Goodman GMP Series Manual

Goodman Manufacturing Company, LP
2550 North Loop West, Suite 400
Houston, Texas 77092
IO-137H www.goodmanmfg.com 12/01
INSTALLATION & OPERATING
INSTRUCTIONS
for GMP & GMPE
POWER VENTED MULTI-POSITION
GAS FURNACE
(CATEGORY I)
WARNING
IF THIS FURNACE IS INSTALLED IN AN ENCLOSED AREA, SUCH AS A GARAGE OR UTILITY
ROOM, WITH ANY OTHER CARBON MONOXIDE PRODUCING DEVICE (i.e., AUTOMOBILE,
SPACE HEATER, ETC.) INSURE THAT THE ENCLOSED AREA IS PROPERLY VENTILATED.
WARNING
CARBON MONOXIDE (REFERRED TO AS CO) CAN CAUSE PERSONAL INJURY OR DEATH
WARNING
THIS FURNACE IS DESIGN CERTIFIED FOR INSTALLATION IN BUILDINGS CONSTRUCTED
ON SITE ONLY.

IO137 2
REPLACEMENT PARTS
Replacement parts for this appliance is available through your contractor or local distributor. For
the location of your nearest distributor consult the white business pages, the yellow page section
of the local telephone book or contact;
SERVICE PARTS DEPARTMENT
GOODMAN MANUFACTURING CO., LP
1501 SEAMIST
HOUSTON, TEXAS 77008
(713) 861 - 2500
The major parts groups are as follows;
BLOWER ASSEMBLY
Motor
Blower housing
Blower wheel
Misc. sheetmetal items
Capacitor
HEAT EXCHANGER
Heat exchanger sections
Innerfront
Secondary coil
ELECTRICAL CONTROLS
Control board
Auxiliary / main limit switch
Roll-out switch
Transformer
Door interlock switch
Air pressure switch
Induced draft blower
BURNER ASSEMBLY
Burners
Manifold
Orifices
Gas valve
Ignitor
Flame sensor
MISCELLANEOUS
Wrapper
Access doors
Chimney
Gaskets and seals
Wiring assemblies
To effectively process the parts requirement, the distributor / contractor will need the entire model
number and serial number found on the series and rating plate located inside the blower compart-
ment.

O137 3
INDEX
WARNINGS & GENERAL INFORMATION .............................................................................. 4, 5
CLEARANCES, LOCATION ..................................................................................................... 5, 6
VENTING...................................................................................................................................... 6
GAS PIPING TABLE................................................................................................................. 7, 8
CIRCULATING & RETURN AIR ............................................................................................ 8 - 10
ELECTRICAL SUPPLY, CONTROL VOLTAGE ................................................................... 10, 11
RATING THE FURNACE...................................................................................................... 11, 12
TIMING THE GAS METER......................................................................................................... 13
SAFETY CONTROLS........................................................................................................... 14, 15
CIRCULATING AIR FILTERS..................................................................................................... 15
SERVICE INSTRUCTIONS ........................................................................................................ 16
SEQUENCE OF OPERATION ................................................................................................... 17
REMOVING AN EXISTING APPLIANCE ................................................................................... 18
INSPECTING AND CLEANING THE HEAT EXCHANGER.................................................. 18, 19
COMBUSTION AIR .............................................................................................................. 19, 20
ILLUSTRATIONS ................................................................................................................ 21 - 23
BLOWER DELAY, HUMIDIFIER & EAC CONTROL .................................................................. 24
WIRING DIAGRAMS ............................................................................................................ 25, 26
LIGHTING INSTRUCTIONS....................................................................................................... 27
VENT TABLES .................................................................................................................... 28 - 45
THIS FURNACE CONTAINS ELECTRONIC COMPONENTS, WHICH REQUIRE A DEFINITE
GROUND. PROVISIONS ARE MADE FOR CONNECTION OF THE GROUND. IF THIS
PRODUCT IS NOT PERMANENTLY AND POSITIVELY GROUNDED NUMEROUS SERVICE
CALLS MAY RESULT. A DEDICATED GROUND FROM THE MAIN POWER SUPPLY OR AN
EARTH GROUND MUST BE PROVIDED.

IO137 4
WARNING
WHILE CARBON MONOXIDE DETECTORS DO PROVIDE ADDITIONAL PROTECTION,
CURRENT LIMITATIONS TO THEIR EFFECTIVENESS REQUIRES THAT YOU OTHERWISE
CONTINUE TO FOLLOW APPROPRIATE INSTRUCTIONS LOCATED IN THE “INSTALLATION &
OPERATING INSTRUCTIONS” AND “USERS INFORMATION” MANUALS RELATING TO
PROTECTING PERSONS FROM THE RISKS OF CARBON MONOXIDE. REVIEW EACH CO
DETECTOR MANUFACTURERS’ EXPLANATION OF THEIR UNIT’S CAPABILITIES AND
FOLLOW THOSE INSTALLATION AND OPERATING MANUAL WHEN INSTALLING AND
OPERATING THESE UNITS.
WARNING
THE CIRCULATING AIR DUCTS MUST BE COMPLETELY AND POSITIVELY SEALED TO
PREVENT COMBUSTION PRODUCTS, INCLUDING CARBON MONOXIDE, FROM ENTERING
THE AIR STREAM.
WARNING
TO ENSURE PROPER INSTALLATION AND OPERATION OF THIS PRODUCT, COMPLETELY
READ AND UNDERSTAND THESE INSTRUCTIONS PRIOR TO ATTEMPTING TO ASSEMBLE,
INSTALL, MAINTAIN, OR REPAIR.
IF THESE INSTRUCTIONS ARE NOT FOLLOWED PRECISELY THERE IS A POTENTIAL OF
CARBON MONOXIDE POISONING, WHICH CAN RESULT IN SERIOUS ILLNESS OR DEATH.
WARNING
THIS FURNACE WAS EQUIPPED AT THE FACTORY FOR USE WITH NATURAL GAS ONLY.
LIQUID PETROLEUM (LP) CONVERSION, IF REQUIRED, MUST BE PERFORMED BY A
QUALIFIED TECHNICIAN FAMILIAR WITH PERFORMING THIS TYPE OF CONVERSION. IF LP
CONVERSION IS REQUIRED, ALL INSTRUCTIONS INCLUDED WITH THE FACTORY
AUTHORIZED KIT MUST BE FOLLOWED. THE ONLY KIT THAT MUST BE USED FOR THIS
CONVERSION IS THE FACTORY AUTHORIZED LPM-01 (GMPH SERIES) OR LPM-03 (GMPE
SERIES). FAILURE TO FOLLOW THOSE INSTRUCTIONS EXPLICITLY MAY CAUSE FIRE,
EXPLOSION, PERSONAL INJURY OR PROPERTY DAMAGE.
WARNING
IF PROHIBITED BY LOCAL CODE DO NOT INSTALL A LIQUID PETROLEUM GAS BURNING
APPLIANCE IN A PIT, BASEMENT OR SIMILAR LOCATION WHERE LP, A HEAVIER THAN AIR
GAS, CAN COLLECT IN LOW AREAS AND MAY NOT DISPERSE NATURALLY. APPLIANCES
SO FUELED SHALL NOT BE INSTALLED IN AN ABOVE GRADE UNDER FLOOR SPACE OR
BASEMENT UNLESS SUCH LOCATION IS PROVIDED WITH APPROVED MEANS FOR
REMOVAL OF UNBURNED GAS.
GENERAL INFORMATION
The GMP and GMPE series of gas furnaces may be installed in the upflow, horizontal or downflow
configuration. Unless otherwise noted, the instructions contained within are valid for all of these
configurations.

IO137 5
These Installation and Operating Instructions are intended for use by fully qualified installation
technicians. Some localities require the installer/servicer to be licensed. If in doubt, check with local
authorities.
INSTALLATION: In the USA this furnace must be installed according to the latest edition of the
ANSI Z223.1 booklet entitled “National Fuel Gas Code” (NFPA 54), and the requirements or codes
of the local utility or other authority having jurisdiction. In Canada this furnace must be installed ac-
cording to the current CAN/CGA-B149.1 & 2 Gas Installation Codes, local plumbing or waste water
codes and other applicable codes.
Additional helpful publications available from the NFPA are, NFPA 90A - Installation of Air Condi-
tioning and Ventilating System, and NFPA 90B - Warm Air Heating and Air Conditioning System.
These publications are available from:
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
ANNUAL inspection of the furnace and its vent system is strongly recommended. It is the installer's
responsibility to inform the user of this importance.
These series of furnaces meet the California NOX emission standards and California seasonal effi-
ciency standards.
LOCATION
DO NOT install this furnace in a mobile home. This furnace is designed only for installation in build-
ings constructed on site and connected to ductwork. When installed in a utility room or closet, the
door opening must be wide enough to allow the largest part of the furnace to enter, or to permit the
replacement of another appliance, such as a water heater.
DO NOT install outdoors. This furnace is designed to be installed indoors only. This furnace should
be installed in such a manner so that it is protected from water. If any components should become
submerged, replace those parts before returning the furnace to operation.
DO NOT use as a construction heater.
DO NOT install in a room used or designed to be used as a bedroom, bathroom or storage closet,
or in any enclosed space with access only through such a room or space.
MINIMUM CLEARANCES TO COMBUSTIBLE SURFACES
Unobstructed front clearance of 24” for servicing is recommended.
VENT SIDES FRONT BACK TOP
B1-VENT SINGLE (PLENUM)
1” 6” 1” 3” 0” 1”
Top clearance for horizontal configuration - 1”.
Line contact to framing is permitted when installed in the horizontal configuration. Line contact is
defined as the portion of the cabinet that is formed by the intersection of the top and side.

IO137 6
ACCESSIBILITY CLEARANCE, WHERE GREATER, SHOULD TAKE PRECEDENCE OVER
MINIMUM FIRE PROTECTION CLEARANCE.
A gas fired furnace for installation in a residential garage must be installed so that the ignition
source and burners are located not less than eighteen inches (18”) above the floor and is protected
or located to prevent physical damage by vehicles.
A gas furnace must not be installed directly on carpeting, tile, or other combustible materials other
than wood flooring.
WARNING
COMBUSTIBLE MATERIAL MUST NOT BE PLACED ON OR AGAINST THE FURNACE JACKET.
THE AREA AROUND THE FURNACE MUST BE KEPT CLEAR AND FREE OF ALL
COMBUSTIBLE MATERIAL INCLUDING GASOLINE AND OTHER FLAMMABLE VAPORS AND
LIQUIDS. THE FURNACE AREA MUST NOT BE USED AS A BROOM CLOSET OR FOR ANY
OTHER STORAGE PURPOSE.
VENTING
See the illustrations and vent tables at the end of this manual for venting procedures.
The venting must be in accordance with the GAMA venting tables. The minimum vertical vent
length allowed is five feet (5’).
ANNUAL inspection of the furnace and its vent system is strongly recommended. Visually check
the vent for corrosion or separation at the joints and seams. It is the contractor’s responsibility to
inform the user of this importance.
All venting shall be in accordance with Part 7, Venting of Equipment, of the National Fuel Gas
Code, ANSI Z223.1, or applicable local building and/or air conditioning codes.
PROPER INSTALLATION OF THE VENTING SYSTEM IS CRITICAL FOR SAFE OPERATION OF
THIS APPLIANCE. CAREFULLY READ AND UNDERSTAND THE INSTRUCTIONS IN THIS
SECTION.
CAUTION
The products of combustion shall be discharged to the outdoors and are intended to be vented ver-
tically.
This appliance is intended to be connected to “B” type vent material. Single wall pipe is to be used
as a vent connector only.
This appliance SHALL NOT be connected to a vent servicing a solid fuel fireplace.
This appliance SHALL NOT be connected to a flue serving a factory built fireplace.
This appliance SHALL NOT be connected to an unlined masonry chimney.
THE USE OF NON-METALLIC VENT MATERIAL IS PROHIBITED.
This appliance CAN NOT BE HORIZONTALLY VENTED unless using an optional power venter
such as the SVB-80 (-5), if permitted by local code.
CONSULT LOCAL CODES FOR SPECIAL ADDITIONAL REQUIREMENTS.

IO137 7
GAS PIPING & GAS PIPE CAPACITY TABLE
Check the rating plate to make certain that the unit is equipped to burn the type of gas supplied.
Care should be taken after the installation of this appliance that the gas control valve is not sub-
jected to high gas supply line pressure.
In making connections, avoid strains as they may cause noise and damage the controls. Always
use a back-up wrench when tightening the gas supply pipe to the gas control valve.
The furnace and its individual shut-off must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5kPa).
The furnace must be isolated from the gas supply piping system by closing its individual manual
shut-off valve during any pressure testing of the gas supply piping system at pressures equal to or
less than 1/2 psig (3.5 kPa).
Check for leaks in the gas supply using soap bubbles or other approved methods.
WARNING
NEVER USE AN OPEN FLAME TO CHECK FOR GAS LEAKS. THIS PRACTICE MAY CAUSE A
FIRE, EXPLOSION, BODILY HARM INCLUDING DEATH OR PROPERTY DAMAGE.
Pipe joint compound must be resistant to the affects of LP gas.
A union and listed manual shutoff must be installed exterior to the furnace cabinet so the control
assembly may be easily removed.
A 1/8” NPT plug on the supply pipe at the manual valve for the purpose of making pressure meas-
urement must also be installed. The valve should be readily accessible for turning on or off. A
capped sediment trap, sometimes referred to as a drip leg, should be installed in the gas supply
pipe as close to the furnace as possible. This trap must incorporate a change of direction of the
gas flow.
Refer to local codes or the below mentioned publications for proper location of the manual shutoff
and sediment trap lengths.
All gas piping must conform to local codes, or in the absence of local codes, to the National Fuel
Gas Code ANSI Z223.1 and / or CAN/CGA B149 Installation Codes.
The gas pipe must be sized to eliminate undue pressure drop. See pipe capacity table or consult
your local utility.
NOTE: Copper tubing must not be used for natural gas installations where more than 3 grains of
hydrogen sulfide per 100 standard cubic feet of gas is present.
For installations in the Commonwealth of Massachusetts see Fuel Gas and Plumbing Code 248
CMR: Appendix C.
Capacity of gas pipe of different diameters and length in ft3/hr. with a pressure drop of 0.3” W.C.
and a specific gravity of 0.60 (natural gas).
PIPE LENGTH OF PIPE IN FEET

IO137 8
SIZE*
10 20 30 40 50 60 70 80
1/2 132 92 73 63 56 50 46 43
3/4 278 190 152 130 115 105 96 90
1 520 350 285 245 215 195 180 170
1 1/4 1050 730 590 500 440 400 370 350
1 1/2 1600 1100 890 760 670 610 560 530
* Nominal size of Iron Pipe in inches.
After the length of pipe has been determined, select the pipe size that will provide the minimum cu-
bic feet per hour of gas flow for the required input of the appliance. In the case where more than
one appliance utilizes the same supply pipe be sure to consider the sum of all appliances. The cu-
bic feet required for the appliances should be determined using the following formula;
Cubic feet per hour of gas required = Gas input of appliance (Btu/hr) / heating value of gas(Btu/hr)
The gas input of the appliance is marked on the specification plate. The heating value of the gas
may be determined by contacting the gas utility or gas supplier.
CAUTION
If the local utility permits the use of a listed flexible gas connector, ALWAYS USE A NEW
FLEXIBLE CONNECTOR. DO NOT USE A FLEXIBLE GAS CONNECTOR WHICH HAS
SERVICED ANOTHER APPLIANCE. AFTER A PERIOD OF TIME THESE LINES MAY BECOME
BRITTLE AND WITH THE DISCONNECTION AND RECONNECTION CAN DEVELOP LEAKS.
CIRCULATING AIR SUPPLY AND RETURN AIR
WARNING
NEVER LAY THIS FURNACE ON IT’S FRONT OR REAR
The circulating air supply may be taken from; 1) outside the building, 2) return ducts from several
rooms, 3) central return, 4) any combination of the above.
When a cooling coil is not installed it is recommended that the supply duct have an access panel
so the heat exchanger can be viewed. This panel shall be of sufficient size to permit the entrance
of a light or probe to assist in the observation of the heat exchanger integrity or sampling the air
stream. It should sealed to prevent air leakage during normal operation.
Return air from one dwelling unit shall not be discharged into another dwelling unit.
CAUTION
DO NOT take return air from bathrooms, kitchens, furnace rooms, garages, utility or laundry rooms
or cold areas. If outside air is utilized it should not be taken from within 10 feet of an appliance vent
outlet, a vent opening or a plumbing drainage system or the discharge from an exhaust system
unless the outlet is three (3) feet above the outside air inlet. DO NOT take return air from areas
where it can pick-up objectionable odors, fumes, or flammable vapors.

IO137 9
Note: When a combination of outdoor and indoor air is used the system should be designed and
adjusted so that the temperature reaching the appliance will not drop below 50oF during heating
operation. When this type of system is used the volume of air must not be reduced.
Plenum chambers and air ducts must be installed in accordance with the Standard for the Installa-
tion of Air Conditioning and Ventilating Systems, NFPA # 90A, or the Standard for the Installation
of Warm Air Heating and Air Conditioning Systems, NFPA # 90B.
If installed in parallel with a cooling unit, the damper or other means used to control the flow of air
must be adequate to prevent chilled air from entering the furnace. If manually operated, must be
equipped with means to prevent operation of the other unit unless the damper is in the full heat or
cool position.
NOTE: UPON INITIAL START-UP SOME SMOKE OR AN ODOR MAY BE PRESENT. THIS IS
NORMAL AND SHOULD DISAPPEAR IN A SHORT AMOUNT OF TIME. IT IS RECOMMENDED
THAT THE DOORS AND WINDOWS BE OPENED UPON INITIAL START-UP TO VENT THE
BUILDING OF THIS NON TOXIC, NON STAINING SMOKE.
CAUTION
One of the most common causes of problems, including premature heat exchanger failure, in
forced air heating systems is insufficient return air.
The return air duct system to the furnace should be approximately equal to or greater than the area
of the warm air discharge. Embosses are provided on the sides of the furnace to act as guidelines
for this purpose.
Consult local codes for specific requirements.
The blower speed should be adjusted to maintain the temperature rise range shown on the rating
plate.
The total static pressure should not exceed 0.50” W.C.
WARNING
NEVER ALLOW THE PRODUCTS OF COMBUSTION, INCLUDING CARBON MONOXIDE, TO
ENTER THE RETURN DUCTWORK OR CIRCULATING AIR SUPPLY. ALL CIRCULATING AIR
DUCTS MUST BE ADEQUATELY SECURED TO THE FURNACE AND COMPLETELY SEALED
AIRTIGHT USING APPROVED CONNECTIONS. THE VENT AND COMBUSTION AIR SUPPLY
PIPES MUST BE PROPERLY INSTALLED AND SUPPORTED TO PREVENT LEAKAGE AS
NOTED ELSEWHERE IN THESE INSTRUCTIONS. WHEN A FURNACE IS MOUNTED ON A
PLATFORM IT MUST BE SEALED AIRTIGHT BETWEEN THE FURNACE AND RETURN
DUCTWORK. THE FLOOR OR PLATFORM MUST PROVIDE SOUND PHYSICAL SUPPORT
FOR THE FURNACE WITHOUT CRACKING, GAPS, SAGGING ETC. AROUND THE BASE AS
TO PROVIDE A SEAL BETWEEN THE SUPPORT AND THE BASE. THE BASE OR PLATFORM
MUST BE SEALED AIRTIGHT TO THE FLOOR.
FAILURE TO PREVENT PRODUCTS OF COMBUSTION FROM ENTERING THE RETURN AIR
SUPPLY MAY CAUSE SEVERE ILLNESS INCLUDING CARBON MONOXIDE POISONING OR
DEATH.
Install the return air to terminate through the base under the furnace. For installations where return
air ducts cannot be run under the floor, the return air supply may be taken from the side(s). The
solid bottom supplied on the furnace must remain in place.
When installed in the downflow position, on combustible material, a special sub-base must be in-
stalled for a heating only application. If a cooling coil is installed under the furnace the sub-base is
not necessary.

IO137 10
WHERE THE MAXIMUM REQUIRED AIR FLOW IS 1800 CFM OR GREATER THE BOTTOM OR
BOTH SIDES MUST BE UTILIZED FOR RETURN AIR SUPPLY. NEVER USE THE REAR OF
THE FURNACE FOR THE RETURN AIR CONNECTION.
WARNING
A SOLID METAL BASEPLATE IS SUPPLIED ON THIS FURNACE. THIS BASEPLATE MUST BE
IN PLACE WHEN THE FURNACE IS INSTALLED WITH SIDE(S) RETURN AIR DUCTS. FAILURE
TO DO SO MAY PERMIT COMBUSTION PRODUCTS, INCLUDING CARBON MONOXIDE, TO
ENTER THE LIVING SPACE. THIS MAY CREATE POTENTIALLY HAZARDOUS CONDITIONS
SUCH AS CARBON MONOXIDE POISONING OR DEATH.
THE FULL SIZE RETURN AIR DUCT OPENINGS MUST BE UTILIZED. EMBOSSES ARE
PROVIDED FOR THIS PURPOSE.
ELECTRICAL SUPPLY CONNECTIONS
The electrical requirements are listed on the series and rating plate on the furnace. A separate
supply line with a current overload device and a manual switch, where required, must be installed.
Type “T” wire or equivalent with a minimum rating of 95oF (35oC) temperature rise must be run di-
rectly from the main power supply to the junction box in the furnace. Use wire which employs cop-
per conductors only.
Installation of the electrical supply should be according to local codes. In the absence of local
codes refer to the National Electrical Code ANSI/NFPA No. 70 (latest edition), which can be ob-
tained from the National Fire Protection Association, Batterymarch Park, Quincy, MA 02269. In
Canada refer to the latest edition of the Canadian Electrical Code C22.1 Part I.
WARNING
THE GAS SUPPLY PIPE MUST NEVER USED FOR GROUNDING PURPOSES.
CONTROL VOLTAGE CONNECTIONS
THERMOSTAT INSTALLATION
Install the thermostat according to the instructions accompanying the thermostat. Run the thermo-
stat wires into the control compartment in the furnace. Connect the thermostat wiring as shown on
the wiring diagram. The thermostat wiring should be a minimum of 18 gauge. Adhere to recom-
mended color code to facilitate future troubleshooting.
The thermostat should be located near the return air grille or opening. It should be approximately 5
feet from the floor level.
Never locate the thermostat where it will be influenced by heat generated from hot water pipes,
lamps, televisions, direct sunlight, supply air registers, etc.
Interconnecting wiring must be secured and protected from damage or disconnection. The use of
solderless connectors or equivalent is recommended.
The low voltage control wiring exiting the furnace is labeled “thermostat wiring."
SETTING THE HEAT ANTICIPATOR

O137 11
The following method should be used in measuring the amp draw of the control circuit to assure
proper adjustment of the thermostat heat anticipator
RATING THE FURNACE
The furnace is supplied with orifices sized for natural gas at altitudes up to 2,000 feet using a
heating value of approximately 1,000 Btu/hr, and should not normally require change. If for use at
altitudes in excess of 2,000 feet refer to the instructions included in the factory authorized high alti-
tude kit (HA-02). Should this appliance be converted to LP, refer to the instructions included in the
factory authorized LP conversion kit LPM-01 (LPM-03 for GMPE).
It is important to check and adjust the input rate of the furnace to prevent an overfiring situation.
Overfiring can cause premature heat exchanger failure. The input is controlled by the supply pres-
sure, orifice size, manifold pressure and heating (calorific) value of the gas.
The supply pressure must be measured with this and all other gas burning appliances in opera-
tion. The supply pressure must be adjusted to the pressure range stated on the series and rating
plate. Applications for altitudes in excess of 2,000 feet usually require an orifice change. The ori-
fices must be selected using the table below. The furnace derate is 4% for each 1,000 feet above
sea level. This table is based upon a heating value of approximately 1,000 Btu/ft3
ALTITUDE NAT. GAS ORIFICE SIZE
0 - 2,000 #42 (#43 on -050)
3,000 #43 (# 44 on -050)
4,000 #44 (#45 on -050)
5,000 #45 (#46 on -050)
6,000 #45 (#47 0n -050)
7,000 #45 (#48 0n -050)
The input to the furnace must be checked AFTER reorificing.
For altitudes above 7,000 feet refer to appropriate section of the National Fuel Gas Code, ANSI
Z223.1. To calculate the input of the furnace for installations in altitudes over 2,000 feet, use the
following formula:
CORRECTED INPUT = SERIES & RATING PLATE INPUT - (ALTITUDE X .04) X (SERIES &
RATING PLATE INPUT / 1000)

O137 12
EXAMPLE:
Corrected input for a 100,000 Btu/hr. appliance installed at an altitude of 6.000 ft.
utilizing natural gas with a heating value of 1,000 Btu/ft3is determined by-
Corrected Input = 100,000 - (6,000 X .04) X (100,000 /
1,000)
Corrected Input = 100,000 - (240 X 100)
Corrected Input = 100,000 - 24,000
Corrected Input = 76,000
Using the orifices sized as shown in the table for 6,000 feet (#45), a meter time of
48.0 seconds is measured. The actual firing rate of the furnace is
Input = 1,000 (heating value of the gas) X 3600 (constant) / 48.0 (meter time for 1
ft3 of gas)
Input = 3,600,000 / 48.0
Input = 76,000 Btu/h
In Canada, the series and rating plate input for the furnace apply to installations up to 2,000 feet
(610m) above sea level. Kit HA-02 for natural and LP gases is required to convert furnaces from
elevations of 2,000 to 4,500 feet (610m to 1,370m). Canadian certification applies to the installa-
tions of up to 4,500 feet above sea level. Installations above 4,500 feet are subject to acceptance
by the local authorities having jurisdiction.
WARNING
BEFORE ATTEMPTING ANY SERVICE OR ADJUSTMENTS - INSURE THAT THE GAS AND
ELCTRICAL SUPPLIES ARE OFF.
TIMING THE GAS METER
Use the following method to determine the firing rate of the furnace. The supply pressure tap
should be located on the field installed piping or gas shut-off valve, or on the combination gas
valve at the location marked “INLET PRESSURE TAP”. The manifold pressure tap is located on
the combination gas valve in the furnace and labeled “OUTLET PRESSURE TAP”.
• Install a manometer graduated in tenths of an inch of water column on the supply pressure tap
on the gas supply pipe.
• Remove plug at the “Manifold” pressure tap on the gas valve and install a second manometer.
• Determine the size of gas meter used.
• Shut off all other gas fired appliances except for the pilots.
• Place furnace in operation.
• Check the supply pressure regulator until the pressure shown on series and rating plate is ob-
tained. Adjust if necessary.
• After 15 minutes of operation, time the meter with a stop watch for 2 revolutions & divide by 2.
• Use the appropriate column to determine the furnace input.
• If necessary, adjust the manifold pressure at the gas valve by removing the regulator cap and
turning the adjustment screw clockwise to raise the pressure and counterclockwise to reduce
the pressure. The manifold pressure must be between 3.2” W.C. and 3.8” W.C. (3.5” nominal)
for natural gas and 9.5” W.C. to 10.5” W.C. for LP (a field conversion is necessary for LP). The

IO137 13
inability to maintain the proper pressure range will require reorificing. After reorificing, repeat
the above steps to insure that the furnace input is adjusted properly.
• Turn off gas and electrical supply, remove manometers and replace any plugs that were re-
moved. Use a pipe joint compound that is suitable for use with LP gas.
• Restore any other appliances affected to their normal operating mode.
METER TIME IN MINUTES AND SECONDS FOR NORMAL INPUT RATING OF FURNACES
EQUIPPED FOR USE WITH NAT. GAS AT 0 - 2,000 FEET ALTITUDE.
INPUT
Btu/hr
METER
SIZE
FT3
HEAT
VALUE
900
MIN. SEC.
HEAT
VALUE
1,000
MIN. SEC.
HEAT
VALUE
1040
MIN. SEC.
HEAT
VALUE
1,100
MIN. SEC.
45,000 1
10
1 12
12 00
1 20
13 20
1 23
13 50
1 28
14 40
75,000 1
10
0 43
7 12
0 48
8 00
0 50
8 19
0 53
8 48
100,000 1
10
0 32
5 24
0 36
6 00
0 37
6 14
0 40
6 36
125,000 1
10
0 26
4 19
0 29
4 48
0 30
5 00
0 32
5 17
150,000 1
10
0 22
3 16
0 24
4 00
0 25
4 10
0 26
4 24
MAIN BURNER ADJUSTMENT
The main burners should not need adjustment in most instances. However, burner air shutters are
provided should adjustment be necessary. After the furnace has been in operation for at least five
(5) minutes loosen the air shutter locking screws and close the shutter until yellow tipped flames
appear. Now slowly open the shutter until the yellow disappears. Retighten the locking screw.
SAFETY CONTROL FUNCTIONS AND CHECK-OUT PROCEDURE
GENERAL
In most cases the safety controls are wired is series with the “W” leg. It is imperative that these
switches remain in the circuit. Never jumper, relocate or bypass any control. The safety controls
must be checked for proper operation at the time of start-up of the furnace.
WARNING
SHOULD ANY SAFETY CONTROL BE ALTERED, JUMPERED OR BYPASSED, A
HAZARDOUS CONDITION SUCH AS FIRE OR THE POSSIBILITY OF CARBON MONOXIDE
ENTERING THE BUILDING MAY OCCUR.
MAIN LIMIT SWITCH
The main limit switch is a 1/2” disc designed to shut off the burner gas should the supply air tem-
perature exceed the maximum design temperature. This switch is not adjustable. To check the
operation, block the return air flow through the unit temporarily. The limit switch should function
and shut the burner gas off within a few minutes. Remove the blockage and allow the switch to
cool sufficiently before reestablishing burner flames.
VENT PRESSURE SWITCH

IO137 14
This furnace uses a vent pressure switch that prevents the furnace from operating should any por-
tion of the vent system become restricted or a venter failure occur. To check this switch, place the
furnace in operation and remove the hose from the switch. The gas burners will extinguish. Re-
placing the hose will allow the furnace to operate normally.
FLAME ROLL-OUT SWITCH
This furnace is equipped with a flame roll-out switch(s). This manually resetable switch is a 1/2”
disc type and is non-adjustable. This switch is designed to shut down the burner gas if there are
flames outside the heat exchanger. Should this switch function, contact a qualified service person
to determine the cause of function before resetting. To reset this switch press the button on top of
the switch after the furnace has cooled. To test the operation of the switch with the furnace in op-
eration, place an open flame on the disc portion of the switch. The switch should function to shut
down the burner gas. Wait until the furnace has cooled sufficiently before resetting the
switch.
FLAME SENSOR
The ignition is provided by an electronic ignition system. The burner flames will become extin-
guished if the flame sensor fails to detect the presence of the burner flame. To test, disconnect the
flame sensor wire before placing the furnace in operation. The electronic ignition device should
attempt to light the burners. However, the burners should shut off after a few seconds of opera-
tion. Disconnect the electrical supply to the furnace, reinstall the disconnected sensor wire and
reset the power supply to restore the furnace to its normal operation.
BLOWER DOOR INTERLOCK SWITCH
The purpose of the switch is to disconnect electrical power to the furnace should the blower door
become dislodged, removed, or not properly reinstalled. ALLOWING THE FURNACE TO
OPERATE WITHOUT THE BLOWER DOOR BEING SECURELY IN PLACE CAN CAUSE
COMBUSTION PRODUCTS TO BECOME CIRCULATED THROUGHOUT THE LIVING AREA
WHICH CAN CAUSE SERIOUS ILLNESS OR CARBON MONOXIDE POISONING. To test the
operation of this switch, place the furnace in operation and remove the blower access door. The
burner flames will extinguish and the venter and circulating air blowers should both stop. To re-
store the unit to normal operation, shut off the electrical power to the unit, replace the blower ac-
cess door and restore the electrical power.
INTEGRATED FAN / IGNITION CONTROL
This furnace is equipped with a combination ignition module and fan control. The ignition source is
an electronic device. This device ignites the burners upon a call for heat. It also controls the venter
blower and the various speed selections and timings of the circulating air blower. This control is
located in the circulating air blower compartment. Upon a demand for heat the venter is energized.
After a short purge, the electronic ignition device is energized. The burners are ignited and after a
short delay, the burner flame is proven. The circulating air blower is energized approximately thirty
(30) seconds after the burners are ignited. The circulating air blower is de-energized by a field se-
lectable fan off timer. THIS CONTROL IS NOT FIELD SERVICABLE.

O137 15
CIRCULATING AIR FILTERS
One of the most common cause of a problem in a forced air heating system is a blocked or dirty
filter. Circulating air filters must be inspected monthly for dirt accumulation and replaced if neces-
sary. Failure to maintain clean filters can cause premature heat exchanger failure.
A new home may require more frequent replacement until all construction dust and dirt is re-
moved. Circulating air filters are to be installed in the return air duct external to the furnace cabi-
net.
CAUTION
Before performing any service on this furnace, including checking or replacing circulating air filters
- disconnect the main power supply.
DO NOT operate the furnace without circulating air filters in place.
MINIMUM FILTER SIZES
FURNACE INPUT FILTER SIZE TYPE
45M 188 IN2PERMANENT
75M 287 IN2PERMANENT
100M 303 IN2PERMANENT
125M 347 IN2PERMANENT
150M 625 IN2PERMANENT
45M 375 IN2DISPOSABLE
75M 555 IN2DISPOSABLE
100M 606 IN2DISPOSABLE
125M 694 IN2DISPOSABLE
150M 1250 IN2DISPOSABLE
PERMANENT NOMINAL 600 C.F.M. DISPOSABLE NOMINAL 300 C.F.M.
TEMPERATURE RISE
The temperature difference between the supply air and the return air of the furnace is known as
the temperature rise. This furnace is designed to operate within the temperature rise range dis-
played on the furnace series and rating plate. To ensure satisfactory performance, the tempera-
ture rise of the furnace must be measured and if necessary adjusted. Use the following procedure
to measure and adjust the temperature rise:
• Before starting the furnace visually inspect all joints and seams in the supply and return air
ducts for leaks. Repair them if necessary.
• Adjust the room thermostat to obtain constant operation.
• Allow the furnace to operate for at least fifteen (15) minutes.
• With an accurate thermometer measure the temperature at the return air. If a combination in-
door / outdoor system is used, the temperature must be measured downstream of the connec-
tion.
• Measure the outlet air tempreture at a point approximately twelve to eighteen (12 -18) inches
from the furnace in the supply air duct work. It may be necessary to measure the outlet air at
several places to obtain an accurate average. NOTE: IF AN AIR CONDITIONING COIL IS
INSTALLED, TAKE CARE SO AS NOT TO DAMAGE THAT COIL.
• Adjust the temperature by changing circulating air blower speed tap. Increasing the motor
speed lowers the temperature rise while lowering the motor speed increases the temperature
rise.

O137 16
MOTOR LUBRICATION AND MAINTENANCE
The circulating air blower is equipped with bearings that are permanently lubricated by the motor
manufacturer and require no lubrication. At the time of the monthly filter inspection clean the exte-
rior of the circulating air motor, especially around the perimeter air holes to prevent the possibility
of overheating due to an accumulation of dust or dirt on the windings and motor casing. As sug-
gested elsewhere in these instructions, the air filters must be kept clean. Dirty filters will restrict
the air flow over the motor windings and possibly cause an overheating condition.
• The venter motor bearings are prelubricated by the motor manufacturer & require no attention.
SERVICE INSTRUCTIONS
DO keep the circulating air filters clean. The heating system will operate more efficiently and eco-
nomically.
DO arrange drapes & furniture so that the supply air registers & return air grilles are unobstructed.
DO close doors and windows. This will reduce the heat load on the system.
DO avoid excessive use of bathroom and kitchen exhaust fans.
DO NOT allow heat generated by televisions, lamps, direct sunlight, etc. to influence the thermo-
stat operation.
DO NOT allow combustible materials to accumulate within (3) feet of the furnace.
DO NOT use the furnace room as a storage area.
DO NOT store gasoline or other flammable liquids or vapors in the vicinity of the furnace.
SEQUENCE OF OPERATION
This appliance is controlled by the room thermostat. Within this section the term lockout is refer-
enced. This lockout is a “soft” lockout, which will re-set after one hour. It is the obligation of the in-
staller to educate the user on the proper use of the thermostat and the sequence of operation in
both the heating and cooling modes. It is also important that any repair or service be performed by
a QUALIFIED service person, not by the user.
R
R
Wrap the “R” leg around a clip-on
amp meter 10 times.
Energize the furnace in the
heat mode. Record the reading.
Divide this reading by
10. Set the heat anticipator
on the thermostat to match
this reading.
EXAMPLE:
If the reading on the amp meter is
“4”, divide this by 10.
The anticipator setting will be .4
amps.

O137 17
HEATING MODE
• The furnace control checks for an open main limit (this limit is normally closed). If the main limit
is open, the furnace will remain inoperable until the limit is closed. During an open limit the cir-
culating air blower and vent blower will be energized. The status light will blink four (4) times.
• The room thermostat reacts to a demand for heat.
• The control will then check to insure that the vent pressure switch is open. If, at this point, the
vent pressure switch is closed the control will blink two (2) times and will remain inoperable un-
til this situation is corrected.
• The venter blower is energized.
• The vent pressure (vacuum) switch will close when it detects a pressure in excess of it’s set-
ting. If the pressure switch fails to close the status light will flash three (3) times. The sequence
cannot continue until the pressure switch closes.
• After a pre-purge period, the electronic ignition device will be energized.
• After a slight delay, the gas valve will open if the flame roll-out switchs are closed.
• The burners will ignite and the flame sensor will detect the presence of flame. The igniter will
then deenergize. If the sensor does not detect the burner flame, the gas valve will close and
the ignition cycle will be repeated for a total of three attempts. If, after the third attempt, the
presence of flame is not detected, the furnace will go into a lockout condition for one (1) hour.
It will then repeat the ignition cycle. This one (1) hour lockout and retry will occur indefinitely.
• Thirty (30) seconds after the main valve is energized the circulating air blower will be activated.
• The furnace will remain in operation until the demand for heat is satisfied.
• Once the demand is satisfied the venter will shut off, and the circulating air blower will shut off
after field adjustable time is attained.
• The furnace will remain dormant until the next demand for heat.
COOLING MODE
The control checks for an open limit. If an open limit is detected the furnace will remain inoperable
until the condition is corrected. During an open limit condition the circulating air blower will be en-
ergized. The status light will blink four (4) times.
• A demand for cooling is initiated.
• The condenser contactor will close.
• After a short delay, the circulating air blower will start on the cooling speed.
• After the room thermostat is satisfied the condenser contractor will open.
• The circulating air blower will remain in operation for approximately sixty (60) seconds.
REMOVING AN EXISTING APPLIANCE
When replacing an existing appliance, the resulting installation must comply with all local codes, or
in the absence of local codes, to the National Fuel Gas Code ANSI Z223.1 and/or CAN/CGA B149
Installation Codes as well as these installation instructions.
If the installation of this furnace requires that an existing appliance be removed from a venting
system that still serves another gas fired appliance it may require that the existing vent be re-
sized. The following steps shall be performed with each appliance connected to the venting sys-
tem placed in operation while any other appliance connected to the venting system are not in op-
eration;

IO137 18
a) Seal any unused openings in the venting system;
b) Inspect the venting system for proper size and horizontal pitch, as required in the National Fuel
Gas Code, ANSI Z223.1 or the CAN/CGA B149 Installation Codes and these instructions. Deter-
mine that there is no blockage or restriction, leakage, corrosion and other deficiencies which could
cause an unsafe condition;
c) In so far as practical close all building doors and windows and all doors between the space in
which the appliance(s) connected to the venting system are located and other spaces in the build-
ing. Turn on clothes dryers and any other appliance not connected to the venting system. Turn on
any exhaust fans such as range hoods and bathroom exhausts, so they shall operate at their
maximum speed. DO NOT operate a summer exhaust fan. Close fireplace dampers;
d) Follow lighting instructions. Place the appliance being inspected in operation. Adjust the ther-
mostat so the appliance shall operate continuously;
e) Test for draft hood equipped appliance spillage at the relief opening after five (5) minutes of
burner operation. Use the flame of a match or candle;
f) After it has been determined that each appliance connected to the venting system properly
vents when tested as outlined above, return all doors, windows, exhaust fans, fireplace dampers
and any other gas-burning appliance back to their previous condition of use;
g) If improper venting is observed during any of the above tests, the venting system must be cor-
rected.
If resizing of the existing vent is required this shall be sized according to Appendix G of the Na-
tional Fuel Gas Code, ANSI Z223.1 or CAN/CGA B149 Installation Codes.
INSPECTING & CLEANING THE HEAT EXCHANGER
CAUTION
Label all wires prior to disconnection when servicing controls. Wiring errors can cause dangerous
and improper operation. Verify proper operation after servicing.
It is the obligation of the installer to advise the user to have the furnace inspected and cleaned
annually. To clean the heat exchanger perform the following:
• Adjust the room thermostat to its lowest setting.
• Turn off the gas and electric supply to the furnace.
• Remove the control access door.
• Open the gas supply union.
• Disconnect the gas supply line attached to the gas valve.
• Remove the wires connected to the gas valve.
• Remove the burner box assembly. Care must be exercised to avoid damage to any compo-
nents.
• Inshot burners should not require cleaning. However, if they exhibit signs of corrosion they can
be cleaned by brushing with a stiff wire brush.
• Remove the vent from the furnace venter blower.
• Remove the venter blower and collector box.

IO137 19
• With a stiff wire brush on a flexible handle remove any loose scale from the heat exchanger at
both the flue and burner openings.
• With a vacuum remove any loose scale dislodged and any additional debris found in the heat
exchanger.
• Visually inspect the heat exchanger cells for any failures using a bright light. If any failures
are discovered it is important to disable the furnace and notify the user to ensure that it
remains inoperable until repairs are implemented.
• Reassemble the furnace in the reverse order. Note: No additional screws or wires are supplied
with this product. All components must be reassembled to avoid an unsafe condition.
• Reconnect gas supply and check for leaks using a soap solution. If a flexible gas line is used
examine it for cracks or weakness. Replace if necessary.
• Restore electrical power.
• Follow the lighting instructions to place the furnace into operation.
SOURCE OF COMBUSTION AIR
The recommended source of combustion air is the outdoor air supply. However, the use of indoor
air in most applications is acceptable except as follows;
1. If the furnace is installed in a confined space it is recommended that the necessary combustion/
ventillation air originate via the attic, crawl space, or direct opening to the outside.
2. If indoor combustion is used, there must be no exposure to the substances.
3. The following installations may require OUTDOOR AIR for combustion, due to chemical expo-
sures;
• Commercial buildings
• Buildings with indoor pools
• Furnaces installed in laundry rooms
• Furnaces installed in hobby or craft rooms
• Furnaces installed near chemical storage areas
Exposures to the following substances in the combustion air supply may also require OUTDOOR
AIR for combustion;
• Permanent wave solutions
• Chlorinated waxes and cleaners
• Chlorine based swimming pool chemicals
• De-icing salts or chemicals
• Carbon tetrachloride
• Halogen type refrigerants
• Masonry acid washing materials
• Cleaning solvents (such as perchloro-
ethylene)
• Printing inks, paint removers, varnishes,
etc.
• Hydrochloric acid
• Cements and glues
• Antistatic fabric soft
• eners for clothes dryer

IO137 20
