Gopod Group GW13B User manual

S/N RD-WI-A.1-001
Revision VA.4
GW13B
(
10W
)
User Manual Page 1OF1
Gopod Group Ltd 2016-07-14 RD-WI-A.1-001 Barry Song
GW13B
User Manual
(Version: 1.0)
Statement
Thank you for using our wireless charger. Before you use it，please read this user manual
carefully. The publisher has the right to revise the related information of the manual at
anytime if needed without any notice.

S/N RD-WI-A.1-001
Revision VA.4
GW13B
(
10W
)
User Manual Page 1OF1
Gopod Group Ltd 2016-07-14 RD-WI-A.1-001 Barry Song
Catalogue
One. Introduction & Accessory ................................................... 3
1．1 Product introduction ................................................... 3
1．2 Product accessory list ................................................. 3
1．3 Compatibility .......................................................... 3
Two. Specifications ............................................................ 3
2．1 Operating voltage ...................................................... 3
2．2 Static current ......................................................... 3
2．3 Operating current ...................................................... 3
2．4 Dimension .............................................................. 3
2．5 Weight ................................................................. 3
Three. Appearance & Interface .................................................. 3
3．1 Product outline & Functional illustration .............................. 3
3．2 Indicator light description ............................................ 4
Four. Instructions ........................................................... 4
4．1 Quick Charge Samsung S7 ................................................ 4
4．2 Quick Charge Samsung Note 5 ............................................ 5
Five. Precautions ............................................................ 5

S/N RD-WI-A.1-001
Revision VA.4
GW13B
(
10W
)
User Manual Page 1OF1
Gopod Group Ltd 2016-07-14 RD-WI-A.1-001 Barry Song
One.Introduction & Accessory
1.1 Product introduction
This product is used for DC-DC QC2.0 5V@9V/2A input (Suggested ), wireless charger electric,
mechanical features and external environment requirements and so on.
1.2 Product accessory list
 GW13B 1 piece
 User manual 1 share
1.3 Compatibility
1. Nexus4、Nexus 5
2. Nokia QI headphone BH-220，NOKIA Lumia820
3. NOKIA Lumia920
4. Google NEXUS 7
5. Samsung NOTE3 、NOTE4, NOTE5、S6、S6/edge、S7、S7/edge
6. LG G3
Two.Specifications
2.1 Operating voltage：V[email protected] 8.6-9.3V
2.2 Static current: 20-60mA±10
2.3 Operating current: 0-2000mA
2.4 Dimension： L87*W87*H7.5mm
2.5 Weight： 63g
Three. Appearance & Interface
3.1 Product outline & Functional
illustration
 As shown in figure
SN Name Functional description
1 MicroUSB port Supply power delivery to GW13B
2 Power light RED LED light, always on while working, off while standby
3 Center Magnetic core to sense the device

S/N RD-WI-A.1-001
Revision VA.4
GW13B
(
10W
)
User Manual Page 1OF1
Gopod Group Ltd 2016-07-14 RD-WI-A.1-001 Barry Song
3.2：Indicator light description
3.1.1：Power On (The Blue LED light will flash 3 seconds and then off)
3.1.2：Standby (The Blue LED light off)
3.1.3：Charging（The Blue LED light will flash 10 seconds and then off）;
3.1.4：Finished (The Blue LED light will stay off)
3.1.5：Fault（The Blue LED light will keep flashing）;
P.S.：The above LED status indicates looping execution.
Four. Instructions
4.1 Product using diagram
4.1 Quick Charge adapter supplies power delivery to GW13B, and then GW13B will wireless quick
charge Samsung S7 9V/1.1A.

S/N RD-WI-A.1-001
Revision VA.4
GW13B
(
10W
)
User Manual Page 1OF1
Gopod Group Ltd 2016-07-14 RD-WI-A.1-001 Barry Song
4.2 Quick Charge adapter supplies power delivery to GW13B, and then GW13B will wireless
quick charge Samsung Note5 9V/1A.
Statement: Support 5V/9V(10W) Samsung Fast Charge Phone,including Note 5,S6,S6/edge,S7,S7/edge.
Support 5W wireless Fast Charge equipments：
1. Nexus4,Nexus5
2. Nokia QI Headphone BH-220，NOKIA Lumia820
3. Nokia Lumia920
4. Google Nexus 7
5. Samsung NOTE3,NOTE4
6. LG G3
Note：When you wanna charge the phone, remember to put it on the right center point of the charger,
if you put on a bit side, the charger can’t sense it, then it won’t be able to charge
your device.
Five.Precautions
5.1 Please do not allow any objects (like Combustible, Needle) or any fluids (like Water, Beverage)
fall into the product, that will lead to a breakdown.
5.2 Please do not use or place the product under the following circumstance: wet environment
(like bathroom, toilet), dusty environment and somewhere corrosive.
5.3 If you don’t use the product for a long time, please remember to place it with a pp bag
and put into the packing box to prevent becoming dusty.
5.4 Please do not repair the product by yourself, or replace any parts of it(Unless there is
any special instructions on the manual).Please send the product back to the seller for repairing.

S/N RD-WI-A.1-001
Revision VA.4
GW13B
(
10W
)
User Manual Page 1OF1
Gopod Group Ltd 2016-07-14 RD-WI-A.1-001 Barry Song
This device complies with part 15 of the FCC Rules. Operation is subject to t
he following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interferen
ce that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio f
requency energy and, if not installed and used in accordance with the instructi
ons, may cause harmful interference to radio communications. However, there is n
o guarantee that interference will not occur in a particular installation. If t
his equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is enco
uraged to try to correct the interference by one or more of the following mea
sures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to whic
h the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
