setup. If the ‘Busy timer’ is
set to Busy the receiver will stay on the
active channel for as long as the signal
is present.

RX1300 INSTRUCTION MANUAL PAGE 15
To stay on an active frequency
indefinitely or to stop the Dual Watch
function press Func DW again. The
receiver will exit the Dual Watch function.
MEMoRy BANkS
The scanner memory storage area has
a capacity of 1300 locations. These are
split into specific segments as follows:
1000 Manual Storage Memories.
200 Automatic Storage Memories.
50 Limited Search Memories
(2 x 25 pairs).
50 Dual Watch memories (2 x 25 Pairs).
MANUAL MEMoRIES
The Manual Memory area allows the
user to manually store up to 1000
individual frequencies. It is split into
memory banks with a maximum capacity
of 40 memory banks, each containing
25 memory locations (40 x 25 = 1000).
However the memory capacity of each
bank is flexible up to a maximum of 100
memories per bank, but at a reduction
in the number of banks available. For
example, in an extreme case where each
bank is programmed with the maximum
100 memories, the number of banks
available would be reduced to 10
(10 banks x 100 memories = 1000
memory capacity).
The default Manual memory banks are
labelled 00 to 39.
AUToMATIC MEMoRIES
The Automatic Memory area can store
up to 200 frequencies in two banks
of 100 memories. The automatic
memory is used when searching a
band of frequencies. The scanner
can automatically store any active
frequencies it finds while searching. The
Automatic Memory banks are labelled
A0 and A1.
LIMITED SEARCh MEMoRIES
The Limited Search Memories consists
of 50 memory locations split into 25
pairs of frequencies. The Limited Search
function allows you to specify the upper
and lower frequency limits of a section
of frequency band that you wish to scan.
These frequency limit ‘pairs’ can be
stored in the Limited Search memories
for recall at a later time.
The Limited Search Memory Upper and
Lower limits are identified as A and b.
The 25 pairs are therefore labelled A00,
b00 to A24, b24.
DUAL WATCh MEMoRIES
The Dual Watch function allows the
radio to switch between two selected
frequencies. The Dual Watch Memories
consists of 50 memory locations split
into 25 pairs of frequencies.
The two Dual Watch frequencies are
identified as A and b. The 25 pairs are
therefore labelled A00, b00 to
A24, b24.

PAGE 16 INSTRUCTION MANUAL RX1300
SToRING FREQUENCIES
INTo ThE MEMoRIES
Manual memories
To manually store a frequency into one
of the manual memories:
1. Press the E/VFO key to select
VFO Mode.
2. Press the BAND key to select the
required Band.
3. Select the frequency that you want to
store using the number keys or the
control knob.
4. Press Func MW to enter the Memory
Write Mode.
5. The receiver will find and display an
empty memory bank and memory
location automatically.
6. If required, use the number keys to
select a new memory bank e.g. For
memory bank 16 press 1 and 6.
7. To change the memory location,
rotate the control knob.
8. Press Func MW again to store
the frequency.
To recall a frequency from the
manual memories:
1. Press the E/VFO key to select
VFO Mode.
2. Press Func MR. The receiver will
enter the Memory Read Mode.
3. To step through the memory banks
press the BANK key or enter the
memory bank directly using the
numbered keys. Memory banks are
numbered 00 to 39.
4. Select the required channel using the
control knob.
Automatic Memories
The Automatic Memory holds
frequencies that are stored automatically
while doing a Band Search.
To store frequencies into the
Automatic Memories:
1. Press the E/VFO key to select
VFO Mode.
2. Select the band and frequency that
you wish to begin searching from.
3. Set the Squelch level to a point where
the receiver is just quiet.
4. Press Func AW to select the
Automatic Write Mode.
5. Press the Bank key to select the
required memory bank (A0 or A1).
6. Press the SCAN/SRC key to
begin scanning.
7. As active frequencies are found they
are automatically stored in the select
memory bank. When all 100 channels
are fully stored the receiver will Beep.
8. To exit from the Automatic memory
Mode, press the E/VFO key.
To recall frequencies from the
Automatic Memories:
1. Press the E/VFO key to select
VFO Mode.
2. Press Func MR. The receiver will
enter the Memory Read Mode.
3. Press the BANK key repeatedly to
step through the memory banks until
A0 or A1 are selected.

RX1300 INSTRUCTION MANUAL PAGE 17
4. Select the required channel using the
control knob.
Limited Search Memories
Here you will be storing a pair of
frequencies that represents the
upper and lower limits of a section of
frequency band you wish to search for
signals.
To store a pair of frequency limits into
the Limited Search Memories.
Here you will be storing a pair of
frequencies that represents the
upper and lower limits of a section of
frequency band you wish to search for
signals.
To store a pair of frequency limits into
the Limited Search Memories.
1. Press the E/VFO key to select
VFO Mode.
2. Press the Band key to select the
required band.
3. Enter the frequency that represents
one end of the range you wish
to search.
4. Press Func LMT. L1 will flash on
the display to indicate that you are
entering the first frequency limit.
5. Press the E/VFO key to accept. L2
will flash on the display to indicate
you are now entering the second
limit frequency.
6. Enter the second frequency limit then
press E/VFO to accept it.
7. Now press Func MW. The receiver
enters the Memory Write Mode and
selects the Pr memory bank.
8. Use the control knob to select an
empty channel to store the
frequency pair.
9. Press Func MW again to store
the frequencies.
The selected frequencies limits will be
stored as a pair of channels in locations
Axx and bxx where xx is the channel
number you selected in step 8.
To recall a frequency limit pair from the
Limited Search Memories.
1. Press the E/VFO key to select
VFO Mode.
2. Press Func MR. The receiver will
enter the Memory Read Mode.
3. Press the BANK key repeatedly to
step through the memory banks until
Pr is displayed.
4. Select the required channel using the
control knob.
5. Set the squelch level to a point where
the receiver is just quiet.
6. Briefly press SCAN/SRC. The radio
will begin scanning between the
selected frequency limits.
Dual Watch Memories
The Dual Watch memories are used to
store a pair of frequencies that will be
monitored when the Dual Watch feature
is enabled. Up to 50 frequencies
(25 pairs) can be stored.

PAGE 18 INSTRUCTION MANUAL RX1300
To store a pair of Dual Watch frequency into the Dual Watch Memories.
1. Press the E/VFO key to select VFO Mode.
2. Press the Band key to select the required band.
3. Adjust the Squelch so the receiver is muted.
4. Enter one of the frequencies that you wish to monitor.
5. Press Func DW. The ‘D’ Dual Watch icon
will be displayed.
6. Enter a second frequency using the control knob or the number keys.
7. Press the E/VFO key to accept. The Dual Watch function will begin.
8. Now press Func MW. The receiver enters the Memory Write Mode and selects
the Du (Dual Watch) memory bank.
9. Use the control knob to select an empty channel to store the frequency pair.
10.Press Func MW again to store the two frequencies. They will be stored Axx and
bxx where xx is the empty channel you selected.
To recall a pair of Dual Watch frequencies from the Dual Watch Memories.
1. Press the E/VFO key to select VFO Mode.
2. Set the squelch level to a point where the receiver is just quiet.
3. Press Func MR. The receiver will enter the Memory Read Mode.
4. Press the BANK key repeatedly to step through the memory banks until Du
is selected.
5. Select the required channel using the control knob.
6. Briefly press the SCAN/SRC key. Dual Watch will begin with the receiver
monitoring the channels in the selected Dual Watch memory.

RX1300 INSTRUCTION MANUAL PAGE 19
MENU SETTINGS
The Menu settings will vary depending on the selected Mode.
· Press the MENU Key to access the Menu settings.
· Press the volume keys to step through the Menu items.
· Rotate the Control knob to change the values of each Menu item.
VFO Mode
FUNCTION DESCRIPTION VALUES
Delay Determines how long the radio will wait on a
frequency after a signal has disappeared while
scanning or Searching
1 -10 Seconds
Beep Activates or deactivates the keypress beeps. ON, OFF
Step Sets the Frequency Step in kHz. When Auto
is selected the receiver automatically uses a
factory preset frequency step for each band.
5, 6.5, 8.33,
9, 10, 12.5,
15, 20, 25, 30,
50,100, 500,
Auto
Memory Shows the available Manual Memory left in
the receiver
0 - 1000
Priority
Time
Sets how long the receiver will wait before
visiting the selected Priority channel when
Scanning or Searching
1 – 10 Seconds
Tone Selects the required CTCSS or DCS tone.
The tone is then activated or deactivated by
pressing Func TONE
See CTCSS/DCS
Table (pg18)
Busy Timer Determines how long the receiver will wait on
a busy channel while Scanning or Searching.
When ‘Busy’ is selected, the receiver will stay
on the busy channel as long as it remains busy.
Busy, 5 Seconds

PAGE 20 INSTRUCTION MANUAL RX1300
Memory Read Mode
FUNCTION MEANING DESCRIPTION
bA Copy Bank Copy Copies a bank of frequencies to
another Bank
CH Copy Channel Copy Copies a frequency from one channel
to another
CH Move Channel Move Moves a frequency from one channel
to another
ALL CLR All Clear Erases all memories in the receiver
bA CLR Bank Clear Erases all the channels in the selected Bank
CH CLR Channel Clear Erases the selected channel
Bank Copy
To copy one bank of frequencies
to another;
1.
Select the bank that you would like to
copy from by pressing Func/ MR.
2. Press Menu, then use the control
knob or the volume keys to select
‘bA Copy’.
3. Press E/VFO to accept
4.
Now select the bank you wish to copy it
to using the number keys or the BANK/
BAND key.
5. Press E/VFO again to copy the
original bank to the new bank. The
original bank will remain unchanged.
Channel Copy
To copy one channel to another;
1. Press
Func/MR .
2. Select the channel that you would like
to copy from.
3. Press Menu then use the control knob
or the volume keys to select
‘CH Copy’.
4. Press
E/VFO to accept. The receiver
will then automatically select the next
empty channel in the same bank.
5. If you don’t wish to use the empty
channel selected by the receiver, use
the
Control Knob, number keys or
the
BANK/BAND key to select the
preferred channel and bank.
CopyING FREQUENCIES BETWEEN MEMoRy BANkS
