Goji Tinchy Stryder ON CLOUD 9 User manual

GPSBTS312
GPSBTS312_IB_Final120815_RC.indd 1 20/8/12 12:21 PM

GPSBTS312_IB_Final120815_RC.indd 2 20/8/12 12:21 PM

1
Unpacking
Remove all packaging from the unit. Retain the packaging. If
you dispose of it please do so according to local regulations.
The following items are included:
Main Unit
Audio Cable x 1 USB Cable x 1
Carry Bag x 1
Instruction Manual x 1
If items are missing, or damaged please contact Partmaster
(UK only).
Tel: [phone] for assistance.
GPSBTS312_IB_Final120815_RC.indd 1 20/8/12 12:21 PM

2
Product Overview
Front View
21 1
1. Speakers
2. LED Indicator
GPSBTS312_IB_Final120815_RC.indd 2 20/8/12 12:21 PM

3
Rear View
ON/OFF AUX IN USB
VOL– VOL+
21 3 4
5 6 7 8
1. VOL+ Button
2. / Button
3. VOL– Button
4. Mic
5. ON/OFF Switch
6. AUX IN Socket
7. (Mini )USB Socket
8. Battery Indicator
GPSBTS312_IB_Final120815_RC.indd 3 20/8/12 12:21 PM

4
First Charge the Battery
The unit has a built-in rechargeable Li-polymer battery.
The battery is charged automatically whenever the unit is
connected to a computer.
Recharging Indicator lights up solid red and blue.
Fully recharged Indicator lights up solid red.
• It takes 5 hours (approx.) to fully charge the battery.
• A fully charged unit has up to 12 hours of playback time.
• There is no standby mode. To save battery life, please
switch off the unit.
• Do not overcharge the battery as it may shorten its life.
GPSBTS312_IB_Final120815_RC.indd 4 20/8/12 12:21 PM

GPSBTS312_IB_Final120815_RC.indd 5 20/8/12 12:21 PM

6
Connecting Your Goji Speakers
VOL– VOL+
ON/OFFAUX INDC IN
USB Cable
(Included)
Mobile Phone
Bluetooth
Audio Cable
(included)
Computer
Audio Device
* All output devices are not included.
GPSBTS312_IB_Final120815_RC.indd 6 20/8/12 12:21 PM

7
Powering ON/OFF
• Switch the ON/OFF switch to the ON position to turn
the unit on. The LED indicator will light up blue.
• Switch the ON/OFF switch to the OFF position to turn
the unit off. The LED indicator will disappear.
Bluetooth
1. Press and hold the / button for approx. 5 seconds to
activate Bluetooth pairing. The LED indicator will flash
blue and red until it pairs. When successfully paired, the
LED indicator will light up solid blue, while a red light
will flash once a second.
2. Search for the system with your Bluetooth device and
you should see “GPSBTS312”. Enter password “0000” if
requested.
GPSBTS312_IB_Final120815_RC.indd 7 20/8/12 12:21 PM

8
Operations
To Press / Hold Effect
Increase Volume Vol + Hold down Louder
Decrease Volume Vol – Hold down Quieter
Answer Call
(during playback)
/ Press once Answer call &
stop playback
End Call
(during playback)
/ Hold down End Call
Reject Call
(any time)
/ Press for 3 secs Reject call
GPSBTS312_IB_Final120815_RC.indd 8 20/8/12 12:21 PM

9
• To successfully answer a call, ensure your mobile device
supports Bluetooth HSP/HFP.
• Ensure your Bluetooth device is configured to take full
advantage of the unit’s functions. Please refer to you
Bluetooth device’s manual for detailed instructions.
• When using the AUX IN function, you need to use your
media device for all operations.
To Press / Hold Effect
Use Speaker for call / Press once
during call
Switch to unit’s mic
and speaker
Use mobile phone
for call
/ Press once
during call
Switch to mobile
phone
Call functions only applicable if mobile phone is paired with
the speaker and both are switched on.
GPSBTS312_IB_Final120815_RC.indd 9 20/8/12 12:21 PM

10
Hints and Tips
Menu Description
No power. • Make sure that the unit is switched ON
at the rear.
• The battery may be exhausted. Connect
the USB cable and plug into a USB port
of a computer which is turned on.
Loud hum or noise
is heard.
• The plugs and sockets are dirty. Wipe
them with a cloth slightly moistened
with an appropriate non-abrasive
cleaning solution.
Cannot answer
calls
• Ensure your mobile phone supports
Bluetooth HSP/HFP.
• Check the mobile phone and unit are
connected.
I cannot find
“GPSBTS312” on my
Bluetooth device.
• Ensure the Bluetooth function is
activated on your Bluetooth device.
GPSBTS312_IB_Final120815_RC.indd 10 20/8/12 12:21 PM

11
Specifications
Model GPSBTS312
Output Power 2W x 2
Bluetooth Bluetooth 3.0 (A2DP / HSP / HFP)
Dimension 136(W) x 70.5(H) x 73.5(D) mm
Features and specifications are subject to change without
prior notice.
Maintenance
Ensure the unit is fully unplugged from the mains socket
before cleaning.
• To clean the unit, wipe the case with a slightly moist,
lint-free cloth.
• Do not use any cleaning fluids containing alcohol,
ammonia or abrasives.
• Do not spray an aerosol at or near the unit.
GPSBTS312_IB_Final120815_RC.indd 11 20/8/12 12:21 PM

GPSBTS312_IB_Final120815_RC.indd 12 20/8/12 12:21 PM

13
Safety Warnings
• Read all the instructions carefully
before using the unit and keep them
for future reference.
• Retain the manual. If you pass the unit
onto a third party make sure to include
this manual.
• Check that the voltage marked on
the rating label matches your mains
voltage.
Damage
• Please inspect the unit for damage
after unpacking.
• Do not continue to operate the unit if
you are in any doubt about it working
normally, or if it is damaged in any way
- switch o, unplug the mains plug and
consult your dealer.
Location of Unit
• The unit must be placed on a at stable
surface and should not be subjected
to vibrations.
• Do not place the unit on sloped or
unstable surfaces as the unit may fall
o or tip over.
• The mains socket must be located
near the unit and should be easily
accessible.
Temperature
• Avoid extreme degrees of temperature,
either hot or cold. Place the unit
well away from heat sources such as
radiators or gas/electric res.
• Avoid exposure to direct sunlight and
other sources of heat.
Naked Flames
• Never place any type of candle or
naked ame on the top of or near
the unit.
Moisture
• To reduce the risk of re, electric shock
or product damage, do not expose
this unit to rain, moisture, dripping
or splashing. No objects lled with
liquids, such as vases, should be placed
on the unit.
• If you spill any liquid into the unit, it
can cause serious damage. Switch it o
at the mains immediately. Withdraw
the mains plug and consult your dealer.
GPSBTS312_IB_Final120815_RC.indd 13 20/8/12 12:21 PM

14
Ventilation
• To prevent the risk of electric shock or
re hazard due to overheating, ensure
that curtains and other materials do
not obstruct the ventilation vents.
• Do not install or place this unit in a
bookcase, built-in cabinet or in another
conned space. Ensure the unit is well
ventilated.
Safety
• Always disconnect the unit from the
mains supply before connecting/
disconnecting other devices or moving
the unit.
• Unplug the unit from the mains socket
during a lightning storm.
Interference
• Do not place the unit on or near
appliances which may cause
electromagnetic interference. If you do,
it may adversely aect the operating
performance of the unit, and cause a
distorted picture or sound.
Supervision
• Children should be supervised to
ensure that they do not play with the
unit and the remote control.
• Never let anyone especially children
push anything into the holes, slots or
any other openings in the case - this
could result in a fatal electric shock.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral
triangle, is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
unit’s enclosure that may be of
sucient magnitude to constitute
a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the manual
accompanying the unit.
GPSBTS312_IB_Final120815_RC.indd 14 20/8/12 12:21 PM

15
Service
• To reduce the risk of electric shock, do
not remove screws. The unit does not
contain any user-serviceable parts.
Please leave all maintenance work to
qualied personnel.
• Do not open any xed covers as this
may expose dangerous voltages.
Maintenance
• Ensure the unit is fully unplugged from
the power supply before cleaning.
• Do not use any type of abrasive pad
or abrasive cleaning solutions as these
may damage the unit’s surface.
• Do not use liquids to clean the unit.
GPSBTS312_IB_Final120815_RC.indd 15 20/8/12 12:21 PM

DSGRetailLtd•MaylandsAvenue•HemelHempstead
Herts•HP27TG•England
IB-GPSBTS312-120815V2
All trademarks are the property of their respective owners and all rights are
acknowledged.
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end
of its life separately from your household waste. There are separate
collection systems for recycling in the EU.
For more information, please contact the local authority or your
retailer where you purchased the product.
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million
spares and accessories available we can deliver direct to
your door the very next day. Visit www.partmaster.co.uk or call 0844 800 3456
(UK customers only) Calls charged at National Rate.
Notes for battery disposal
The batteries used with this product contain chemicals that are harmful to the
environment. To preserve our environment, dispose of used batteries according
to your local laws or regulations. Do not dispose of batteries with normal
household waste.
For more information, please contact the local authority or your retailer where
you purchased the product.
GPSBTS312_IB_Final120815_RC.indd 16 20/8/12 12:21 PM
