GMP CUB44PWHT User manual

GLOBAL PROCUREMENT AND MARKETING LIMITED
4 X 4 Cube Plus
Assembly Instructions - Please keep for future reference
No. people Assembly Time SKU #
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please email [email protected]
CUB44PWHT
Dimensions
Width: 144.8cm
Depth: 39cm
Height: 144.8cm
60 mins
(approx.)
1
CUB44PGRY
For purchasing this
GPM Limited
product
CUB44PGRY
CUB44PWHT
144.8cm
144.8cm
39cm

2
Check you have all the
components and tools listed
on pages 4 and 5.
Remove all fittings from the
plastic bags and separate
them into their groups.
Keep children and animals
away from the work area,
small parts could choke if
swallowed.
Make sure you have enough
space to lay out the parts
before starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close to
its final position (in the same
room) as possible.
Assemble on a soft, level
surface to avoid damaging the
unit or your floor.
We do not recommend the
use of power
drill/drivers for
inserting screws,
as this could
damage the unit.
Only use hand screwdrivers.
Dispose of all packaging
carefully and responsibly.
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Warnings
·Place heaviest items in the lowest drawers.
·Useless specifically designed to accommodate, do not set TVs
or other heavy objects on top of this product.
·Never allow children to climb or hang on drawers, doors or
shelves.
·Never open more than one drawer at a time.
·Do not defeat or remove the drawer interlock system.
·Use of tip-over restraints may only reduce, but not eliminate,
the risk of tip-over.
CHILD SAFETY
ANCHOR AND PROTECT A CHILD
Use of anti-tip kit is required
CLIMBING MAY RESULT IN SERIOUS INJURY
Care and Maintenance
Only clean using a damp cloth and
mild detergent, do not use bleach or
abrasive cleaners.
From time to time check that there
are no loose screws on this unit.
This product should not be discarded
with household waste. Take to your
local authority waste disposal centre.
If you are unhappy with the product and wish to return it,
please follow the retailer's returns procedure.

Exploded View If you have damaged or missing components,
email: [email protected]
3
1
1
2
2
3
4
3
555
555
555
55
5
