Gorenje GS643D60W User manual

GS643D60W
GS643D60X
User manual
Dishwasher

Contents
4Your dishwasher .....................................................................................................................
5Safety instructions ..................................................................................................................
6Automatic child lock - CL ........................................................................................................
6Child lock - CL .........................................................................................................................
6Installation .................................................................................................................................
6Overflow guard .........................................................................................................................
6Packaging .................................................................................................................................
6Disposal ....................................................................................................................................
7Symbols on the appliance ........................................................................................................
8Before washing for the first time ...........................................................................................
81. Water hardness ....................................................................................................................
92. Basic settings .......................................................................................................................
9Top up with rinse aid ................................................................................................................
9Top up with salt ........................................................................................................................
10Greener dishwashing ..............................................................................................................
10Save energy and water .............................................................................................................
11Loading the dishwasher .........................................................................................................
11Fragile dishes ............................................................................................................................
11Loading affects the results ........................................................................................................
11The dishwasher's baskets ........................................................................................................
11Top cutlery tray .........................................................................................................................
12Upper basket ............................................................................................................................
13Lower basket ............................................................................................................................
14Using the dishwasher .............................................................................................................
14Add detergent ...........................................................................................................................
15On/Off .......................................................................................................................................
15Select program .........................................................................................................................
16Select option .............................................................................................................................
16Start/Pause/Stop ......................................................................................................................
17If you want to load more dishes ................................................................................................
17Power failure .............................................................................................................................
17Once the program has finished .................................................................................................
17The best drying results .............................................................................................................
17Unloading the dishwasher ........................................................................................................
18Program chart .........................................................................................................................
19Settings ....................................................................................................................................
21Care and cleaning ...................................................................................................................
21Top up with rinse aid ................................................................................................................
21Top up with salt ........................................................................................................................
22Clean the filter ...........................................................................................................................
22Cleaning the spray arms ...........................................................................................................
23Clean the outside of the dishwasher ........................................................................................
23CLn - Run the Self-clean program ...........................................................................................
23Remove blockages ...................................................................................................................
24Winter storage/transport ...........................................................................................................
2

25Troubleshooting ......................................................................................................................
30Installation ...............................................................................................................................
30Safety instructions ....................................................................................................................
30Transport protection for the door .............................................................................................
30Placing the dishwasher .............................................................................................................
31Adjust the height and slide the dishwasher into place .............................................................
32Drainage connection .................................................................................................................
32Connection to water supply ......................................................................................................
33Electrical connection .................................................................................................................
33Fit the sound insulation .............................................................................................................
33Remove dishwasher worktop ...................................................................................................
34Service .....................................................................................................................................
34Number of program cycles .......................................................................................................
35Technical data and energy labelling .....................................................................................
35Technical data ...........................................................................................................................
35Information for consumers ........................................................................................................
35Information for test institute ......................................................................................................
35Declaration of conformity ..........................................................................................................
3

Your dishwasher
Install the dishwasher, see the chapter Installation. Press .
The first time the dishwasher is switched on, it is important that you choose the right settings to ensure
good dishwashing results. See the chapter Before washing for the first time.
Display
Start/Pause/Stop
Select program
On/Off
Special programOptionProgram
Self-clean
Delayed start
Speed wash
Eco 55°
Auto 45-65°
1h 65°
Intensive 70°
Glass 40°
Hygiene 70°
Information on the display
See the chapter Care and cleaning.
Top up with rinse aid
Top up with salt
CLn Run the Self-clean program
NOTE!
The control panel only reacts to use when the door is closed.
4

Safety instructions
•Read the user manual and keep it in a safe place!
•Number of standard place settings: 16
•Never use the dishwasher for any purpose other than that
specified in these operating instructions.
•Do not load the dishwasher door or dishwasher baskets with
anything other than dishes.
•Never leave the dishwasher door open as someone may trip
on it. Push the baskets in to avoid risking the dishwasher
tipping over.
•Use only dishwasher detergent!
•This machine can be used by children aged 8 and upwards,
and by people with reduced physical capacity, mental ability,
memory loss or lacking experience and knowledge. These
individuals must be supervised when using the machine or
have instructions on how to use the machine and understand
the risks that can occur. Cleaning of the machine must not
be carried out by children without supervision.
•Damaged supply cord must only be replaced by the
manufacturer's service centre or someone similarly
professionally qualified.
•Only use the dishwasher in household-type environments
for dishwashing household dishes. All other use is prohibited.
•Never place dishes with solvent residues in the dishwasher
due to the risk of explosion. Nor may dishes that contain
ash, wax or lubricants be washed in the dishwasher.
•Children must be watched. Do not allow children to use or
play with the dishwasher. Be especially vigilant when the
door is open. Some detergent may remain inside! After
adding detergent, always start the dishwasher immediately.
WARNING!
Knives and other pointed items must be placed horizontally
in the dishwasher's special cutlery baskets.
5

WARNING!
Children must be supervised –dishwasher detergent is
corrosive!
Automatic child lock - CL
You can activate the Automatic child lock setting to prevent children from starting the dishwasher.
See the chapter Settings. CL (Child Lock) will be shown on the display when pressing the control
panel. (To unlock, press and hold for three seconds.)
Child lock - CL
To prevent children from stopping the current dishwashing program, you can activate the child lock
function. Once you have started a program, press and hold for three seconds. CL (Child Lock) will
be shown on the display when pressing the control panel. (To unlock, press and hold for three
seconds.)
Installation
See the chapter Installation.
Overflow guard
The overflow guard starts pumping out the water and turns off the water supply if the water level in
the dishwasher exceeds the normal level. If the overflow guard is triggered, F54 (Overfilling water)
appears on the display. Turn off the water tap and contact your nearest service centre. (To avoid water
leakage outside the dishwasher, do not remove the plug from the wall socket until the water tap on
the supply line has been turned off!)
Packaging
The outer packaging protects the product during transport. The packaging material is recyclable.
Separate the different packaging materials to help reduce raw material use and waste. Your dealer
can take the packaging for recycling or direct you to the nearest recycling centre. The packaging is
comprised of:
•Corrugated cardboard made from up to 100% recycled material.
•Expanded polystyrene (EPS) with no added chlorine or fluorine.
•Supports made from untreated wood.
•Protective plastic made from polyethylene (PE).
Disposal
The dishwasher is manufactured and labelled for recycling. When the dishwasher has reached the
end of its service life and is to be disposed of, it should immediately be made unusable. Pull out the
power cable and cut it as short as possible.
Contact your local authority for information about where and how your dishwasher should be correctly
recycled.
6

Symbols on the appliance
Recycle as electrical waste.
Read the user manual.
Approved in accordance with the relevant EU directives.
Approved in accordance with the relevant UK legal requirements.
7

Before washing for the first time
1. Water hardness
In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral
content). Hard water leaves a white coating on dishes and the dishwasher.
Checking water hardness
Water hardness is specified using German degrees of water hardness (°dH), French degrees of water
hardness (°fH), English degrees of water hardness (°eH) or millimoles per litre (mmol/l).
A water supply with a water hardness in excess of 5°dH (9°fH / 6°eH / 0.9 mmol/l) must be softened.
This is done automatically with the aid of the built-in water softener. In order for the water softener to
function properly, its settings must be adjusted to the hardness of the water supply. Once you have
adjusted the water softener settings, add detergent and rinse aid in doses suitable for soft water.
Contact the local waterworks to check the water hardness in your area.
Make a note of the water hardness:____________
Recommended settingmmol/l°eH°fH°dH
4:000.0-0.90-60-90-5
4:011.0-1.47-1010-146-8
4:021.5-2.011-1415-209-11
4:032.1-2.515-1821-2512-14
4:042.6-3.419-2426-3415-19
4:053.5-4.325-3035-4320-24
4:064.4-5.231-3644-5225-29
4:075.3-7.037-4953-7030-39
4:087.1-8.850-6171-8840-49
4:098.9628950
If the water hardness exceeds 50°dH (89°fH / 62°eH / 8.9 mmol/l), we recommend connecting an
external water softener.
Increased consumption during regeneration
The dishwasher's built-in water softener is regularly regenerated to maintain its function. Regeneration
extends the dishwashing program and increases energy and water consumption. Just how often the
dishwasher's water softener is regenerated depends on the selected setting.
Example: If the Eco 55° program is run with a water hardness of 14°dH (25°fH / 18°eH / 2.5 mmol/l),
the water softener is regenerated at regular intervals (after 5 dishwashing cycles), energy consumption
increases by 0.015 kWh, and water consumption increases by 2.3 litres, while the program time is
extended by 3 minutes. Regeneration takes place during the program’s main wash.
WARNING!
Hard water leaves a white coating on dishes and inside the dishwasher. It is therefore important
that you select the right setting for the water softener! See Water hardness in the chapter Settings.
Never run the dishwasher with an empty salt compartment if the water supply has a water
hardness in excess of 5°dH (9°fH / 6°eH / 0.9 mmol/l).
8

2. Basic settings
The first time the dishwasher is switched on, it is important that you choose the right settings to ensure
good dishwashing results. See page 19.
Set up:
•Rinse aid
•Water hardness
•TAB (All-in-one detergent)
3. Top up with rinse aid
Drying is faster and a better result is achieved
if you use rinse aid. You will also achieve a
better dishwashing result with clear and
spotless dishes.
Lift up to open
Press to close
Top up the rinse aid compartment with rinse
aid if you have selected Rinse aid 3:01 - 3:05.
1. Open the rinse aid compartment lid.
2. Carefully top up with rinse aid to the level marked MAX.
3. Wipe up any splashes of rinse aid around the compartment.
4. Close the lid firmly.
When the rinse aid needs topping up, the symbol lights on the display.
4. Top up with salt
For a water supply with a hardness above 5 °dH
(9 °fH / 6 °eH / 0.9 mmol/l), fill with salt.
Add salt to the salt compartment if you have
selected Water hardness 4:01 - 4:09.
1. Remove the salt compartment lid by turning it anticlockwise.
2. Place the funnel supplied with the dishwasher in the salt compartment top-up hole. Before washing
for the first time, pour in about 1 l of water. (Water is only needed the first time.)
3. Add enough salt to fill the salt compartment (max. 750 gram). Use special dishwasher salt.
4. Wipe away excess salt and turn the lid clockwise until in the closed position.
When the salt needs topping up, the symbol lights on the display.
WARNING!
In order to avoid rust stains a dishwashing program must be started immediately after adding
salt.
9

Greener dishwashing
Save energy and water
When using a dishwasher in a residential setting, less energy and water are generally used compared
to washing the dishes by hand.
Do not rinse under running water
Do not rinse the dishes under running water as this will lead to increased energy and water consumption.
Simply scrape off large food particles before loading the dishwasher.
Choose a green detergent
Read the environmental declaration on the packaging!
Too much detergent, rinse aid and salt can result in less effective dishwashing and also entail greater
environmental impact.
Run a fully loaded dishwasher
Save energy and water by waiting until the dishwasher is full before running a program (see number
of standard place settings). Use the 1h 65° program with the Speed wash option to rinse the
dishes if there are any unpleasant odours.
Run programs at a lower temperature
If the dishes are only slightly dirty, you can select a program with a low temperature.
Select dishwashing program –Eco 55°
This program is suitable for washing normally soiled dishes and is the most effective program in terms
of combined energy and water consumption. This program is used to assess compliance with EU
legislation on ecodesign.
The dishwashing program is designed for an effective wash using as little energy and water as possible.
The program washes at a low temperature for a long time.
Activate the setting –TotalDry
A shorter dishwashing program and better drying results are achieved if you activate the TotalDry
setting, which automatically opens the dishwasher door. Wait until the dishwasher indicates that the
program has ended and the dishes have cooled before unloading the dishwasher. (If the dishwasher
is built-in, the surrounding furnishings must be resistant to any condensation from the dishwasher.)
Connect to cold water
Connect the dishwasher to the cold water supply if the building is heated using oil, electricity or gas.
Connect to hot water
Connect the dishwasher to the hot water supply (max. 70 °C) if the building is heated using an
energy-efficient means such as district heating, solar power or geothermal power. Choosing a hot
water connection reduces the dishwasher's energy consumption.
NOTE!
Do not exceed the permitted water supply temperature. Certain materials used in some cookware
cannot withstand high heat. See Fragile dishes in the chapter Loading the dishwasher.
10

Loading the dishwasher
Fragile dishes
Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot
withstand high heat, others can be damaged by dishwasher detergent.
Exercise caution with, for example, handmade items, fragile decoration, crystal/glassware, silver,
copper, tin, aluminium, wood and plastic. Look for the "Dishwasher safe" marking.
Loading affects the results
Load the dishes carefully to ensure the best washing and drying results with the lowest possible energy
and water consumption. Give your dishwasher the best chance to reach and clean all surfaces, as
well as to dry the dishes as thoroughly as possible.
•All dirty surfaces should face inwards and downwards!
•Dishes should not be placed in or on each other.
•Angle dishes with hollows, such as cups, so that the rinse water will run off. This is also important
for plastic items.
•Make sure small items cannot fall through the dishwasher basket; place them in the top cutlery
tray.
The dishwasher's baskets
The dishwasher is equipped with a top cutlery tray, an upper basket and a lower basket.
The appearance of the baskets may differ depending on the dishwasher setup.
WARNING!
Be careful with fully loaded dishwasher baskets. Push the baskets in to avoid risking the
dishwasher tipping over.
Top cutlery tray
The top cutlery tray has space for cutlery, ladles, whisks, serving cutlery and similar items.
The top cutlery tray is comprised of three parts
that can be moved sideways to better
accommodate the dishes.
11

Upper basket
Place glasses, cups, bowls, side plates and saucers in the upper basket. All dirty surfaces should face
inwards and downwards! Wine glasses are placed on the wine glass shelf and knives are placed in
the knife stand on the right.
Knife stand
3 positions
Raising and lowering the upper basket
1. Pull out the upper basket.
2. Grab the sides of the upper basket with both hands and lift it up.
3. If the upper basket is raised while in the top position, it will drop to the bottom position.
Note that both sides of the basket must always be set to the same height.
12

Lower basket
Place plates, side plates, serving dishes and pots in the lower basket. Cutlery can be placed in the
cutlery holder.
Fit the cutlery holder to achieve maximum loading
capacity. (Found inside the enclosed plastic bag.)
Adjustable plate supports
The adjustable plate supports can be folded down to make it easier to load pots and bowls.
NOTE!
Check that the spray arms can rotate freely.
13

Using the dishwasher
Add detergent
Follow the instructions on the detergent packaging. This dishwasher is fitted with a water softener,
so use detergent and rinse aid doses suitable for soft water.
Too much detergent can result in less effective dishwashing and also entails greater environmental
impact.
Detergent compartment
The detergent compartment must be dry when adding detergent.
If powder or liquid dishwasher detergent is
used, add a small amount of the detergent to
the compartment for prewash detergent.
Press to open Close the lid
Prewash detergent Main wash detergent
NOTE!
Use only dishwasher detergent! Washing up liquid must not be used as the foam that forms
prevents the dishwasher from operating effectively.
All-in-one detergent
There are many types of all-in-one detergents on the market. Read through the directions for these
products carefully.
Activate the TAB setting when using an all-in-one detergent that contains rinse aid.
Dishwasher tablets are not recommended for short programs (less than 75 minutes). Use powder or
liquid dishwasher detergent instead.
NOTE!
Optimal washing and drying results are achieved by using normal detergent together with
separately dispensed rinse aid and salt.
Contact the detergent manufacturer if you have questions about the detergent.
14

Display
Start/Pause/Stop
Select program
On/Off
NOTE!
The control panel only reacts to use when the door is closed.
On/Off
Close the door properly, otherwise the dishwasher will not start. Press . Also turn on the water tap
if it is turned off.
Select program
Select a program to suit the type of dishes and how dirty they are. Eco 55° is always pre-selected.
Press one or more times until the desired program is activated, which is indicated by an indicator
light.
Eco 55°
This program is suitable for washing normally soiled dishes and is the most effective program in terms
of combined energy and water consumption. This program is used to assess compliance with EU
legislation on ecodesign.
You can read more about greener dishwashing in the chapter Greener dishwashing.
For heavily soiled dishes with a lot of grease, a program with higher temperatures should be used.
Auto 45-65°
The dishwasher can measure how dirty the dishes are and adjust water consumption and temperature
accordingly. When newly installed, the program needs to be run five times before it is fully adapted
and can provide the best results.
1h 65°
A quick program for slightly dried leftovers. (This program is not intended for burnt food, such as on
oven dishes.)
The TotalDry option is important for ensuring the best drying results.
15

Intensive 70°
A program with a high temperature for dissolving grease on very dirty dishes, such as pans, casserole
dishes and oven dishes. If these dishes do not completely fill the dishwasher, you can add plates and
other dishes.
Glass 40°
A gentle dishwashing program with a low temperature for washing fragile items made of crystal/glass.
Remember to use a small amount of detergent and to place items so that they do not touch each
other during the wash. See also Fragile dishes in the chapter Loading the dishwasher. Porcelain that
has just been used without dried leftovers can also be washed using this program.
Hygiene 70°
This program is ideal to use where demands on hygiene are extra high, e.g. for baby bottles and
cutting boards. The temperature is high both in the main wash and in the final rinse.
Self-clean
Self-cleaning program for hygienic cleaning of the dishwasher tub, spray arms and spray pipes.
This program should be run (with no dishes in the machine) using normal dishwasher detergent or
citric acid. Special dishwasher cleaners are also available on the market. For the removal of limescale
deposits, see Dishwasher tub in the chapter Care and cleaning.
NOTE!
CLn The dishwasher will indicate at regular intervals that Self-clean needs to be run.
Press and hold until CLn is shown on the display to select the program.
Select option
Press the options ( , ) to activate them. (The available options vary between programs.)
Delayed start
When you select Delayed start, the dishwasher will start 1-24 hours after you press .
1. Press once to activate Delayed start. Press several times, or hold it in, to set the desired number
of hours. The time for Delayed start is shown on the display.
2. Press . The timer counts down and the dishwasher starts after the selected delay.
If you want to cancel the Delayed start option, press and hold for three seconds.
Not available for: Self-clean
Speed wash
This option shortens the program time, but uses more energy and water.
Press to activate the option. The program time is updated on the display.
Not available for: Auto 45-65°, Glass 40°, Hygiene 70°, Self-clean
Start/Pause/Stop
Press . The display starts counting down.
16

Stopping or changing a program
Press and hold for three seconds to pause the program. If you want to interrupt or change the
program after starting the dishwasher, press and hold for another five seconds.
Open the door and top up with new detergent if the lid of the detergent dispenser has opened. Close
the door. Then select a new program and press .
Remaining time
Once you have chosen a program and options, the time the program took when last used is displayed.
Once you have started the dishwasher, the display shows the remaining program time. The remaining
time is updated during the drying phase.
This may differ somewhat from time to time depending on the temperature of the water supply, the
amount of dishes, the ambient temperature and other factors.
If you want to load more dishes1)
Press and hold for three seconds to pause the program. Open the door. Add the dishes and close
the door. Press .
Power failure
If the dishwasher is turned off due to a power failure when a dishwashing program is running, the
program continues when power is restored. If the power is cut during drying, the program is interrupted.
If you open the door for more than 2 minutes during drying, the program will be interrupted.
Once the program has finished
Once the program has finished, "End" appears on the display.
At the end of the program one short signal will sound. Chapter Settings describes how to change this
function.
The dishwasher switches off automatically after the program ends. Shut off the water tap after each
use (if required by your insurance company).
The best drying results
•Fully load the dishwasher.
•Angle dishes with hollows, such as cups, so that the rinse water will run off. This is also important
for plastic items.
•Top up with rinse aid or increase the rinse aid dosage setting.
•Activate the TotalDry setting. See the chapter Settings.
•Allow the dishes to cool before unloading the dishwasher.
Unloading the dishwasher
Hot porcelain is more fragile. Leave the dishes to cool in the dishwasher before unloading them.
Unload the lower basket first to avoid any water drops from the upper basket falling onto the dishes
in the lower basket.
1) You should not load more dishes if the lid of the detergent dispenser has been opened.
17

Program chart
Consumption values 1)
Final rinse
Number of rinses
Main washNumber
of prewashes
OptionDetergent (ml)Program
Water cons.
(liter)
Energy
(approx. kWh)
Dishwashing
time
(approx. hrs:min)
11.00.852:5549 °C255 °C
3)
25Eco 55° 2)
13.0-20.50.9-1.42:10-3:1060 °C2-345-65 °C1-2
3)
25Auto 45-65°
14.51.11:0065 °C365 °C
3)
251h 65°
17.01.62:5070 °C270 °C225Intensive 70° 10.50.71:4050 °C240 °C20Glass 40° 10.51.31:0570 °C270 °C25Hygiene 70°
1) Consumption values vary depending on the temperature of the incoming water, room temperature, load size, selected additional functions and more. The values for the Eco 55° program are accurate,
others are indicative only. The dishwasher's built-in water softener is regularly regenerated to maintain its function. Regeneration extends the dishwashing program and increases energy and water consumption. Just how often the dishwasher's water softener is regenerated depends on the selected setting.
2) This program is suitable for washing normally soiled dishes and is the most effective program in terms of combined energy and water consumption. This program is used to assess compliance with
EU legislation on ecodesign.
3) TotalDry. See the chapter Settings.
18

Settings
1. Press .
2. To open the dishwasher's settings menu, press and hold and until SEt is shown on the
display.
3. Press to step through the settings menu.
4. Press to step through the alternatives.
5. Confirm the selected setting by pressing .
6. To exit the menu, step through it or press .
Confirm / Next settingSelect alternative
Open the dishwasher's settings menu
AlternativesSettings
You can activate the Automatic child lock setting to prevent
children from starting the dishwasher.
1:00 (Off)
1:01 (On)
Automatic child lock
(CL)
To temporarily deactivate or activate the Automatic child
lock setting, press and hold for three seconds.
CL (Child Lock) will be shown on the display when pressing
the control panel. (To unlock, press and hold for three
seconds.)
A beep confirms that the control panel has been pressed.2:00 - 2:03Sounds
A beep indicates when a dishwashing program has ended.(2:00 Off)
Error messages are always indicated by a loud buzzer.
Setting for rinse aid dosage. The rinse aid dispenser can
be adjusted between 3:00 (Off) and 3:05 (High dosage).
3:00 - 3:05
(3:00 Off)
Rinse aid
Increase the rinse aid dosage:
•If the dishes have water marks.
Decrease the rinse aid dosage:
•If the dishes have a sticky white/blue film.
•If the dishes are streaked.
•Build-up of foam. If you have very soft water, the rinse
aid can be diluted 50:50 with water.
Pre-selected at factory: 3:04
19

AlternativesSettings
Adjusting the water softener. Select a setting depending
on the hardness of the water supply. It is important that
this setting is correct!
4:00 - 4:09
(4:00 Off)
Water hardness
See 1Water hardness in the chapter Before washing for the
first time.
For a water supply with a hardness above 5 °dH (9 °fH /
6 °eH / 0.9 mmol/l), fill with salt.
For a water supply with a hardness below 6°dH (10°fH /
7°eH / 1.0 mmol/l), select 4:00. The water softener is deac-
tivated and no salt needs to be added.
Pre-selected at factory: 4:04
Activate this setting when using an all-in-one detergent that
contains rinse aid.
5:00 (Off)
5:01 (On)
TAB
(All-in-one detergent)
This setting reduces the rinse aid dosage and affects how
often the dishwasher's built-in softener is regenerated.
Pre-selected at factory: 5:00
The dishwasher door opens automatically, which shortens
the program time and improves the drying results. Wait
until the dishwasher indicates that the program has ended
and the dishes have cooled before unloading the dishwash-
er. (If the dishwasher is built-in the surrounding furnishings
must be resistant to any condensation from the dishwasher.)
6:00 (Off)
6:01 (On)
TotalDry
Not available for: Hygiene 70°, Self-clean
TotalDry is pre-selected and cannot be deactivated for the
Eco 55° program.
Any error messages.F--Error readout
When contacting the service department, you may be asked
to provide the most recent error messages.
Restores all settings to the factory defaults.rStRestore factory de-
faults Select rSt and confirm by pressing .
To exit the dishwasher's settings menu, select End and
press .
EndExit
(The menu closes automatically after three seconds.)
20
