Goodmans GDVD67W4LCDAC User manual

GDVD67W4LCDAC
Portable DVD Player
With Remote Control
Quick Guide
82-182-00480
All manuals and user guides at all-guides.com
all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
2
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 3
Package Contents
1. Portable DVD player x 1
2. RCA Audio cable x 1
3. RCA Video cable x 1
4. 12-Volt cigar adaptor plug x 1
5. Earphone x 1
6. Carry bag x 1
7. Remote Control x 1
8. Power adaptor x 1
Front view
1. LCD screen
2. SPEAKERS
3. PLAY button
4. PAUSE button
5. STOP button
6. Remote sensor
7. Power indicator
8. OPEN button
Getting to Know Your Portable DVD Player
1
2
3
4
5
2
6
7 8
All manuals and user guides at all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
2
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 3
Right side
1. Volume control
2. Headphones socket
3. Coaxial output socket
(Digital Audio)
4. Audio output socket
1 2 3 4 5 6 7
5. Video output socket
6. POWER switch
7. DC IN Socket
All manuals and user guides at all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
4
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 5
Remote Control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1. INFO. button
2. SETUP button
3. PAUSE/UP button
4. MENU button
5. F.BWD/LEFT button
6. PLAY/SEL. button
7. PREVIOUS button
8. STOP/DOWN button
9. NUMERICAL buttons
10. LCD button
11. SUBTITLE button
12. TITLE button
13. ANGLE button
14. F.FWD/RIGHT button
15. AUDIO button
16. NEXT button
17. A-B REPEAT button
18. 1/ALL REPEAT button
19. MUTE button
All manuals and user guides at all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
4
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 5
Battery installation for the remote control
Insert the battery and match the (+) and (-) on battery to the marks inside
the battery compartment.
First-time use:
Remember to remove the insulating
Mylon piece from the battery.
Service life of battery
1. If the remote control unit fails to work even when it is operated
near the player, replace the battery.
2. Use a 3V lithium battery.(CR2025)
+
CR2025
OPEN
PUSH
All manuals and user guides at all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
6
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 7
Power Supply
Connecting the portable DVD player to Power.
Connect the supplied AC power adaptor or 12 volt cigar adaptor plug to
the DC IN socket on the player, the other end to the wall outlet or the
cigar lighter socket.
(a) By AC power adaptor
(b) By cigar adaptor plug
(supplied)
(supplied)
All manuals and user guides at all-guides.com
all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
6
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 7
Connection
Connecting to a TV
Note:
1. Before connecting, make sure to turn the power off to your TV
and portable DVD player.
(Yellow)
Video
Input
(White) (Red)
Audio Input
Connecting to external equipment
Note:
1. Before connecting, make sure to turn the power off to portable
DVD player and external equipment.
Video cable
(supplied)
Coaxial cable
(not supplied)
Portable DVD player
Connecting earphones
Audio cable (supplied)
Portable DVD player
All manuals and user guides at all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
8
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 9
For using the portable DVD player in a vehicle, please read the following
instructions:
STEP 1. Unzip and open the carry bag.
STEP 2. Pack your DVD player into the carry bag.
(a) Adjust the elastic straps and tighten it securely.
(b) Fasten the straps with the velcro.
STEP 3. Attach the bag to the headrest part by two steps.
(a) Snap the buckles together.
(b) Adjust the straps with the stoppers.
How to Use In a Vehicle
(a)
(b)
(a)
(b)
All manuals and user guides at all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
8
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 9
STEP 4. Flatten this unit.
Note: To place a disc, bend the base of the player
upward at a 90° angle.
STEP 5. Connect the cigar adaptor plug to the power socket on
the portable DVD player, the other end to the cigar
lighter socket.
180°
(supplied)
All manuals and user guides at all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
10
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 11
Playing a Disc
STEP 1. Connect it to Power.
(a) Connect the supplied AC power adaptor to a wall outlet mains socket
(b) Connect to supplied 12 Volt cigar adaptor plug in a car
STEP 2. Open the display panel.
STEP 3. Slide POWER switch to the ON position to turn on the
portable DVD player.
All manuals and user guides at all-guides.com

PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE
10
PORTABLE DVD QUICK GUIDE
PORTABLE DVD QUICK GUIDE 11
STEP 4. Press OPEN button to open the DVD Door.
STEP 5. Gently hold the edge of the disc, then place it in the
centre and push gently until the disc is securely located
with the printed side up.
STEP 6. Close the DVD Door.
STEP 7. Press PLAY/SEL. to play the disc.
