Goldstar GBV241 User manual

DVD Player+
Video Cassette Recorder
OWNER’S MANUAL
MODEL : GBV 241
Before connecting, operating or adjusting this product,
please read this instruction booklet carefully and completely.

2
Safety Precautions
This lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to
the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: Do not install this equipment in a confined space
such as a book case or similar unit.
NOTE TO CABLE/TV INSTALLER: This reminder is provided to
call the cable T system installer’s attention to Article 820-40 of
the National Electric Code (U.S.A.). The code provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of the cable entry as practical.
CAUTION:
This D D+ CR employs a Laser System.
To ensure proper use of this product, please read this owner’s
manual carefully and retain for future reference should the unit
require maintenance, contact an authorized service location.
Use of controls, adjustments, or the performance of proce-
dures other than those specified herein may result in haz-
ardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open
the enclosure. isible laser radiation when open. DO NOT
STARE INTO BEAM.
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects filled with liquids, such
as vases, should be placed on the apparatus.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the modifi-
cations are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an
unauthorized change or modification is made.
REGULATORY INFORMATION: FCC Part 15
This product has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the product is
operated in a residential installation. This product generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this product does cause harmful
interference to radio or television reception, which can be
determined by turning the product off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the product and
receiver.
Connect the product into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/T technician
for help.
NOTES ON COPYRIGHTS:
It is forbidden by law to copy, broadcast, show, broadcast
via cable, play in public, or rent copyrighted material without
permission.
This product uses copyright protection developed by
Macrovision. Copy protection signals are recorded on some
discs. When recording and playing the pictures of these discs
on a CR, picture noise will appear.
This product incorporates copyright protection technology that
is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection tech-
nology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
SERIAL NUMBER: The serial number is found on the back of
this unit. This number is unique to this unit and not available to
others. You should record requested information here and
retain this guide as a permanent record of your purchase.
Model No. _________________________________
Serial No. _________________________________
CAUTION: TO PRE ENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR É ITER LES CHOC ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU’AU FOND.
WARNING: TO REDUCE THE RISK OF FIRE OR ELEC-
TRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO
RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMO E CO ER (OR BACK)
NO USER-SER ICEABLE PARTS INSIDE
REFER SER ICING TO QUALIFIED SER ICE
PERSONNEL.

INTRODUCTION
3
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions. - All these safety and oper-
ating instructions should be read before the product is
operated.
2. Keep these instructions. - The safety, operating and
use instructions should be retained for future refer-
ence.
3. Heed all warnings. - All warnings on the product and
in the operating instructions should be adhered to.
4. Follow all instructions. - All operating and use
instructions should be followed.
5. Do not use this product near water. – For example:
near a bath tub, wash bowl, kitchen sink, laundry tub,
in a wet basement; or near a swimming pool; and
other areas located near water.
6. Clean only with dry cloth. – Unplug this product from
the wall outlet before cleaning. Do not use liquid
cleaners.
7.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions. -
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over- heating. The open-
ings should never be blocked by placing the product
on a bed, sofa, rug or other similar surface. This prod-
uct should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is pro-
vided or the manufacturer’s instructions have been
adhered to.
8. Do not install near any heat sources such as radi-
ators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. D
o not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are pro-
vided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the product.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
apparatus. When a cart is used, use caution
when moving the cart/product combination to
avoid injury from tip-over.
13. Unplug this product during lightning storms or
when unused for long periods of time.
14.
Refer all servicing to qualified service personnel.
Servicing is required when the product has been
damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or
objects have fallen into the product, the product
has been exposed to rain or moisture, does not
operate normally, or has been dropped.
CAUTION:
PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL.
AND THOSE MARKED ON THE PRODUCT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This product has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this product will protect you if you observe the following proce-
dures for installation, use, and servicing.
This product does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.

4
Table of Contents
Introduction
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . 3
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . 6
About Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Selecting the iewing Source. . . . . . . . . . . . . . . . 6
Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . 7
Display Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connections Panel . . . . . . . . . . . . . . . . . . . . . . . . 10
Preparation
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-13
Connecting Antenna/Cable T to D D+ CR . . . 11
Basic T Connections . . . . . . . . . . . . . . . . . . . . 12
Optional, Preferred T Connections . . . . . . . 12-13
Before VCR Operation . . . . . . . . . . . . . . . . . . . 14-16
On-Screen Display(OSD) . . . . . . . . . . . . . . . . . . 14
On-Screen Menus Setup . . . . . . . . . . . . . . . . . . 14
Setting the CR Setup Menu Options . . . . . . . . 15
Channel Selection . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . 16
Before DVD Operation . . . . . . . . . . . . . . . . . . . 17-20
General Explanation. . . . . . . . . . . . . . . . . . . . . . 17
On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . 17
D D Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 18-20
 General Operation . . . . . . . . . . . . . . . . . . . . 18
 Language . . . . . . . . . . . . . . . . . . . . . . . . . . 18
 Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
 Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
 Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
 Parental Control . . . . . . . . . . . . . . . . . . . . . . 20
Operation
Tape Operation . . . . . . . . . . . . . . . . . . . . . . . . . 21-26
Normal Playback . . . . . . . . . . . . . . . . . . . . . . . . 21
Special Effect Playbacks . . . . . . . . . . . . . . . . . . 21
 Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
 Still Picture and Frame- y-Frame Play ack . 21
 Slow Motion . . . . . . . . . . . . . . . . . . . . . . . . . 21
 CM Skip (Commercial Skip) . . . . . . . . . . . . . 21
 EZ (EASY) Review. . . . . . . . . . . . . . . . . . . . 21
Normal Recording . . . . . . . . . . . . . . . . . . . . . . . 22
Timer Recording . . . . . . . . . . . . . . . . . . . . . . 22-23
Instant Timer Recording . . . . . . . . . . . . . . . . . . . 24
Dubbing and Editing. . . . . . . . . . . . . . . . . . . . . . 24
Copying from D D to CR. . . . . . . . . . . . . . . . . 24
HS Hi-Fi Stereo System/MTS Broadcast . . . . . 25
Tape Counter Memory Feature. . . . . . . . . . . . . . 26
Additional Information . . . . . . . . . . . . . . . . . . . . 26
DVD Operation . . . . . . . . . . . . . . . . . . . . . . . . . 27-29
Playing D Ds . . . . . . . . . . . . . . . . . . . . . . . . . . 27
General Features . . . . . . . . . . . . . . . . . . . . . . . . 27
 Selecting other TITLEs. . . . . . . . . . . . . . . . . 27
 Selecting other CHAPTERs . . . . . . . . . . . . . 27
 Slow Motion . . . . . . . . . . . . . . . . . . . . . . . . . 27
 Still Picture and Frame- y-Frame Play ack . 28
 Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
 Random. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
 Repeat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
 Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . 28
 Time Search . . . . . . . . . . . . . . . . . . . . . . . . 28
 3D Surround . . . . . . . . . . . . . . . . . . . . . . . . 28
 Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
 Marker Search . . . . . . . . . . . . . . . . . . . . . . . 29
Special D D Features . . . . . . . . . . . . . . . . . . . . 29
 Checking the contents of DVD Video discs: Menus . 29
 Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 29
 Disc Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 29
 Camera Angle . . . . . . . . . . . . . . . . . . . . . . . 29
 Changing the Audio Language . . . . . . . . . . . 29
 Su titles. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Operation with Audio CD and MP3 Disc . . . . . 30-31
Playing an Audio CD and MP3 Disc . . . . . . . . . . 30
Notes on MP3 Recordings . . . . . . . . . . . . . . . . . 30
 Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
 Selecting other Tracks . . . . . . . . . . . . . . . . . 31
 Repeat Track/ All/ Off . . . . . . . . . . . . . . . . . . 31
 Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
 Random. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
 Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . 31
 3D Surround . . . . . . . . . . . . . . . . . . . . . . . . 31
 Changing the Audio Channel . . . . . . . . . . . . 31
Operation with JPEG Disc. . . . . . . . . . . . . . . . . . . 32
iewing a JPEG disc . . . . . . . . . . . . . . . . . . . . . 32
 Moving to another File . . . . . . . . . . . . . . . . . 32
 Still Picture . . . . . . . . . . . . . . . . . . . . . . . . . 32
 To flip the picture . . . . . . . . . . . . . . . . . . . . . 32
 To rotate picture . . . . . . . . . . . . . . . . . . . . . . 32
 Notes on JPEG Recordings . . . . . . . . . . . . . 32
Programmed Playback . . . . . . . . . . . . . . . . . . . . . 33
Programmed Playback with Audio CDs and
MP3 Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
 Repeat Programmed Tracks/ All/ Off . . . . . . 33
 Erasing a Track from Program List . . . . . . . . 33
 Erasing the Complete Program List . . . . . . . 33
Reference
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 34-35
Language Code List . . . . . . . . . . . . . . . . . . . . . . . 36
Country Code List . . . . . . . . . . . . . . . . . . . . . . . . . 37
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
About the symbols for instructions
Indicates hazards likely to cause harm to the unit
itself or other material damage.
Indicates special operating features of this unit.
Indicates tips and hints for making the task easier.

INTRODUCTION
5
Before Use
Playable Discs
D D
(8 cm/12 cm disc)
Audio CD
(8 cm/12 cm disc)
In addition, this unit can play a CD-Rs or CD-RWs that
contain audio titles, MP3 or JPEG files.
otes
– Depending on the conditions of the recording
equipment or the CD-R/RW disc itself, some
CD-R/RW discs cannot be played on the unit.
– The unit cannot play discs that contain data other
than MP3 and CD-DA data.
– Do not attach any seal or label to either side
(the labeled side or the recorded side) of a disc.
– Do not use irregularly shaped CDs
(e.g., heart-shaped or octagonal). The unit may
malfunction.
otes on DVDs
Some playback operations of D Ds may be intentionally
fixed by software manufacturers. As this unit plays
D Ds according to disc content designed by the software
manufacturer, some playback features of the unit may
not be available or other functions may be added.
Refer also to the instructions supplied with the D Ds.
Some D Ds made for business purposes may not be
played on the unit.
Regional code of this DVD+VCR and DVDs
This D D+ CR is designed and manufactured
for playback of Region 1 encoded D D software.
The region code on the labels of some D D
discs indicate which type of D D+ CR can play those
discs. This unit can play only D D discs labeled 1 or
ALL. If you try to play any other discs, the message
“Check Regional Code” will appear on the T screen.
Some D D discs may not have a region code label even
though their playback is prohibited by area limits.
ote on DTS-encoded CDs
When playing DTS-encoded CDs, excessive noise may
be exhibited from the analog stereo output. To avoid
possible damage to the audio system, turn down the
volume before playing back such discs, adjust the vol-
ume gradually, and keep the volume level low. To enjoy
DTS Digital SurroundTM playback, an external 5.1 chan-
nel Digital SurroundTM decoder system must be con-
nected to the digital output of the unit.
Disc-related Terms
Title (DVD only)
The main film content or accompanying feature content
or music album.
Each title is assigned a title reference number enabling
you to locate it easily.
Chapter (DVD only)
Sections of a picture or a musical piece that are smaller
than titles. A title is composed of one or several chap-
ters. Each chapter is assigned a chapter number to
enable you to locate the chapter you want. Depending
on the disc, chapters may not be recorded.
Track (audio CD only)
Sections of a musical piece on an audio CD. Each track
is assigned a track number, enabling you to locate the
track you want.
Remote Control Battery Installation
Detach the battery cover on the rear of the
remote control, and insert two R03 (size
AAA) batteries with and aligned
correctly.
Caution
Do not mix old and new batteries. Never mix different
types of batteries (standard, alkaline, etc.).
Remote Control Operating Range
Point the remote control at the remote sensor and press
the buttons.
Distance: About 23 ft (7 m) from the front of the
remote sensor
Angle: About 30° in each direction of the front of the
remote sensor
1
AAA
AAA
IMPORTANT NOTE:
SPENT OR DISCHARGED BATTERIES MUST BE
RECYCLED OR DISPOSED OF IN A SAFE MANNER
IN COMPLIANCE WITH ALL APPLICABLE LAWS.
FOR DETAILED INFORMATION, CONTACT YOUR
LOCAL COUNTY SOLID WASTE AUTHORITY.
Manufactured under license from Dolby Laboratories. Dolby
and the double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works. Copyright
1992-1997 Dolby Laboratories. All rights reserved.
DTS and DTS Digital Out are trademarks of Digital Theater
Systems, Inc.

6
Before Use (Continued)
Precautions
Handling the unit
When shipping the unit
The original shipping carton and packing materials
come in handy. For maximum protection, re-pack the
unit as it was originally packaged at the factory.
When setting up the unit
The picture and sound of a nearby T , CR, or radio
may be distorted during playback. In this case, position
the unit away from the T , CR, or radio, or turn off the
unit after removing the disc.
To keep the surface clean
Do not use volatile liquids, such as insecticide spray,
near the unit. Do not leave rubber or plastic products in
contact with the unit for a long period of time. They will
leave marks on the surface.
Cleaning the unit
To clean the cabinet
Use a soft, dry cloth. If the surfaces are extremely dirty,
use a soft cloth lightly moistened with a mild detergent
solution. Do not use strong solvents such as alcohol,
benzine, or thinner, as these might damage the surface
of the unit.
To obtain a clear picture
The D D+ CR is a high-tech, precision device. If the
optical pick-up lens and disc drive parts are dirty or
worn, the picture quality will be poor.
Regular inspection and maintenance are recommended
after every 1,000 hours of use. (This depends on the
operating environment.)
For details, please contact your nearest dealer.
Notes on Discs
Handling discs
Do not touch the playback side of the disc.
Hold the disc by the edges so that fingerprints will not
get on the surface.
Do not stick paper or tape on the disc.
Storing discs
After playing, store the disc in its case.
Do not expose the disc to direct sunlight or sources of
heat, or leave it in a parked car exposed to direct sun-
light, as there may be a considerable temperature
increase inside the car.
Cleaning discs
Fingerprints and dust on the disc can cause poor pic-
ture quality and sound distortion. Before playing, clean
the disc with a clean cloth. Wipe the disc from the cen-
ter out.
Do not use strong solvents such as alcohol, benzine,
thinner, commercially available cleaners, or anti-static
spray intended for older vinyl records.
About Symbols
About the symbol display
“ ” may appear on the T screen during operation.
This icon means the function explained in this owner’s
manual is not available at that moment or with that
specific D D.
About the disc symbols for instructions
A section whose title has one of the following symbols are
applicable only to those discs represented by the symbol.
D Ds.
Audio CDs.
MP3 Discs.
JPEG Discs.
JPEG
MP3
CD
DVD
No
Yes
Selecting the Viewing Source
You must select one of your output sources (D D or
CR) to view on the T screen.
•If you want to view DVD deck output source:
Press D D on the remote or D D/ CR on the front panel
until D D indicator in the display window lights and output
source of D D deck is viewed on the T screen.
•If you want to view VCR deck output source:
Press CR on the remote or D D/ CR on the front panel
until CR indicator in the display window lights and output
source of CR deck is viewed on the T screen.
otes
•If you insert a disc while the D D+ CR is in the CR
mode, the D D+ CR will switch to D D mode
automatically.
•If you insert a cassette tape without an erasure pre-
vention tab intact while the D D+ CR is in the D D
mode, the D D+ CR will switch to CR mode auto-
matically.

7
INTRODUCTION
Front Panel Controls
PAUSE/STEP(XX/CC)
Pause playback of a tape or a disc
in the D D or CR deck
temporarily/press repeatedly for
frame-by-frame playback.
OPEN/CLOSE (ZZ)
Opens or closes the disc tray.
Remote Sensor
Point the D D+ CR remote control here.
Display window
Shows the current status of the D D+ CR.
Disc Tray (DVD deck)
Insert a disc here.
POWER
Switches the D D+ CR ON and OFF.
DVD/VCR (output select)
Select one of your output sources to
view on the T screen between D D
and CR.
REC/ITR (zz)
To record normally or to activate Instant Timer Recording.
CH (vv/VV)
To scan up or down through memorized channels.
STOP (xx)
Stops playback of a disc or tape.
LINE 2 (VIDEO IN/AUDIO IN (Left/Right))
Connect the audio/video output of an
external source (Audio system,
T /Monitor, another CR).
Cassette Compartment (VCR deck)
Insert a video cassette here.
EJECT(ZZ)
Ejects the tape in the CR deck.
COPY
Press to copy a D D in the
D D deck to a HS tape in
the CR deck.
PLAY
To play back a
recorded tape
or disc.
Forward SKIP/SCAN
DVD: Go to NEXT chapter/track. Press and hold for
two seconds for a fast forward search.
VCR: Advances the tape during the STOP mode or for
fast forward picture search.
Reverse SKIP/SCAN
DVD: Go to beginning of current chapter/track or to previous
chapter/track. Press and hold for a fast reverse search.
VCR:
Rewinds the tape during the STOP mode or for fast reverse picture search.

8
Display Window
DVD VCR
REC
PM
COPY
TV
D D+ CR is in CR timer recording mode
or a CR timer recording is programmed.
A cassette is loaded in the CR deck.
CR deck is selected.
D D+ CR is Recording a tape.
Indicates PM time. (AM is not displayed.)
Lights when T mode is active (See page 22.)
A disc is loaded in the D D deck.
(Lights when a disc is loaded in the D D deck
and flashes when no disc is loaded.)
Indicates repeat mode.
D D to CR copy is in progress.
Indicates total playing time, elapsed time, remaining time or
current deck status (Playback, Pause, etc).
D D deck is selected.

9
INTRODUCTION
Remote Control
DVD/VCR select button
Select the output source (D D or CR)
to view on the T screen.
POWER
Switches D D+ CR ON and OFF.
TV/VCR
To view channels selected by the CR
tuner or by the T tuner.
DISPLAY, CLK/CNT
Accesses On-Screen display.
Switches among the clock, tape counter
and tape remaining modes on the display.
b/B/v/V(left/right/up/down)
- Selects an option in the menu
-
v/V: Selects CR channels. Manually
adjusts the tape’s picture onscreen.
SETUP, MENU
Accesses or removes D D Setup menu
and CR menu.
TITLE 
Displays the disc’s Title menu, if
available.
PAUSE/STEP (XX) 
Pause playback or recording
temporarily/press repeatedly for frame-
by-frame playback.
STOP (xx) 
Stops playback.
REC/ITR (zz) 
Records normally or activates Instant
Timer Recording.
0-9 numerical buttons
Selects numbered options in a menu.
AUDIO 
Selects an audio language (D D) or an
audio channel (CD).
SUBTITLE 
Selects a subtitle language.
MARKER 
Marks any point during playback.
SEARCH 
Displays MARKER SEARCH menu.
REPEAT, EZ review 
Repeat chapter, track, title, all.
Replays the specified segment twice.
RANDOM, CM Skip 
- Plays tracks in random order.
- Fast forwards picture search through
30 seconds of recording.
A-B, SP/SLP 
- Repeats sequence.
- Selects recording speed
OPEN/CLOSE, EJECT (ZZ)
- Opens and closes the disc tray.
- Ejects the tape in the CR deck.
SELECT/ENTER
- Acknowledges menu selection.
- Displays functions on the T screen.
INPUT
To select the CR deck’s source
(Tuner, LINE 1, or LINE 2).
DISC MENU
Accesses menu on a D D disc.
RETURN
Removes the Setup menu.
FORWARD (>>)
D D: Search forward*/go to next
chapter or track.
CR: Advances the tape in STOP mode
or for fast forward picture search.
* Press and hold button for about two
seconds.
PLAY (HH)
Starts playback.
BACKWARD (..)
D D: Search backward*/go to beginning
of current chapter or track or go to previ-
ous chapter or track.
CR: Rewinds the tape in STOP mode
or for fast reverse picture search.
* Press and hold button for about two
seconds.
PROGRAM
Accesses or removes Program menu.
CLEAR
Removes a track number on the
program menu or a mark on the
MARKER SEARCH menu.
ANGLE
Selects a D D camera angle if
available.
ZOOM
Enlarges D D video image.
ote
This remote control use the same buttons for CR and D D
functions (ex. PLAY).
To use the CR, first press the CR button.
To use the D D, first press the D D button.

10
Connections Panel
Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause permanent
damage to the unit.
VCR IN LINE 1
(VIDEO IN/AUDIO IN (Left/Right))
Connect the audio/video output of an external
source (Audio system, T /Monitor,
another CR).
ANTENNA INPUT
Connect the HF/UHF/CAT antenna to this terminal.
DVD/VCR OUT (VIDEO/AUDIO (Left/Right))
Connect to a T with video and audio inputs.
AUDIO OUT (Left/Right) (DVD OUT)
Connect to a T , amplifier, receiver, or stereo system.
DIGITAL AUDIO OUT (COAXIAL) (DVD OUT)
Connect to digital (coaxial) audio equipment.
AC Power Cord
Plug into the power source.
S-VIDEO OUT (DVD OUT)
Connect to a S- ideo Input on T .
COMPONENT VIDEO OUT
(Y Pb Pr) (DVD OUT) Connect to a T with Y Pb Pr inputs.
RF. OUT(DVD/VCR OUT)
Connect to a T with RF coaxial inputs.
