1
Safety
Prior to handling the machine, this instruction manual should be read and understood.
Read this manual carefully before use and keep for future reference.
This instruction manual remains valid as long as the customer does not change anything
on the product.
The machine is intended for industrial use. It must be handled only by technically trained
personnel.
Always wear appropriate personal protective equipment in accordance with the
local regulations.
The machine has been designed and manufactured according to state-of-the-art
meth
ods. Nevertheless, residual risks may remain. This instruction manual highlights
potential
hazards where appropriate. Safety notes and warning messages are tagged
with one of the keywords DANGER, WARNING, CAUTION, as follows:
DANGER
...indicates animminentdangerous situationthatwill result in deathorserious
injuriesif not prevented.
WARNING
... indicates a potentially dangerous situation that could result indeathor serious
injuries.
CAUTION
... indicates a potentially dangerous situation that could result in minor injuries.
Add: 1st floor,1st Bldg, Pengdong Ind Park, Shuilian Mountain, Nanchen DongGuan, China
www.goorui.com www.gooruisidechannelblower.com
2
Product Description
IN Suction connection
OUT Discharge connection
NOTE
Technical term.
In this instruction manual, weconsiderthattheterm ‘machine’ refers to the
‘sidechannel blower’.
Add: 1st floor,1st Bldg, Pengdong Ind Park, Shuilian Mountain, Nanchen DongGuan, China
www.goorui.com www.gooruisidechannelblower.com
2.1
Operating Principle
The machine works on the impulse principle,i.e. Kinetic energy is transferred from
the impeller to the conveyed medium and then is converted into pressure.
The change in pressure is made without the use of any lubrication whatsoever.
NOTICE
Lubricating a dry running machine (process chamber).
Risk of damage to the machine!
•
Do not lubricate the process chamber of the machine with oil or grease.
2.2
Application
The machine is intended for the suction and/or compression of air and other dry, non-
aggressive, non-toxic, non-flammable and non-explosive gases.
Conveying of other media leads to an increased thermal and/or mechanical load on the
machine and is permissible only after a consultation with GOORUI.
The machine is intended for the placement in a non-potentially explosive environment.
The machine is not capable of maintaining ultimate pressure. The minimum allowed
ultimate pressure is to be read from the nameplate of the machine.
By means of process control and/or vacuum relief valves it must be made sure that the
minimum allowed ultimate pressure will not be under run.
Permitted environmental conditions, see Technical Data [►16].
2.3
Optional Accessories
2.3.1
Pressure relief Valve
The pressure relief valve controls inlet pressure when the machine is used on
vacuum duties.
Add: 1st floor,1st Bldg, Pengdong Ind Park, Shuilian Mountain, Nanchen DongGuan, China
www.goorui.com www.gooruisidechannelblower.com
The pressure regulating valve controls pressure when the machine is used on
Overpressure duties.
|
2.3.2
Inlet Filter
The inlet filter protects the machine against dust and other solids in the process gas. The
inlet filter is available with a cartridge.
2.3.3
Silencer
A silencer at the discharge connection (OUT) can be provided to reduce the exhaust gas
noise.
0870168588_SE0630-
0850F1_A0001_IM_en
•
Make sure that the environment of the machine is not potentially explosive.
•
Make sure that the ambient conditions comply with the Technical Data [►16].
•
Make sure that the environmental conditions comply with the protection class of the
motor.
•
Make sure that the installation space or location is vented such that sufficient
cooling of the machine is provided.
•
Make sure that cooling air inlets and outlets are not covered or obstructed and
that the cooling air flow is not affected adversely in any other way.
•
Make sure that the machine is placed or mounted horizontally/vertically, with a
maximum deviation of 1° in anydirection.
•
Make sure that the machine is placed or mounted horizontally on a flat surface.
•
Make sure that all provided covers, guards, hoods, etc. are mounted.
If the machine is installed at an altitude greater than 1000 meters above sea level:
•
Contact your sales representative, the motor should be de-rated or the
ambient temperature limited.
If the machine is installed outdoor:
•
Provide a protective cover against the weathering effects.
3.2 Connecting Lines / Pipes
•
Remove all protective caps before installation.
•
Make sure that the connection lines cause no stress on the machine‘s connection; if
necessary use flexible joints.
•
Make sure that the line size of the connection lines over the entire length is at least as
large as the connections of themachine.
In case of very long connection lines it is advisable to use larger line sizes in order to
avoid a loss of efficiency. Seek advice from your sales representative.
3.2.1 Suction Connection
NOTICE
Intruding foreign objects or liquids.
Risk of damage to the machine!
If the inlet gas contains dust or other foreign solid particles:
•
Install a suitable filter (5 micron or less) upstream from the machine.
3.2.2 Discharge Connection
Depending on the specific order, other connection dimensions may apply.
•
Make sure that the discharged gas will flow without obstruction. Do not shut off or
throttle the discharge line.
0870168588_SE0630-
0850F1_A0001_IM_en
3.3 Electrical Connection
DANGER
Live wires.
Risk of electrical shock.
•
Electrical installation work must only be executed by qualified personnel.
• Make sure that the power supply for the motor is compatible with the data on
the nameplate of the motor.
•
Provide overload protection according to EN 60204-1 for the motor.
•
Make sure that the motor of the machine will not be affected by electric or electro-
magnetic disturbance from the mains; if necessary seek advice from yoursales
representative.
•
Connect the protective ground conductor.
•
Electrically connect the motor.
NOTICE
Incorrect connection.
Risk of damage to the motor!
•
The wiring diagrams given below are typical. Check the inside of the terminal box for
motor connection instructions/diagrams.
0870168588_SE0630-
0850F1_A0001_IM_en
3.3.1 Wiring Diagram Single-Phase Motor
-Models: GHBH XXX 12 XXX 220V, 1 Phase
3.3.2 Wiring Diagram Three-Phase Motor
NOTICE
Incorrect direction of rotation.
Risk of damage to the machine!
•
Operation in the wrong direction of rotation can destroy the machine in a short time!
Prior to start-up, ensure that the machine is operated in the right direction.
If the rotation of the motor must be changed:
•
Switch any two of the motor phase wires.
-Models: GHBH XXX 34 XXX 220V/480V 3 Phase
-Models: GHBG XXX 34 XXX 220V/480V 3 Phase
-Models: GHBH XXX 36 XXX 480V/720V 3 Phase
-Models: GHBG XXX 36 XXX 480V/720V 3 Phase
0870168588_SE0630-
0850F1_A0001_IM_en
4 Commissioning
NOTICE
Lubricating a dry running machine (process chamber).
Risk of damage to the machine!
•
Do not lubricate the process chamber of the machine with oil or grease.
CAUTION
During operation the surface of the machine may reach temperatures of more than
70°C.
Risk of burns!
•
Avoid contact with the machine during and directly after operation.
CAUTION
Noise of running machine.
Risk of damage to hearing!
If persons are present in the vicinity of a non-noise insulated machine over extended
periods:
•
Make sure that ear protection is being used.
•
Make sure that the installation conditions (see InstallationConditions [►7])
are complied with.
•
Switch on the machine.
•
Make sure that the maximum permissible number of starts does not exceed
6 starts per hour.
•
Make sure the working/pause periods are equal with multiple starts
per hour. As soon as the machine is operated under normal operating
conditions:
• Measure the motor current and record it as reference for future maintenance and
trouble shooting work.
0870168588_SE0630-
0850F1_A0001_IM_en
5Maintenance
WARNING
Machines contaminated with hazardous material.
Risk of poisoning!
Risk of infection!
If the machine is contaminated with hazardous material:
•
Wear appropriate personal protective equipment.
CAUTION
Hot surface.
Risk of burns!
•
Prior to any action requiring touching the machine, let the machine cool down first.
•
Shut down the machine and lock against inadvertent start up.
•
Vent the connected lines to atmospheric pressure.
If necessary:
•
Disconnect all connections.
5.1 Maintenance Schedule
The maintenance intervals depend very much on the individual operating conditions.
The intervals given below are desired to be considered as starting values which should
be shortened or extended as appropriate. Particularly heavy duty operation, such as
high dust loads in the environment or in the process gas, other contamination or ingress
of processmaterial, can make it necessary to shorten themaintenance intervals
significantly.
Interval
Maintenance work
Monthly
•
Clean the machine from dust and dirt.
in case of an inlet filter being installed:
•
Check the inlet filter cartridge, replace if
neces
sary.
Every 6 months
•
Clean the machine from dust and dirt.
•
Make sure that the electronic components and the
cooling fan are free from dust.
Yearly
•
Carry out a visual inspection and clean the machine
from dust and dirt.
•
Check the electrical connections and the monitoring
devices.
•
Clean the inlet and outlet silencer.
Every 5 years
•
Have a major overhaul on the machine (contact
your sales representative ).
/
0870168588_SE0630-
0850F1_A0001_IM_en
5.2 Cleaning from Dust and Dirt
Clean the ventilation grilles
and cooling fins
6.Overhaul
NOTICE
Improper assembly.
Risk of premature failure!
Loss of efficiency!
•
It is highly recommended that any dismantling of the machine that goes beyond any-
thing that is described in this manual should be done through GOORUI.
WARNING
Machines contaminated with hazardous material.
Risk of poisoning!
Risk of infection!
If the machine is contaminated with hazardous material:
•
Wear appropriate personal protective equipment.
In case of the machine having conveyed gas that was contaminated with foreign
materials which are dangerous to health:
•
Decontaminate the machine aswellas possible and state the contamination
status in a ‘Declaration of Contamination’.
0870168588_SE0630-
0850F1_A0001_IM_en
7Decommissioning
•
Shut down the machine and lock against inadvertent start up.
•
Vent the connected lines to atmospheric pressure.
•
Disconnect all connections.
If the machine is going to be stored:
•
See Storage [►6].
7.1
Dismantling and Disposal
•
Separate special waste from the machine.
•
Dispose of special waste in compliance with applicable regulations.
•
Dispose of the machine as scrapmetal.
8Spare Parts
NOTICE
Use of non-GOORUI genuine spare parts.
Risk of premature failure!
Loss of efficiency!
•
The exclusive use of GOORUI genuine spare parts and consumables is recommended
for the proper function of the machine and for granting of warranty.
Commercially available standard parts are to be purchased onthe open
market. If other parts are required:
•
Contact your sales representative for the detailed spare parts and accessory list.
0870168588_SE0630-
0850F1_A0001_IM_en
9.Troubleshooting
DANGER
Live wires.
Risk of electrical shock.
•
Electrical installation work must only be executed by qualified personnel.
CAUTION
Hot surface.
Risk of burns!
•
Prior to any action requiring touching the machine, let the machine cool down first.
Problem
Possible Cause
Remedy
The machine does not start.
At least two power supply
leads are interrupted
•
Check the fuses, terminals
and power supply cables
The motor is not supplied
with the correct voltage.
•
Check the power supply.
The motor is defective.
•
Repair the machine
( contact us ).
The machine does not
start;
humming noise.
One power supply lead is
interrupted
•
Check the fuses, terminals
and power supply cables
Impeller defective
•
Replace impeller
Impeller is jammed
•
Open the cover, remove
foreign body and clean.
•
Check the impeller gap.
Bearing on motor side
machine side is defective
•
Replace defective bearing.
Motorprotectives witch
trips
when starting the
machine. Power
consumption is too high.
Winding short-circuit
•
Check the winding.
Motor overloaded.
Throttling does not
match specification on
rating plate
•
Reduce throttling.
•
Clean filters, mufflers and
connecting pipes.
Compressor is jammed.
•
See Themachinedoes
not start; humming
noises [►14].
The machine runs very
noisily.
The machine runs in the
wrong direction
•
Check the direction of
rotation.
Bearings lacking grease
•
Relubricate or replace if
necessary.
Defective bearings.
•
Repair the machine
( contact us).
The machine runs with
abnormal flow noises.
The flow speed is too high
•
Use larger sized pipes.
The silencers are soiled.
•
Check silencer inserts,
cleanor replaceif
necessary.
0870168588_SE0630-
0850F1_A0001_IM_en
The machine does not reach
the usual pressure on the
suction connection.
Suction or discharge lines
too long or section diameter
too small.
•
Uselargerdiameteror
shorter lines.
•
Seek advice from your
local sales
representa
tive.
The machine runs in the
wrong direction.
•
Check the direction of
rotation, see Wiring
Diagram Three-Phase
Motor
Different density of
conveyed medium
•
Take conversion of
pressure value into
account. Contact us if
necessary.
Change in blade profile due
soiling.
•
Check the impeller, clean
or replace if necessary.
In case an inlet screen is
installed:
The inlet screen is partially
clogged.
•
Clean the inlet screen.
In case a vacuum relief valve
is installed:
The vacuum relief valve is
misadjusted or defective.
•
Replace the vacuum relief
valve.
Incase aninlet filter valve is
installed:
The inlet filter cartridge is
partially clogged.
•
Replace the inlet filter
cartridge.
Leak in the system.
•
Repair leak.
Internal parts are worn or
damaged.
•
Repair the machine (con-
tact us).
The machine runs too hot.
Insufficient cooling.
•
Remove dust and dirt
from the machine.
Ambient temperature too
high.
•
Observe the permitted
ambient temperature.
Compressor leaky.
Seals on silencer defective.
•
Check silencer seals
and
replace
ifnecessary
Seals inmotorarea
defective.
•
Check motor seals and
replace if necessary
For the solution of problems not mentioned in the troubleshooting chart contact your
sales representative.
This manual suits for next models
4
Table of contents
