Good Will Instrument GPT-9600 series User manual

Universal Input Voltage Range
Additionally, the GPT-9600 seriesprovides the universal input voltage range for operating equipment
The GPT-9600 Series, carrying a high-efficiency PWM amplifier design, generates output source up to 98%
efficiency. This greatly reduces the energy loss from heat dissipation and therefore lowers the temperature
within the cabinet. The suppression of temperature rise during heavy-duty operation of the tester significantly
increases tester’s reliability and service lifetime.
FriendlyUserInterface
Large LCD, High Intensity Indicators and Function Keys
The 240 x 48 display clearly shows the applied voltage, test parameters, test conditions, measurement value
and result on the screen at the same time. The real-time status update on the LCD display accompanied by
the multi-colored LED status indicators on the front panel allow operators to have a full control of the test
process to perform precession test and avoid unnecessary operation risks at the same time. The status
indicator above the high voltage output terminal will automatically flash when an output is in place. In addition,
the function keys arranged below the LCD display provide convenient operation that test functions can be
easily changed by a single pressing.
SimplyAUTOMode
Simply AUTO Mode
For models that include the Insulation Resistance test function; there is a simple AUTO mode (W-I or I-W)
which allows the operator to run two test functions in sequence. The first test function can either be a
withstanding voltage test followed by an insulation resistance test or vice versa, – thus eliminating the need to
push the START button twice to run two separate tests.
Support the Universal input voltage

GPT9600_NPI_Final Page 3 of 9
countries with different electrical power standards. With the GPT-9600 series, the hustle of switching or
selecting input voltage range can be left behind. Furthermore, 50Hz or 60Hz can be selected to provide a
stable and appropriate test voltage without relying on the electrical environment conditions of input power so
as to meet the test requirements.
Key Features of the GPT-9600 Series
z100VA AC Test Capacity
z240x48 Ice Blue Dot Matrix LCD
zAuto W-I and I-W Mode
zTrue RMS Current Measurement
zZero Crossing Turn-on Operation
zSafety INTERLOCK Function
zPWM Switching Amplifier to Enhance the Power Efficiency and Reliable Testing
zAutomatically Switching Input Source for Universal Input Voltage
zInterface : Remote Terminal, Signal I/O
High Intensity LED Indictors to
show the status of safety tester.
High Voltage Output
f
or
AC 5kV or DC 6kV
Remote Terminal provides
“start” and “stop” control by
an external controller.
240 x 48 Matrix LCD display, supports a
grater view of setting parameters and
testing voltage /or results.
F
unction keys, corresponding to the
f
unctions display on the screen.
Reserve
p
or
t
f
or calibration use only
The Signal I/O port
p
rovides remotely
“start” and “stop” function and monitor
the test status of the tester.
Automatically switching input source
f
or worl
d
–wide input voltage
High
Voltage Output
Return terminal

ApplicationsandTargetMarkets
Production and Routine Testing of Electrical Products
¾Information Tech. Equipment
¾Consumer Products
¾R.L.C
component
¾Other tests with AC/DC withstanding testing lower than 20mAac or 5mAdc cut-off current
z240 x 48 matrix LCD display and high intensity status indicators for clear and easy observation.
zVarious safe considerations, zero crossing turn-on operation / fast cutoff / protective Interlock
key/ discharge after testing, to ensure the safety of operator.
zPWM amplifier design to ensure the precision tests of the DUT and the reliability and service
lifetime of tester.
zAUTO mode test procedure for W-I or I-W.
zVarious control methods, manual / remote terminal / signal I/O, to fit with the actual requirement
of workplace environment.
zAutomatically switching input source for universal input voltage to prevent incorrect input source
from damaging the instrument.
Product Outlook of the GPT-9600 Series
Front Rear

GPT9600_NPI_Final Page 6 of 9
Orderinginformation:
GPT-9603 AC 100VA AC/DC Withstanding Voltage/Insulation Resistance Tester
GPT-9612 AC 100VA AC Withstanding Voltage/Insulation Resistance Tester
GPT-9602 AC 100VA AC/DC Withstanding Voltage Tester
GPT-9601 AC 100VA AC Withstanding Voltage Tester
Included Accessories
Quick Start Guide x 1,
CD x1(completed user manual)
Power cord x 1,
Interlock key x 1,
Remote terminal male plug x 1,
Test lead GHT-114 x 1
GHT-114
Optional Accessories
GHT-113 High Voltage Test Pistol
GHT-205 High Voltage Test Probe
GRA-417 RACK Adapter Panel (19”, 4U)
Dimensions of the GPT-9600 Series
AC/ DC Withstandi ng Vol tage /
Insulation Resistance TesterGPT-9603
ESC FIELD
5.0kVAC MAX.
6.0kVD C MAX.
RETURN
322.0
134.0
148.2
328.9
385.0
EDIT SAVE UTILITY

Selection Guide of the GPT-9600 Series
NEW NEW NEW NEW
Output Capacity 100VA
Model GPT-9601 GPT-9602 GPT-9612 GPT-9603
AC Withstanding (ACW) 5kVac
20mA
5kVac
20mA
5kVac
20mA
5kVac
20mA
DC Withstanding (DCW) ------ 6kVdc
6mA
------ 6kVdc
6mA
Insulation Resistance (IR) ------ ------ 50/100/250/
500/1000Vdc
2000MΩ
50/100/250/
500/1000Vdc
2000MΩ
Ground Bond (GB) ------ ------ ------ ------
ARC Detection YES YES YES YES
Ramp-Up Function 0.1s Fixed 0.1s Fixed 0.1s Fixed 0.1s Fixed
Memory Storage for Setting 1 2 2 3
AUTO Mode ------ ------ AC-IR or IR-AC AC-IR or IR-AC
DC-IR or IR-DC
Safety Interlock YES YES YES YES
Remote Terminal YES YES YES YES
Signal I/O YES YES YES YES
USB/RS232C Interface ------ ------ ------ ------
GPIB Interface ------ ------ ------ ------
Display, LCD 240 x 48 240 x 48 240 x 48 240 x 48
CE Compliance YES YES YES YES
ServicePolicy
1) 2-Year warranty
2) Service Support
The service instructions in the Service Manual will help distributors repair defective units promptly.
Should a board replacement be necessary to fix a defective unit, a board swapping service is provided
by Good Will Instrument to facilitate the repairs done at a distribution site.
3) GW Instek continues to provide the after sales support through its website. The most updated version
of the service manual and Marcom material for the GPT-9600 series will be posted on the distributor
zone of GW Instek Website at http://www.gwinstek.com.

The GPT-9600 Series Specifications
AC Withstanding Voltage [for all models]
Output-Voltage Range 0.10kV~ 5.00kV
Output-Voltage Resolution 10V
Maximum Rated Load 100 VA (5kV/20mA)
Maximum Rated Current 20mA (0.5kV＜V5kV)≦, 5mA (0.1kV V≦≦0.5kV)
Output-Voltage Waveform Sine wave
Output-Voltage Frequency 50 Hz / 60 Hz selectable
Voltage Regulation ±(1.5% + 2 counts) [full load ->no load]
Voltmeter Accuracy ±(1.5% of reading + 2 counts)
Current Measurement Range [1] 0.01mA~20.0mA
Current Best Resolution 0.01mA(0.01mA~9.99mA)
0.1mA(10.0mA~20.0mA)
Current Measurement Accuracy ± (2.0% of rdg + 5 counts) when HI SET<1.00mA
± (2.0% of rdg + 3 counts) when HI SET≥1.00mA
Window Comparator Method Yes
ARC Detect Yes
RAMP (Ramp-Up Time) 0.1s Fixed
TIMER (Test Time) OFF, 1s~180s
GND ON
[ 1 ] Output Limitation in AC Withstanding Voltage Testing as below.
Upper Current Pause Output Time
15mA≦I≦20mA At least as long as the output time Approx. 180 seconds
AC 0.01mA≦I<15mA Not necessary Continuous output possible
DC Withstanding Voltage [for GPT-9602/9603]
Output-Voltage Range 0.10kV~ 6.00kV
Output-Voltage Resolution 10V
Maximum Rated Load 25W (5kV/5mA)
Maximum Rated Current 6mA (0.5kV＜V6kV)≦, 2mA (0.1kV V 0.5kV)≦≦
Voltage Regulation ±(1.5% + 2 counts) [full load ->no load]
Voltmeter Accuracy ±(1.5% of reading + 2 counts)
Current Measurement Range [1] 0.01mA~6.00mA
Current Best Resolution 0.01mA(0.01mA~6.00mA)
Current Measurement Accuracy ± (2.0% of rdg + 5 counts) when HI SET<1.00mA
± (2.0% of rdg + 3 counts) when HI SET≥1.00mA
Window Comparator Method Yes
ARC Detect Yes
RAMP (Ramp-Up Time) 0.1s Fixed
TIMER (Test Time) OFF, 1s~180s
GND ON
[ 1 ] Output Limitation in DC Withstanding Voltage Testing as below.
Upper Current Pause Output Time
DC 0.01mA≦I≦6.00mA Not necessary Continuous output possible

Insulation Resistance [for GPT-9612/9603]
Output Voltage 50V/100V/250V/500V/1000V
Output-Voltage Accuracy ±(3.0% of setting + 1 count) with no load
Voltage Regulation ±(1.5% + 2 counts) [full load ->no load]
Voltmeter Accuracy ±(1.5% of reading + 2 counts)
Resistance Measurement Range 1MΩ~ 2000MΩ
Test Voltage Measure Range Accuracy
50V / 100V / 250V 1~50MΩ
51~2000MΩ
±(5% of reading + 2MΩ)
±(10% of reading + 2MΩ)
500V / 1000V 1~500MΩ
501~2000MΩ
±(5% of reading + 2MΩ)
±(10% of reading + 2MΩ)
Output Impedance 600kΩ
Window Comparator Method Yes
RAMP (Ramp-Up Time) 0.1s Fixed
TIMER (Test Time) 1s~180s
GND OFF
General
Note
The specifications apply when the GPT-9600 series are powered on for at least 30
minutes at 15°C~35°C.
Display 240 x 48 Ice Blue dot matrix LCD
AUTO Mode* AC-IR / IR-AC / DC-IR / IR-DC
Interface Remote, Signal I/O
Power Source AC 100-120 V / 220-240 V ±10%
Power Line Frequency 50/60Hz
Power Consumption Max 400VA
Dimensions 322(W) x 148(H) x 385(D) mm
Weight Approx. 9kg max.
* The available Auto mode depends on the selected model
Environment
Note
To operate over the specific temperature range may cause damage to the circuit.
And, do not use in a place where strong magnetic or electric field exists.
Warranty Environment 15°C to 35°C, Humidity 70% (no condensation)≦
Operation Environment 0°C to 40°C, Humidity 70% (no condensation)≦
Storage Environment -10°C to 70°C, Humidity 85% (no condensation)≦
Installation Location Indoors at an amplitude of up to 2000m
