Installation, use and maintenance manual EN

M0104 F
2 /32
Installation, use and maintenance
Bulletin M0104 F
ENGLISH

3/124
3 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
1 INDEX
2 FACSIMILE COPY OF EU DECLARATION OF CONFORMITY 4
3 GENERAL WARNINGS 4
4 SAFETY INSTRUCTIONS 5
5 FIRST AID RULES 6
6 GENERAL SAFETY RULES 7
7 TRANSPORT, HANDLING AND UNPACKING 7
7.1 DIMENSIONS AND WEIGHTS 8
7.2 PACKAGE CONTENTS/PRE-INSPECTION 8
8 MACHINE AND MANUFACTURER IDENTIFICATION 9
8.1 PLATES POSITIONS 10
9 DESCRIPTION OF MAIN COMPONENTS 11
9.1 BODY 11
9.2 PUMPING UNIT 11
9.3 PULSER METER 12
9.4 CONTROL SYSTEM 12
9.5 NOZZLE 12
9.6 LEVEL INDICATOR (OPTIONAL) 12
9.7 DISPLAY COVER 12
10 TECHNICAL SPECIFICATIONS 13
10.1 TECHNICAL DATA 13
10.2 POWER CONSUPTION 13
11 INTENDED USE 13
12 INSTALLATION 14
12.1 POSITIONING 14
12.2 FIXING 15
12.3 HYDRAULIC CONNECTIONS 16
12.4 ELECTRIC CONNECTIONS 17
13 STARTING 19
13.1 INITIAL PRIMING 20
14 METER CALIBRATION 21
15 DAILY USE 21
15.1 FUEL DISPENSING 22
16 MAINTENANCE 22
16.1 ROUTINE MAINTENANCE 22
16.2 SPECIAL MAINTENANCE 25
17 TROUBLESHOOTING 26
18 DEMOLITION AND DISPOSAL 27
19 EXPLODED VIEWS 28

M0104 F
4 /32
Installation, use and maintenance
2 FACSIMILE COPY OF EU DECLARATION
OF CONFORMITY
The undersigned: PIUSI S.p.A.
Via Pacinotti 16/A z.i. Rangavino - 46029 Suzzara - Mantova - Italy
HEREBY STATES under its own responsibility that the equipment described below:
Description: DIESEL FUEL DISPENSER
Model: CUBE 70 MC
Serial number: refer to Lot Number shown on CE plate affixed to product
Year of manufacture: refer to the year of production shown on the CE plate affixed to the product
complies with the following legislation:
- Machine Regulations
- Electromagnetic Compatibility
- ROHS II Regulations
The technical file is at the disposal of the competent authority following motivated request at PIUSI
S.p.A. or following request sent to the e-mail address: [e-mail].
THE ORIGINAL DECLARATION OF CONFORMITY IS PROVIDED SEPARATELY WITH THE PRO-
DUCT
3 GENERAL WARNINGS
Important
precautions
To ensure operator safety and to protect the pump from potential damage,
workers must be fully acquainted with this instruction manual before performing
any operation.
Symbols used in
the manual
The following symbols will be used throughout the manual to highlight safety
information and precautions of particular importance:
ATTENTION
This symbol indicates safe working practices for operators and/or potentially
exposed persons.
WARNING
This symbol indicates that there is risk of damage to the equipment and/or
its components.
NOTE
This symbol indicates useful information.
Manual
preservation
This manual should be complete and legible throughout. It should remain avail-
able to end users and specialist installation and maintenance technicians for con-
sultation at any time.
Reproduction
rights
All reproduction rights are reserved by Piusi S.p.A.
The text cannot be reprinted without the written permission of Piusi S.p.A.
© Piusi S.p.A.
THIS MANUAL IS THE PROPERTY OF Piusi S.p.A.
ANY REPRODUCTION, EVEN PARTIAL, IS FORBIDDEN.
This manual belongs to Piusi S.p.A., which is the sole proprietor of all rights indicated
by applicable laws, including, by way of example, laws on copyrights. All the rights
deriving from such laws are reserved to Piusi S.p.A.: the reproduction, including par-
tial, of this manual, its publication, change, transcription and notification to the pub-
lic, transmission, including using remote communication media, placing at disposal
of the public, distri¬bution, marketing in any form, translation and/or processing, loan
and any other activity reserved by the law to Piusi S.p.A..

5/124
5 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
4 SAFETY INSTRUCTIONS
Mains - pre-
liminary checks
before instal-
lation
ATTENTION
You must avoid any contact between the electrical power supply and the fluid
that needs to be FILTERED.
Maintenance control
Before any checks or maintenance work are carried out, disconnect the power source.
FIRE AND
EXPLOSION
When flammable
fluids are present
in the work area,
such as gasoline
and windshield
wiper fluid, be
aware that flam-
mable fumes can
ignite or explode.
To help prevent fire and explosion:
Use equipment only in will ventilated area.
Keep work area free of debris, including rags and spilled or open containers of
solvent and gasoline.
Do not plug or unplug power cords or turn lights on or off when flammable fumes
are present.
Ground all equipment in the work area.
Stop operation immediately if static sparking occurs or if you feel a shock. Do
not use equipment until you identify and correct the problem.
Keep a working fire extinguisher in the work area.
ELECTRIC
SHOCK
Electrocution or
death
This equipment must be grounded. Improper grounding, setup or usage of the
system can cause electric shock.
Turn off and disconnect power cord before servicing equipment.
Connect only to a grounded electrical outlets.
Use only 3 wire extension cords in accordance with local electrical codes. Exten-
sion cords should have a ground lead.
Ensure ground prongs are intact on power and extension cords.
Do not expose to rain. Store indoors.
Never touch the electric plug of socket with wet hands.
Do not turn the dispensing system on if the power connection cord or other im-
portant parts of the apparatus are damaged, such as the inlet outlet plumbing,
dispensing nozzle or safety devices. Replace damaged components before opera-
tion.
Before each use check that the power connection cord and power plug are not
damaged. If damaged, have power connection cord replaced before use by a
qualified electrician.
The electrical connection between the plug and socket must be kept well away
from water.
Unsuitable extension leads can be hazardous, in accordance with current regula-
tions. only extension cords that are labelled for outdoor use and have a sufficient
conduction path should be used outdoors.
For safety reasons, we recommend that, in principle, the equipment be used only
with a earth-leakage circuit breaker (max 30 mA).
Electrical connections must use ground fault circuit interrupter (GFCI).
Installation operations are carried out with the box open and accessible electri-
cal contacts. All these operations have to be done with the unit isolated from the
power supply to prevent electrical shock!

M0104 F
6 /32
Installation, use and maintenance
EQUIPMENT
MISUSE
Misuse can
cause death or
serious injury
!
Do not operate the unit when fatigued or under the influence of drugs or alcohol.
Do not leave the work area while equipment is energized or under pressure.
Turn off all equipment when equipment is not in use.
Do not alter or modify equipment. Alterations or modifications may void agency
approvals and create safety hazards.
Route hoses and cables away from traffic areas, sharp edges, moving parts, and
hot surfaces.
Do not kink or over bend hoses or use hoses to pull equipment.
Keep children and animals away from work area.
Comply with all applicable safety regulations.
Do not exceed the maximum operating pressure or the temperature of the part
with lower nominal value of the system. See Technical Data in all equipment
manuals.
Use fluids and solvents that are compatible with the wetted part of the system.
See Technical Data in all equipment manuals. Read the manufacturer’s instruc-
tions of the fluids and solvents. For more information on the material, request
the safety data sheet (MSDS) from the distributor or dealer.
Check the equipment every day. Immediately repair or replace worn or dam-
aged parts only with original spare parts of the manufacturer.
Make sure the equipment is classified and approved compliant with the stan-
dards of the environment where it is used.
Use the equipment only for the intended use. Contact your distributor for more
information.
Keep hoses and cables far from traffic areas, sharp edges, moving parts and
hot surfaces.
Do not bend or overbend the hoses or use the hose to pull the equipment.
BURN HAZARD
Equipment sur-
faces and fluid
that is heated
can become
very hot during
operation
To avoid severe burns do not touch hot fluid or equipment.
TOXIC FLUID
OR FUMES
HAZARD
Read MSDS’s to know the specific hazards of the fluids you are using.
Store hazardous fluid in approved containers, and dispose of it according to ap-
plicable guidelines.
Prolonged contact with the treated product may cause skin irritation: always
wear protective gloves during dispensing.
5 FIRST AID RULES
Electrocution disconnect the unit from the mains, or use a dry insulator as protection while
moving the electrocuted person far from any conductor. Do not touch the elec-
trocuted person with bare hands until he/she is far from any conductor. Ask
qualified and trained people for help immediately
SMOKING
PROHIBITED
When operating the dispensing system and in particular during refuelling, do not
smoke and do not use open flame.

7/124
7 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
6 GENERAL SAFETY RULES
Essential protective
equipment character-
istics
Wear protective equipment that is:
- suited to the operations that need to be performed;
- resistant to cleaning products.
Personal
protective
equipment that
must be work
Safety shoes;
Close-fitting clothing;
Protective gloves;
Safety goggles;
Other
Equipment
Instruction manual
7 TRANSPORT, HANDLING AND UNPACKING
CUBE MC is shipped in a cardboard packaging that cannot be stacked.
During storage follow the directions shown on the packaging with graphic
patterns about the handling side. If the machine is lifted, check if the capacity
of the lifting means and of the accessories (such as the bands) is correct. The
use of mechanical means for handling and lifting must be solely entrusted to
authorised and suitably trained staff.
During machine inactivity, both packed or unpacked, it should be stored in an
area protected against weather agents (rain, moisture, sun, etc...) and dust.
To open the cardboard packaging, use scissors or a cutter, taking care not to
damage the system.
With the help of a second operator, fully open the packaging and grasp the
CUBE MC putting it vertical, so that it can be positioned afterwards.
Once removed from the packaging, the station should always be kept vertical.
The packaging elements (cardboard, wood, cellophane, polystyrene, etc...)
must be placed in the suitable containers and not left in the environment or
within children easy reach as they are potentially harmful. Disposal should be
performed in compliance with the standards in force in the utilisation country.
The following indications
are specified on the pack-
age:
- an arrow indicating the
TOP side;
- a label containing all
the information relating
to the equipment (model,
weight, etc.).
SB_D_001

M0104 F
8 /32
Installation, use and maintenance
7.1 DIMENSIONS AND WEIGHTS
MODEL WEIGHT (Kg) PACKAGE DIMENSIONS (mm)
CUBE MC 25 400 x 400 x 460
PEDESTAL KIT 15 -
319
500
157
189
55 290
125
194
295 50
7.2 PACKAGE CONTENTS/PRE-INSPECTION
Foreword Before assembly, make sure the machine is integer controlling all parts for
possible damage that could hinder safety and functionality.
In case of doubt, do not start up and contact the manufacturer's technical
service.
Control if the accessory set is complete.
At the end of the control, assemble CUBE MC:
1
FIT THE HOSE
SUPPORT HOOK
2
FIT THE
EQUALISER
OPERATING
LEVER

9/124
9 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
MOUNTING
EXAMPLE
3
APPLY THREAD
SEALER AT
THE POINTS
SHOWN IN THE
PHOTO, BEFORE
PROCEEDING
WITH FINAL AS-
SEMBLY
8 MACHINE AND MANUFACTURER IDENTIFICATION
The SELF SERVICE stations feature an identification plate that is attached to
the shell showing
- Model
- Serial number / Year of manufacture
- Technical data
- EC mark
- Instruction manual code
ATTENTION Before installing the unit, check that the model is right and suitable for cur-
rently available supply voltage and frequency

M0104 F
10 /32
Installation, use and maintenance
8.1 PLATES POSITIONS
The dispensing system is equipped with decals and/or plates to provide opera-
tors with the necessary important information. Make sure that these do not
deteriorate or become detached over time.
NOTE Should this situation arise, please contact our support department and ar-
range to have the damaged or missing plates sent back and replaced where
necessary.
The decals present are as follows:
ON
OFF
- Pump activation plate
PIUSI SPA
SUZZARA (MN)
ITALY
2022
1234567
F0059400D
CUBE 70 MC
230V\50 Hz IB-PIUSI 2018
230 V 50 Hz 550 W 4,2 A
2900 rpm < 75 Db IP 55
Qmax: 72 l/min Pmax: 3,4 bar
S1=continuous Condenser : 450 V - 14 µF
3 - CE plate with technical data
4 - “ATTENTION” plate
applied to the seal of the station door, with indications of reading
of the instructions for use before use.
F0059400D
CUBE MC
F0059400D
1234567
5 corner label
to be applied on the box
ON
OFF
PIUSI SPA
SUZZARA (MN)
ITALY
2022
1234567
F0059400D
CUBE 70 MC
230V\50 Hz IB-PIUSI 2018
230 V 50 Hz 550 W 4,2 A
2900 rpm < 75 Db IP 55
Qmax: 72 l/min Pmax: 3,4 bar
S1=continuous Condenser : 450 V - 14 µF

11/124
11 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
9 DESCRIPTION OF MAIN COMPONENTS
9.1 BODY
CUBE MC dispensers are designed for the transfer of diesel fuel for private use. Characterized by maxi-
mum safety and simplicity of use, CUBE dispensers are dependable, high-performance equipment that is
quickly installed and ready for use. Equipment and features are:
1 - Blade type rotating self-priming
pump with incorporated by-pass
valve.
2 - Motor with degree of protec-
tion IP55 and heat protection, 230
V AC single phase.
3 - Four meters of anti-static rub-
ber tube for fuel.
4 - Automatic type dispenser
nozzle with ON/OFF switch inte-
grated in the nozzle support.
5 - Steel body with anti-corrosion
treatment and paint finish. Control
system.
6 - System management
7 - Meter
INSPECTION
PANEL
ROOF
NOZZLE
HOUSING
4
5
6
9.2 PUMPING UNIT
Unit with blade type self-priming
electric pump,featuring bypass
valve. Such a valve allows func-
tioning for brief periods of time
even with the dispensing nozzle
closed. The motor, which is di-
rectly coupled to the pump body,
is asynchronous, of the closed
type(degree of protection IP 55
according to EN60034-5-86
standard) self-ventilated, single
phase. For further details, refer to
the single components manuals.
7
1
23

M0104 F
12 /32
Installation, use and maintenance
9.3 PULSER METER
The K600/3 Pulser meter features a measurement system with high-precision oval gears designed for ac-
curate fuel metering. These have a sturdy die-cast aluminium structure and are complete with inlet suction
filter. They are easy to service and reliable. For further details, see the dedicated manual.
9.4 CONTROL SYSTEM
The electronic control system -MC- ensures the dispenser can only be used by authorised personnel.
All the data relating to each dispensing operation are stored and can be transferred to a PC (optional).
For further details, see the dedicated manual.
9.5 NOZZLE
SELF SERVICE is supplied with automatic nozzle, with delivery shutoff device operating when the tank is
full.
9.6 LEVEL INDICATOR (OPTIONAL)
The efficient electronic indicator “OCIO” is integrated in the management system to check and measure
fuel level in tanks. Further information can be found in the corresponding manual,
9.7 DISPLAY COVER
To ensure adequate
protection and the
correct visibility of
the CUBE MC dis-
play units,including
in very strong light
conditions, a pull-out
display unit cover has
been integrated inthe
structure. This can
be lowered in case of
need. In very strong
light conditions, wead-
vise always keeping
the display cover low-
ered when not in use.

13/124
13 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
10 TECHNICAL SPECIFICATIONS
10.1 TECHNICAL DATA
MODEL Voltage Frequency Power Absorption Max Flow Rate
CUBE MC70 MC 230 V 50 HZ 900 W 4,2 A 70 l/min
CUBE MC70 MC 110 V 60 HZ 550 W 5,5 A 69 l/min
10.2 POWER CONSUPTION
NOTE The CUBE MC stations must be powered by a power line with the same RATED
VOLTAGE /FREQUENCY as that indicated on the identification plate. The fol-
lowing max. variations can be accepted:
- VOLTAGE +/- 5%
- FREQUENCY +/- 2%
ATTENTION Power supply from lines with values that do not fall within the indicated limits
could cause damage to the electrical components.
The IDENTIFICATION PLATE shows maximum ABSORBED POWER (in Am-
pères), with respect to which, the power protection appliances required by ap-
plicable standards (not supplied with the station) must be sized. The maximum
absorbed power refers to intended-use operation - DISPENSING OF DIESEL
FUEL - with power supply within the above-mentioned limits.
11 INTENDED USE
WARNING
Flammable
liquids and explo-
sive atmosphere
The system was not designed for dispensing of diesel, petrol, flammable liquids
with flash point <55°C/131°F, or for operation in environments with potentially
explosive atmosphere. The use in the above mentioned conditions is forbidden.
ATTENTION
Environmental
conditions
The use of the system for purposes different from those specified in sec-
tion «Intended use» is strictly forbidden. Do not operate the system for any
purpose other than the purpose described within this manual; all other use
is considered «IMPROPER» and will result in Piusi S.p.A. disclaiming any re-
sponsibility for damage to property, people, animals or to the system itself.
Fluid Permitted
- DIESEL FUEL at a VISCOSITY from 2 to 5.35 cSt (at a temperature of 37.8°
/ 100°F C). Minimum Flash Point (PM): 55°C / 131°F (In accordance with the
EN590)
- Paraffinic HVO/XTL: EN 15940
ATTENTION
Environmental
conditions
TEMPERATURE: min. –20° C / max +60° C
RELATIVE HUMIDITY: max. 90%
The temperature limits shown apply to the pump components and must be
respected to avoid possible damage or malfunction.

M0104 F
14 /32
Installation, use and maintenance
12 INSTALLATION
CUBE MC can be installed outside. Nevertheless, it is advisable to locate it un-
der the shelterof a roof to ensure the dispenser’s longevity and provide greater
comfort during refuelling inthe event of bad weather. The installation of the dis-
penser must be carried out by skilledpersonnel and performed according to the
instructions provided in this chapter.Whenever CUBE MC is not installed under
cover, a “display cover” is provided to protected thedisplay and keyboard.
WARNING
Authorised
installation
personnel
All installations must be carried out by authorised and competent personnel
only. Authorised persons must
- install the system in dry and well-ventilated place;
- ensure the correct installation of equipment required for the correct function-
ing of the pump;
- only use accessories that have been supplied with the system.
ATTENTION The use of accessories that are unsuitable and were not provided with the
system is strictly prohibited. Piusi S.p.A. accepts no responsibility for damage
to persons, property or the environment caused by failure to comply with this
requirement.
THE DISPENSING SYSTEM IS FOR PROFESSIONAL USE ONLY.
As per the current legislation, the dispensing system must be used n premises
that are sufficiently well-lit.
The dispensing system has been specifically designed for use in a dry place. If
installed outside, an adequate protective covering must be provided.
Motors are not explosion-proof. DO NOT install SELF SERVICE in places with
danger of explosion.
12.1 POSITIONING
The positioning of the SELF SERVICE must be such that it is possible to:- Easily
remove the panels to access the inner components when necessary.- Observe
the distances and maximum differences in level between the station and the
tank.- Securely fasten the casing to the ground on a horizontal surface. Station
positioning determines the following parameters, which distinguish each instal-
lation:
Hp: Priming height
Ls: Total length of the suction pipe - from the foot valve to the
station(expressed in metres)
To ensure correct station operation, the following limitations must always be
kept to:
Hp max: not over 3 metres
LS max: not over 15 metres

15/124
15 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
12.2 FIXING
Before starting installation, make sure no packaging materials are trapped in the pipes. Prepare suitable
stilts or fixing brackets depending on the fixing position of the CUBE MC. The tube coming from the tank
must be aligned to the threaded inlet of the pump filter which is located under the CUBE MC.
ABOVE-GROUND
TANK
MAX.
MIN.
Hp
UNDERGROUND
TANK
Hp
MAX.
MIN.

M0104 F
16 /32
Installation, use and maintenance
12.3 HYDRAULIC CONNECTIONS
ATTENTION The use of accessories that are unsuitable and were not provided with the
system is strictly prohibited. Piusi S.p.A. accepts no responsibility for damage
to persons, property or the environment caused by failure to comply with this
requirement.
Always follow the below-listed instructions:
- Use pipes and joints suitable for operation in vacuum conditions.
- Use pipes and accessories suitable for treated fluid. Unsuitable materials can
result in serious damage to the pump; they can also cause pollution.
- Do not use conical threaded connectors that could cause damage to the
threaded connector on the pump filter if tightened excessively
- Use wide-radius bends so that pressure losses are reduced to minimum levels.
- Check that suction pipe is perfectly clean and free from scales.
- Install a FOOT VALVE equipped with FILTER at suction pipe end. Place the
foot valve on tank bottom. Foot valve and pipe must have the SAME DIAM-
ETER.
- Before starting installation, make sure that no packing material has been left
in the pipes.
SUCTION LINE The diameter of the “Ds” suction line must be selected according to the station
model and the position of the station with respect to the tank. With reference to
the “Hp” and “Ls” values indicated at point H2, the following MINIMUM DIAM-
ETERS of the suction pipe must always be ensured.
MAXIMUM
LENGTH OF
THE SUCTION
PIPES
The maximum length of the tubing, the diameter of the tubing, the difference in
height, are parameters that are tightly linked to creating suction conditions. The
latter must not be such as to create back pressure greater than 0.6 bar. It fol-
lows as a consequence that, after respecting the minimum diameter of the tub-
ing specified in the “Recommendations and Warnings” below, the length of the
tubing decreases as the difference in height that the diesel fuel must overcome
increases and vice versa: in fact, the back pressure progressively increases by
0.08 bar for every meter increase in the static height of the pump with respect
to the level of the diesel fuel in the tank.
RECOMMEN-
DATIONS AND
WARNINGS
- The suction pipe must resist a pressure of at least 10 bar and must be of a
diameter NOT LOWER THAN 1’’ 1/4.
- The tubing must be suitable to functioning under back-pressure.
- Use tubing and accessories suitable for use with diesel fuel. Materials that
are not suitable for use with diesel fuel can cause damage to the pump, harm
people and cause pollution.
- Any curves in the suction pipes must be of the widest radius possible to limit
the loss of head.
- Make sure that the suction pipe is clean and free of scum.

17/124
17 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
12.4 ELECTRIC CONNECTIONS
ATTENTION The installation operations are performed with door open and power con-
tacts accessible. All these operations must be performed with the appliance
isolated from the power mains to avoid any risk of electric shocks!
All the installation operations must be performed by qualified electro-tech-
nical or electronic staff.
The sections of the cables must be appropriate to the current rates of the
device
Electric connections shall be carried out by specialized personnel in a profes-
sional way. Full compliance with the regulations in force in the country where
the unit is installed and with the wiring diagrams contained in this manual is
required
ATTENTION The CUBE MC dispenser does not feature overload cutouts and, consequent-
ly, as witch board must be fitted upstream of the CUBE MC complete with
residual current circuit breaker suitable for the type of CUBE MC to be in-
stalled.
CUBE MC features a terminal board cover. Inside this cover are the terminals
which the installer must connect up to:
- The mains power line
- The RS 485 data line to the PC + level indicator (optional).
NOTE The connector block, accessible through the front panel opening, is already
wired up to the CUBE MC components, according to the block diagram shown
below.
1-
Remove the right termi-
nal board cover.
2-
Connect the cables as
shown in the diagram.
3-
Close the terminal board
cover box again.
7 8
9
10
11
DX
SX
Power 230V
To Motor
OPTIONAL
(RS485 + LEVEL
INDICATOR)
PULSER
K600
         
NOTE The parts indicated in the diagram are the only connections to be made by the
customer:
- Connection to power mains.
- RS485 output to PC (OPTIONAL).

M0104 F
18 /32
Installation, use and maintenance
ATTENTION For CUBE MC commissioning, no further power connections are required. All the elec-
tronic components housed in the MC BOX are already wired up and factory tested.
It is therefore NEVER necessary for the installer or station manager to open the MC
BOX except to replace the protection fuses housed on the I/O card (see photo below).
The installer should carry out a plug/socket connection for a quick sectioning
of the electric system in case of failures.
Below are the main connections and the fuses to be replaced by skilled service
technicians only.
TASTIERA
112
Power 230V
To Motor
I/ O Card
CPU Card
DISPLAY Card
KEY Reader
1
2
5
3
4
7
6
OPTIONAL (RS485 + LEVEL INDICATOR)
PULSER K600
JUMPER
        
KEY: 1 Key reader (I-Button) 2 Display card 3 CPU card 4 Keyboard 5 I / O card 6 Jumper 7 Electrical boxes

19/124
19 /32
EN
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
EN (translated from italian) CUBE • MC
13 STARTING
FOREWORD To correctly commission the CUBE MC the sequence of operations indicated below must
be followed and the MC control system functions must be known (see attached manual).
ELECTRICAL
POWER
SUPPLY
Once the power connections have been made, the CUBE MC can be energised by
means of the master switch to be fitted by the installer on the upstream line. Switching on
of the MC system will be indicated by the lighting up of the two backlit LCDs fitted on the
front. Even when the nozzle is taken out of its seat, the pump WILL NOT start as it has not
been enabled by the MC system.
WETTING
THE PUMP
CUBE MC features a self-priming pump that makes first startup easier. To start the appli-
ance, the suction pipe need not therefore be completely full of diesel fuel. For quick prim-
ing, especially in the case of installations distinguished by a considerable difference in level
between the pump and the tank, it is however important for the pump to be “wetted”,
meaning that there must be a small quantity of diesel fuel inside the impeller chamber. The
pump is supplied adequately “wetted” and ready for use. If however the installer considers
the pump to be totally dry, perhaps due to prolonged storage, he will have to wet it as he
thinks best.
STATION
CONFIGURATION
Every CUBE MC station can be adapted to the specific requirements of the sta-
tion manager.T o do this the MC control system must be CONFIGURED.
ATTENTION
MC configuration is crucial and must be done by skilled personnel. To perform
this operation, the MC manual must be carefully and thoroughly read.
After completing configuration, user PIN CODES can be assigned to the persons
charged with using CUBE MC, in accordance with the detailed information in
the MC manual
DISENGAGING
THE
“MC” SYSTEM
All the CUBE MC functions are controlled by the MC control system. The MC
system can never the less be disengaged for any startup or maintenance ac-
tivities requiring repeated pump starting. In these case, it is often convenient to
simplify pump startup by not having to enter any code and record any dispensing
data. To do this, a JUMPER has been fitted on the card that permits switching
from AUTOMATIC mode (code request to access dispensing) to MANUAL mode
(no code request).
ATTENTION
The jumper is only accessible by opening the front panel and is positioned
as shown in the photo. In this operating mode, MC does not record any data
relating to performed dispensing operations. BEFORE ACCESSING THIS
JUMPER, ALWAYS INTERRUPT THE POWER SUPPLY
In MANUAL mode:
• The MC LCDs could be off or continue
to display whatever was showing at the
time of switch over from AUTO to MAN.
• To start the pump, no PIN CODE is re-
quired; the pump will start as soon as
the nozzle is taken off its seat and will
stop when the nozzle is put back.
• The quantity dispensed by CUBE MC
is not indicated in any way.

M0104 F
20 /32
Installation, use and maintenance
13.1 INITIAL PRIMING
To prime the pump:
- Take the nozzle off its seat
- Enter the previously assigned PIN CODE (if the jumper is on)
- Lift the control lever
- The pump will start immediately and will continue running indefinitely until the
control leveris moved to OFF position.
ON
POSITION
OFF
POSITION
Operate the lever of the automatic nozzle, keeping the spout inside an adequate
container or the same suction tank. Air will first of all come out of the nozzle and
then DIESEL FUEL will gradually begin to flow.
ATTENTION
The first priming of the pump must be done by skilled personnel who must
monitor all the various stages involved. If only air continues to come out after
more than two minutes, STOP THE PUMP and make sure:
• This is not working dry, but is at least “wetted” with diesel fuel.
• The suction pipe prevents any air from infiltrating and that this is completely
submerged.
• The filters are not blocked.
• The suction and/or supply lines are not blocked.
• Installation (level difference, diameter and pipe length) is within the limits
indicated at chapter “HYDRAULIC CONNECTIONS”.
• The disconnection valve is closed.
Continue dispensing until the flow is regular and air free. Position the control
lever in OFF position:-The pump stops. Place the nozzle back in its seat.
