Gold-TEC AUDII DAAK-1000 User manual

Gold-Tec AUDII
Audio Amplifier
User Manual
Model: DAAK-1000

Congratulaon on purchasing your
AUDII AMP
Audio Amplifier!
Metal detecting is a fascinating and rewarding
activity enjoyed by many people all over the
world. By getting to know and use your Audii Amp
you will find that the audio enhancement and
clarity will make hearing small targets easier.
With the assistance of this device you too can
become one of the many, finding gold and other
treasures.
You to can go out there and have a good
Gold-Tecing Day!
We of Gold-Tec are wishing you
enjoyable & profitable adventures.
Neil looking for a target

Table of Contents
Introduction 1
AUDII AMP & Attachments 2
Power Supply 3
Assembly 4
Technical Specification 5
Accessories 5
Caution 5
Warranty 6
A target has been found
One nice 1 oz nugget 400mm (15”) Down.

1
Neil using the AUDII AMP with is GPX 5000
Pinpoinng the target
Introducon
The AUUDII AUDIO AMPLIFIER is design for
persons who are wanng to enhance their gold
recovery to become more successful Detectorists.
• The device delivers crystal clear audio to your
headphones or speaker enabling you to easily
discern those faint signals from small targets.
• The detector’s signals are ltered to minimise
interference from outside noise sources and
improves your ability to work comfortably for longer
periods of me, increasing the chances of nding
that gold or treasure.
• Reduces potenally loud damaging signals from
geng to both the headphones or speaker – lie
when you nd that “buried n can”.
• The AUDII is protected against excessive heat
condions.
• The higher baery voltage provides more audio
amplier output range and stability.
• Ease of use simply plug and play.

Audio output Jack
Speaker/Headphones
ON/OFF Volume
Audio input Charging input
240V-12V DC charging adaptor Audio input Cable
12V car charging cable
2
AUDII AMP & Attachments

3
Digging up the target
Power Supply (Fig.2)
The AUDII is power by a 7.4V 2000 mAh Lithium
rechargeable baery. Included in the in the device is a
dedicated charger and baery protecon systems.
Note: The baery should be fully charged before use.
Charging from a car 12V DC outlet:
 Select the unit car charging adaptor supplied with
your kit .
 Insert the 2.1mm Female DC plug into the male
bulkhead DC ng (5).
 Plug the cigaree lighter end into the 12V DC outlet
of your car.
Charge Status Indicator: (Fig.2)
 Power ON, is displayed with a green LED (6).
 When baery is charging s red LED (6) is on.
 When fully charged the green LED will turn OFF.
You will have an 15-hour use me from a 3-4 hour
charge.
The AUDII AMP automacally adjusts to maintain
audio and detecng performance as the baery
discharges during use.
1
6
5
3
4
2
Fig. 1 Fig. 2

Assembly
Audio Input Cable: (Fig.2)
 Select the audio cable supplied in the kit.
 Carefully insert the female 2 pin plug into the male
2 pin input plug (1) ed to the boom panel.
 Screw the lock nut securely.
Audio Amplier Output: (Fig.1)
The AUDII provides two dedicated switchable audio
amplicaon for the use of headphones or external
speaker.
 The 6.5mm audio output jack (2) ed to the top
panel, is to be used with mini external speaker
supplied in the kit. The external speaker and hapc
transducer can be used at the same me.
ON/OFF Volume Switch: (Fig.1)
 the switch (3) is used to acvate the two audio amps
and controlling the volumes.
Headphones/speaker Switch Mode: (Fig.1)
 The toggle switch (4) is used to acvate and
switching between the two dedicated audio
ampliers supplied for the use of headphones or
External speaker.
The device is ed with a belt clip , so clip it on and it’s
ready to be used.
4
The target has been dug up
1
6
5
3
4
2
Fig. 1 Fig. 2

Setup Procedure (AUDII AMP & Metal Detector)
Once you have connected the aachment to the AUDII
AMP. Clip it to the waist band of your harness, Fallow
the next steps and you will be ready to start detecng.
 Connect the device to your detector by inserng
the 6.5mm male jack from the audio cable of the
device to your detector power pack or baery
audio output female jack.
 Next turn on both machines and let the detector
go through its tuning cycle. On the AUDII adjust
the volume of your headphones or external
speaker to a comfortable level.
 Know just adjust your threshold level and o you
go.
Note: to load is not good, but to quiet is not good
ether. You have to hear the threshold working,
so you can hear the faint targets.
5
Looking for the it in the pile of
dirt

Technical Specifications
6
AUDII AMP: Audio amplier
Audio amplier: 2 - 15 w dedicated audio
ampliers
Audio output 1: Headphones
Audio output 2: External speaker
Power supply: 7.4V Lithium baery
Baery capacity: 2000 mAh
Audio output jack: 6.5mm female jack
Audio input cable: 6.5mm male jack & 2 pin plug
Charging 240V: 240V-12V DC switch mode
adaptor
Charging 12V: Fused car charging adaptor (5A)
with 2.1mm plug
Cautions
 Please use only supplied components or oponal
accessories produced by Gold-Tec to avoid damage
to the unit.
 Please refer to our distributors or direct to Gold-Tec
for the oponal accessories suitable for your unit.
 To reduce the risk of damage, do not expose the
AUDII to rain or moisture.
 When charging never place the unit on dashboard of
a car. Always place it in a cool place. Lithium
baeries do not like to be abused. Explosions could
occur.
Accessories
GT3021: Audio Extension Cable, 1.6m suits SDC & GPX
detectors.
GT3011: 240V-12VDC regulated switchmode power
adaptor, 2.1mm plug - 2A
GT1001: Mini External Speaker & 3.5mm to 6.5mm jack
adaptor.
GT2011: Gold-Tec Universal Bungee, suits all detec-
tor models.
There it is, a nice lile gold
nugget

7
Warranty
The AUDII AMP control unit has a 1 year warranty
covering parts and labour. Refer to your online
registraon for details.
The warranty period commences from the date of
purchase.
The Gold-Tec warranty does not cover damage caused
by accident, misuse, neglect, alteraon, modicaon or
unauthorised service.
It is the responsibility of the owner to pay all transport
costs for geng the unit to Gold-Tec. The repaired unit
will be returned to the owner freight free.
Note: The warranty is not transferable. The warranty
will only be valid when the online warranty registraon
has been completed within 14 days of original purchase.
Gold-Tec Australia
Giving you the Edge
Ph: [phone]
Email: [e-mail]
www.gold-tec.com.au
Remember to always ll in
your holes
