Goodmans 359779 User manual

MODEL: 359779
ALARM CLOCK WITH
Qi WIRELESS CHARGING
USER MANUAL

Welcome
Your Alarm Clock with Qi Wireless Charging
2.1 In the Box
2.2 Front View
2.3 Back View
2.4 Side View
Quick Setup
3.1 Power ON/OFF
3.2 Setting the Clock & Alarm
4.1 Nightlight
4.2 Display Backlight
3.3 Charging Your Qi Enabled Device
3.4 Charging Do’s and Dont's
Display and Nightlight
Troubleshooting
Technical Specifications
1
2
3
4
5
6
EC Declaration7

Welcome
Thank you for choosing this Goodmans product. We have been
making electrical products for the British people for over 90 years.
Each of our products have been carefully designed to be great at
what they do and this one is no exception. We hope you enjoy your
new Alarm Clock with Qi Wireless Charging.
Your Alarm Clock with Qi Wireless Charging
1
2
2.1 In the Box
Carefully remove your Alarm Clock with Qi Wireless Charging from
the packaging.
Inside the box you will find:
1 x Alarm Clock with Qi Wireless Charging
1 x Power Adapter
1 x Type-C USB Cable
Quick Start Guide
Instruction Manual
Safety & Guarantee Manual

2.2 Front View
LED Nightlight
3 modes of adjustable nightlight.
Used to charge your QI enabled device.
Connect the Type C USB cable and Power
adapter to the input port.
QI Charging Location
Wireless Charging Indicator Light
Display
Power Adapter Input Port
2.3 Side View

2.4 Side View
Nightlight Button
Press this button to turn the nightlight on or off. When the
nightlight is on, press to adjust the 3 levels of brightness.
The USB port can support charging for devices without Qi function.
Press the “M” button to enter the time setting.
Press and hold the “M” button to enter the alarm setting.
Press the “+” & “-” button to adjust the brightness level on the
display.
Press the “+” & “-” button to set the time and alarm when you
have selected the time or alarm settings.
“M” button
“+” & “-” button
USB Output

3.1 Power ON/OFF
Quick Setup
3
Connect the Type C cable to the Type C input port at the back of
the Alarm Clock.
Connect the power adapter to a wall socket and the alarm clock
will turn on automatically.
1.
2.
3.3 Charging Your QI Enabled Device
Place your Qi device on the centre of the charging location.
The charging indicator light will turn Blue when charging.
1.
2.
When your device is fully charged, the indicator light will turn off.
If the Blue indicator light is flashing, your QI device has not been
placed on the charging area correctly.
Note: Fast charge won't work when you are using the QI wireless
charging and the USB charging at the same time.
3.
4.
3.2 Setting the Clock & Alarm
Time setting: Press the 'M' button to select time settings. Use
the '+' and '-' buttons to set the minutes and press 'M' to confirm.
Then use the '+' and '-' buttons again to set the hours and press
'M' to confirm.
Alarm Setting: Press and hold the 'M' button to select alarm
settings. Use the '+' and '-' buttons to set the minutes and press
'M' to confirm.
Then use the '+' and '-' buttons again to set the hours and press
'M' to confirm.
Press and hold '+' and '-' to turn the alarm ON or OFF.
1.
2.
Alarm Clock: When the alarm sounds, press any button on the
right side to turn off the alarm.
3.
Snooze Setting: When the alarm sounds, please tap the Qi
charging location to activate the snooze function.
4.

3.4 Charging Do’s & Dont’s
• If your device supports fast charging we recommend that you use
an 3.0 adapter that has Qualcomm Quick Charge technology.
• Do not use in a hot, humid or corrosive environment.
• Do not place the wireless charger too close to magnetic stripes or
chip cards.
• Please keep the wireless charger at least 20cm away from any
implantable medical devices (pacemakers, implantable
cochlear, etc.)
• Keep away from children.
• Do not use a metal case for your smartphone when using the
wireless charger.
• For optimum charging times make sure that your device is not
in a protective case that is more than 2mm thick, and that it is
positioned in the centre of the wireless charger.
• Remove your smartphone from the wireless charger when fully
charged.
4.1 Nightlight
Display and Nightlight
4
The Nightlight has 3 brightness levels.
Press the nightlight button to switch On/Off and select the
different brightness levels.
1.
2.
4.2 Display Backlight
The display backlight has 3 brightness levels.
Press the “+ “ & “ -” button to select the different brightness levels.
1.
2.

Troubleshooting5
Technical Specifications6
Problem
Model Number
What to do
My device is
not charging.
The alarm did not
sound at the correct
time.
Make sure your device is placed in
the centre of the charging location.
If the phone is in a protective case,
remove it and try again.
Make sure your device is Qi enabled.
359779
Make sure the current time is correct.
Check the alarm clock time is set
correctly, and confirm whether there
is an alarm clock indicator on the
display screen.
Power Input DC 5V 2.0A (Normal)
DC 9V 1.67A (Fast charge)
USB Output
5V 1.0A (Normal)
9V 1.2 (Fast charge)
Wireless Output
DC 5.0V 1.0A (Normal)
DC 5.0V 2.0A max. (Fast charge,
please use 3.0 adapter)
Dimensions 140 x 100 x 75mm
Weight 149 g

Information on Waste Disposal for Consumers of
Electrical & Electronic Equipment
This product is intended for use within UK
This Product complies with the below listed EU directives.
The completed declaration of conformity is available upon request
for relevant enquiries.
This mark on a product and/or accompanying documents
indicates that when it is to be disposed of, it must be treated as
Waste Electrical & Electronic Equipment (WEEE).
Any WEEE marked waste products must not be mixed with general
household waste, but kept separate for the treatment, recovery and
recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE
marked waste to your Local Authority Civic waste site, where it will be
accepted free of charge.
If all consumers dispose of Waste Electrical & Electronic Equipment
correctly, they will be helping to save valuable resources and
preventing any potential negative effects upon human health and the
environment, of any hazardous materials that the waste may contain.
Made in China
Imported by B&M Retail Ltd, Dakota Drive, Liverpool, L24 8RJ, UK
The "Qi" symbol is a trademark of the wireless power consortium.
2014/53/EU Radio Equipment Directive
2011/65/EU Restriction of Hazardous Substances
EC Declaration
7
